- Page 1 Quick Start Guide C-130 Access Point Arista Networks www.arista.com DOC-03483-02...
- Page 2 © Copyright 2020 Arista Networks, Inc. The information contained herein is subject to change without notice. Arista Networks and the Arista logo are trademarks of Arista Networks, Inc in the United States and other countries. Other product or service names may be trademarks or service marks of others.
-
Page 3: Table Of Contents
Mounting Instructions using the Silhouette/Interlude Bracket Mount ............13 Mounting Instructions using the Wall Mount Bracket..................13 Power the Access Point On.........................13 Using C-130 with Power Adapter .......................14 Connect Access Point to the Network......................14 Access Point Troubleshooting..................15 Appendix A: AP-Server Mutual Authentication ............16... -
Page 4: About This Guide
Installing the AP constitutes your acceptance of the terms and conditions of the EULA mentioned above in this document. Intended Audience This guide can be referred by anyone who wants to install and configure the C-130 access point. Document Overview This guide contains the following chapters: •... -
Page 5: Package Content
Package Content The access point (AP) package must contain the components shown in the following figure. C-130... - Page 6 Figure 1: Package Components...
- Page 7 Note down the MAC address before mounting the device on the ceiling or at a location that is difficult to access. If the package is not complete, please contact Arista Networks Technical Support Team at support-wifi@arista.com, or return the package to the vendor or dealer where you purchased the product. C-130...
-
Page 8: C-130 Overview
Top Side Ports on C-130 on page 9 Front Panel of C-130 The front panel of the C-130 has 4 functional LEDs that indicate the working of the device. Figure 2: Front Panel LEDs Table 2: Labels: Front Panel LEDs... -
Page 9: Rear Panel Of C-130
Rear Panel of C-130 The rear panel of the C-130 provides an PoE+ Ethernet port that enables you to connect the device to a wired LAN through a switch or a hub and power the device by using the 802.3af/802.3at standard. -
Page 10: Top Side Ports On C-130
Ethernet SSID. Top Side Ports on C-130 The top side panel of the AP has a console port, a USB port, and a Reset pin. Figure 4: Top Side Panel Table 6: Labels: Top Side Panel... - Page 11 The Reset Pin Hole and the USB port are on the top side of the device as shown in the figure above. The Reset Pinhole resets the C-130 device to factory defaults. To reset the device, press and hold the Reset Pin Hole for 10 sec until all LEDs go off which indicates that the device has rebooted.
-
Page 12: Install The C-130
The mounting procedure can be divided into two parts: 1. Affixing the bracket to the T -grid: Use the mounting bracket to install the C-130 on the ceiling. Fix the bracket to the T-grid and rotate the bracket so that it snaps on the T-grid. - Page 13 2. Mounting C-130 on the bracket: Place the first mounting post on the rear-side of the device on to the lower notch of the bracket. Rotate the device such that the center mounting post fits in to the center notch on the bracket.
-
Page 14: Mounting Instructions Using The Silhouette/Interlude Bracket Mount
Power the Access Point On The C-130 device can be powered on by plugging one end of the Ethernet cable into the PoE+ (802.3at) switch or injector and the other end into the Ethernet/PoE+ port on the C-130. Ensure the PoE+ source you are using is turned ON. -
Page 15: Using C-130 With Power Adapter
To connect C-130 to the network, you should meet the following prerequisites: • Ensure that a DHCP server is already available on the network to enable network configuration of the C-130. • DNS should be able to resolve the server discovery primary: redirector.online.spectraguard.net, secondary: wifi-security-server). -
Page 16: Access Point Troubleshooting
'Authentication failed ' event is raised on the server. Refer to the event for recommended action. The AP has encountered a problem. • If you are using Arista Cloud Services, then open the TCP port 443 (SSL). If you have an on-premises installation, then open UDP port 3851 and port 80. -
Page 17: Appendix A: Ap-Server Mutual Authentication
Note: Although the server is backward compatible, that is, older version APs can connect to a newer version server, this is not recommended. C-130...
