- Page 1 Quick Start Guide InBio Pro ZKBioSecurity 3.0...
-
Page 2: Table Of Contents
............Aux. Output Connection ............Ethernet Connection ............LAN Connection ..............Direct Connection ..............Restore Factory Setting ............. Restore factory setting ............Installation Diagram ............Troubleshooting ..............Electrical Specifications ........... Specifications ................InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 3: What's In The Box
What’s in the Box 2 Screws & Anchors 2 Screwdrivers 4 Diodes InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 4: Optional Accessories
Optional Accessories Wiegand Card Reader Prox Card InBio Pro Cabinet K1-1 Exit Button ZK4500 Enrollment reader CR10E Card Enroller RS485 Fingerprint Reader InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 5: Safety Precautions
Clean the device often to remove dust on it. In cleaning, do not splash water on the device but clean it with a smooth cloth or towel. Contact your supplier in case of a problem. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 6: Product Pin Diagram
Product PIN Diagram Figure 1 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 7: Led Indicators
Figure 5 Flashing (RUN) Green LED indicates that panel is in normal working state. Figure 6 Flashing (CARD) Yellow LED indicates that the card is read by the panel. Figure 7 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 8: Product Dimension
4.17 in (106 mm) 4.17 in (106 mm) 1.42 in (36 mm) Figure 8 InBio Pro- Metal Cabinet 13 in (330 mm) 15.7 in (400 mm) 3.56 in (90.5 mm) Figure 9 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 9: Installation Of Panel & Cabinet
Inserting Panel to Rail Mounting Rail Figure 11 We recommend drilling the mounting plate screws into solid wood (i.e. stud/beam). If a stud/beam cannot be found, then use the supplied drywall plastic mollies (anchors). InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 10: Wiring Legend
Wiring Legend Figure 12 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 11: Power Wiring Diagram
Power Wiring Diagram Without Backup Battery Ground Switching Power Supply Figure 13 With Backup Battery Ground Switching Power Supply Figure 14 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 12: Rs485 Fingerprint Reader Connection
RS485 Fingerprint Reader Connection ETHERNET Note: Power Supply can only Power Panel and Two readers 12V DC 12V DC RS485 Fingerprint Reader Figure InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 13: Dip Switch Setting For Rs485 Reader
If the cable length is more than 200 address 2 is for OUT reader) meters or 600 ft , the number 6 switch should be ON as below: Distance: More than 200 meters InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 14: Wiegand Connection
Wiegand Connection DC+(6-14V) Wiegand D0 Wiegand D1 Green LED Beeper Wiegand Card Reader Figure 17 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 15: Rex Connections
REX Connections Separate Power Supply 12V DC(+) 12V DC( - ) BUTTON Unused ZK ABK Exit Button K2 Exit Switch Figure 18 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 16: Lock Connection
Lock Connection Connecting a Lock with External Power Supply (Dry Contact) ETHERNET Door Contact Sensor Sensor 12V DC FR107 Diode Figure 19 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 17: Lock Connection
Connect the lock as show in the diagram, (see figure 23 and 24). Back of InBio460Pro Select one Relay Figure 20 Default setting Take off jumpers Jumpers Plug Jumpers 1, 2 - 3, 4 2, 3 - 4, 5 Figure 21 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 18: Lock Connection
12V DC FR107 Diode 16 or 18 AWG shielded cable recommended 12V DC Figure 22 Normally Closed Lock Powered From Lock Terminal (Wet Contact) ETHERNET 12V DC FR107 Diode 12V DC Figure 23 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 19: Aux. I/O Connection
Aux. I/O Connection Aux. Input Connection ETHERNET 12V DC Figure 24 Aux. Output Connection ETHERNET 12V DC Figure 25 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 20: Ethernet Connection
Figure 26 Direct Connection To connect InBio Pro Panel with a PC directly, connect both devices with a straight network cable. As the InBio Pro Panel supports auto MDI/MDIX, it is not necessary to use a crossover type cable. -
Page 21: Restore Factory Setting
Figure 28 Restore factory setting If you forget the IP address of the InBio Pro panel or the device does not work normally, you can use the number 7 DIP switch to restore InBio Pro Panel to factory default settings. The parameters which gets reset are device IP address, communication password, gateway, and subnet mask. -
Page 22: Installation Diagram
Installation Diagram Ethernet Communication wire 220/110 V Input InBio Pro Access Control Bundle Sensor CEILING Electric Lock OUTDOOR INDOOR Exit Button Outdoor Wiegand card reader Indoor Wiegand card reader Figure 30 InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 23: Troubleshooting
2 Years from original purchase date, replacement/repair of hardware under ZK standard warranty requires an evaluation of the failed system by a ZK Technical Support specialist, and the issuance of a Technical Support RMA number. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 24: Electrical Specifications
Pull- up resistance (Ω) 4.7k up with 4.7k resistors WIEGAND INPUT Voltage (V) 10.8 13.5 Current (mA) ZK ELECTRIC LOCK Voltage (V) DC 10.8 13.2 Current (mA) May vary as per models InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 25: Specifications
Specifications Note: Please note that the below specifications are only applicable for ZMM220 InBio Pro panels. GL Exclusive InBio-160 Pro InBio-260 Pro InBio-460 Pro Feature Number of 1 Door 2 Door 4 Door doors controller Numbers of 4(2 RS-485 Reader, 2... - Page 26 Creating a Time Zone ............Creating an Access Level ..........Enrolling Personnel .............. Wiegand Format ..............Add & Delete Personnel to Access Level ..... Real -Time Monitoring ............Exporting Reports ..............First-Person Normally Open .......... InBio Pro and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 27: Downloading
Downloading Go to http://www.zkteco.com/product/ZKBioSecurity3.0_421.html Download the latest software and related files as required. Once downloaded, extract the rar file to a new folder. Click on setup to begin installstion. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 28: Installation
Add an open port (Default 8088) or ask a network administrator for an open port. Click the check box to add firewall exception for this port. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... - Page 29 Select the mode of database. The default will be PostgreSQL, if you want to select any other database, then select Alternative database . Click Browse and choose or create a folder to store your backup files. Select/Create the required folder. Click OK. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 30: Adding Device
Click on Access to get below interface of Access Module of the software. Click on Device. Click on Search Device . Click Search to search all the access controllers on the network. From the list, click Add to add the required device. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... - Page 31 IP address as shown below: When the device is not in the same network with server, customers should down- load the tool and search the device as shown below: InBio Pro and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 32: Creating A Time Zone
Click Access Control > Time Zones > Add to access the time zone setting interface. After setting the time zone, click OK to save, and the time zone will appear in the list. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 33: Creating An Access Level
Click Access Levels Click New. Enter the details and click OK. You need to add doors to the access levels. Select the required door(s). Move the selected door(s). Click OK to finish adding doors. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 34: Enrolling Personnel
It must be a unique 9 characters length with the valid range of 1-79999999. It can be configured based on actual conditions. The Person- nel No. contains only numbers by default but may also include letters after setting parameters. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... - Page 35 Tick the required box. F. Fingerprint: Enroll the Personnel Fingerprint or Duress Fingerprint. Duress Fingerprint is to trigger the alarm and send the signal to the system in case of emergency. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 36: Wiegand Format
The previous Wiegand Format 37: the first parity bits (p) check “eeeeeeeeeeeeeeeeee, ” the second parity bits check “ooooooooooooooooooo”. Card Check Format only can be set “p, x, m, f, c, s”, Parity Check Format only can be set “x, b, o, e. ” InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 37: Add & Delete Personnel To Access Level
Click Add to Levels. Select Level(s). Click to move the selected level(s) to the right, and then click OK to complete adding. The added level(s) will appear in the list on to the right side. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 38: Real -Time Monitoring
You can also filter by Area, device name, Serial number to check a specific de- vice transactions or all at once. Hover over a door icon to open pop up menu as shown below and click Re- mote Closing, Remote Opening, or Cancel Alarm and more. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 39: Exporting Reports
Click OK. Personnel Module: Click Personnel Click Person Filter the data (Department, Personnel ID, and more) if required and click on search Click on Export to get the list. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... -
Page 40: First-Person Normally Open
Click Access Click Access Control Click First-Person Normally Open Click New Select the door Select the Time Zone. Add the specific person. Once this person checks in, this feature is activated. InBio Pro and ZKBioSecurity 3.0 Quick Start Guide... - Page 41 6 Kingsbridge Road, Suite 8 Fair eld, NJ 07004 T: +1 862 505 2101 sales@zkaccess.com www.zkaccess.com ZKAccess-division of ZKTeco InBio Pro and ZKBioSecurity 3.0 Quick Start Guide...
