<14> Color Steer
<15> Focus
<16> IP
<17> Freq/THI
<18> B Steer
<19> CW
<20> PW
<21> B
<22> Color
<23> M
<24> Update
<25> Dual
<26> Quad
<27> Power
<28> Save Cine
<29> Review
<30> Save Img
<31> Cine
<32> iTouch
<33> Depth/Zoom
<34> Freeze
<35> Menu
<36>
<37> Back
<38> Change
Toggle to adjust ROI steering angle of a linear transducer
in the Color/Power mode.
Toggle to adjust focus position for B images.
Toggle to select IP for B images.
Toggle to adjust the current transducer frequency and
harmonic frequency.
Toggle to adjust steering scan of a linear transducer or
trapezoid imaging.
Press to enter the CW mode; rotate to adjust gain of a
CW image.
Press to enter the PW mode; rotate to adjust gain of a
PW image.
Press to enter the B mode; rotate to adjust gain.
Press to enter the Color Doppler mode; rotate to adjust
gain.
Press to enter the M mode; rotate to adjust gain of an M
image.
Press to switch between image windows in M/B mode，
PW/B or CW/B mode., Press to start or end image
capture in the 3D mode.
Enters dual-split screen display, or changes the live
image window in Dual.
Enters the quad-split screen display, or changes the live
image window in the Quad mode.
Press to enter the Power Doppler mode; rotate to adjust
gain.
Quickly saves cine files to the default region of the
internal hard disk in the preset image format.
Reviews the image files of the current patient or the last
patient.
Quickly saves image files to the default region of the
internal hard disk in the preset image format.
Enters the cine review status.
Press to optimize images.
When the Depth indicator lights on, the knob is used for
adjusting image depth by turning it; when the knob is
pressed down and the Zoom indicator lights on, the knob
is used for adjusting magnification factor by turning it.
Freezes or unfreezes an image.
Invokes or closes the menu corresponding to the current
status.
Multifunction knob: it functions differently depending upon
different statuses. Refer to the relevant sections for
specific functions.
Returns to the previous operation.
Changes the active
measurement; or opens the comment library in the
comment status.
