A
Hydraulic oil filler cap
B
Oil tank cap
The hydraulic oil level is checked with a bayonet placed under the oil fill cap
6.3. Hydraulic oil changing
It is recommended that the oil and oil filter were changed once a year, assuming that the machine is
working 8 hours a day. In justified cases, the exchange should be carried out frequently. The oil filter
is located under the oil tank cap B (Pic.6.2).
Recommended hydraulic oil is AGIP ARNICA 46 or other with the same parameters (norm ISO L-HV
and DIN 51524 t.3 HVLP).
6.4. Hydraulic cylinders and pins lubcrication
PIC.6.2 HYDRAULIC OIL REPLENISHMENT
24
A
B
