OXFORD DINING FURNITURE
Easy Assembly Instructions
Before you
start, here is
some helpful
advice
1.
We suggest you spend a short time reading through this leaflet and then
follow the simple step by step instructions.
2.
Do not discard any of the packaging until you have checked that you have
all the parts and the pack of fittings.
3.
Assemble this product on a carpet.
4.
All you will need to assemble this unit is a screwdriver and light hammer.
5.
Keep glue and fittings out of childrens' reach
In the unlikely event that this product has missing or
damaged parts, please call 0845 640 0800 to obtain spares.
.
Advertisement
Table of Contents
Related Manuals for Argos OXFORD DINING FURNITURE
Summary of Contents for Argos OXFORD DINING FURNITURE
- Page 1 OXFORD DINING FURNITURE Extendable Dining Table Easy Assembly Instructions Before you We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. start, here is some helpful Do not discard any of the packaging until you have checked that you have all the parts and the pack of fittings.
- Page 2 Component parts and fittings contained in the box Extendable Dining Table Fittings M8x80mm Bolt x 8 12x60mm Nut x 4 M8x13mm Nut x 8 M16/8.5x1.2mm Washer x 8 M13/8.5x2.5mm Gasket x 8 W13.5xT2mm Spanner x 1 43x35x34mm x4 Total: 7 Parts...
- Page 3 ASSEMBLY - STAGE ONE Leg Assembly ○ Insert B into ○ Screw in bolts ○ ○ A into Repeat for all four legs. Set the legs onto the base of table. Screw in the ○ nuts C with the ○ ○...
- Page 4 ASSEMBLY - STAGE TWO Leaf Assembly ○ Insert 3 into the holes of short rail (x2). Make sure the rails of ○ are held securely by the wedge under the table.
- Page 5 ASSEMBLY - STAGE THREE How to shorten the table To shorten the table, remove the ○ leaves 3 from the sides. Turn them over, and insert them under ○ the top 1 , one on each side. Turn the wood block between the leaves under the table to hold them...
- Page 6 Oxford - Extendable Dining Table Assembly Instructions - 603/0438 Please keep for future reference Dimensions Length - 210cm Width - 90cm Height - 75cm Important – Please read these instructions fully before starting assembly Ｉｍｐｏｒｔａｎｔ – Ｐｌｅａｓｅ ｒｅａｄ ｔｈｅｓｅ ｉｎｓｔｒｕｃｔｉｏｎｓ ｆｕｌｌｙ ｂｅｆｏｒｅ ｓｔａｒｔｉｎｇ ａｓｓｅｍｂｌｙ If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Issue 1 - 9/12/09...
- Page 7 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Do not stand or put weight on • We do not components and tools listed on the product, this could cause recommend the pages 2 and 3.
- Page 8 Components - Panels Please check you have all the panels listed below underside Leg x 4 (73 x 6.5cm) (150 x 90cm) Extension panel x 2 (90 x 61.8cm)
- Page 9 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 0845 640 0800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 10 Assembly Instructions Step 1 Step 1 Fitting bolts Insert assembly bolt into leg , screw bolts into assembly bolt Repeat with remaining legs Step 2 Attaching legs Attach four legs using washer , and spring washer . Tighten the bolts with spanner...
- Page 11 Fill in the holes of short rail with cover blocks(x4) Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 0845 640 0800 Argos Ltd MK9 2NW...
