- Page 1 Quick Start Guide ProCapture-T & ProRF-T ZKBioSecurity 3.0...
-
Page 2: Table Of Contents
Power Connection ..............Ethernet Connection ............. RS485 Connection ..............ZKBioSecurity Lock Relay Connection ............. Wiegand Output Connection ........Software Standalone Installation ............. Installation and Device Operation ..............Setup starts at Page 18 ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 3: Safety Precautions
Clean the device often to remove dust on it. In cleaning, do not splash water on the device but clean it with a smooth cloth or towel. Contact your supplier in case of a problem. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 4: On Using Face Recognition Device
If it is necessary to move the device, its vertical height should not be changed. Factors Affecting the Preciseness of Verification Non-identical registration Non-identical registration and verification gestures and verification height ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 5 During verification, it is required to show your face in the center of the screen and fit your face into the green frame in the screen. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 6: Device Overview
Card Reader Area Area ProRF-T ProCapture-T Left side & bottom view is common for both the devices Speaker USB Slot Reset Button Security Screw Holes (for securing the device onto the back plate) ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 7 12pin Cable connectors Exit Button Door Sensor Doorbell Auxiliary In Tamper alarm button 485B Beep RJ45-6 RJ45-3 485A Green LED RJ45-2 Red LED RJ45-1 Lock Button Sensor Bell Auxilliary Power In +12V ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 8: Product Dimensions & Installation
(i.e. stud/beam). If a stud/beam cannot be found, use supplied drywall plastic anchors. Use security screws to fasten the device to back plate. Insert the device to back plate. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 9: Power Connection
RJ45-1 +12V 12V DC 12V DC Adaptor Recommended Power Supply • 12V±10%, at least 500mA • To share the power with other devices, use a power supply with higher current ratings. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 10: Ethernet Connection
Ethernet Connection LAN Connection 485B RJ45-6 485A RJ45-3 RJ45-2 RJ45-1 +12V Network Cable Apator Ethernet cable DESCRIPTION WIRE RJ45-6 Black ZKB ioSecurity RJ45-3 RJ 45- 2 Green RJ 45- 1 Yellow ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 11: Rs485 Connection
If the cable length is more than 200 meters or 600 ft, the number 6 switch should be ON as below. Distance: More than 200 meters 1 2 3 4 5 6 1 2 3 4 5 6 ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 12: Lock Relay Connection
When electrical lock is connected to the Access Control System, you must parallel one FR107 diode (equipped in the package) to prevent the self-inductance EMF from affecting the system. Do not reverse the polarities. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 13 RJ45-6 485A RJ45-3 RJ45-2 RJ45-1 +12V +12V Sensor DESCRIPTION WIRE Black Gray Black COM1 White Blue Yellow BELL+ Orange BELL- Green Purple Brown Do not use FR107 Diode Normally Closed Lock ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 14: Wiegand Output Connection
Wiegand Output Connection 485B RJ45-6 485A RJ45-3 RJ45-2 RJ45-1 +12V ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 15: Standalone Installation
Standalone Installation ZKBioSecurity ZKBioSecurity Ethernet ALARM Sensor No Touch EXIT Exit Button Lock Doorbell ProCapture-T Rs485 Fingerprint Reader ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 16: Device Operation
If DHCP is enabled, IP cannot be set manually. Display in Status Bar: To set whether to display the network icon on the status bar of initial interface. Not all products have this function, the real product shall prevail. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 17 To prevent passing back which causes risks to security. Once this function is en- abled, entry and exit records must be matched in order to open door. In Anti-Passback, Out Anti-Passback and In/Out Anti-Passback functions are available. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
- Page 18 To cancel the triggered alarm mode, carefully check whether the device and back plate are se- curely connected to each other, and reinstall the device properly if necessary. How to cancel alarms? Verify a registered user. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
- Page 19 Creating a Time Zone ............Creating an Access Level ..........Enrolling Personnel .............. Wiegand Format ..............Add & Delete Personnel to Access Level ..... Real -Time Monitoring ............Exporting Reports ..............ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 20: Downloading
Downloading Go to http://www.zkteco.com/product/ZKBioSecurity3.0_421.html Download the latest software and related files as required. Once downloaded, extract the .rar file to a new folder. Click on setup to begin installstion. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 21: Installation
Add an open port (Default 8088) or ask a network administrator for an open port. Note: Stanalone device doesn’t support https. Click the check box to add firewall exception for this port. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 22 Select the mode of database. The default will be PostgreSQL, if you want to select any other database, then select Alternative database . Click Browse and choose or create a folder to store your backup files. Select/Create the required folder. Click OK. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 23: Adding Device
Click on Access to get below interface of Access Module of the software. Click on Device. Click on Search Device . Click Search to search all the sandalone devices on the network. From the list, click Add to add the required device. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 24 IP address as shown below: When the device is not in the same network with server, customers should down- load the tool and search the device as shown below: ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 25: Creating A Time Zone
Click Access Control > Time Zones > Add to access the time zone setting interface. After setting the time zone, click OK to save, and the time zone will appear in the list. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 26: Creating An Access Level
Click New. Enter the details and click OK. You need to add doors to the access levels. Select the required door(s). Move the selected door(s). Click OK to finish adding doors. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 27: Enrolling Personnel
It must be a unique 9 characters length with the valid range of 1-79999999. It can be configured based on actual conditions. The Person- nel No. contains only numbers by default but may also include letters after setting parameters. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 28 Tick the required box. Fingerprint: Enroll the Personnel Fingerprint or Duress Fingerprint. Du- ress Fingerprint is to trigger the alarm and send the signal to the system in case of emergency. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
-
Page 29: Wiegand Format
Parity Position, s indicates Site Code, c indicates Cardholder ID, f in- dicates Facility Code, m indicates Manufactory Code, e indicates Even Parity, O indicates Odd Parity, b indicates both odd check and even check, x indicates par- ity bits no check. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 30: Add & Delete Personnel To Access Level
Select Level(s). Click to move the selected level(s) to the right, and then click OK to complete adding. The added level(s) will appear in the list on to the right side. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 31: Real -Time Monitoring
Hover over a door icon to open pop up menu as shown below and click Re- mote Closing, Remote Opening, or Cancel Alarm and more. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... -
Page 32: Exporting Reports
Click OK. Personnel Module: Click Personnel Click Person Filter the data (Department, Personnel ID, and more) if required and click on search Click on Export to get the list. ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide... - Page 33 6 Kingsbridge Road, Suite 8 Fair eld, NJ 07004 T: +1 862 505 2101 sales@zkaccess.com www.zkaccess.com ZKAccess-division of ZKTeco ProCapture-T & ProRF-T and ZKBioSecurity 3.0 Quick Start Guide...
