oventionovens.com
Register Online!
(see page 2)
Matchbox
Installation and Operating Manual
WARNING
Do not operate this equipment unless you
have read and understood the contents of
this manual! Failure to follow the
instructions contained in this manual may
result in serious injury or death. This
manual
contains
information concerning the maintenance,
use, and operation of this product. If
you're unable to understand the contents
of this manual, please bring it to the
attention of your supervisor. Keep this
manual in a safe location for future
reference.
2940 Hwy 14 W, Rochester, MN 55901
Oven
™
No opere este equipo al menos que haya
leído y comprendido el contenido de este
manual! Cualquier falla en el seguimiento
de las instrucciones contenidas en este
manual puede resultar en un serio lesión
important
safety
o
muerte.
importante información sobre seguridad
concerniente al mantenimiento, uso y
operación de este producto. Si usted no
puede entender el contenido de este
manual
supervisor. Almacenar este manual en
una localización segura para la referencia
futura.
P/N 07.04.620.00
ADVERTENCIA
Este
manual
contiene
por
favor
pregunte
a
su
Models: M1313
M1718
AVERTISSEMENT
Ne pas utiliser cet équipement sans avoir
lu et compris le contenu de ce manuel !
Le
non-respect
des
contenues dans ce manuel peut entraîner
de graves blessures ou la mort. Ce
manuel
contient
des
importantes
concernant
l'utilisation et le fonctionnement de ce
produit. Si vous ne comprenez pas le
contenu de ce manuel, veuillez le signaler
à votre supérieur. Conservez ce manuel
dans un endroit sûr pour pouvoir vous y
référer plus tard.
© 2013 Ovention, Inc.
instructions
informations
l'entretien,

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matchbox M1313 and is the answer not in the manual?

Questions and answers

Related Manuals for Ovention Matchbox M1313

Summary of Contents for Ovention Matchbox M1313

  • Page 1 à votre supérieur. Conservez ce manuel manual in a safe location for future supervisor. Almacenar este manual en dans un endroit sûr pour pouvoir vous y reference. una localización segura para la referencia référer plus tard. futura. © 2013 Ovention, Inc.

  • Page 2: Table Of Contents

    Hotshot Hotline 855-298-OVEN(6836) INTRODUCTION Ovention™ matchbox™ Ovens set a new standard in cooking quality, speed, flexibility, and efficiency. a new discovery in air handling not only speeds the cooking process, but “scrubs” and recirculates the air through the oven—eliminating the need for a hood system in most installations.

  • Page 3: Important Safety Information

    • Do not steam clean or use excessive water on unit. required on this unit, contact an Authorized Ovention • This unit is not “jet-proof” construction. Do not use jet- Service Agent or contact the Ovention hotshot hotline at clean spray to clean this unit. 855-298-6836.

  • Page 4: Model Description

    Operator controls consist of two touchscreens (one for each cooking surface), a Standby switch, and a main Disconnect switch Ovention™ matchbox™ Ovens are designed to provide (model m1718 only). Two removable crumb trays, one below each unequaled flexibility in both kitchen and front-of-the-house platform, allow for easy cleanup.

  • Page 5: Model Designation

    44/49 NEma 6-50P 229 lbs. (102 kg) NOTE: Ovention Matchbox Ovens are designed to accept NOTE: The specification label is located on the left side of the either 208 VAC or 240 VAC. The oven will adjust unit. See the label for the serial number and verification automatically to the input voltage.

  • Page 6: Dimensions

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 SPECIFICATIONS 2940 Hwy 14 W, Rochester, MN 55901 Dimensions Overall Depth height Footprint Footprint Rear Platform Body Model Width (A) Width (D) Depth (E) Width (F) Width (G) Width (h) m1313 49-7/8″...

  • Page 7: Installation

    2940 Hwy 14 W, Rochester, MN 55901 General 7. Install a crumb tray underneath each platform. Ovention™ matchbox™ Ovens are shipped with most • Slide the tray underneath the platform and into the tray components pre-assembled. Care should be taken when support against the oven chamber.

  • Page 8: Operation

    3. Touch the desired setpoint temperature on the right touchscreen. Use the following information and procedures to operate an Ovention™ matchbox™ oven. • The slider assembly will move to its default position, if it is not already there. NOTE: Model 1313 ovens are designed for pan sizes up to a •...

  • Page 9: Cooking

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OPERATION 2940 Hwy 14 W, Rochester, MN 55901 Cooking Use the following procedures to cook a single item or cook CAUTION multiple items continuously. BURN hAzARD: Pan/tray will be very hot upon removal— use oven mitt, pan gripper, or other utensil to remove.

  • Page 10: Programming Menu Items

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OPERATION 2940 Hwy 14 W, Rochester, MN 55901 Programming Menu Items 4. Touch either NEW or EDIT to create or edit a menu item. Use the following procedure to edit or create menu items. This •...

  • Page 11: Changing The Setpoint Temperature

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OPERATION 2940 Hwy 14 W, Rochester, MN 55901 Changing the Setpoint Temperature Creating/Editing Setpoint Temperatures Use the following procedure to change the setpoint temperature Use the following procedure to edit or create the setpoint for the oven.

  • Page 12: Uploading From A Usb Drive

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OPERATION 2940 Hwy 14 W, Rochester, MN 55901 5. Edit or create a setpoint temperature. a. Touch either an existing “setpoint name” box or an LEFT TOUCHSCREEN RIGHT TOUCHSCREEN empty “setpoint name box”.

  • Page 13: General

    10. Polish the exterior surfaces of the oven using a good required on this unit, contact an Authorized Ovention quality stainless steel cleaner. Service Agent or contact the Ovention hotshot hotline at Weekly Cleaning 855-298-6836. 1. Turn off the Standby switch and allow unit to cool. Cooling fans will operate until the oven chamber temperature drops below 140°F (60°C).

  • Page 14: Maintenance

    7. Close the oven door and secure both door latches. IMPORTANT NOTE: 8. Perform the “Weekly Cleaning” procedure in this section. Use of cleaning chemicals not approved by Ovention when cleaning the oven chamber will void the warranty. Form No. OVmm-0113...

  • Page 15: Troubleshooting Guide

    Service agent or Ovention Hotshot for assistance. Temperature High Limit Reset Button NOTE: To locate an Authorized Ovention Service Agent, access the Ovention website at www.oventionovens.com and select the Sales & Service tab, or call the Hotshot Hotline at 855-298-OVEN(6836).

  • Page 16: Options And Accessories

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OPTIONS AND ACCESSORIES 2940 Hwy 14 W, Rochester, MN 55901 Approved Products Chemco Dirt Buster III Oven Cleaner (P/N 0700-8001) Use Chemco Dirt Buster III Oven Cleaner to clean cooking grease and residue safely from the slider system end caps, jet plates, and oven chamber.

  • Page 17: Limited Warranty

    Ovention reserves the right to accept or reject any such claim Ovention in its sole discretion. in whole or part. Ovention will not accept the return of any Product without prior written approval from Ovention, and all THE FOREGOING WaRRaNTIES aRE EXCLUSIVE aND IN approved returns shall be made at Buyer’s sole expense.
  • Page 18 Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 NOTES 2940 Hwy 14 W, Rochester, MN 55901 Form No. OVmm-0113...
  • Page 19 Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 NOTES 2940 Hwy 14 W, Rochester, MN 55901 Form No. OVmm-0113...

  • Page 20: Authorized Parts Distributors

    Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 OVENTION AUThORIzED PARTS DISTRIBUTORS 2940 Hwy 14 W, Rochester, MN 55901 ALABAMA IOWA NEW yORK TExAS Jones mcLeod appl. Svc. Electric motor Service Co. acme american Repairs, Inc.
