<18> Power switch

2.1.2 Complete System with LCD Monitor

No Name
<1> Monitor
<2> Monitor support arm Supports and adjusts height and position of LCD monitor
<3> Brightness buttons
<4> Contrast buttons
<5> Locking lever
Used for turning on/off the power supply
Displays the images and parameters during scanning
Adjust brightness of LCD monitor
Adjust contrast of LCD monitor
Locks the monitor in the lowest status
2-3
System Overview
Function
