The Remote - PS Audio Stellar Strata Owner's Reference Manual

Included With •
The Stellar •
Strata •
•

The Remote

1
2
3
4
5
6
®
6-foot Power Cable
Owner's Reference Manual
Remote Control
2 AAA batteries
Getting Started
Stellar Strata Amplifier
1 The Off button. This turns the Strata off.
2 Fixed Volume Button (Home Theater). This
toggles Fixed Volume mode on or off.
3 Left/Right/Up/Down arrow keys. Up and Down
7
adjust volume. Left / Right adjusts balance.
8
4 Filter mode button. Select F1, F2, or F3 filters.
9 Note that this only applies to digital inputs.
10
5 Volume button. + volume up, - volume down.
6 Input select section.
7 The On button. This turns the Strata on.
8 The Dim button. This shuts off the display.
11
9 The Mute button. This mutes the audio output.
The phase button. Toggles between in phase
10
and out of phase.
The remote uses 2 AAA batteries that are in-
11
cluded and will need to be installed.
6
