LED Indicators

InBio Pro and ZKBioSecurity 3.0 Quick Start Guide
Figure 2
Figure 3
Figure 4
Figure 5
Figure 6
Figure 7
LINK Solid Green LED
communication is normal.
Flashing (ACT) Yellow LED
data communication is in progress.
EXT RS485 (TX/RX) Flashing Yellow
& Green LED
indicates communication is
in progress.
Flashing (POWER) Red LED
the panel is powered on.
Flashing (RUN) Green LED
that panel is in normal working state.
Flashing (CARD) Yellow LED
that the card is read by the panel.
indicates TCP/IP
indicates
indicates
indicates
indicates
