ResMed Tubing Wrap STANDARD User Instructions

Tubing Wrap
STANDARD AND SLIMLINE
User Instructions
English • Deutsch • Français • Italiano • Español • Português • Nederlands • Svenska • Dansk • Norsk • Suomi • 简体中文 •
繁體中文
English
The tubing wrap is intended to reduce condensation
and temperature loss in ResMed air tubing when
connected to a device.
The tubing wrap is available in two variants, Standard
(33963) and SlimLine (36811), referred to collectively
as 'tubing wrap' throughout this manual.
Code Colour
33963 Blue
36811 Grey
Fitting
1. Fully unzip the tubing wrap and unfasten the
Velcro ™ strap.
2. Lay the tubing wrap down with the inside
facing up.
3. Pass one end of the air tubing through the closed
zipper end of the tubing wrap until the rubber
cuff is through.
4. Hold the rubber cuff in position, then zip up the
tubing wrap.
5. Fold the extended end of the zipper back against
the tubing wrap and secure using the Velcro
strap. Only the rubber cuffs should now be
visible.
Note: If you have a Standard tubing wrap and you
want to use it with SlimLine air tubing, you must
complete this additional step between steps 3 and 4:
• At the open end of the tubing wrap, fold the
extra length over by approximately 6" (15 cm)
and secure using the Velcro.
WARNING
Do not use the tubing wrap if the room
temperature is above 86°F (30°C). At higher
temperatures the air temperature at the mask
may be too hot.
Note: For any serious incidents that occur in relation
to this device, these should be reported to ResMed
and the competent authority in your country.
Length Diameter
6'6" (2 m) 0.75" (19 mm)
6' (1.8 m) 0.6" (15 mm)
Cleaning instructions
The tubing wrap should be hand washed or dry
cleaned only. Wash the tubing wrap separately when
new, as the colour may run. Do not bleach.
To wash the tubing wrap:
1. Wash in cold to warm water using a mild
detergent.
2. Rinse well and drip dry.
Note: Hand washing your tubing wrap does not
replace the need to clean your air tubing.
Disposal
The tubing wrap and packaging does not contain any
hazardous substances and may be disposed of with
your normal household refuse.
Symbols
The following symbols may appear on your tubing
wrap or packaging.
Warning; Consult instructions for use;
Manufacturer;
Representative; Catalogue Number;
REF
Code; Importer;
glossary at www.resmed.com/symbols
Deutsch
Die Komforthülle soll bei Anschluss an ein Gerät
die Kondensierung in den Schlauchsystemen
von ResMed sowie den Temperaturverlust durch
dieselben reduzieren.
Die Komforthüllen sind in zwei Ausführungen
erhältlich: Standard (33963) und SlimLine (36811).
In diesem Handbuch werden diese allgemein als
Komforthüllen bezeichnet.
Code Farbe
33963 Blau
36811 Grau
European Authorised
Batch
Medical device. See symbols
Länge Durchmesser
2,0 m 19 mm
1,8 m 15 mm
