Introduction

The LW Scientific Zip-IQ TT centrifuge is a 6-place test tube centrifuge for spinning blood, urine, and other fluids in
0.5ml to 15ml test tubes and microtubes. The unit is very small, conserving counter space in the lab, but also sturdy
with suction-cupped feet for stability. Two programmable buttons allow you to set quick and easy speed and time
selections. The RPM / RCF button toggles between displaying RPM or RCF (g-force). The digital controls allow speed
and time to be adjusted with the touch of a finger and will show real-time speed and time remaining. The mainte-
nance-free, brushless motor spins at 5,000rpm (2,500g) producing serum in as little as 5 minutes. Slow the speed to
2,000rpm (400g) to spin urines in 5 minutes. The auto-brake stops the rotor in 10 seconds, and the lid opens automati-
cally upon completion.
A
B
C
D
E
F
L
100 Lauman Lane, Suite A, Hicksville, NY 11801
Tel: (877) 877-7274 | Fax: (516) 801-2046
Email: Info@nyscopes.com
www.microscopeinternational.com
Zip-IQ TT Centrifuge
A
B
C
D
E
F
G
H
I
J
K
L
M
Includes:
• 6-place angled rotor for 7ml-15ml tubes
• 6 black inserts for 5ml-6ml tubes
• 6 white inserts for 3ml-4ml tubes
• 6 green inserts for 0.5ml-2.0ml microtubes
• Hex wrench for rotor screw
M
Instruction Manual
Lid
Rotor
Open Button
P2 Button
Speed Adjustment
Start/Stop Button
Emergency Release Lever
(Bottom of unit)
Time Adjustment
P1 Button
RPM / RCF Button
LCD Display
Power Jack
Power Switch

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Zip-IQ TT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LW Scientific Zip-IQ TT

  • Page 1 Introduction The LW Scientific Zip-IQ TT centrifuge is a 6-place test tube centrifuge for spinning blood, urine, and other fluids in 0.5ml to 15ml test tubes and microtubes. The unit is very small, conserving counter space in the lab, but also sturdy with suction-cupped feet for stability.
  • Page 2 Warranty LW Scientific instruments have a one (1) year limited warranty. This warranty is not valid on normal wear and tear, cosmetic damages caused by chemicals, solvents, and/or cleaning solutions, as well as acts of God. Please register your product online at: www.LWScientific.com/warranty_form.
  • Page 3 Because of safety issues with high g-forces in a centrifuge, it is recommended that rotors be inspected monthly for wear and fatigue. If there is any indication of wear, the rotor should be removed from service. Contact LW Scientific for return instructions so the rotor can be evaluated by a technician for repair or replacement. After 2 years of service, it is recommended that rotors be returned to LW Scientific for inspection or replacement.
  • Page 4 Recommended Fluid Speeds and Times Set the speeds and times as follows, or defer to clinical protocols if different: Fluid Tube Size Inserts Speeds Times Blood Large (6ml-15ml) None or Black 5,000rpm 5 minutes Blood Small (3ml-5ml) White 5,000rpm 6 minutes Blood Microtubes (0.5ml-2.0ml) Green...
