Instructions
™
VPM
Hydraulic, Plural-Component, High-Viscosity, Variable-Ratio Proportioner.
For pouring and dispensing sealants and adhesives. For professional use only.
Not approved for use in European explosive atmosphere locations.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
See page 4 for model information, including maximum working pressure and approvals.
VPM-12
ti17692a
VPM-25
313875J
EN
ti17693a

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VPM Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Graco VPM Series

Summary of Contents for Graco VPM Series

  • Page 1 Instructions ™ 313875J Hydraulic, Plural-Component, High-Viscosity, Variable-Ratio Proportioner. For pouring and dispensing sealants and adhesives. For professional use only. Not approved for use in European explosive atmosphere locations. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. See page 4 for model information, including maximum working pressure and approvals.

  • Page 2: Table Of Contents

    Initial Machine Setup ..... 22 Graco Standard Warranty ....88 Adjust Motor Control Module Selector Switch .

  • Page 3: Related Manuals

    Related Manuals Related Manuals Manuals are available at www.graco.com. Component manuals in English: System Manual 312764 VPM Repair-Parts Power Distribution Box Manual 3A0239 Power Distribution Boxes Instruc- tions-Parts Pumpline Manuals 312375 ® Check-Mate Displacement Pumps 3A0021 Vertical Hydraulic Driver Repair-Parts...

  • Page 4: Models

    If 2000 psi hoses were purchased and installed by Graco, the working pressure for the machine is already setup for the lower 2000 psi (14 MPa, 138 bar) working pressure by Graco. If the machine was purchased without hoses and aftermarket hoses rated at or above 3000 psi are to be installed, see Adjust Motor Control Module Selector Switch on page 27 for the procedure to setup the machine for higher rated hoses.

  • Page 5: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
  • Page 6 Warnings WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: • Use equipment only in well ventilated area. • Eliminate all ignition sources; such as pilot lights, cigarettes, portable electric lamps, and plastic drop cloths (potential static arc).

  • Page 7: Important Two-Component Material Information

    Important Two-Component Material Information WARNING BURN HAZARD Equipment surfaces and fluid that’s heated can become very hot during operation. To avoid severe burns: • Do not touch hot fluid or equipment. SPLATTER HAZARD Hot or toxic fluid can cause serious injury if splashed in the eyes or on skin. During blow off of platen, splatter may occur.

  • Page 8: Moisture Sensitivity Of Isocyanates

    A (Red) and B (Blue) Components Moisture Sensitivity of • Use moisture-proof hoses specifically designed for ISO, such as those supplied with your system. Isocyanates • Never use reclaimed solvents, which may contain moisture. Always keep solvent containers closed Isocyanates (ISO) are catalysts used in two component when not in use.
  • Page 9 A (Red) and B (Blue) Components 313875J...

  • Page 10: Component Identification

    Component Identification Component Identification AA Advanced Display Module (see page 18) AG Boom Lift Lever AB Hydraulic Power Pack AH Mixer AC Vertical Hydraulic Driver AJ Main Power Switch AD RAM Assembly AK Air Supply Inlet AE Ratio Check Dispense Valves/Ports AL Electrical Enclosure AF Power Distribution Box VPM-25 shown...
  • Page 11 Component Identification VPM-25 shown ti17702a . 2: Component Identification 313875J...
  • Page 12 Component Identification VPM-12 ti17703a 313875J...
  • Page 13 Component Identification RAM Assembly BA Vertical Hydraulic Driver BF Blowoff Air Supply Line Connector BB Pump Lower BG Platen Lift Rod BC Platen BH Pump Bleeder Valve BD Integrated Air Controls BJ Pump Wet Cup BE Platen Bleed Port BK Material Line ti17705a 313875J...
  • Page 14 Component Identification Integrated Air Controls Circuit Breakers The integrated air controls include: • Main air slider valve (CA): turns air on and off to the ram system. When closed, the valve relieves pressure downstream. Most circuit breakers are located inside the power distri- bution box.

  • Page 15: Hydraulic Power Pack

    Component Identification Hydraulic Power Pack 257442_313873-5_1t 257442_313873-5_2t Shown with shroud removed Key: 8 Gallon Hydraulic Oil Reservoir (see Technical Data on Motor Control Module (see page 16) page 87 for specifications) Electric Motor Hydraulic Oil Filter Dipstick Hydraulic Fluid Drain Port Hydraulic Housing 313875J...

  • Page 16: Motor Control Module (Mcm)

    Component Identification Motor Control Module (MCM) The MCM is located in the Hydraulic Power Pack. NOTICE If the Motor Control Module is replaced, the selec- When installed, the end of the MCM with the power tor switch must be set prior to initial startup of the input connection (12) faces down and the end with the Motor Control Module or damage may occur.
  • Page 17 Component Identification Description Access Cover Module Status LEDs Warning Label A (Red) MCM only: ADM, Power Distribution Box 1A, 1B B (Blue) MCM only: FCM, Power Distribution Box NOTE: 1A and 1B are interchangeable. Three-way Splitter to: Oil Low Level Sensor, Dispense Valve Solenoid, Footswitch Oil Temperature Sensor...

  • Page 18: Advanced Display Module (Adm)

    Component Identification Advanced Display Module (ADM) User Interface TI12362a1 . 7: ADM Component Identification - Front Buttons Call Call Button Function Button Function Softkeys Defined by icon next to softkey Enable/disable ADM Enable/ Abort Abort current operation Disable Enter Accept change, acknowledge error, System Displays system status select item, toggle selected item...
  • Page 19 Component Identification ti12902a . 8: ADM Component Identification - Rear Key: Flat Panel Mount Module Status LEDs Model Number Identification Label Accessory Cable Connection USB Interface (see Appendix E - USB Operation Software Token Access Cover beginning on page 80 Battery Access Cover CAN Cable Connection to MCM See ADM Troubleshooting on page 53 for LED status information.
  • Page 20 Component Identification ADM Screen Components See the ADM appendix sections beginning with Appendix A - ADM Icons Overview on page 57 for more informa- tion. Current date and time Previous screen Current screen Next screen Operating Mode Faults, Status Enter/Exit screen Previous screen no.

  • Page 21: Fluid Control Module (Fcm)

    Component Identification Fluid Control Module (FCM) The fluid control module is located inside the electrical enclosure. ti12337a1 ti12336a1 . 11: Key: Module Connection Screws Access Cover Module Status LEDs CAN Connectors (one is connected to MCM, other is unused) 313875J...

  • Page 22: Setup

    Setup Setup Initial Machine Setup b. Connect air line on boom to boom director valve located on boom support. Perform this setup procedure to prepare the machine for initial operation. c. Install mixer onto boom. d. Connect electrical cables from base to boom. e.
  • Page 23 Setup 4. Fill pump wet cups 2/3 full with pointed up and the sensor is on the outlet side (top, as shown) of the flow meter. IsoGuard Select fluid. A (Red) Side B (Blue) Side b. Hand tighten flow meter fittings to allow proper positioning of the entire assembly.
  • Page 24 Setup e. Connect the flow meter cable. Electrical Cord Requirements NOTE: Power cord is not supplied. See the following table. Table 1: Power Cord Requirements Cord Requirements Model AWG (mm 230V, 3 phase 8 (8.4), 3 wire + ground 400V, 3 phase 6 (13.3), 4 wire + ground †...
  • Page 25 Setup Power Line Voltage Surges The chart below shows the permissible magnitude and duration of temporary over-voltage events: Power conversion equipment can be sensitive to voltage fluctuations on incoming power. The Motor Control Mod- ule falls under the category of power conversion equip- Maximum Permissible Transient Voltage Surges * Constructed from ITIC 1996 curve, referenced by IEC 61000-2-4 ment because energy is stored on a capacitive bus and...
  • Page 26 Setup 11.If applicable, attach and adjust b. Navigate to Advanced #2 screen then set units of measure. See page 63. drum low/empty sensor. c. Navigate to Advanced #3 screen then NOTE: An optional kit can be purchased to indicate enable/disable system features. See page 64. either when the drum is low or when it is empty.

  • Page 27: Adjust Motor Control Module Selector Switch

    Setup Adjust Motor Control Module Selector Switch NOTICE If the Motor Control Module is replaced, the selector switch must be set prior to initial startup of the • Do not install components rated to less than the Motor Control Module or damage may occur. highest pressure in the selected pressure range.

  • Page 28: Startup

    Startup Startup Moving parts can pinch or amputate fingers. When the pump is operating and when raising or lowering the ram, keep fingers and hands away from the pump intake, platen, and lip of the drum. 1. Perform all required maintenance tasks. See Main- tenance on page 47.

  • Page 29: Change Drum

    Change Drum Change Drum 7. Remove bleed stick from platen bleed port (J). Excessive air pressure in the material drum could cause the drum to rupture, causing serious injury. The platen must be free to move out of the drum. Never use drum blowoff air with a damaged drum.

  • Page 30: Priming

    Priming Priming 1. Place waste containers below both ratio check dis- 8. Continue dispensing until clean, air-free material is pense valves. dispensed from both sides then press to stop NOTE: Both ratio check dispense valves will be open dispensing. when dispensing in Prime Mode. Only one pump moves but material may drip from the other ratio check dis- 9.

  • Page 31: Operation

    Operation Operation ADM Operation Overview NOTE: After startup, press to enable the ADM. ADM Navigation Diagram Run Screens Optional: Home Errors #1 Events #1 Maintenance Diagnostic Errors #2 Events #2 Errors #... Events #... Password Entry (if enabled) Setup Screens Shot #1 Sequences #1 Calibration...
  • Page 32 Operation Navigation Overview Change ADM Values For all ADM screens to be accessible and functional, the To edit information in a screen, such as a shot definition ADM must be enabled and an operating mode other or a system setting like time or date format, follow this than Standby or Disabled must be selected.

  • Page 33: Machine Operation Overview

    Operation Machine Operation Overview Ramp Up Feature Learning Mode The purpose of the ramp up feature is to enable dis- When a flow rate or dispense ratio is requested that the pensing at the correct ratio but at a reduced flow rate machine has not learned, the system will use the pump when materials are too thick to dispense at the correct volume of each pump to estimate the pump velocities...

  • Page 34: System Setup And Calibration

    Operation System Setup and Calibration 7. Navigate to the System 2 screen. Perform this entire procedure if any of the following con- ditions are met: • The machine is new • One or both materials in the system have changed since last performing this procedure •...
  • Page 35 Operation 12. Select the flow meter types installed on your sys- 16. Press tem. For VPM-25 systems, select “HG6000” for the A (Red) side and “SRZ-100” for the B (Blue) side. For VPM-12 systems, select “HG6000” for both sides. If no flow meters are installed, select the “Dis- able”...
  • Page 36 Operation b. Place a waste container below the ratio check Flow Rate and Ratio Learning valves. The next steps will cause the machine to 25. At the main Calibration screen, press to erase dispense material. all learned data. c. Press then .
  • Page 37 Operation 29. On the main run screen, verify the ratio check valve NOTE: Continue base purge until clean material comes out of the end of the mixer. button is not active. d. When all mixed material is pushed out of the mixer, press to stop dispensing.
  • Page 38 Operation 41. Weigh the two buckets and use the net weight of each dispensed material to calculate the actual ratio of the dispensed material. 42. If the calculated ratio of the weighed materials does not match the ratios displayed on the ADM, go to step 1 to re-calibrate the flow meters.
  • Page 39 Operation Flow Meter or Flow/Ratio Calibration 8. Weigh both buckets and enter the net weight of each material dispensed in the last two fields pro- vided on the screen. 1. At the main Calibration screen, press to erase any previously learned flow meter calibration data. NOTE: After the weights are entered the K-factor will be shown to the right of the weights.
  • Page 40 Operation No Flow Meter Machine Calibration 3. Press to exit the setup screen and verify the It is highly recommended that the user operate the ratio check option is not selected. machine in weight mode when flow meters are not installed or have been disabled.
  • Page 41 Operation 7. Place waste containers below the ratio check noz- NOTE: After entering the net weight of B (Blue) material, zles and start a ratio check dispense. Adjust the the ADM will inform the user how close the respective ratio check opening screws until the pressures dis- flow of the pump was to the desire rate.
  • Page 42 Operation NOTE: It is recommended that the user calibrate the machine at the extreme rates where it will be used. Example: If the machine is to be used at mixed flows between 300 & 500 grams/second (at 3:1 ratio), cali- brate the machine at the two 300 and 500 grams/ sec- ond extremes, then stop the calibration process.

  • Page 43: Dispensing

    Operation Dispensing Dispense in Sequence Mode Sequences can be defined on the Sequences screen. Sequences are defined on the Sequences screen, see Dispense in Shot Mode page 60. To dispense in Shot mode, at least one shot number must be defined. Shots are defined on the Shots 1.
  • Page 44 Operation Dispense in Operator Mode 7. Check the ADM for errors and pop-up notifications that could indicate a faulty dispense. Press acknowledge any displayed errors. Operator Mode begins dispensing when is pressed and stops when it is pressed again. NOTE: If a footswitch is used, press and hold to dis- pense.

  • Page 45: Shutdown

    Shutdown Shutdown Short-term 7. Place container under the mixer and allow mixer to drain completely. 1. Place container under mixer. NOTICE 2. If using a moisture-sensitive material, park pumps. Preventing material from draining from the mixer may cause material in the mixer to harden and dam- a.

  • Page 46: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Procedure 1. Perform Shutdown procedure. 2. Set the ram director valve to neutral position. 3. Place a waste container below each ratio check valve. In the following step, any pressure in the lines will be instantly relieved which may lead to material spraying out of the valve and splashing in the bucket.

  • Page 47: Maintenance

    Maintenance Maintenance Change Hydraulic Oil and Filter Change break-in oil in a new unit after the first 250 hours of operation or within 3 months, whichever comes first. After initial break-in, see the following table for rec- Check all sub-component manuals for maintenance ommended oil and filter change schedule.

  • Page 48: Install Upgrade Tokens

    To install software upgrades: 1. Use correct software token stated in the table. See ti12334a1 r_257396_3b9905_04b ™ Graco Control Architecture Module Programming manual for instructions. NOTE: Upgrade all modules in the system to the software version on the token, even if you are replacing only one or two modules.

  • Page 49: Advanced Display Module (Adm)

    Maintenance Advanced Display Module (ADM) Motor Control Module (MCM) Keep heat sink fins clean at all times. Clean them using compressed air. Replace Battery A lithium battery maintains the ADM clock when power NOTE: Do not use conductive cleaning solvents on the is not connected.
  • Page 50 Maintenance 313875J...

  • Page 51: Troubleshooting

    Troubleshooting Troubleshooting Light Tower (Optional) Signal Description Green on only System is powered up and there are For information about ADM error and event codes see no error conditions present Appendix D - ADM Event and Error Codes Overview, Yellow on An advisory exists page 69.
  • Page 52 Troubleshooting Problem Cause Solution Material imbalance Inadequate flow from pump; cavitation Increase fluid supply to proportioning pump Worn pump inlet valve ball/seat or gasket, repair as necessary Erratic pump movement Pump cavitation Feed pump pressure is too low, adjust pressure to within required range Pump output low Obstructed fluid hose or mixer;...

  • Page 53: Adm Troubleshooting

    Troubleshooting ADM Troubleshooting ti12902a ti12362a1 . 16: ADM Component Identification - Rear ADM System Status LEDs (B) Conditions Module Status LED Signal Description Green on Run mode, System on Green flashing Setup mode, System on Yellow on Run Mode, System off ADM Module Status LEDs (N) Conditions Module Status LED Signal...

  • Page 54: Motor Control Module

    Troubleshooting Motor Control Module Diagnostic Information Table 3: LED Status Signal Module Status LED Signal Description Green on System is powered up Yellow on Internal communication in progress Red solid MCM hardware failure. Replace MCM Red flashing fast Uploading software Red flashing slow Token error, remove token and upload software token again...
  • Page 55 Troubleshooting Acceptable Size and Duration of Power Line Voltage Fluctuations The Motor Control Module is designed to withstand volt- age fluctuations from the incoming power supply. If the incoming power supply goes outside of the tolerable range, an over-voltage condition is flagged and the sys- tem shuts down in an alarm state.

  • Page 56: Fluid Control Module

    Troubleshooting Fluid Control Module Diagnostic Information Module Status LED Signal Diagnosis Green on System is powered up Yellow Internal communication in progress Red solid FCM hardware failure. Replace FCM. Red flashing fast Uploading software Red flashing slow Token error. Remove token and upload software token again.

  • Page 57: Appendix A - Adm Icons Overview

    Appendix A - ADM Icons Overview Appendix A - ADM Icons Overview Setup Screen Icons Icon Description Icon Description Learn Top-Most Piston Position Enter Screen Go to Next Calibration Screen Exit Screen Begin Weight Calibration Shot Erase Selected Item Dispense Valve Details Erase All Items Shown Shot Number Change Multiple Values...

  • Page 58: Home Screen Icons

    Appendix A - ADM Icons Overview Home Screen Icons Icon Description Icon Description Prime A (Red) Side Select Operating Mode Prime B (Blue) Side Initiate Dispense Enter Screen Dispense Disabled Exit Screen Ratio Check Erase Selected Item Park Piston Erase All Items Shown Park Piston Disabled Weight Close Dispense Valve...

  • Page 59: Appendix B - Adm Setup Screens Overview

    Appendix B - ADM Setup Screens Overview Appendix B - ADM Setup Screens Overview Setup Screens Navigation Diagram Calibration Shot #1 Sequences #1 System #1 Maintenance Supply Conditioning #1 Advanced #1 Shot #2 Sequences #2 System #2 Conditioning #2 Advanced #2 Shot #...
  • Page 60 Appendix B - ADM Setup Screens Overview Sequences Calibration - Learn Mode This screen is for learning the mechanical limits for pis- This screen allows the user to edit sequence definitions. ton travel. The contents of this screen change based on the Dis- pense mode.
  • Page 61 Appendix B - ADM Setup Screens Overview System #1 System #2 This screen allows the user to set mechanical system This screen allows the user to set the Gel Timer proper- settings and the Dispense Mode setting. ties and set which items are installed on the machine. Dispense mode can be set to volume or weight.
  • Page 62 Appendix B - ADM Setup Screens Overview System #3 Maintenance This screen allows the user to edit the labels for the A This screen shows shot number and sequence position (Red) and B (Blue) sides of the machine. The labels set counters.
  • Page 63 Appendix B - ADM Setup Screens Overview Conditioning #1 Advanced #1 NOTE: Platen heaters are available as an option on the This screen allows the user to set the language, date VPM system. format, current date, time, setup screens password, screen saver delay, and turn on or off silent mode.
  • Page 64 Appendix B - ADM Setup Screens Overview Advanced #3 Advanced #4 This screen is for enabling the optional Diagnostic This screen allows the user to control the availability of screen and for enabling USB log downloading and USB some key system features. errors.

  • Page 65: Appendix C - Adm Run Screens Overview

    Appendix C - ADM Run Screens Overview Appendix C - ADM Run Screens Overview Run Screens Navigation Diagram Optional: Home Errors #1 Events #1 Maintenance Diagnostic Errors #2 Events #2 Errors #... Events #... Home Screens Disabled The Home screen is the first screen that displays when the machine is started and when switching from the Setup screens to the Run screens.
  • Page 66 Appendix C - ADM Run Screens Overview Shot Operator This mode allows the user to dispense using one of the This mode allows users to dispense without using pre- defined shots. See Shots screen on page 59. Shot defi- defined shot numbers or sequences. Use to set nition including flow, ratio, progress, and size is shown at the bottom of the screen.
  • Page 67 Appendix C - ADM Run Screens Overview Errors Screen Maintenance The Errors screens display the 50 most recent system This screen displays historical information for each errors. Each error entry includes a description and error pump including material usage and pump cycles. The code along with a date and time stamp.

  • Page 68: Optional Screens

    Appendix C - ADM Run Screens Overview Optional Screens Diagnostic Screen The optional Diagnostic screen can be enabled in the Advanced #4 screen, see page 64. The Diagnostic screen shows status information for vari- ous system components. Status Screen The status screen provides all of the operational func- tionality of the Home screen except for operating mode selection.

  • Page 69: Appendix D - Adm Event And Error Codes Overview

    Appendix D - ADM Event and Error Codes Overview Appendix D - ADM Event and Error Codes Overview Event Codes Event Code and String Triggers Event Code and EQU1-R: Settings The system settings were successfully String Triggers Downloaded transferred from the ADM to a USB EAA0-R: Base Purge Base purge performed drive.

  • Page 70: Error Codes

    Appendix D - ADM Event and Error Codes Overview Error Codes Error Error Code Error Name Error Description Type Cause Solution The three point calibration data is invalid, system will operate in weight mode but will attempt Invalid to volumetrically calculate 0500 Weight Cal.
  • Page 71 Alarm Current commanding too much current Module code software, if problem persists contact Graco On the ADM go into the Setup screens to the System Pumps are defined with The requested dispense screens then make sure that the pump sizes are...
  • Page 72 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Pump cannot reach the Increase restriction in the system requested pressure Setpoint Not D2A1 The set point was not reached Deviation Reached Pump cannot reach the Decrease restriction in the system...
  • Page 73 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Low oil level Check oil level and if low add more hydraulic fluid Check to ensure the hydraulic oil level sensor is Loose/bad connection properly connected to the MCM and that the wire has not been damaged...
  • Page 74 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Ensure the material flow is equally restricted on both Dispense line is clogged material lines On the ADM go into the setup screens -> System-> Pressure imbalance is and ensure the pressure imbalance value is the defined too low...
  • Page 75 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Blue Tank T4B5 High Fluid Alarm Temp. Red Inline T4A3 High Fluid Alarm Temp. Blue Inline T4B1 High Fluid Alarm Defective RTD Replace RTD Temp.
  • Page 76 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Red Blanket T6C6 Alarm RTD Fault Blue Blanket T6C5 Alarm Loose or bad connection Check RTD wiring RTD Fault RTD 2 is giving no or invalid data Red Chiller T6C7...
  • Page 77 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution Red Blanket T9C6 Ctrl Alarm Shutdown Blue Blanket T9C5 Ctrl Alarm Shutdown Red Inline T9C3 Ctrl Alarm Shutdown Blue Inline T9C1 Ctrl Alarm Overheated...
  • Page 78 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution No power to directional Make sure the directional valve has power valve Make sure the cord to the directional valve is Bad directional valve connected to the correct port and the cord is not connection...
  • Page 79 Appendix D - ADM Event and Error Codes Overview Error Error Code Error Name Error Description Type Cause Solution On the ADM go into the setup screens -> System-> System incorrectly setup and ensure that all pages have properly defined Invalid The requested controlling values...

  • Page 80: Appendix E - Usb Operation

    Appendix E - USB Operation Appendix E - USB Operation The second option is the Erase icon which will reset the NOTICE last download date to a time where all logs can be Low-quality USB stick drives may lead to burning downloaded.

  • Page 81: Log Files, Folder Structure

    Appendix E - USB Operation Log Files, Folder Structure . 19: DOWNLOAD, DATAxxxx Folders Each time a stick-drive is inserted into the ADM USB port, a new folder named DATAxxxx is created. The number at the end of the folder name is incremented each time a stick-drive is inserted and data is transferred through the USB. In each DATAxxxx folder there are three log files.
  • Page 82 Appendix E - USB Operation Example 2-JOB File The 2-JOB file is the Shot Data log file. Example 3-SYSTEM File The 3-SYSTEM file is the Software Version log file. 313875J...

  • Page 83: Transfer System Settings

    7. Turn the Main Power Switch to the OFF position The user should never attempt to modify the SET- then back to the ON position. TINGS.TXT file in any way. Graco is not responsible for damages caused by an improperly modified 8. Plug the USB stick-drive into a computer.

  • Page 84: Update Custom Language

    Appendix E - USB Operation Update Custom Language Use the following process to customize the text on the NOTE: Immediately following uploading the language ADM. The language file DISPTEXT.TXT can be modi- file, remove the DISPTEXT.TXT file from the UPLOAD fied in Excel but must be saved as a Unicode Text file folder to prevent accidental loss of data the next time the with the extension .TXT in order for it to properly import.
  • Page 85 Appendix E - USB Operation Example SETTINGS.TXT File Example DISPTEXT.TXT File NOTICE The user should never attempt to modify the SET- TINGS.TXT file in any way. Graco is not responsible for damages caused by an improperly modified setup file. 313875J...
  • Page 86 Appendix E - USB Operation 313875J...

  • Page 87: Technical Data

    Technical Data Technical Data Air Inlet Pressure ......85-100 psi (0.59-0.69 MPa, 5.9-6.9 bar) Wetted Parts .

  • Page 88: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
