Caution!
It is forbidden turning in opposite movement of the two tracks, doing so may cause
damage to the mini digger.
Support position steering ( C, Pic.4.1)
1
1 – support lowering
N – neutral position – support stops (the lever returns to that position
N
automatically)
2
2 – support lifting
Arm position steering ( D, Pic.4.1)
3
1
N - neutral position (arm stay in neutral
position)
1 – arm lifting
2 – arm lowering
N
4
3 – turning left
4
4 – turning right
2
14
