ScrapBox SEW STATION Assembly Instructions Manual page 13

R I G HT S ID E C ONFIGUR ATION
L E F T SID E C ONF I GURATION
Install barrel
lock receiver
Proprietary, patented product and assembly instructions. Do not copy or distribute.
Side 2
Back
Top
Side 2
Side Table
Attach Side Table using (3) hinges and (18)
11
euro screws. DO NOT tighten screws all the
way at first. Once table is attached tighten
one screw in each hinge and repeat until all
screws are tight.
Base
Side 1
Side Table
Base
Back
Top
Side 1
Attach Side Table using (3)
11
hinges and (18) euro screws. DO
NOT tighten screws all the way
at first. Once table is attached
tighten one screw in each hinge
and repeat until all screws are
tight.
Install barrel
lock receiver
13
