- Page 1 O W N E R S M A N U A L Balón Series Borderless, or Minimally Bordered Flexible Screen System Producers of Professional Projection Screens...
- Page 2 Printed in U.S.A. ©2019 Stewart Filmscreen Corporation Stewart Filmscreen reserves the right to make changes to the product specified in this document. Sizes and specifications subject to change without notice at Manufacturer’s discretion. From time to time, this document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at:...
-
Page 3: Table Of Contents
Balón Series O W N E R S M A N U A L Contents To the Owner Preparing the Installation Frame Assembly Instructions EZ Mount Bracket System Attaching the Screen to the Frame Attaching The Screen to The Frame (Edge UST) Caring for and Cleaning the Screen Product Warranty Maintenance Notes... -
Page 4: To The Owner
Congratulations on your purchase of one of the finest optical viewing screens available anywhere in the world! Please take a moment to review this manual, it will help ensure you many years of trouble-free service from your new Stewart Filmscreen product ABOUT THE BALÓN SERIES Your Balón Series fixed frame supports virtually all projection applications The Quick Snap feature... -
Page 5: Frame Assembly Instructions
PREPERATION (CONTINUED) You will need: Lint-free, clean cloth gloves for handling the screen Ladders for the personnel supporting the screen during the mounting process A level Fasteners appropriate for the surface on which the screen is being mounted A drill Tools for tightening fasteners Note: Bolts and other fasteners for the screen are standard gauge and sizes used in the U S A regardless of where they will be installed For this reason, the sizes are expressed in inches rather than metric... - Page 6 Figure 1: Frame Assembly Rear View DETAIL C Aud. Right Top Corner DETAIL B Aud. Left Top Corner DETAIL D DETAIL A Aud. Right Bottom Corner Aud. Left Bottom Corner Stewart Filmscreen...
-
Page 7: Ez Mount Bracket System
EZ MOUNT BRACKET SYSTEM Professional mounting techniques should be used Stewart Filmscreen cannot be liable for substandard or faulty installations i CAUTION Be careful not to touch or scratch the viewing surface To accurately position the Balón Series frame, you will mount the EZ Mount hanging bar and temporarily... - Page 8 (I.E. WOOD / SELF-DRILLING SCREW ALUMINUM STUD (INCLUDED) EZ Mount Bracket Figure 3: Wall Mounting - Side/Top View Figure 4: Wall Mounting - Side/Bottom View Support Structure #12x2” Self-Drilling Support Structure (ie: Wood/Aluminum Stud) Screw (included) (ie: Wood/Aluminum Stud) Stewart Filmscreen...
-
Page 9: Attaching The Screen To The Frame
ATTACHING THE SCREEN TO THE FRAME DO NOT perform this step UNTIL instructed to do so in the mounting section i CAUTION Be careful not to touch or scratch the viewing surface Do not use any tools to fasten the screen to the frame Do not fold or crease the screen Wear lint-free gloves UNPACKING AND UNROLLING THE SCREEN... - Page 10 5 Connect the springs from the border trim to the holes in the frame To find the holes look for the colored dots See step 5 Stewart Filmscreen...
-
Page 11: Attaching The Screen To The Frame Edge Ust
ATTACHING THE SCREEN TO THE FRAME EDGE UST i CAUTION This screen Material is not like any other Stewart offers Read all direction before attempting to install A minimum of two people ( four are recommended) are required to install the Balón Edge UST White gloves a needed to protect the screen surface Not handling properly will cause permanent damage to the screen Do not fold or crease the screen... - Page 12 Note that the screen is labelled “Top” & “Bottom”, these MUST match the “Top” & “Bottom” labels on the frame for proper viewing Fig. 5 Roll screen out face down Stewart Filmscreen...
- Page 13 ATTACHING THE SCREEN TO THE FRAME EDGE UST (CONT) Lay the frame on the screen with the lacing cord facing up a Once again, ensure the “Top” & “Bottom” labels on the screen align with the “Top” & “Bottom” labels on the frame b Align all four corners of the screen with the corners of the frame See Fig 6 Fig.
- Page 14 Finally, secure the fascia caps in place by connecting the fastening springs to the frame Note: The fastening points on the frame are marked by red dots The screen is now fully assembled and ready to be mounted to the wall Follow the mounting procedures for Balón Edge with EZ mount Stewart Filmscreen...
- Page 15 ATTACHING THE SCREEN TO THE FRAME EDGE UST (CONT) i For best results maintaining screen alignment on frame, have four people work simultaneously, one on each edge of the screen Two people working on opposite edges is recommended at minimum e Repeat this process until the first three hooks on either side of each red hook have been laced Fig.
-
Page 16: Caring For And Cleaning The Screen
A draftsman-style brush may be used to lightly whisk away any loose dirt or dust particles (This type of brush is usually available at office supply stores ) Stewart Filmscreen has an optional screen cleaning kit that contains the proper type of brush Contact your dealer if you would like to obtain this cleaning kit... - Page 17 Corporation shall not be liable for any and all consequential damage(s) occasioned by the breach of any written or implied warranty pertaining to the sale of a Stewart Filmscreen product in excess of the purchase price of the product sold...
-
Page 18: Maintenance Notes
MAINTENANCE NOTES Stewart Filmscreen... - Page 19 1161 W. Sepulveda Blvd., Torrance CA 90502 USA 800.762.4999 Tel: 310.784.5300 Fax: 310.326.6870 Email: request@stewartfilmscreen.com ©2019 Stewart Filmscreen. Specifications are subject to change without notice.
