- Page 1 Better Products. Better Value. 900 mm Built In Oven OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. DORSET/ DEVON...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. ATB 4411/4421 DORSET ATB 4511/4521 DEVON Voltage: 230/240 Volts AC 50Hz Wattage: 5.0/5.4kW Height: 885mm Width: 595mm Depth: 545mm (excluding handles and knobs) Weight: 53kg These appliances comply with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. -
Page 3: Table Of Contents
The Electronic Timer (Devon only) ........ - Page 4 Care of Stayclean Surfaces (Devon only) ........
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix cooker, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures which may differ from your previous cooker. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This cooker is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the cooker has been removed before the cooker is used. -
Page 7: After Use
You must ensure that the grill control is in the 'OFF' position when the timer control has been set for automatic cooking. (Devon only). Ensure that the anti-tilt shelves are put in place correctly. Refer to instructions on pages 26 and 28. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS THINGS YOU NEED TO KNOW WARNINGS: This cooker must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in accordance with these instructions. This cooker must be earthed. Do not remove the screws from the earth tab extending from the oven mains terminal block (Fig. -
Page 9: Preparing Cabinet For Fitting Oven
NOTE: It is good practice to: Fit an Earth Leakage Circuit Breaker to your house wiring. Wire your appliance to the latest IEE regulations. PREPARING CABINET FOR FITTING OF OVEN Make sure the cabinet is the correct size for the appliance to be fitted (Ref. -
Page 10: Recommended Cabinet Dimensions
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES) Fig. 2 Built In Installation & Cross section through cabinet showing oven positioned... -
Page 11: How To Finish Unpacking
HOW TO FINISH UNPACKING Place packed cooker next to the cabinet in which it will be installed. Remove the cooker packing except for bottom tray which should be left in position until the cooker is ready to be fitted into its cabinet. Ensure the owner is given these operating instructions. -
Page 12: Connecting To The Mains Terminal
Lift cover and remove screw from cable clamp. See Fig. 5. Fig.5 CONNECTING TO MAINS TERMINAL Warning: This cooker must be earthed. Make connection as shown in Fig. 6 by proceeding as follows:- Fig.6 Preform wires to the appropriate shape to suit fitting into the mains terminal block. -
Page 13: Fitting Into The Cabinet
FITTING INTO THE CABINET IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out. Using a tape measure establish the internal width of the cabinet. Refer to page 8 if greater than 565mm. -
Page 14: Introduction
B - Main Oven Indicator Neon C - Main Oven Temperature Control D - Second Oven Indicator Neon GETTING TO KNOW YOUR OVEN (DEVON). A - Electronic Timer B - Main Oven Indicator Neon C - Main Oven Temperature Control... -
Page 15: Rating Plate
See page 17 for further information about setting the time of day and use of the minute minder. ( Devon only ) The timer must be set for manual cooking before the oven will operate. See page 19 for details on how to set the timer. -
Page 16: Grill And Oven Furniture
2 straight shelves (for main oven cooking) ( Devon only ) Scuffing of the Stayclean oven lining by the oven furniture pack may occur during transit. These marks will disappear after the oven elements have been burnt off for the first time. -
Page 17: The Electronic Minute Minder (Dorset Only)
THE ELECTRONIC MINUTE MINDER (DORSET ONLY ) DECREASE CONTROL & MINUTE MINDER SETTING BUTTON INCREASE CONTROL ) COOKING SYMBOL ) PUSH BOTH CLOCK SETTING CONTROL ) MINUTE MINDER SYMBOL The electronic minute minder can also indicate the time of day. 1. - Page 18 The minute minder will begin to count down once set. At the end of the timed period, an audible signal will sound for up to 30 seconds. The display will flash showing the time of day. See Fig. 6. To stop the sound and flashing press button (1). The display will stop flashing and show the time of day, e.g.
-
Page 19: The Electronic Timer (Devon Only)
THE ELECTRONIC TIMER (DEVON ONLY ) AUTO DISPLAY MINUTE MINDER BUTTON COOKING HOURS BUTTON STOP TIME BUTTON COOKING SYMBOL MANUAL SELECTOR BUTTON DECREASE CONTROL INCREASE CONTROL NOTE: STEP 1 BELOW MUST BE FOLLOWED BEFORE THE OVEN WILL OPERATE 1. SET THE TIME OF DAY When the electricity supply is first switched ON, the display will flash both 0.00 and AUTO. - Page 20 Release the minute minder button and the display will return to the time of day after 5 seconds. During the operation of the minute minder the remaining time period can be shown in the display by pressing the minute minder button ).
- Page 21 Note: When the automatic timed period starts, the oven neon will cycle ON and OFF during cooking. TO SET THE TIMER TO SWITCH OFF ONLY Ensure the electricity supply is switched ON and that the correct time of day is displayed, e.g.
- Page 22 5. THINGS TO NOTE The time of day cannot be altered whilst the AUTO symbol is lit. A programme may be cancelled by returning the cooking hours to zero. Press the cooking hours button ( ) depress ( - ) button until 0.00 is displayed.
-
Page 23: The Grill
The grill is a dual circuit grill which means that the whole area of the grill can be used or, for economy purposes the centre section only can be used when cooking smaller quantities of food. SELECTING THE DUAL GRILL (DORSET/ DEVON). Turn the grill control clockwise for full grill or anticlockwise for the centre section only. -
Page 24: Hints And Tips
HINTS AND TIPS Most foods should be placed on the grid in the grill pan to allow maximum circulation of air to lift the food out of the fats and juices. Food such as fish, liver and kidneys may be placed directly on the grill pan base if preferred. -
Page 25: Grilling Chart
GRILLING CHART FOOD SHELF Toast 2crk. Bacon Rashers 2crk. Beefburgers 2crk. Chicken Joints 2crk. Chops - Lamb 2crk. Pork 2crk. Fish - Whole Trout/Mackerel 2crk. Fillets - Plaice/Cod 2crk. Kebabs 2crk. Kidneys - Lamb/Pig 2crk. Sausages 2crk. Steaks - Rare 2crk. -
Page 26: The Second Oven
It gives especially good results if used to cook fruit cakes, sweet and savoury flans or quiche. SELECTING THE SECOND OVEN (DORSET/ DEVON). Ensure the grill control is in the off, 'O' position. Turn the second oven temperature control to the required setting. - Page 27 There should always be at least 2.5cm (1") between the top of the food and the element. This gives best cooking results and allows room for rise in yeast mixtures, Yorkshire puddings etc. When cooking cakes, pastry, scones, bread etc., place the tins or baking trays centrally below the element.
-
Page 28: The Main Fan Oven
30. As a guide reduce temperatures by about 20°C-25°C for your own recipes. BATCH BAKING The fan oven cooks evenly on all shelf levels, especially useful when batch baking. SELECTING THE FAN OVEN (DORSET/ DEVON). Turn the main oven temperature control to the required setting. -
Page 29: Hints And Tips
HINTS AND TIPS Arrange the shelves in the required positions before switching the oven ON. Shelves are numbered from the bottom upwards. When cooking more than one dish in the fan oven, place dishes centrally on different shelves rather than cluster several dishes on one shelf, this will allow the heat to circulate freely for the best cooking results. -
Page 30: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit... -
Page 31: Defrosting
It is preferable to thaw fish, meat and poultry slowly in the fridge. However, this process can be accelerated by using the defrost function. SELECTING DEFROST (DORSET/ DEVON). Turn the main oven temperature control to the defrost setting ( This function DOES NOT require a temperature setting on the oven temperature control. -
Page 32: Helpful Hints When Buying And Preparing Food
HELPFUL HINTS WHEN BUYING AND PREPARING FOOD Care must be taken when handling foods in the home. Always follow the basic rules of food hygiene to prevent bacterial and microbial growth and cross contamination when preparing, reheating, cooking, cooling, defrosting and freezing foods:- 1. -
Page 33: Care And Cleaning
MAY CAUSE DAMAGE AND IS A SAFETY CLEANING INSIDE THE OVENS The Stayclean surface inside the ovens should not be cleaned manually. (Devon only). See page 34 "Care of Stayclean Surfaces". Aerosol cleaners must not be used on Stayclean surfaces and must not come into contact with elements or the door seal as this may cause damage. -
Page 34: Care Of Stayclean Surfaces (Devon Only)
DO NOT attempt to use the oven without the glass being in place. CARE OF STAYCLEAN SURFACES (DEVON ONLY) Stayclean surfaces destroy splashes of food and fats when the oven temperature is raised to around 220°C. -
Page 35: Replacing The Oven Light Bulb
REPLACING THE OVEN LIGHT BULB The type of bulb required is a 300C 25 watt small Edison Screw. Part number 572 491 5431-00/1. (Available through Tricity Bendix service centres). CAUTION: DISCONNECT THE COOKER FROM THE ELECTRICITY SUPPLY BEFORE REPLACING THE BULB. -
Page 36: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your cooker before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the cooker is under guarantee. -
Page 37: Service And Spare Parts
It is a recommendation by the manufacturer that annual servicing of the product is done by the manufacturers approved service organisation. In the event of your appliance requiring service Tricity Bendix Limited have an arrangement with Electrolux Group Service. Before calling out an Engineer, please ensure that you have read the details under the heading 'Something Not Working?' and have the model number and purchase date to hand. -
Page 38: Customer Service Centres
Dunoon Argyll PA23 7AL Electrolux After Sales Service McBain Refrigeration Unit 4 Upcott Avenue Pottington Industrial Estate Barnstaple N.Devon EX31 1HN Electrolux After Sales Service James Stewart & Son 2-8 Wood Market Kelso Borders TD5 7AX Electrolux After Sales Service... - Page 39 EH FK G KA KY1-16 ML GLASGOW PA1-23, PH1-7 GUERNSEY All Codes SA33-39 HAVERFORDWEST SA41-44 SA61-73 HR1-9 LD1-8 HEREFORD SY7 ,18 NP7-8 YO11-18 HULL YO25 HU1-19 DN14 IV1-28, 30-36, 52-56, INVERNESS PH19-26, 42-44 KW1-14 INVERNESS PH30-41 IV40-51 ISLE OF WIGHT PO30-41 ISLE OF ARRAN KA27...
- Page 40 Manchester M28 3PT Electrolux After Sales Service South West Domestic Service 01626-65909 Unit 2 Zealley Industrial Est Kingsteignton Newton Abbott South Devon TQ12 3SJ Electrolux After Sales Service GMS (Cymru) 01745-591616 Unit 2 Coed- Parc Abergele Road Rhuddlan Clwyd, Wales LL18 5UG...
- Page 41 REDRUTH TR1-20, 26, 27 PL10-15, 17, 18, 22-35 ROTHSAY PA20 SHETLAND Own Sales SHETLAND Own Sales SHETLAND SY1-6 SHREWSBURY SY8-17 SY19-22 SOUTH COAST BN16-18. GU27-35 PO1-22. BH DT SO TR21-25 DN 8, 9, DN15-20 DN21 sub codes 3,4 only SOUTH HUMBERSIDE DN31-40 LN (3 sub code 6 only), 7 LN11-13...
-
Page 42: Guarantee Conditions
All service work under this guarantee must be undertaken by a Tricity Bendix service representative or authorised agent. Any appliance or defective part replaced shall become the Company's property. - Page 44 This handbook is accurate at the date of printing, but will be superseded and should be disregarded if specifications or appearance are changed. Better Products. Better Value. TRICITY BENDIX,99 OAKLEY ROAD, LUTON, BEDFORDSHIRE, LU4 9QQ A Division of Emaco Limited Registered in England No. 176547 Registered Office. 101 Oakley Road, Luton LU4 9RJ. MODEL NO.
