- Page 1 Wireless Full Duplex Intercom System Beltpack HDI-PT190 User’s Manual Please read the manual carefully before operation...
-
Page 2: Table Of Contents
Table of Contents Check the Contents of the Package ....................3 Introduction of Components ......................3 Indicator Status ............................3 Preparation ............................. 4 Basic Operations ............................ 5 (1)Power On or Off ........................5 (2)Volume Adjustment ........................ 5 (3)Setting ............................5 (4)Calling Process ......................... -
Page 3: Check The Contents Of The Package
Check the contents of the package The box contains the following items. If there is any damage or loss, please contact the your dealer. Item Quantity beltpack Antenna USB charger Mini USB Charging Cable Instruction manual Introduction of Components Part name Part name Part name Headset interface... -
Page 4: Preparation
Preparation (1)Charge the Battery a. Plug the power adapter's plug into a power outlet. b. Insert the USB cable into the Mini USB interface at bottom of the beltpack. c. When the red indicator lights up, it indicates that charging is started; when the green indicator lights up, it indicates that charging is complete. -
Page 5: Basic Operations
(3)Install headset Align the headphone connector at the interface and and plug in. Press the connector button before pulling it out. Basic Operations (1)Power on or off Screw the Power / Volume knob clockwise until you hear a “click” to turn on the device. Screw counterclockwise to turn off. - Page 6 You have to choose different mode for each type of headset, namely HEADPHONE or EARPHONE. It is HEADPHONE for factory setting. You could change the setting. Press the setting button to enter the headset type setting under the help of the headset prompt.
- Page 7 ⑤Reset Setting Press the setting button to enter reset under the help of the headset prompt. Then press the PTT button to restore factory settings. ⑥Exit Setting Press PTT button to exit setting. ⑦Other Advanced Settings Advanced settings require a dedicated configuration data cable, you can change the encryption password, use more channels, and adapt your own modified headset, etc.
-
Page 8: Calling Process
(4)Calling Process Press [PTT] on the headset to initiate a call to the beltpack / BS180 base station in the current channel, and release the button to end the talk. The BS180 base station can initiate a call at any time, regardless of the beltpack, and the BS180 base station only allows one beltpack to initiate a call while speaking. -
Page 9: Headphones
Headphones Bilateral Headphone Unilateral Headphone HP-MC220 HP-MC210 Dedicated to suppress background Dedicated to suppress background noise. noise. Maintenance and Cleaning In order to ensure that the device can perform its good performance and extend its service life, please familiarize yourself with the following to better carry out daily maintenance and cleaning. -
Page 10: Cleaning
Cleaning Please clean the bag regularly and use a clean, dry towel or brush to wipe off the dust on the surface of the purse。 If the body of the purse is dirty, use neutral detergent and non-woven fabric to ... -
Page 11: Warranty Card
Warranty card In order to safeguard your rights and interests, please fill in carefully and keep it properly as a voucher for maintenance. Dealer’s information Product model Date of sale Dealer’s name Contact number User’s information User’s name Contact number Address E-mail... - Page 12 NAYA WeChat subscription number Shanghai Naya Intelligence Technology Co., Ltd. http://www.nayatec.com...
