LW Scientific MiniVID USB Instruction Manual

USB Version Specifications

Models: MVC-U5MP-EMTN, MVC-U5MP-USB3
Chip identification: UCMOS05100KPA
Hardware Configuration:
Sensor Model APTINA MT9P001
Scan Mode Progressive
Max. Resolutio 2592 x 1944 (Approx.5,040,000 Pixels)
Sensor Size 1/2.5" (5.70mm(H)x4.28mm(V), Diagonal 7.13mm)
Pixel Size 2.2μm x 2.2μm
Responsivity 0.53v/lux-sec(550nm)
Dynamic Range 66.5dB
A/D Converter 10-bit, 8-Bit R.G.B to PC
SN Ratio 40.5dB
Spectral Range 400-650nm (with IR-filter)
Frame Size and Rate 5fps @2592 x 1944, 18fps @1280 x 960, 60fps @640 x 480
(Multiple Speed Level)
Binning 1 x 1, 2 x 2, 4 x 4
Exposure Electronic Rolling Snap(ERS),0.21~2000ms,ROI Auto & Manual
Color Rendering Technique Ultra FineTM Color Engine
White Balance One Push ROI White Balance/ Manual Temp-Tint Adjustment
Capture/Control API DirectShow, Twain
Capture Mode Still Picture and Video
Software Environment
Operating System Microsoft Windows XP / Vista / 7 / 8 / 10 (32 & 64 bit)
PC Requirements CPU: Equal to Inter Core2 2.8GHz or Higher
Memory 2GB or More
USB Port USB2.0 High-speed Port

Operating Environment

Operating Temperature -30~70ºC
Storage Temperature -40~125ºC
Operating Humidity 30~80%RH
Storage Humidity 10~60%RH
Power Supply USB Port <5V 500mA DC
P. 770.270.1394 F. 770.270.2389
MKT-7.5.3-L-184 | Rev 1
865 Marathon Parkway Lawrenceville GA 30046

Introduction

The innovative MiniVID USB digital eyepiece camera slips into any standard microscope eyepiece tube,
in place of the eyepiece, for crisp imaging or video micrography in an instant. The MiniVID camera is
intended for use in a professional environment to capture digital images or video under a microscope in
accordance with the guidelines set forth in this operations manual.
•Small and Portable
•Fits Into Any Standard Eyetube or C-mount Trinoc
•Includes Software
