使用説明書 OperatingInstructions 加濕空氣清新機 HumidifyingAirPurifier 型號 F-VXL40H Model No. 本產品爲室內專用 Thisproductisforindooruseonly. 中文………………………… 3 English ································23 感謝閣下選購 Panasonic 產品。 使用產品前請仔細閱讀本使用說明書,並請妥善保管。 ● ThankyouverymuchforpurchasingthisPanasonicproduct. ● Before operating this product, please read the instructions carefully, and save this manual for future use.
Page 2
如果電源線已損壞,必須找製造商、服務代理商或有資格人士更換,以免發生危險。 ● 此產品不適合身體、感官或精神功能遲緩,或缺乏經驗與知識的人(包括兒童)使用,除非他們在負責其安全的人的 ● 監督或指引下使用。 請看管好兒童,確保他們不會以本產品玩耍。 ● 維護保養前或加水時,請務必拔下電源插頭。 ● ● If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. ● This product is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experiences and knowledge, unless they have been given supervision or instruction concerning use of the product by a person responsible for the safety.
Page 23
OperatingInstructions HumidifyingAirPurifier F-VXL40H Model No. Contents Page Parts identification ··························25 Operating conditions·······················25 Safety precautions ··························26 Preparation ·····································28 Operating methods ·························30 ·Clothes Refresh / Child Lock ··············· 32 Care and maintenance ···················33 ·Reference time for the 2 in 1 HEPA composite and deodorizing filter replacement ·········································...
Page 24
“ Housedustcatcher”sucksthedirtnearthefloorpowerfully. E quippedwithnanoe™technology “ Econavi”operationmakeselectricutilityexpensecheaper. Evaluated by the test method of Panasonic own. Test Method : Operate at “Clean air” mode for 24 hours in the test chamber of 23 m . 5 cigarettes have been smoked.
Partsidentification Front Back Air outlet (nanoe™ emission outlet) Control panel Humidity sensor Filter frame Handle (Right and left) Front panel Air inlet Anti-fungus (Both sides) assembly (Inside) Power cord Humidifying filter Air inlet (Front) Tray Power plug Dirt sensor Tray handle Water-level Floater (Inside) window...
Safetyprecautions Alwaysobservetheseprecautions These safety precautions are provided for your protection. Please read and follow them carefully to avoid personal injury or damage to the product itself or other properties. T hefollowingsymbolsdifferentiatethelevelsofdangerandinjurythatmayresultiftheproductisnot usedcorrectlyasinstructed. This symbol indicates that This symbol indicates that improper handling may cause a WARNING CAUTION...
Page 27
CAUTION D onotputtheproductinthe D onotusecrackedordamaged followingplaces: tray. ● An unstable or high place. (This may cause spillage and wet the furniture.) (Otherwise it may drop down or fall over, then D onotputchemicals,airfresheners, cause injury, wet the furniture, leakage, electric shock or fire.) oressentialoilintothetray.
Preparation Beforestartup Installthe2in1HEPAcompositeanddeodorizingfilter Writedownthe Takeoutthe2in1 Installthe2in1 installationdate HEPAcompositeand HEPAcompositeand onthelabel. deodorizingfilter deodorizingfilter fromthepolybag. andthefrontpanel. Remove the front panel. Install the 2 in 1 HEPA composite and deodorizing filter. Pull it forward (Install in the correct direction.) with both hands. 2 in 1 HEPA composite and deodorizing filter With the front side towards yourself (setting the side with...
Page 29
Fillthetraywithwater Turnon Removethetray,fillitwithwater, Connectthepower andinstallitback. plug. (Water is not required when the product operates in “Clean air” mode.) Wipe the water off the ● power plug and your Be sure to disconnect the power plug before water supply the product. hands before inserting it.
Operatingmethods Controlpanel Humidifying indicator “nanoe™” indicator Humidity indicator Check indicator ECONAVI indicator PM2.5 indicator Light sensor Air Volume button Clothes Refresh button / / indicator indicator(P.32) Power Off / On button Child Lock button / Clean indicator indicator(P.32) E CONAVIindicator C leanindicator ●...
Page 31
Howtooperate Startoperation ● Fill the tray with water when you want to operate in the "Humidifying clean air" mode. Water is not required when the product is operated in the mode of “Clean air”. Selecttheair volume Twoshort beeps To adjust air volume automatically corresponding Auto to the level of air pollution Each press of the button...
Operatingmethods ClothesRefresh/ (continued) ChildLock ClothesRefresh Torefreshunpleasantodorofclothes ● After 1 hour operation, the product will switch to the previous operation mode. (The indicator is lit.) T ocancel Press the button again. (The indicator is turned off.) Note ● When you press the [Air Volume] button during “Clothes Refresh” operation, “Clothes Refresh”...
Careandmaintenance 2in1HEPAcompositeanddeodorizing filter/Body/Frontpanel/Dirtsensor ● Beforecleaning Do not use the detergent other than the neutral one for kitchen purpose. (Deterioration, deformation or breakage Be sure to disconnect of plastic parts may occur.) the power plug. ● When using chemically treated cloth, follow its instructions. 2in1HEPAcompositeanddeodorizingfilter Body,Frontpanel <aboutonceevery2weeks>...
Page 34
Careandmaintenance Tray (continued) ● Beforecleaning Do not use the detergent other than the neutral one for kitchen purpose. (Deterioration, deformation or breakage Be sure to disconnect of plastic parts may occur.) the power plug. ● You can use the oxygen-based bleaching agent only when cleaning the humidifying filter.
Humidifyingfilter/Filterframe Humidifyingfilter,Filterframe <aboutonceamonth٭ > (based on operation of 8 hours every day) Humidifying filter Filter frame Pressandwashinwaterorwarm Washwithwater. water(belowabout40°C). ● ● Do not scrub with brush or do not wash with Do not scrub the anti-fungus assembly with brush, or do washing machine.
●Target: adhered cigarette odor ●Test outcome: odor intensity drops 1.2 grades within 2 hours. [BAA33-130125-D01] nanoe™ and the nanoe™ mark are trademarks of Panasonic Corporation. Functionsoftheanti-fungusassembly It inhibits the enzyme with the anti-fungus agent and keeps water in the tray clean.
Page 37
Econavioperation It is the automatic operation by combining the “patrol mode” in which the product checks the dirt in the air in the room every hour, with the “learning mode” in which the product can forecast the dirt generation by mastering the generation time of dirt every day.
FAQs Please confirm the following before you contact us for repair. Theairiscoldduringhumidifying? Abuzzisheardfromtheairoutlet? ● ● During "Humidifying clean air" operation, The noise comes from nanoe™ generation the air coming from the product will be is normal. colder than the room temperature, since ●...
Page 39
Toturnoffthebeepsound announcingwaterrefilling ● You can turn off the second and subsequent beep sounds. (You cannot turn off the first beep sound.) Stop operation, then press and hold simultaneously. ([Child Lock] and [Clothes Refresh] indicators are lit in turn.) Release the buttons when the setting reaches [No].
Troubleshooting If a problem has occurred, investigate it by referring first to the table below. If the problem still persists, please disconnect the power plug and contact an authorized service center (as described in the warranty) for a check or repair. Symptom Pleasecheckthefollowing: ●...
Page 41
Symptom Pleaseconfirmthefollowing: ● Is the humidifying filter or the filter frame installed properly? (P.35) I tisdifficulttoinstallthetrayto → If they are installed incorrectly, it may be difficult to install / remove thebody. the tray to/from the body. T hehumidifyingindicatorblinks. ●...
Specifications Power supply 220 V~ 50 Hz Clean air Humidifying clean air Operation mode Power consumption (W)٭ Operating noise (dB) Humidifying amount (mL/h)٭ ―٭ ―٭ Air volume (m /min) Capacity of the tray approx. 1.6 L Power code length 2.0 m Product dimension Width 330 mm ×...
