Maxxair MAXXFAN DOME 3810 Installation Instructions, Information And Operating Manual

Installation Instructions,
INFORMATION AND OPERATING GUIDE
READ AND SAVE THESE INSTRUCTIONS
NOTE: Refer to Installation Instructions, Information and Operation Guides regarding the
model you have purchased.
The MAXXFAN Dome fan is an exhaust fan only.
The MAXXFAN Dome fan installs into a 6 1/4 inch diameter opening.
To determine if your opening is correctly sized, simply remove the interior garnish trim ring
of your existing vent and measure the opening or verify the opening is large enough by
sliding the MAXXFAN Dome sleeve into the opening.
The MAXXFAN Dome is designed for a minimum roof thickness or wall thickness of 1 inch
to a maximum of 6 inches.
The MAXXFAN Dome fan requires a minimum 12 Volt DC, 2 amp service. Confirm that the
circuit you intend to use will accommodate the additional load. Circuit must be fused and
use appropriate gauge stranded wire for electrical connections.
WARNING!
TO PERSONS, OBSERVE THE FOLLOWING:
a) Use this unit in the manner intended by AIRXCEL, INC. If you have questions,
contact the manufacturer.
b)
Before servicing or cleaning unit, switch power off at service panel and lock the
service disconnecting means to prevent power from being switched on
accidentally. When the service disconnecting means cannot be locked, securely
fasten a prominent warning device, such as a tag, to the service panel
CAUTION!
FOR GENERAL VENTILATION USE ONLY. DO NOT USE TO
EXHAUST HAZARDOUS OR EXPLOSIVE MATERIALS AND VAPORS.
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS, OBSERVE THE FOLLOWING:
Installation work and electrical wiring must be done by qualified persons(s) in
accordance with all applicable codes and standards, including fire-rated construction.
P/N: 11-90056
MAXXFAN DOME
FOR MODELS 3810, 3812
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
.
09-24-2019
