6.2 Start-Up procedure

The CSL Elite Wheel Base+ has an improved and faster start-up procedure:
ATTENTION:
Wheel Base+ is in progress never touch the attached steering wheel in
order to avoid injuries or incorrect calibration!
Step1: Press the ON/OFF button "
•
the CSL Elite Wheel Base+, marked in the picture above:
• Step2: The fans start working, the LED above the ON/OFF
Button "
• Step3: The CSL Elite Wheel Base+ starts turning to the
right side (clockwise) until mechanical limit is reached. Then it runs back
to the the left side (counter clockwise) and stops.
▪
▪
• Step4: The currently installed firmware version is shown on the LED
display of the Fanatec
shown on the picture on the right hand side:
• Step5: If the wheel centre was not yet calibrated 'CAL' will
blink on the LED display of the steering wheel as shown
on the picture on the right hand side:
▪
▪
• Step6: Your CSL Elite Wheel Base+ is ready to use. If
the wheel centre was previously calibrated, step 5 can be skipped and
the CSL Elite Wheel Base+ is ready to use immediately. If you use a
H-pattern shifter the wheel base firmware will request to calibrate the
gears automatically now. Refer to chapter 'Shifter calibration mode later
in this user manual'.
29
When initialisation and auto calibration of the CSL Elite
" is lit red.
at the centre position (0°) if wheel centre was manually calibrated
before. Note: If SPR is set to low values or '000' the CSL Elite
Wheel Base+ will stop in a different position after calibration run.
at about -60° on the left hand side if wheel centre was not yet
calibrated (e.g. after firmware update; see description above in
this chapter).
®
Proceed with a manual wheel centre calibration as
described in chapter 'Hotkeys' of this manual.
The CSL Elite Wheel Base+ is ready to use after
manual wheel centre calibration.
" at the front plate of
steering wheel for a moment as
