INSTALLATION AND MAINTENANCE INSTRUCTIONS
FIGHTER 1330
FIGHTER 1330
031078

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FIGHTER 1330 and is the answer not in the manual?

Questions and answers

Related Manuals for Nibe FIGHTER 1330

Summary of Contents for Nibe FIGHTER 1330

  • Page 1 MOS GB 0712-3 INSTALLATION AND MAINTENANCE INSTRUCTIONS FIGHTER 1330 FIGHTER 1330 031078...

  • Page 3: Table Of Contents

    High room temperature ........79 Inspection ............18 Low hot water temperature or no hot water ..79 Start up with a FIGHTER 1330 ......20 Standby mode ............. 79 Start up with several FIGHTER 1330s in a system 20 Alarm ..............

  • Page 4: Concise Product Description

    Completed by the installer when the heat pump is installed Type designation / serial number FIGHTER 1330- _ _ kW / 089 _ _ _ _ _ _ _ _ _ _ _ Installation date Installer...

  • Page 5: System Description

    System description Principle of operation FIGHTER 1330 consists of two heat pump modules Ground water can also be used as a heat source. This and a CPU unit with a display to control the heat pump requires an intermediate heat exchanger.

  • Page 6: Front Panel

    Value of the current parameter. ule) is operational. Third row: Description of current display param- eter. Fourth row: Shows menu numbers, key lock, clock I II III Additional symbol symbol and time. Indicates when immersion heater is opera- tional. FIGHTER 1330...
  • Page 7 Summer mode: parameter change as well as confirm a Only hot water production using FIGHTER 1330. The circu- parameter change. lation pumps and additional heating are blocked. However, See the section Control > General.

  • Page 8: Room Temperature

    One to three lines approximately represents a 1 degree change in room temperature. NOTE! An increase in the room temperature may be inhibited by the radiator or floor heating thermostats, if so these must be turned up. FIGHTER 1330...

  • Page 9: Setting The Heating Controls

    Setting the heating controls Setting using diagrams Offset heating curve -2 The heating control system of the FIGHTER 1330 is HEATING CURVE VÄRMEKURVA controlled by the outside temperature. This means the °C flow temperature is regulated in relation to the current 15 14 13 12 outdoor temperature.

  • Page 10: General Information For The Installer

    3 x 450 – 4 x 450 m 3 x 150 – 5 x 150 m The FIGHTER 1330 must be installed on a firm sur- 4 x 500 – 4 x 500 m 4 x 170 – 5 x 200 m face, preferably a concrete floor or a concrete founda- tion in a boiler room or a separate equipment room.

  • Page 11: Opening The Top Covers

    General information for the installer Opening the top covers Opening the lower covers FIGHTER 1330...

  • Page 12: Pipe Connections

    58 °C and an outgoing temperature from the heat pump of approx. 65 °C. When FIGHTER 1330 is not equipped with shut off valves, these must be fitted outside of the heat pump to assist future service work.

  • Page 13: Pressure Expansion Vessel

    11 13 15 17 19 21 °C 100 200 300 400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1. Condenser out 2. Condenser in Available pressure, heating medium side Pressure FIGHTER 1330 -22 Pressure Tryck FIGHTER 1320-20 Tryck FIGHTER 1330-30/40...

  • Page 14: Filling And Venting The Collector System

    Rock collector Level vessel Soil collector KB-in Brine in KB-out Brine out Brine pump Particle filter Filling the heating medium system The heating medium system is filled with water until the required pressure is reached and then vented. FIGHTER 1330...

  • Page 15: Internal Venting Valves

    Filling of collector system is done by pumping ready mixed brine through the filling valve. Venting and filling are repeated until all the air has been removed and the correct pressure (0.5 - 3 bar) has been obtained. FIGHTER 1330...

  • Page 16: Docking

    13.43 VVB / ACK KB-ut SÄV SÄV KB-in FIGHTER 1330 gives priority to hot water charging at Heat pump module A Return sensor half power (heat pump module B) via a shuttle valve Shutoff valve Control valve (RV). When the water heater/accumulator tank (VVB/...

  • Page 17: Example Fighter 1330 Docked With An Electric Element/Electric Boiler And Water Heater

    13.43 VVB / ACK KB-ut SÄV KB-in FIGHTER 1330 gives priority to hot water charging at Heat pump module A half power (heat pump module B) via a shuttle valve Shutoff valve (RV). When the water heater/accumulator tank (VVB/ Heat pump module B...

  • Page 18: Electrical Connections

    NOTE! Electrical installation and servicing must be carried out under the supervi- sion of a qualified electri cian in accordance with the stipulations in force. FIGHTER 1330...

  • Page 19: Connection

    ■ Note that FIGHTER 1330 provides 230V control ■ The FIGHTER 1330 does not include an isolator signals that are intended to control external switch on the incoming electrical supply. The instal- contactors and not to drive pumps.

  • Page 20: Description Of Functions - Start Up Inspection

    3. Set in the Service position from menu 8.1.1. (See the example in Control > Changing parameters.) 4. On delivery FIGHTER 1330 is set with English as the menu language, if another language is requi- red this can be changed in the menu 8.1.2.
  • Page 21 When all heat pumps have undergone this inspection, control in menu 0.2.1. continue with “Description of functions” - “Start up” > “Start up with a FIGHTER 1330” or if several FIGHERS 12. Remove the strap for compressor A (KPRAA). 1330 are connected “Description of functions” - “Start 13.

  • Page 22: Start Up With A Fighter 1330

    1. Start the heat pump by turning the power switch (8) to the 1 position. The unit will now enter screen 1. FIGHTER 1330 is delivered as the Master. Other saver mode and the text Master will be shown on units in the system must be selected as unique sla- the bottom row of the display.

  • Page 23: Operating Type Selection

    Description of functions - Start up Operating type selection The operating type must be selected for each connect- ed FIGHTER 1330. This is selected in the sub-menus to 0.2.0 and can be selected from: Off: Compressor modules A and B are not used. No communication with the heat pump.

  • Page 24: Master / Slave

    Description of functions - Start up Master / Slave FIGHTER 1330 is always delivered as the Master. Up to 8 Slaves can be connected to the Master. Only one heat pump with each address can be installed in the same system, i. e. only one Master and only one Slave...

  • Page 25: Description Of Functions - Basic Functions

    5.4.7/5.4.8, and/or the external heating medium pump (VBP3) when Economy is The outline diagram with docking instruc- selected in menu 6.1.1. Adjustable between 1 and tions is available at www.nibe.com 120 minutes. The factory setting is 5 minutes. FIGHTER 1330...

  • Page 26: Heat Production

    (230 V), X6:20 (N) (max 0.2 A) on the EBV-card. Only hot water production using FIGHTER 1330. The Note that FIGHTER 1330 delivers 230 V control sig- circulation pumps and additional heating are blocked. nals intended to control external contactors and However, when Extra hot water is activated the addi- not to drive pumps.
  • Page 27 55 °C. +10. NOTE! The value cannot be changed using the plus and minus buttons, only by using the Off- set heating curve knob on the Master unit. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 28: Hot Water Production

    1 starts at 50 °C and stops at X4:11 and X4:12 on the EBV-card. 55 °C then compressor 2 starts at 49.5 °C and stops at 54.5 °C i.e. each FIGHTER 1330 connected for pos- sible switching between hot water and heating has its own shuttle valve.

  • Page 29: Extra Hot Water

    X4:3 and X4:4 on the EBV-card. +Base card +EBV-card The outline diagram with docking instruc- tions is available at www.nibe.com Quick guide - menu settings Extra hot water Extra hot water water production is set here. The value is adjust- able between 50 and 80 °C, or ”Off”.

  • Page 30: Electrical Additional Heater

    ETS-1 is connected to terminal blocks X6:13 (N) and on Expansion card 1. X6:15 (230 V with activation). FIGHTER 1330 delivers 230 V control signals for addi- ETS-2 is connected to terminal blocks X6:11 (N) and tional heat, i. e. signals to control external relays, con- X6:12 (230 V with activation).
  • Page 31 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V 230 V The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 32: Oil Boiler

    EBV-card. In standby mode the output ETS-3/OP (Base card) is voltage fed and with that, FIGHTER 1330 requests the oil boiler. However, the boiler shunt (SV-P) must be +Base card controlled manually in standby mode.
  • Page 33 Here you select at which degree-minute setting the first additional heater step shall start for heat- ing. The value is adjustable between -3000 and 0. The factory setting is -500. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 34: Gas Boiler

    2.0). In the event of excess tempera- ation in opposite direction to heating operation, which ture, FIGHTER 1330 calculates a surplus in the form normally means the shunt closes completely during of degrees-minutes, which means that the connection cooling operation.
  • Page 35 The ing mode. The value is adjustable between 0 and value is adjustable between 1 and 9 °C. The fac- 30 °C. The factory setting is 20 °C. tory setting is 4 °C. FIGHTER 1330...

  • Page 36: Fixed Condensing

    (FG) during period 2 when Own program is selected in menu 9.2.1. The value is adjustable between 15 and 50 °C. The outline diagram with docking instruc- The factory setting is 35 °C. tions is available at www.nibe.com FIGHTER 1330...

  • Page 37: Room Control

    Even the menu 3.5 (External adjustment 2) ed in menu 9.1.11. The value can be adjusted comes into question if the Sub shunt (SV-V2) between 10 and 30 °C in increments of 0.5 °C. has been activated. Factory setting is 20 °C. FIGHTER 1330...

  • Page 38: Electrical Additional Heater

    To connect the relays ETS-4 to ETS-6, see the section To connect HPAC on Expansion card 1 see the section Description of functions - Basic functions > Electrical Description of functions - Basic functions > HPAC. additional heater. FIGHTER 1330...

  • Page 39: Hot Water Circulation Pump

    Menu 6.1.5 Periodtime Hw-cp Here the period time for the hot water circulation pump is set here. Adjustable between 10 and 60 minutes. The factory setting is 15 minutes. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 40: Pool

    If several compressors are available for pool opera- tion, these start at 5 minute intervals until no more are available or the number of started compressors is the same as the number that is selected in menu 6.5.5. FIGHTER 1330...
  • Page 41 “On” in menu 9.1.5 If it is “On”, compr. B in the heat pump that is selected in menu 5.1 is permitted to carry out pool heating. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 42: Sub Shunt

    The shunt valve (SV-V2) is connected to the terminal blocks X6A:5 (230 V decrease signal), X6A:6 (N) and X6A:7 (230 V increase signal). Note that FIGHTER 1330 delivers 230 V control sig- nals intended to control external contactors and not to drive pumps.
  • Page 43 The value is adjustable between 1 able between 10 and 65 °C. The factory setting is and 10. The factory setting is 1. 15 °C. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 44: Docking Instructions

    X6B is required in order to access the following functions. When it has been connected the card must be activated in menu 9.1.2. Docking instructions Outline diagrams with docking instructions for the functions on the expansion card 2 is at the address www.nibe.com FIGHTER 1330...

  • Page 45: Groundwater Pump

    (CP-G) is connected to terminal block X6B:24 (max fusing 6 A and 250 V) and the control signal/power supply is on X6B:25. +Exp. card 2 The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 46: Passive Cooling With 4 Pipe System

    If a sub- merged tube is not available, use the copper tube sup- plied. The sensor is connected to screw terminals J5:7 and J5:8 on the “measurement card”. +Measure card +Exp. card 2 FIGHTER 1330...
  • Page 47 (UG) when the heat pump is permitted to produce cooling. The value can be set between 0 and 30 °C. The factory setting is 25 °C. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 48: Passive Cooling With 2 Pipe System

    A and the control voltage is 230 V. External supply to the control signal/power supply for the circulation pump (CP-K) is connected to terminal block X6B:22 (max fusing 6 A and 250 V) and the con- trol signal/power supply is on X6B:23. +Exp. card 2 FIGHTER 1330...
  • Page 49 (UG) when the heat pump is permitted to produce cooling. The value can be set between 0 and 30 °C. The factory setting is 25 °C. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...

  • Page 50: Combined Cooling/Heating Modes With Accumulators

    If a submerged tube is not available, use the copper tube supplied. The sensor is connected to screw terminals J4:23 and J4:24 on the “measurement card”. The outline diagram with docking instruc- tions is available at www.nibe.com FIGHTER 1330...
  • Page 51 10 secs/min controlling the produce heat. The value can be set between 0 shunt. The value can be set between 1 and 10. and 30 °C. The factory setting is 20 °C. The factory setting is 1. FIGHTER 1330...

  • Page 52: Description Of Functions - External Control

    Description of functions - External control Electrical connection, external control/blocking of the additional heat and compressor FIGHTER 1330 can be controlled up to a certain point using signals from an external system (e.g. DUC). All control signals must come from potential free relays.

  • Page 53: Control

    The key symbol will then be shown on the dis- Ensure the operating mode is not play. The same procedure is used to deactivate the changed during quick movement. key lock. FIGHTER 1330...

  • Page 54: Changing Parameters

    Control FIGHTER 1330...
  • Page 55 Control FIGHTER 1330...
  • Page 56 Control FIGHTER 1330...

  • Page 57: Main Menus

    Control FIGHTER 1330...

  • Page 58: 0.0 System

    (Pool) or cooling (Cold) are shown here. pressostat has tripped during hot water charging Menu 0.1.1 Status Master A and FIGHTER 1330 has automatically lowered the set temperature with the value in brackets. The The current mode of compressor module A is...

  • Page 59: 2.0 Flow Temperature

    -10 and +10. The fac- tory setting is 0. Normal menus: displayed in all menu modes. Extended menus: Only displayed when extended or service is selected in menu 8.1.1. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...
  • Page 60 Pressing the Enter button returns you to menu 2.0. Normal menus: displayed in all menu modes. Extended menus: Only displayed when extended or service is selected in menu 8.1.1. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...

  • Page 61: Flow Temperature 2

    5 gives 10 seconds in control of the sub shunt. The value is adjustable between 1 and 10. The factory setting is 1. Menu 3.10 Return * Accessories Pressing the Enter button returns you to menu 3.0. FIGHTER 1330...

  • Page 62: 4.0 Outdoor Temperature

    Normal menus: displayed in all menu modes. Menu 5.2.8 Return Extended menus: Only displayed when exten- Pressing the enter button returns you to menu ded or service is selected in menu 8.1.1. 5.2.0. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...
  • Page 63 The value is saved in the microprocessor and thus is not reset even when the heat pump is switched off using the main power switch. Menu 5.3.8 Return Pressing the enter button returns you to menu 5.3.0. FIGHTER 1330...
  • Page 64 Normal menus: displayed in all menu modes. selected in menu 5.1 is permitted to carry out pool Extended menus: Only displayed when extended heating. or service is selected in menu 8.1.1. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...

  • Page 65: 6.0 External Units

    1 and 60 minutes. The factory setting is 3 minutes. 6.2.0. Menu 6.1.7 Return Pressing the enter button returns you to menu 6.1.0. * Only shown when the accessory in question is connected and activated in menu 9.1.x. FIGHTER 1330...
  • Page 66 The lowest flow temperature in cooling mode. The ded or service is selected in menu 8.1.1. value is adjustable between 2 and 65 °C. the fac- Service menus: Only displayed when service is tory setting is 5 °C selected in menu 8.1.1. FIGHTER 1330...
  • Page 67 The value can be adjusted between 0 and 18. Factory setting is 1. Menu 6.5.6 Return Pressing the enter button returns you to menu 6.5.0. * Only shown when the accessory in question is connected and activated in menu 9.1.x. FIGHTER 1330...
  • Page 68 Extended menus: Only displayed when extended or service is selected in menu 8.1.1. * Only shown when the accessory in question is con- Service menus: Only displayed when service is nected and activated in menu 9.1.x. selected in menu 8.1.1. FIGHTER 1330...
  • Page 69 The lowest flow temperature in cooling mode. The value is adjustable between 2 and 65 °C. The fac- tory setting is 5 °C. * Only shown when the accessory in question is connected and activated in menu 9.3.x. FIGHTER 1330...

  • Page 70: 7.0 Clock

    Pressing the Enter button returns you to menu 6.0. Normal menus: displayed in all menu modes. Extended menus: Only displayed when extended or service is selected in menu 8.1.1. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...

  • Page 71: 8.0 Other Settings

    The same start and stop times deactivates Extra hot water. Menu 7.5.9 Return Pressing the enter button returns you to menu 7.5.0. Menu 7.6 Return Pressing the Enter button returns you to menu 7.0. FIGHTER 1330...
  • Page 72 Normal menus: displayed in all menu modes. Extended menus: Only displayed when extended Menu 8.2.9 Return or service is selected in menu 8.1.1. Pressing the enter button returns you to menu Service menus: Only displayed when service is 8.2.0. selected in menu 8.1.1. FIGHTER 1330...

  • Page 73: 9.0 Service Menus

    Control 9.0 Service menus Menu 9.1.0 System settings Menu 9.1.11 Room control mode Pressing the enter button takes you to sub-menus Here the type of room control connected is set. for the system settings. Selectable modes are Off, Thermostat, RG05 or RG10.
  • Page 74 15 and 50 °C. The factory tripped. setting is 35 °C. Menu 9.3.x.9 Brine in/out Menu 9.2.7 Return Shows the incoming (KBinA/B) and outgoing (KButA/ Pressing the enter button returns you to menu B) brine temperature when the alarm tripped. 9.2.0. FIGHTER 1330...
  • Page 75 Pressing the Enter button returns you to menu 9.0. Normal menus: displayed in all menu modes. Extended menus: Only displayed when extended or service is selected in menu 8.1.1. Service menus: Only displayed when service is selected in menu 8.1.1. FIGHTER 1330...

  • Page 76: Component Positions

    Component placement 6a 6b FIGHTER 1330-22 FIGHTER 1330-30, 40 FIGHTER 1330...

  • Page 77: List Of Components

    (B) 60 a, b EMC-Filter Compressor heater 63 ** Particle filter 164 *** Phase sequence monitor 65 a, b Drying filter Terminal block -X200, compressor heater 69 a, b Contactor, compressor operation Accessories Enclosed Only 30, 40 kW FIGHTER 1330...

  • Page 78: Dimensions

    Cable gland, electrical supply Cable gland, sensors (72) Heating medium flow (B) Ø28 (5) Brine out Ø42 (73) HW-return from water heater Ø28 (71) Heating medium return Ø35 (70) Heating medium flow (A) Ø28 (4) Brine in Ø42 FIGHTER 1330...

  • Page 79: Accessories

    Part no. 069 320 6 kW Part no. 018 088 9 kW Part no. 018 090 EP 42 EP 26 °C °C Electric element 15 kW Electric boiler 26 kW Electric boiler 42 kW Adapted for controlling from Fighter 1330 FIGHTER 1330...

  • Page 80: Technical Specifications

    1 x R25, Part no. 024 076 Three current transformers Aluminium tape female) 1 x R32, Part no. 024 077 Part no. 018 569 Part no. 025 179 Part no. 424 088 1 x R40, Part no. 024 194 FIGHTER 1330...

  • Page 81: Low Room Temperature

    In the event of malfunction or operating disturbances first check the points below: Low room temperature NOTE! As FIGHTER 1330 can be connected Cause: Compressor and electric element do not heat up. to a large number of external units Action: Check and replace the any blown circuit and even these should be checked.

  • Page 82: Alarm

    The temperature of the outgoing heating medium (VBFA or VBFB) is outside the compressor's working range. This may be due to: ■ Incorrect flow. ■ Incorrect settings The alarm is reset when the temperature drops 2 degrees on the return line. FIGHTER 1330...

  • Page 83: Constant Alarm

    5.4.11 (Reset alarm). ■ Leakage in the brine circuit. The alarm is reset once the fault has been rectified and the unit has been restarted or the alarm has been acknowledged in menu 5.4.11 (Reset alarm). FIGHTER 1330...

  • Page 84: Draining, Heating Medium Side

    ■ Start FIGHTER 1330 and check whether the circu- lation pump runs. It is usually easier to start the circulation pump with FIGHTER 1330 running, switch (8) set to 1. If helping 16/19 the circulation pump to start is performed with FIGHT- ER 1330 running, be prepared for the screwdriver to jerk when the pump starts.
  • Page 85 FIGHTER 1320...
  • Page 86 FIGHTER 1320...
  • Page 88 NIBE CZ, V Zavetri 1478/6, CZ-170 00 Prague 7 Tel: +420 266 791 796 Fax: +420 266 791 796 E-mail: centrala@nibe-cz.com www.nibe-cz.com NIBE Systemtechnik GmbH, Am Reiherpfahl 3, 29223 Celle Tel: 05141/7546-0 Fax: 05141/7546-99 E-mail: info@nibe.de www.nibe.de Vølund Varmeteknik, Filial af NIBE AB, Brogårdsvej 7, 6920 Videbæk Tel: 97 17 20 33 Fax: 97 17 29 33 E-mail: info@volundvt.dk www.volundvt.dk...

This manual is also suitable for:

Fighter 1320

Table of Contents
