Related Manuals for Frico ICWP
Summary of Contents for Frico ICWP
- Page 1 ICWP ..4 ..18 ..25 ..32 ..11 ..39 ..46 ..53 ..60...
-
Page 2: Wiring Diagrams
ICWP ICWP Type ICWP17 Wiring diagrams ICWP Output selector Safety limit thermostat Thermostat... -
Page 3: Technical Specifications
Black 1,5 mm Yellow/Green 1,5 mm Schuko socket l=180mm l=170mm 16A CE PVC Cable Technical specifications Carboninfra ICWP , portable with wide heat distribution, installation height 0,4 – 1,5 m Type E-nr (SE) EL-nr (NO) Heat Voltage Amperage Max. filament... - Page 4 The heat lamp in IC have very long service life, the operating time is up to 10 000 h. ICWP is a portable radiant heater which gives a comfortable heat in the occupied zone from close range and also wider heat distribution.
-
Page 5: Constituent Parts
ICWP Constituent parts Control ICWP Output selector Reflector Wide angle 80° Upper element Double on, 50% power IR-carbon- Lower element element on, 50% power Medium wave Both element Ventilating on, 100% power body Front grid metal Thermostat Control room thermostat +5 –... - Page 6 ICWP Bracket Rotating to horizontal or vertical position Rip for horizontal Rip for position vertical position Rotating from The heater must Rotating from horizontal to vertical be off and the plug vertical to horizontal position, 90°. pulled from the position, 90°.
- Page 7 ICWP Mounting Plastic cover 2 cable clips Post Post Stopper screw Fixing screw Stand legs Plastic feet Stand foot 1. Push each stand leg firmly into the stand foot until it reaches the stopper inside. 2. Push the post firmly into the stand foot.
- Page 8 ICWP Mounting Cable that are not needed can The post is pushed in the stand be conveniently stored in the foot and fastened with fixing cable channel under the stand screw. foot. The plug from the heater is inserted into the socket in the stand foot and the lid is closed.
- Page 9 ICWP Mounting Mounting of bracket After assembly and after the radiation angle is set, tighten the screws. Note: Please observe minimum mounting distance in the manual. Minimum mouting distance Radiant angle 30° Possible to turn vertically Min 1,5 m Fully...
- Page 10 ICWP Maintenance Safety Note! When using for the first time or when • During operation the surfaces of the unit starting up after a long period of disuse, a are hot! small amount of smoke and a slight odour • The unit must not be fully or partially...
- Page 11 Main offi ce Frico AB Tel: +46 31 336 86 00 Box 102 Fax: +46 31 26 28 25 SE-433 22 Partille mailbox@frico.se Sweden www.frico.se For latest updated information and information about your local contact: www.frico.se...
