Summary of Contents for Tricity Bendix TBS 603
- Page 1 INSTRUCTION BOOKLET BUILT-IN OVEN MODEL TBS 603 Please read this instruction booklet before using the appliance...
-
Page 3: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the oven. If you need assistance, contact our Customer Care Department on 08705 950950 Installation • This oven must be installed by qualified personnel to the relevant British Standards. •... -
Page 4: Table Of Contents
Contents For the User Important Safety Information Description of the Appliance Controls Before the First Use Using the Oven Using the Fan Oven Cooking Chart Defrosting Grilling Cleaning the Oven If something goes wrong Service and Spare Parts Guarantee Conditions Guide to Use the instructions The following symbols will be found in the text to guide you throughout the Instructions:... -
Page 5: Description Of The Appliance
Description of the Appliance End of Cooking Programmer Control Panel Oven door Accessories Removable handle Oven Function Control Light Thermostat Control Light TIMER MAINS THERMOSTAT Grill / Roasting pan Oven Function Control Thermostat Control Knob Knob FUNCTION TEMPERATURE Grill Pan Grid... -
Page 6: Oven Function Control Knob
Controls Oven Function Control Knob Oven Light - The oven light will be on without any cooking function. Defrost Setting - This setting is intended to assist in thawing of frozen food Fan oven cooking - This allows you to roast or roast and bake simoultaneously using any shelf, without flavour transference. -
Page 7: Before The First Use
Before the First Use Remove all packaging, both inside and outside the oven, before using the appliance. Before first use, the oven should be heated without food. During this time, an unpleasant odour may be emitted. This is quite normal. 1. -
Page 8: Telescopic Shelf Supports
Telescopic shelf supports Shelf level 2 is fitted with telescopic shelf supports. 1. Pull the right and left hand telescopic shelf supports completely out, as shown in the diagram. 2. Place the shelf or the grill pan on the telescopic shelf supports, as shown in the diagram, then gently push them all inside the oven. -
Page 9: Using The Fan Oven
Using the Fan Oven The air inside the oven is heated by the element around the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. The advantages of cooking with this function are: Faster Preheating As the fan oven quickly reaches temperature, it is not usually necessary to preheat the oven although you... -
Page 10: Cooking Chart
Cooking Chart This chart is intended as a guide only. It may be necessary to increase or decrease the temperature to suit your individual requirements. Only experience will enable you to determine the correct setting for your personal requirements. Food Biscuits Bread Casseroles... - Page 11 Hints and Tips Runner positions are not critical, but make sure the shelves are evenly spread. When cooking more than one dish in the fan oven, place dishes centrally on the shelves rather than several dishes on one shelf. When the oven is full, you may need to allow slightly longer cooking time.
-
Page 12: Defrosting
Defrosting The oven fan operates without heat and circulates the air, at room temperature, inside the oven. This increases the speed of defrosting. However, please note that the temperature of the kitchen will influence the speed of defrosting. This function is particularly suitable for delicate food which could be damaged by heat, e.g. -
Page 13: Grilling
Grilling Grilling must be carried out with the oven door closed. The grill pan handle must be removed from the pan. How to Use the Grill 1. Turn the oven control function knob on 2. Turn the thermostat control knob on the required temperature. -
Page 14: Cleaning The Oven
Cleaning the Oven Before cleaning always allow the cooling fan to cool the cooker down before switching off at the electricity supply. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. Cleaning materials Before using any cleaning materials on your oven, check that they are suitable and that their use is... - Page 15 Oven Cavity The enamelled oven cavity is best cleaned whilst the oven is still warm. Wipe the oven over with a soft cloth soaked in warm soapy water after each use. From time to time it will be necessary to do a more thorough cleaning, using a proprietary oven cleaner.
-
Page 16: Replacing The Oven Light
Replacing The Oven Light If the oven bulb needs replacing, it must comply with the following specifications: - Electric power: 15W, - Electric rate: 230-240 V (50 Hz), - Resistant to temperatures of 300 C, - Connection type: E14. These bulbs are available from your local Force Service Centre. -
Page 17: If Something Goes Wrong
If the appliance is not working correctly, please carry out the following checks, before contacting your local Tricity Bendix Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 18: Service And Spare Parts
Service Force Centre by telephoning: 08705 929929 Your call will be routed to the Service Centre covering your post code area. The addresses of Tricity Bendix Service Force Centres are detailed on the following pages. TRICITY BENDIX STANDARD GUARANTEE CONDITIONS... - Page 19 TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Force Centre telephone 08705 929 929 CHANNEL ISLANDS GUERNSEY Guernsey Electricity PO Box 4 Vale , Guernsey Channel Islands JERSEY Jersey Electricity Company PO Box 45 Queens Road St Helier...
- Page 20 TRICITY BENDIX SERVICE FORCE To contact your local Tricity Bendix Service Force Centre telephone 08705 929 929 MIDLANDS BIRMINGHAM 66 Birch Road East, (M18) Wyrley Road Industrial Estate Witton Birmingham B67DB BOURNE Manning Road Ind (M44) Estate Pinfold Road Bourne...
-
Page 21: Technical Data
Technical Data DIMENSIONS Height OF RECESS Width Depth DIMENSIONS Height OF THE Width OVEN CAVITY Depth Oven capacity Electrical Connection The oven is designed to be connected to 230-240V (50Hz) electricity supply. The oven has an easily accessible terminal block which is marked as follows: Letter L Live terminal... -
Page 22: Building In
Building In Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. BUILDING IN The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant diagrams;...
