Mount The Y Motor - Geeetech Prusa I3 X Building Instructions

Shenzhen GETECH CO.,LTD
GEEETECH
(this picture is just for reference, the plates are not exactly the same as that for I3 X)
* Tips:
the Y-axis must be a rectangle, that is the rods on both side should be parallel, so is
the front and back plate. Otherwise it will cause obstruction for the belt later. You can
use a Digital Caliper to measure.
You can watch the video here.

3. Mount the Y motor

Part name Part ID Required number pic
stepper motor No.63 1
5
