Nu-Link2-Pro PCBA

Main Chip:
M48SKIDAE
ETM Connector
Start Button
SWD Connector
Figure 2.2-1 shows the main components and connectors from the front side of Nu-Link2-Pro PCBA.
The following lists components and connectors from the front view:

Main Chip: M48SKIDAE

Micro SD Card Slot

Micro USB Connector

USB Connector

Bridge Connector

SWD Connector

Start Button

ETM Connector
Figure 2.2-2 shows the main components and connectors from the rear side of Nu-Link2-Pro PCBA.
The following lists components and connectors from the rear view:
Mar. 13, 2020
Nu-Link2-Pro Debugger and Programmer

Figure 2.2-1 Front View of Nu-Link2-Pro PCBA

Figure 2.2-2 Rear View of Nu-Link2-Pro PCBA

Page 11 of 77
Micro SD Card Slot
Micro USB Connector
USB Connector
Bridge Connector
Function Switch (Reserve)
