Rear Panel View

1
2
3
4
5
6
7
8
9
1
10
3 4
2
®
Power switch
IEC inlet
USB firmware port
Network input (# 9)
USB audio input (# 8)
Optical input (# 7)
COAX inputs (# 5 & 6)
I S input (# 4)
2
Trigger output
Right analog output
7
5
6 7
8 9
Getting Started
11
12
13
14
15
16
17
18
19
20
9 11
10
12 13 14
Stellar Strata Amplifier
Left analog output
Single ended analog input (# 3)
Single ended analog input (# 2)
Single ended analog input (# 1)
Right balanced analog input (# 1)
Left balanced analog input (# 1)
Right negative speaker output
Right positive speaker output
Left negative speaker output
Left positive speaker output
