Wooden Filer
Assembly Instructions
Dimensions
Width - 39cm
Depth - 39.5cm
Height - 80cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 0345 6400800
Please keep for future reference
-
-
227/6966
Version 1 Date: 28/04/14
Advertisement
Related Manuals for Argos Wooden Filer
Summary of Contents for Argos Wooden Filer
- Page 1 Width - 39cm Depth - 39.5cm Height - 80cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800 Version 1 Date: 28/04/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce the likelihood of components and tools listed on or put weight on the product, the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Argos = 0345 6400800 Please check you have all the panels listed below Pilot holes for guidance only Right side panel Left side panel Back panel (38.9 x 78.3cm)
- Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. (This Screw is included in the bag of runner) Runner x 8 12mm Screw x 24...
- Page 5 Assembly Instructions Step 1 Attaching runners Middle hole Position Runners front edge of the Right side panel Slide top of the Runners back. 1.7cm Use screws to fix the Runners on the Right side panel Pilot holes for runner position Finished front edge Slide top of Runners forward and fix as...
- Page 6 Assembly Instructions Step continued Position Runners front edge of the Left side Middle hole panel Slide top of the Runners back. Use screws to fix the 1.7cm Runners on the Left side panel Finished front edge Pilot holes for runner position Slide top of Runners forward and fix as Middle hole...
- Page 7 Assembly Instructions Step 2 Attaching plastic supports Use Screws to fix Plastic supports onto the Front bottom panel Use Screws to fix Front bottom panel onto the Front panel Place a small amount of Glue into the dowel holes. Insert Dowels into the Front bottom panel Step 3...
- Page 8 Assembly Instructions Step 3 - continued Position Middle panel and Back bottom panel onto the Left side panel Insert Locking nuts into the Middle panel and Back bottom panel Unfinished back edge Use a screwdriver to turn Locking nuts clockwise to lock. Position Right side panel onto the unit.
- Page 9 Assembly Instructions Step 4 Attaching top panel Screw Locking pins into the Top panel Insert Locking pins Note: as far as shown. Do not over tighten. Carefully locate the Top panel onto the unit. Insert 4 Locking nuts into the unit. Use a screwdriver to turn Locking nuts clockwise...
- Page 10 Assembly Instructions Step 5 Fixing back panel Unfinished back surface Attach Back panel onto the unit using Nails Important: The unit MUST be ‘square’ when back is attached. Step 6 Small drawer assembly Screw Locking pins into the Small drawer front Insert Locking pins Note: as far as shown.
- Page 11 Assembly Instructions Step 6 - continued Fix Small drawer left side onto the Small drawer front Fix Small drawer right side onto the Small drawer front Insert 2 Locking nuts into the holes (they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock.
- Page 12 Assembly Instructions Step 6 - continued Position the Small drawer back onto the unit using Screws Use Screws to fix the Drawer handle onto the Small drawer front Step 7 Large drawer assembly Screw Locking pins into the Large drawer front Insert Locking pins Note:...
- Page 13 Assembly Instructions Step 7 - continued Fix Large drawer right side onto the Large drawer front Insert 2 Locking nuts into the holes (they will only insert one way). Use a screwdriver to turn Locking nuts clockwise to lock. Insert 2 Locking nuts into the holes (they will only insert one way).
- Page 14 Assembly Instructions Step 7 - continued Use Screws to fix the Handle onto the Large Left Right drawer front Position Plastic filer supports onto the Drawer side panels. Step 8 Inserting drawers With help, carefully stand unit upright. Warning: The unit is heavy. Lift with care.
- Page 15 Warning: Before drilling, check wall for hidden pipes and cables. Reposition the unit and fix wall strap using Screw Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: Argos = 0345 6400800...
- Page 16 A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
