Sauder Orchard Hills 418650 Manual

Computer desk with hutch
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Computer Desk with Hutch
Orchard Hills Collection | 418650
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
The original desktop.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-32
Français pg 33-36
Español pg 37-40
Lot # 370256
04/21/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading
Need help?

Need help?

Do you have a question about the Orchard Hills 418650 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Orchard Hills 418650

Summary of Contents for Sauder Orchard Hills 418650

  • Page 1 Orchard Hills Collection | 418650 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 RIGHT DRAWER SIDE (2) HUTCH UPRIGHT (1) KEYBOARD SHELF (1) LEFT DRAWER SIDE (2) DESK TOP (1) DRAWER FRONT (2) D708 DRAWER BOTTOM (2) HUTCH TOP (1) LONG DIVIDER (2) MODESTY PANEL (1) SHORT DIVIDER (2) Page 2 418650 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D708 D708 www.sauder.com/services 418650 Page 3...
  • Page 4 115K 116K KNOB - 1 120K BACKPLATE - 1 FELT DISC CARD - 1 PULL - 2 PULL MOUNT - 4 NAIL - 72 CORD CLIP - 1 CAM COVER - 6 METAL PIN - 19 Page 4 418650 www.sauder.com/services...
  • Page 5 BROWN 1-1/2" FLAT HEAD SCREW - 4 18S BROWN 1" FLAT HEAD SCREW - 4 BLACK 1-1/8" MACHINE SCREW - 1 30S BLACK 1-9/16" FLAT HEAD SCREW - 8 SILVER 5/8" FLAT HEAD SCREW - 4 www.sauder.com/services 418650 Page 5...
  • Page 6 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty carton å to avoid scratching your unit or the fl oor. Push twenty-one HIDDEN CAMS (1F) into the RIGHT å...
  • Page 7 Righty tighty. NOTE: You should start each SCREW a few turns before å Lefty loosey. completely tightening any of them. Do not overtighten. SILVER 1-1/8" FLAT HEAD SCREW (10 used in this step) Curved edge Curved edge www.sauder.com/services 418650 Page 7...
  • Page 8 CABINET LEFTS (45BB) to the UPRIGHT (E). Use eight GOLD 5/16" FLAT HEAD SCREWS (3S) through holes #1 and #4. Roller end Finished edge Roller end Finished edge GOLD 5/16" FLAT HEAD SCREW (8 used in this step) Page 8 418650 www.sauder.com/services...
  • Page 9 Step 4 Fasten the RAIL BRACKETS (45G) to the LEFT END (B). å Use four GOLD 9/16" LARGE HEAD SCREWS (5S). GOLD 9/16" LARGE HEAD SCREW (4 used in this step) Finished edge www.sauder.com/services 418650 Page 9...
  • Page 10 END (B). Use four GOLD 5/16" FLAT HEAD SCREWS (3S). NOTE: Use the exact holes shown in the RAIL BRACKETS. å GOLD 5/16" FLAT HEAD SCREW (4 used in this step) Roller end Finished edge Roller end Finished edge Page 10 418650 www.sauder.com/services...
  • Page 11 NOTE: There are no pre-drilled holes in the MOLDINGS (BB). The å SCREWS will tighten into the grooves. GOLD 9/16" LARGE HEAD SCREW (12 used in this step) (6 used) These edges should be even. These edges should be even. www.sauder.com/services 418650 Page 11...
  • Page 12 ANGLE BRACKETS and into the DESK MOLDING. NOTE: There are no pre-drilled holes in the MOLDING (Z). å The SCREWS will tighten into the groove. GOLD 9/16" LARGE HEAD SCREW (6 used in this step) (3 used) These edges should be even. Page 12 418650 www.sauder.com/services...
  • Page 13 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 418650 Page 13...
  • Page 14 HUTCH LEFT END as shown in the diagram. Fasten the LONG SHELF (K) to the SHORT DIVIDERS (W). Use å two BROWN 1-1/2" FLAT HEAD SCREWS (14S). Finished edge 9-5/8" (4 used) BROWN 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 14 418650 www.sauder.com/services...
  • Page 15 å SHELF (K) insert into the holes in the HUTCH UPRIGHT (G). Finished edge i t h f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 418650 Page 15...
  • Page 16 HUTCH UPRIGHT as shown in the diagram. Fasten the SHORT SHELF (L) to the LONG DIVIDERS (V). Use two å BROWN 1-1/2" FLAT HEAD SCREWS (14S). Finished edge 7-5/8" (8 used) BROWN 1-1/2" FLAT HEAD SCREW (2 used in this step) Page 16 418650 www.sauder.com/services...
  • Page 17 å SHELF (L) insert into the holes in the HUTCH RIGHT END (C). i t h o f a c S u r D E N H I D Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 418650 Page 17...
  • Page 18 Fasten the DESK TOP (H) to the HUTCH ENDS (C and D) å and HUTCH UPRIGHT (G). Use six BLACK 1-7/8" FLAT HEAD SCREWS (2S). fi n i s h r f a BLACK 1-7/8" FLAT HEAD SCREW (6 used in this step) Page 18 418650 www.sauder.com/services...
  • Page 19 H I D D E N S u r f a c H I D D E N i t h o Maximum Arrow 210 degrees Minimum 190 degrees www.sauder.com/services 418650 Page 19...
  • Page 20 H I D S u r f a c H I D D E N i t h o Finished edge Maximum Arrow 210 degrees BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Minimum 190 degrees Page 20 418650 www.sauder.com/services...
  • Page 21 å UPRIGHT (F), and BOTTOM (M). Use four GOLD 9/16" LARGE HEAD SCREWS (5S) through the ANGLE BRACKETS and into the BASE. GOLD 9/16" LARGE HEAD SCREW (8 used in this step) Curved edge (4 used) www.sauder.com/services 418650 Page 21...
  • Page 22 H I D D E N i t h For support, place packing foam and magazines under the HUTCH TOP. Maximum Arrow 210 degrees BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Minimum 190 degrees Page 22 418650 www.sauder.com/services...
  • Page 23 BACK. Carefully cut out the holes needed. Carefully cut out the rectangles in the BACKS for proper ventilation of your CPU. NAIL These holes must line up (72 used in this step) over the UPRIGHTS (E and G) and SHELVES (K and L). Notch www.sauder.com/services 418650 Page 23...
  • Page 24 Step 19 Fasten two HINGE SPACERS (22H) and two HINGES (40H) to the å DOOR (P). Use four SILVER 5/8" FLAT HEAD SCREWS (23S). SILVER 5/8" FLAT HEAD SCREW (4 used in this step) Page 24 418650 www.sauder.com/services...
  • Page 25 Fasten the BACKPLATE (120K) and KNOB (116K) to the å DOOR (P). Use a BLACK 1-1/8" MACHINE SCREW (21S). See the next step for DOOR adjustments. å 116K 120K BLACK 1-1/8" MACHINE SCREW (1 used in this step) www.sauder.com/services 418650 Page 25...
  • Page 26 To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 26 418650 www.sauder.com/services...
  • Page 27 Turn the CORD CLIP (4P) into the KEYBOARD SHELF (Q). å NOTE: The CORD CLIP is used to hold your keyboard cord å against the KEYBOARD SHELF. Roller end Roller end Finished edge BROWN 1" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 418650 Page 27...
  • Page 28 D88). Use four BLACK 1-9/16" FLAT HEAD SCREWS (30S). NOTE: Be sure the DRAWER BOTTOM D708 ) inserts into the å groove of the DRAWER BACK (D78). Repeat this step for the other drawer. å Page 28 418650 www.sauder.com/services...
  • Page 29 Repeat this step for the other drawer. å Roller end Screw head - turn CAM to line up holes in the SLIDES with holes in DRAWER SIDES Roller end GOLD 5/16" FLAT HEAD SCREW (8 used in this step) www.sauder.com/services 418650 Page 29...
  • Page 30 FILE RODS (8B), then press this FILE GLIDE over the LEFT DRAWER SIDE (D88). Repeat this step for the other drawer. å Insert the FILE RODS into the holes of your choice in the FILE GLIDES, depending on your fi le sizes. Page 30 418650 www.sauder.com/services...
  • Page 31 ENDS (C and D) and HUTCH UPRIGHT (G). (6 used) 10 lbs. To cover HIDDEN CAMS total 20 lbs. 7 lbs. total 70 lbs. 20 lbs. 114K 115K 40 lbs. 35 lbs. each SILVER 5/8" MACHINE SCREW (4 used for the PULLS) www.sauder.com/services 418650 Page 31...
  • Page 32 #4. The higher the screw in the oblong hole, the higher your drawer front will be. The lower the screw, the lower the drawer front. Page 32 418650 www.sauder.com/services...
  • Page 33 EXTRÉMITÉ DROITE ..........1 35AW ÉLÉMENT DROITE............1 pour future référence. EXTRÉMITÉ GAUCHE ..........1 35AX ÉLÉMENT GAUCHE ...........1 Pour contacter Sauder EXTRÉMITÉ DROITE DE SURMEUBLE ..1 35AY TIROIR DROIT ..............1 en ce qui concerne cet EXTRÉMITÉ GAUCHE DE SURMEUBLE ..1 35AZ TIROIR GAUCHE ............1 élément, faire référence...
  • Page 34 TABLETTE LONGUE (K) dans les trous dans MOULURES DE SURMEUBLE. le MONTANT DE SURMEUBLE (G). REMARQUE : Les MOULURES (BB) ne comportent pas de trous pré- percés. Serrer les VIS dans les rainures. Page 34 418650 www.sauder.com/services...
  • Page 35 ÉTAPE 20 DESSOUS (M). Serrer quatre EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer de bien insérer la GOUPILLE EN MÉTAL du Relever, avec précaution, l'élément dans sa position verticale. MONTANT GAUCHE dans le DESSUS DE BUREAU. www.sauder.com/services 418650 Page 35...
  • Page 36 REMARQUE : S'assurer que le FOND DE TIROIR (D708) s'encastre dans la Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour rainure de l'ARRIÈRE DE TIROIR (D78). meubles ou d’un chiff on humide. Essuyer. Répéter cette étape pour l'autre tiroir. Page 36 418650 www.sauder.com/services...
  • Page 37 EXTREMO IZQUIERDO ..........1 CORRIMIENTO DE ARCHIVERO.....4 pour future référence. EXTREMO DERECHO DE ORGANIZADOR ..1 VARILLA DE ARCHIVERO ........4 Pour contacter Sauder EXTREMO IZQUIERDO DE ORGANIZADOR ..1 EXCÉNTRICO ESCONDIDO ......21 en ce qui concerne cet PARAL DERECHO ............1 PASADOR DE EXCÉNTRICO ......21 PARAL IZQUIERDO .............1...
  • Page 38 ORGANIZADOR (C y D). Pase seis TORNILLOS DORADOS DE CABEZA GRANDE de 14 mm (5S) a través de los SOPORTES ANGULARES y dentro de las MOLDURAS DE ORGANIZADOR. NOTA: No hay agujeros perforados en las MOLDURAS (BB). Los TORNILLOS apretarán dentro de las ranuras. Page 38 418650 www.sauder.com/services...
  • Page 39 16 mm (23S). FONDO (M). Apriete cuatro EXCÉNTRICOS ESCONDIDOS. NOTA: Asegúrese de que la ESPIGA DE METAL en el PARAL IZQUIERDO se PASO 20 introduzca en el PANEL SUPERIOR DE ESCRITORIO. Cuidadosamente ponga la unidad en posición vertical. www.sauder.com/services 418650 Page 39...
  • Page 40 Utilice cuatro TORNILLOS NEGROS DE CABEZA PERDIDA de 40 mm (30S). NOTA: Asegúrese de que el FONDO DE CAJÓN (D708) ajuste en la ranura del DORSO DE CAJÓN (D78). Repita este paso para el otro cajón. Page 40 418650 www.sauder.com/services...
  • Page 41 à Les téléviseurs peuvent être particulièrement un téléviseur. cet eff et. lourds. De plus, le poids et l’emplacement du tube image ont tendance à rendre les téléviseurs instables et enclins à tomber vers l’ a vant. www.sauder.com/services 418650 Page 41...
  • Page 42 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y propensa a volcarse hacia adelante. Page 42 418650 www.sauder.com/services...
  • Page 43 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 44 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
