Cardioline 200P User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
200P
User manual
Rev.01 – 08.04.2019

Advertisement

Table of Contents
loading

Related Manuals for Cardioline 200P

Summary of Contents for Cardioline 200P

  • Page 1 200P User manual Rev.01 – 08.04.2019...
  • Page 2 200P All rights reserved © Cardioline SpA. CARDIOLINE® is a registered trademark of Cardioline SpA. This publication may not be reproduced, in whole or in part, in any form or manner, without prior written authorisation Cardioline Spa Via Linz, 151...

  • Page 3: Table Of Contents

    200P Table of Contents GENERAL INFORMATION .........................1 1.1. Other important information ......................1 SAFETY INFORMATION ..........................2 ELECTROMAGNETIC COMPATIBILITY (EMC) .....................5 3.1. Guidance and Manufacturer's declaration - Electromagnetic emissions .........6 3.2. Guidance and Manufacturer's declaration - Electromagnetic immunity .........6 3.3. Guidance and Manufacturer's declaration - Electromagnetic immunity .........7 3.4.
  • Page 4 200P 7.6. Troubleshooting table ........................22 TECHNICAL SPECIFICATIONS ........................24 8.1. Harmonised standards applied ......................24 WARRANTY ..............................25 10. DISPOSAL ..............................26...

  • Page 5: General Information

    Other important information This manual was written with the utmost care. Should you find any details which do not correspond to those contained in this manual, please inform Cardioline SpA who will correct such inconsistencies as soon as possible. The information contained in this manual is subject to change without notice.

  • Page 6: Safety Information

    SAFETY INFORMATION SAFETY INFORMATION Cardioline SpA will be held responsible for the safety, reliability and functionality of the devices only if: 1. the assembly operations, modifications or repairs are carried out by Cardioline SpA or by its Authorised Service Centre;...
  • Page 7  The internal rechargeable battery is hermetically sealed NiMH and requires no maintenance. Should the battery be faulty, contact Cardioline technical assistance service.  The low battery warning is designed for the recommended batteries only. Using other types of batteries may lead to a lack of indication resulting in device failure.
  • Page 8 200P SAFETY INFORMATION  The device is intended for use in hospitals or doctor's offices and should comply with the following environmental requirements: Ambient temperature ..... +10°C to +40°C Relative humidity ......50% to 90% Atmospheric pressure ..... 700 hPa to 1060 hPa ...

  • Page 9: Electromagnetic Compatibility (Emc)

    Therefore it could be necessary to take measures to mitigate these effects, such as re-directing or repositioning the device or shielding the room.  The use of accessories and cables other than those recommended by Cardioline may cause an increase in emissions or a lowering in the protection of the system. ...

  • Page 10: Guidance And Manufacturer's Declaration - Electromagnetic Emissions

    200P ELECTROMAGNETIC COMPABILITY (EMC) 3.1. Guidance and Manufacturer's declaration - Electromagnetic emissions The device is intended to operate in the electromagnetic environment specified below. The customer or the user of the device must guarantee that it is used in this environment.

  • Page 11: Guidance And Manufacturer's Declaration - Electromagnetic Immunity

    200P ELECTROMAGNETIC COMPABILITY (EMC) (>95% dip in U (>95% dip in U for 5 s for 5 s Power frequency and Power frequency magnetic fields should be at levels magnetic field frequency of 50 and 3 A/m characteristic of a typical location in a typical...

  • Page 12: Recommended Separation Distances Between Portable And Mobile Rf Communications Equipment And The Device

    200P ELECTROMAGNETIC COMPABILITY (EMC) NOTE 1: At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2: These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people.

  • Page 13: Symbols And Label

    200P SYMBOLS AND LABEL SYMBOLS AND LABEL 4.1. Explanation of the symbols Symbol Description Comply with the instructions in the use manual CE marking – compliance with the European Union directives Manufacturer Reference number (product code) Serial Number Year of manufacture...

  • Page 14: Device Label

    200P SYMBOLS AND LABEL 4.2. Device label...

  • Page 15: Introduction

    200P can be powered with an internal battery or from the power mains. The printer was designed to work with the Cardioline Cubestress and TouchECG applications. It also comes with a printing driver so that it can be used from any Windows application able to operate with Windows- compatible printers.
  • Page 16 200P INTRODUCTION Rear view: On/off Power supply switch...

  • Page 17: Preparation For Use

    200P PREPARATION FOR USE PREPARATION FOR USE 6.1. Installing the printer Before connecting the printer to the PC, install the printing driver. 1. From the Windows Start menu, select “Settings” and then “Devices”; 2. Select “Printers and scanners” and then “Add a printer or a scanner”; the computer will start...
  • Page 18 3. Select “Add local or network printer with manual settings”; 4. Select “Use an existing port” and choose “USB001” from the drop-down menu; 5. Insert the supplied CD or USB drive, select “Driver Disc”, select the “Cardioline” driver and click “Next”;...
  • Page 19 200P PREPARATION FOR USE 6. Accept the suggested printer name and click “Next”; 7. Select “Always trust software …” and click “Install”; 8. Select “Do not share this printer” and click “Next”;...

  • Page 20: Loading The Paper

    200P PREPARATION FOR USE 9. Connect the printer to the computer with a USB cable and turn the printer on. 10. After loading in the paper, press “Print test page” 11. Click “End”. 6.2. Loading the paper Load paper in the device as follows: 1.

  • Page 21: Switching The Device On/Off

    NOTE: after printing it is important that the paper is cut by pulling it to the right instead of to the left. If the paper is pulled towards the left the door may accidentally open, thus causing problems with any subsequent prints. NOTE: For the best performance of the thermal printer, use the thermal paper recommended by Cardioline. 6.3. Switching the device ON/OFF Use the switch at the back of the device to switch the device on and off.

  • Page 22: Battery Operation

    200P PREPARATION FOR USE When the device is not working, it should be plugged in to charge the battery. NOTE: The first time it is used, the battery must still be fully charged, connecting the device to the power supply.

  • Page 23: Maintenance And Troubleshooting

    To switch the device off completely, disconnect the power cable and keep the ON/OFF key pressed. Always perform this operation before proceeding with authorised repairs of the device. 7.3. Regular maintenance Cardioline suggests to regularly check the device:  Perform a functional and operation check daily ...

  • Page 24: Device Cleaning

    200P MAINTENANCE AND TROUBLESHOOTING If you notice anything needing a repair, contact an authorised assistance operator to perform it. 7.3.2. Device cleaning Unplug the device. Clean the external surface of the device with a damp lint-free cloth, using a neutral detergent diluted with water.

  • Page 25: Recommendations

    200P MAINTENANCE AND TROUBLESHOOTING 7.4. Recommendations Ensuing any type of assistance on the device or should you suspect non-conforming operation, we recommend the following procedures:  Check that it works properly.  For use in medical facilities, periodically check the electrical safety of the device ...

  • Page 26: Troubleshooting Table

    Noisy printer Open the door and close it firmly.  Non original paper Paper sliding problems Verify Cardioline paper is in place.  Paper placed incorrectly Take out paper and position it as described in this manual.  Incorrect installation/invalid Device not printing Go to printer properties, display the “Port”...
  • Page 27 Verify paper is in place. If the exam is not automatically printed at the end of the acquisition, try to print it manually. If manual print does not work contact Cardioline customer service. Verify auto-print settings.  Software problem Block of the device Press the On/Off button for at least 10 seconds to restart the device.

  • Page 28: Technical Specifications

    200P TECHNICAL SPECIFICATION TECHNICAL SPECIFICATIONS Thermal printer ......... 8 dot/mm - 216mm; A4/Letter z-fold Automatic print speed ....... 5, 10, 25, 50 mm/s Power supply ........Medical grade AC power supply (100-240 1.5-0.75 A VAC 50/60 Hz); internal rechargeable battery (NiMH) Internal battery .........

  • Page 29: Warranty

    Cardioline Spa declines all liability for any damage which may be caused, directly or indirectly, to persons or property as a consequence of non-compliance with all the prescriptions specified in the manual, especially warnings regarding installation, safety, use and maintenance of the equipment, as well as non-operation of the equipment.

  • Page 30: Disposal

    200P DISPOSAL DISPOSAL Pursuant to Italian Legislative Decree no. 49 dated 14 March 2014 "Implementation of Directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE)", the crossed-out "wheeled bin" symbol on the medical device indicates that, at the end of its service life, the product must be collected separately from other wastes.
  • Page 31 200P...
  • Page 32 Sales Office Via F.lli Bronzetti, 8 20129 Milan, Italy T. +39 02 94750470 F. +39 02 94750471 Factory Via Linz, 151 38121 Trento Italy T. +39 0463 850125 F. +39 0463 850088...
