Summary of Contents for Lutron Electronics seeTouch SG-2W
- Page 1 030747b 8/28/02 10:12 AM Page 1 Window Treatment LUTRON Wallstations for use with 3000 Series and 4000 Series systems ❑ ❑ SG-2W SG-3WRL ❑ ❑ SG-3W SG-3WD ❑ SG-5WRL...
- Page 2 030747b 8/28/02 10:12 AM Page 2 Note: Window Treatment Wallstations can only control zones on GRAFIK Eye Control Units with software revision 7-0 or higher. Window Treatment Wallstations will not function correctly with Control Units with lower software revisions. SG-2W SG-3WRL Open Button Status...
- Page 3 030747b 8/28/02 10:12 AM Page 3 Wallstation circuits are classified as Class 2 circuits (U.S.A.) and Wiring Notes PELV circuits (IEC). Unless otherwise specified, the voltages do not exceed 24 VAC or 15 VDC. As Class 2 circuits, they comply System Maximums: with the requirements of NFPA 70 National Electrical Code...
- Page 4 030747b 8/28/02 10:12 AM Page 4 Installation Warning: Always turn Off the circuit breaker/MCB or 5. Address Wallstations. Each Wallstation remove the main fuse from the power line before in a system must be assigned a Address doing any work. Failure to do so can result in serious unique address.
- Page 5 030747b 8/28/02 10:12 AM Page 5 7. Wiring must be done in a daisy-chain and 1-to-1 configuration (please see Installer's Guide included with Control Unit for more information). Each Wallstation terminal will accept up to two #18 AWG (1.0 mm ) wires.
- Page 6 030747b 8/28/02 10:12 AM Page 6 System Communications Communication between Wallstation and Control Unit must be established prior to normal operation. Follow these steps: 1. Put the Wallstation in setup mode (only one Wallstation can be in setup mode at a time). Press and hold the buttons indicated (see examples below) for about 3 seconds, until the LED(s) start cycling.
- Page 7 030747b 8/28/02 10:12 AM Page 7 2. Identify the Control Unit(s) to be controlled by the Wallstation (All Units must be addressed!) To add an individual window treatment zone from a Control Unit: Press the All LEDs will light up ZONE button for the window treatment zone to be controlled by the Wallstation.
- Page 8 Lutron Electronics Co., Inc. NFPA, National Electric Code, and NEC are registered trademarkds of the National Fire Protection Association, Inc., Quincy, Massachusetts. © 2002 Lutron Electronics Co., Inc. Lutron Electronics Co., Inc. Made and printed in U.S.A. P/N 030-747 Rev.B 6/02...
