Page 1
HITCH LOCK (1X) SAFETY CLIP (1X) IMPORTANT WARNING T IS CRITICAL THAT ALL YAKIMA RACKS AND ACCESSORIES BE PROPERLY AND SECURELY ATTACHED TO YOUR VEHICLE MPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO OTHERS...
Page 2
INSTALL TONGUE TO MAST Put pivot plate in place. Insert mast through Insert bushing tongue. through tongue around shaft from mast. INSTALL BOLT, AND WASHER. • IMPORTANT: Pivot plate must fit over step on axle. • Install bolt, passing through large washer.
Page 3
INSTALL HITCH BOLT, LOCK-WASHER, AND WASHER. INSERT TONGUE INTO VEHICLE'S HITCH. Install bolt, IF SPARE TIRE CAUSES lock washer, INTERFERENCE, DO NOT and washer USE THIS PRODUCT! from right side of receiver. TIGHTEN with adjustable wrench. INSTALL PIVOT COVER. • Pull knob. •...
Page 4
Attach one rubber strap to each CRADLE POSITIONING cradle and stabilizer. To slide cradles along the carrier arms, close cradle and stabilizer. stabilizer Close cradles while loading bikes. LOAD LARGEST OR HEAVIEST BIKE FIRST. Stabilize the bike • Always load first frame in bike with chain the cradle...
LOCK BIKES TO CARRIER. • Pass cable through bike frame. • Attach lock to pin. • Lock the lock. • Access lock cable from recess at rear of mast. TO FOLD MAST DOWN AND ACCESS LOWERING THE ARMS THE REAR: •...
Page 6
7:00 AM to 5:00 PM PST. This product is covered by YAKIMA’s “Love It Till You Leave It” Limited Lifetime Warranty To obtain a copy of this warranty, go online to www.yakima.com or email us at yakwarranty@yakima.com or call (888) 925-4621...
