INSTALLATION AND OPERATION MANUAL
MBP63A2
SAVE THESE INSTRUCTIONS
Please read this manual and follow the instructions for installation and operation.
©2020 Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners.
©2020 Cyber Power Systems (USA), Inc.. All rights reserved.
I
K01-0000808-00
Advertisement
Table of Contents
Related Manuals for CyberPower MBP63A2
Summary of Contents for CyberPower MBP63A2
- Page 1 SMART APP ONLINE UPS SYSTEM INSTALLATION AND OPERATION MANUAL MBP63A2 SAVE THESE INSTRUCTIONS Please read this manual and follow the instructions for installation and operation. ©2020 Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners.
-
Page 2: Safety Instructions
Read this manual thoroughly before attempting to unpack, install, or operate the Maintenance Bypass PDU (MBP). The SmartApp Online MBP63A2 models that are covered in this manual are intended for installation in an environment within 32°F to 104°F (0°C to 40°C), free of conductive contaminants. - Page 3 SAFETY INSTRUCTIONS CONT. PERSONAL SAFETY CAUTION CAUTION - To reduce the risk of fire, connect only to a circuit provided with 40 amperes (5,000 VA) /50 amperes (6,000 VA)/60 amperes (8,000 VA)/75 amperes (10,000 VA) maximum branch circuit overcurrent protection in accordance with the National Electric Code, ANSI/NFPA 70 and the Canadian Electrical Code, Part I, C22.1.
-
Page 4: Product Safety
SAFETY INSTRUCTIONS CONT. PRODUCT SAFETY RISK OF ELECTRIC SHOCK Maintenance Bypass PDU (MBP) covered in this document are permanently- connected equipment and only qualified maintenance personnel may carry out installations. Wiring must be done by qualified personnel. DO NOT USE FOR MEDICAL OR LIFE SUPPORT EQUIPMENT! Under no circumstances should this unit be used for medical applications involving life support equipment and/ or patient care. -
Page 5: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS ..........................II Special Symbols ..................................II Personal Safety ..................................III Product Safety ..................................IV INTRODUCTION ............................... 1 Maintenance Bypass PDU (MBP) ............................1 Whats In The Box ..................................3 HARDWARE INSTALLATION ........................4 Front Panel Description ............................... 4 Brackets Installation ................................ -
Page 6: Introduction
INTRODUCTION The CyberPower Maintenance Bypass PDU (MBP) allows the seamless transfer of an electrical load from UPS power to utility power for uninterrupted operation of connected equipment when performing maintenance, replacing batteries, or installing a new UPS. The key features include: •... -
Page 7: Operations With Mbp Detection Cable Installed
4. Press the “ ▲ ” and “ ▼ ” buttons to scroll through the “Information” submenu to check the MCU version*. [NOTE] If the MCU version* is UE_V3Rn and the number of n is less than 6,(For Example: MCU Ver. = UE_V3R5) Please contact CyberPower for assistance to upgrade the MCU version*. [NOTE]*MCU version is the UPS Firmware version. -
Page 8: Whats In The Box
User’s manual MBP detection cable 3.3ft Registration card L6-30P power cord 3.3ft with cable gland for MBP63A2 to 6K UPS output Rackmount brackets connection and L6-30R power cord 3.3ft with cable gland for MBP63A2 to Flat head screws: M4X6L (4) -
Page 9: Hardware Installation
HARDWARE INSTALLATION MBP FRONT PANEL DESCRIPTION 1. UPS INPUT SWITCH 2. Input/Output terminal blocks connect to UPS 3. “Bypass” Red light LED indicator (Bypass source ready) 4. “Normal” Green light LED indicator ( UPS source ready OK to switch ) 5. -
Page 10: Brackets Installation
HARDWARE INSTALLATION CONT. The MBP can be mounted in a rackmount or vertical tower orientation. Please follow the instructions below for the respective mounting methods. 1. Brackets installation Attach the two brackets to the MBP using the provided screws M4X6L*4pcs. MBP mounted horizontally in a rackmount MBP mounted vertically in a rackmount ©2020 Cyber Power Systems (USA), Inc. -
Page 11: Mbp Installation
HARDWARE INSTALLATION CONT. 2. MBP Installation Secure the MBP to rack, CyberPower rack-mounted UPS or a wall with the provided screws M5X8L*2pcs. MBP mounted horizontally with a CyberPower UPS MBP mounted with a CyberPower UPS in tower mode Wall-mounted Caution: Important Instructions To prevent the risk of fire or electric shock, only use the supplied hardware to attach the mounting brackets. -
Page 12: Electrical Installation
ELECTRICAL INSTALLATION HARDWIRING THE INPUT/OUTPUT TERMINALS Important! Set the UPS INPUT switch of the MBP to the “O” off position before hardwire connecting. UPS INPUT SWITCH Bypass Normal TO UPS MBP UPS OK DETECTION to switch 63A / 250V~ FROM UPS OUTPUT TO UPS NORMAL AC SOURCE OUTPUT NORMAL AC SOURCE... -
Page 13: Operations To Retain Epo & Roo Function
ELECTRICAL INSTALLATION CONT. CONNECT MBP TO 8K/10K UPS INPUT/OUTPUT CONNECT INTERNAL WIRES THROUGH CONDUITS FOR MBP63A2 TO UPS 1. Separate the top and bottom covers by Loosening the two screws to separate the top and bottom covers. Fix the terminal block bottom cover and tighten the two screws to fix the terminal block bottom cover on the MBP. - Page 14 CONNECTION AND CONNECT L6-30R POWER CORD FOR MBP63A2 TO 6K UPS INPUT CONNECTION [NOTE] MBP63A2 to 5K/6K UPS input and output connection should using L6-30R/L6-30P power cord which is an accessory in box. 1. Separate the top and bottom covers by loosening the two screws to separate the top and bottom covers.
- Page 15 ELECTRICAL INSTALLATION CONT. CONNECTING THE MAINTENANCE BYPASS PDU TO A UPS Connect the input/output as shown in the following diagrams for different models OL5KRTHD/OL6KRTHD TO NORMAL OUTPUT TO EQUIPMENT (Load) AC SOURCE (Utility) OL6KRT OUTPUT TO TO NORMAL EQUIPMENT (Load) AC SOURCE (Utility) OL8KRT/OL10KRT OUTPUT TO...
- Page 16 ELECTRICAL INSTALLATION CONT. CONNECTING MBP TO A UPS WITH A STEP-DOWN TRANSFORMER OL5KRTHD/OL6KRTHD WITH A STEP-DOWN TRANSFORMER TO NORMAL AC SOURCE (Utility) OUTPUT TO OUTPUT TO EQUIPMENT (Load) EQUIPMENT (Load) OL6KRT/OL6KRTF WITH A STEP-DOWN TRANSFORMER TO NORMAL AC SOURCE (Utility) OUTPUT TO OUTPUT TO EQUIPMENT (Load)
- Page 17 [NOTE]If the MCU version* is UE_V3Rn and the number of n is less than 6,(For Example: MCU Ver. = UE_V3R5) Please contact CyberPower for assistance to upgrade the MCU version*. ©2020 Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners.
- Page 18 Before turn off UPS, MBP need to set to bypass and keep provide power from utility. 1. Check that the UPS is correctly connected to the MBP63A2 (see previous chapter HARDWIRING T H E I N P U T/O U T P U T T E R M I N A L co n n e c t i n g t h e i n p u t /o u t p u t a n d M B P d e te c t i o n ) If the UPS is equipped with outlets, those outlets can no longer be used (loads can only be connected to the MBP outlets or the MBP Output terminal blocks).
- Page 19 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63A2 AND MBP DETECTION CABLE CONT. 8. Important ! The signal input setting of UPS should set to “Manual Bypass” for MBP detection (refer to the UPS user manual as following) (1) OL5KRTHD/OL6KRTHD models :...
- Page 20 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63A2 AND MBP DETECTION CABLE For UPS removal, follow the MANDATORY steps below: 1. Release two screws by screw driver and open the Cover of MBP switch, UPS will be automatically turning to “Bypass mode”.
- Page 21 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63A2 AND MBP DETECTION CABLE CONT. 6. Set the UPS INPUT switch of the MBP to the “O” off position and wait 90 seconds to make sure UPS is totally shut down. 7. UPS stops, the UPS can now be disconnected, as described below: (1) First opening the I/O terminal blocks cover of UPS, check if hazardous voltage is no longer present on UPS terminal blocks by using an electrical safety tester.
- Page 22 ELECTRICAL INSTALLATION CONT. RETURN TO NORMAL OPERATION CONT. : (1)OL5KRTHD/OL6KRTHD models : Set up communication Signal input Manual Bypass Save Change? (2)OL6KRT/OL8KRT/OL10KRT/OL6KRTF/OL8KRTF/OL10KRTF models : Configure Signal input Manual Bypass Save ? [NOTE] If not follow the step to set the UPS Signal input to Manual bypass function enable and correctly connected MBP detection cable, it will be caused UPS damage.
- Page 23 UPS is doing maintenance, if load connect to UPS outlet, the load will be lost. Before turn off UPS, MBP need to set to bypass and keep provide power from utility. 1. Check that the UPS is correctly connected to the MBP63A2 (see previous chapter HARDWIRING THE INPUT/OUTPUT TERMINAL connecting the input and output but no need to connect MBP detection).
- Page 24 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63A2 CONT. 3. Release two screws by screw driver and open the Cover of MBP switch and Check that the MBP manual Bypass switch is to the “Bypass” position. 4. Set the upstream circuit breaker (not provided) to the “I” on position to switch On the Normal AC source (Utility) power.
- Page 25 ELECTRICAL INSTALLATION CONT. UPS START-UP WITH MBP63A2 CONT. 11. Verify that the UPS is on Bypass mode by checking UPS display panel (refer to the UPS user manual). 12. Verify that the “Normal” green light of the MBP goes On, indicating that the UPS output power is available on the MBP.
- Page 26 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63A2 For UPS removal, followed the MANDATORY steps below: 1. Firstly UPS should set to bypass mode from LCD Panel (refer to the UPS user manual as following) (1) OL5KRTHD/OL6KRTHD models : Controls Manual Bypass...
- Page 27 ELECTRICAL INSTALLATION CONT. UPS REPLACEMENT WITH MBP63A2 CONT. 7. Set the UPS INPUT switch of the MBP to the “O” off position and wait 90 seconds to make sure UPS is totally shut down. 8. UPS stops, the UPS can now be disconnected, as described below: (1) First opening the I/O terminal blocks cover of UPS, check if hazardous voltage is no longer present on UPS terminal blocks by using an electrical safety tester.
- Page 28 ELECTRICAL INSTALLATION CONT. RETURN TO NORMAL OPERATION CONT. : 5. Press the UPS “ON/OFF” power button for 3 seconds to start the UPS, UPS will be turning to line mode. 6. UPS should set to bypass mode from LCD Panel (refer to the UPS user manual as following) (1) OL5KRTHD/OL6KRTHD models : Controls Manual Bypass...
-
Page 29: Technical Specifications
32°F to 104°F / 0°C to 40°C Operating Relative Humidity 0% – 90% non-condensing Compatibility list for CyberPower UPS OL5KRTHD, OL6KRTHD, OL6KRT, OL8KRT, OL10KRT, OL6KRTF,OL8KRTF,OL10KRTF ©2020 Cyber Power Systems (USA), Inc. All rights reserved. All other trademarks are the property of their respective owners. -
Page 30: Product Registration
PRODUCT REGISTRATION CyberPower requests that you complete and return the Warranty Registration Card enclosed with the Product or register the Product at its website (www.cyberpowersystems.com/registration) to establish that you are the Initial Customer of the Product, and therefore entitled coverage under the Limited Warranty (Registration is not required for coverage, but note: if you do not register your purchase, you will be required to provide proof of purchase.) - Page 31 If your product requires warranty service you must provide a copy of your dated purchase receipt or invoice. If the Product is defective in material or workmanship, CyberPower will repair or replace it at CyberPower's expense, or, if CyberPower is unable to or decides not to repair or replace the...
- Page 32 Minnesota, United States of America. However, before bringing a claim for a breach of a warranty, a claimant shall pursue a Warranty with CyberPower as set forth in this Warranty; however to the extent the claimant's claim is not for a breach of warranty this informal mechanism shall not be required.
- Page 33 CyberPower limits the duration and remedies of such warranties to one year or the duration of this Limited Warranty if so required, and, at CyberPower’s option, the repair or replacement services described herein. Some States or Provinces do not allow limitations on how long an implied warranty (or condition) may last, so the limitation described above may not apply to you.
- Page 34 Product. All warranties are null and void if, in CyberPower's sole discretion: the Product in use during the Occurrence is not provided to CyberPower or its representative for inspection upon CyberPower's or its representative's request at the sole expense of the Initial Customer;...
- Page 35 (collectively, “High Risk Activities”). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities or with aquariums. CyberPower does not authorize use of any Product in any High Risk Activities or with Aquariums. ANY SUCH USE IS IMPROPER AND IS A MISUSE OF THE PRODUCT.
- Page 36 The application of the United Nations Convention of Contracts for the International Sale of Goods is expressly excluded. CyberPower is the warrantor under this Limited Warranty. For further information please feel free to contact CyberPower at Cyber Power Systems (USA), Inc. | 4241 12th Ave E., STE 400, Shakopee, MN 55379 (877) 297-6937 | https://www.cyberpowersystems.com/support/#support-request-start...
- Page 37 Cyber Power Systems (USA), Inc. | www.CyberPowerSystems.com For USA and Canada | 4241 12th Ave East, Suite 400, Shakopee, MN 55379 | Toll-free: 877.297.6937 For all other regions | Please visit our website for local contact information. Copyright © 2020 Cyber Power Systems (USA), Inc. All rights reserve. ©2020 Cyber Power Systems (USA), Inc.
