Summary of Contents for Tricity Bendix TBF 610
- Page 1 INSTRUCTION BOOKLET ι ELECTRIC OVEN TBF 610 Please read this instruction booklet before using the appliance...
-
Page 2: Maintenance And Cleaning
You MUST read these warnings carefully before installing or using the oven. If you need assistance, contact our Customer Care Department on 08705 950950 Installation • This oven must be installed by qualified personnel to the relevant British Standards. • This oven is heavy. -
Page 3: Table Of Contents
Contents For the User Important Safety Information Description of the Oven Controls Before the First Use Using the Oven Hints and Tips The Fan Oven Cooking chart - Fan Oven Grilling Defrosting Cleaning the Oven Replacing the Oven Light Something not working Service and Spare Parts Customer Care Department Guarantee Conditions... -
Page 4: Description Of The Oven
Description of the Oven 1. Control panel 2. Oven Control Function Knob 3. End of cooking Programmer 4. Thermostat Control Knob 5. Thermostat Control Light 6. Mains on Light Oven accessories Removable handle Grill / Roasting pan 7. Air Vents for Cooling Fan 8. -
Page 5: Oven Function Control Knob
Controls Oven Function Control Knob (Fig. 1) Oven Light - The oven light will be on without any cooking function. Defrost Setting - This setting is intended to assist in thawing of frozen food. Fan cooking - This allows you to roast or roast and bake simoultaneously using any shelf, without flavour transference. -
Page 6: The Safety Thermostat
The Safety Thermostat This oven is provided with a safety thermostat. In case of malfunctioning of the main thermostat, and consequent over-heating, the safety device will stop the power supply to the appliance. If this happens, call your local Service Force Centre. Under no circumstances should you attempt to repair the appliance yourself. -
Page 7: Using The Oven
Using the Oven Always cook with the oven door closed. Stand clear when opening the drop down oven door. Do not allow it to fall open - support the door using the door handle, until it is fully open. The oven has four shelf levels, and is supplied with two shelves. -
Page 8: The Fan Oven
The Fan Oven The air inside the oven is heated by the element around the fan situated behind the back panel. The fan circulates hot air to maintain an even temperature inside the oven. The advantage of cooking with this function is energy saving through: Faster Preheating "... -
Page 9: Cooking Chart - Fan Oven
Cooking times in the tables do not include pre-heating. We recommend to pre-heat the oven for about 10 minutes before cooking. TYPE OF DISH CAKES Whipped up kneading Shortbread dough Butter-milk cheese cake Apple cake Strudel Jam-tart Fruit cake Sponge cake Christmas cake Plum cake Small cakes... -
Page 10: Grilling
Grilling must be carried out with the oven door closed. The grill pan handles must be removed from the pan during grilling. Always use oven gloves to remove and replace the grill pan handles. Ensure that you support the grill pan when removing it from the oven. -
Page 11: Defrosting
Defrosting The oven fan operates without heat and circulates the air, at room temperature, inside the oven. This increases the speed of defrosting. However, please note that the temperature of the kitchen will influence the speed of defrosting. This function is particularly suitable for delicate food which could be damaged by heat, e.g. -
Page 12: Cleaning The Oven
Cleaning the Oven Before cleaning always allow the cooling fan to cool the oven down before switching off at the electricity supply. This appliance cannot be cleaned with steam or with a steam cleaning machine. The oven should be kept clean at all times. A build-up of fats or other foodstuffs could result in a fire, especially in the grill pan. -
Page 13: Oven Cavity
Models in stainless steel or aluminium: We recommend to clean the oven door using only a wet sponge and dry it up after cleaning with a soft cloth. Never use steel wool, acids or abrasive products as they can damage the oven surface. Clean the oven control panel following the same precautions. -
Page 14: Something Not Working
If the appliance is not working correctly, please carry out the following checks, before contacting your local Service Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 15: Service And Spare Parts
Customer Care Department For general enquiries concerning your Tricity Bendix ap- pliance or for further information on Tricity Bendix prod- ucts, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.tricity-bendix.co.uk... -
Page 16: Guarantee Conditions
We, Tricity Bendix, undertake that if, within 12 months of the date of the purchase, this Tricity Bendix appliance or any part thereof is proved to be defective by any reason only of faulty workmanship or materials, we will, at our... -
Page 17: Important Safety Information 2 Installation
Installation The oven must be installed according to the instructions supplied. Technical Data Dimensions of recess Height Width Depth Dimensions of the oven cavity Height Width Depth Oven capacity Electrical Connection The oven is designed to be connected to 230 V (50 Hz) electricity supply. -
Page 18: Securing The Oven To The Cabinet
Building In Please ensure that when the oven is installed it is easily accessible for the engineer in the event of a breakdown. Building In The surround or cabinet into which the oven will be built must comply with these specifications: the dimensions must be as shown in the relevant "... - Page 19 TBF 610 0,79 kWh 0,78 kWh 43 min. 41 min. 1130 cm²...
-
Page 20: Customer Care
CUSTOMER CARE Tricity Bendix Major Appliances Addington Way Luton Bedfordshire LU4 9QQ Tel: 08705 950 950 © Electrolux plc 2003 From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx.
