- Page 1 Better Products. Better Value. 600 mm Built In Oven OPERATING AND INSTALLATION INSTRUCTIONS MODEL SOMERSET/SUSSEX...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. ATB 3311, 3321 SOMERSET Voltage: 230/240 Volts AC 50 Hz Wattage: 2.4/2.6kW Height: 595 mm Width: 595 mm Depth: 545 mm (excluding handles and knobs) Weight: 37kg MODEL NO. ATB 3411, 3421 SUSSEX Voltage: 230/240 Volts AC 50 Hz Wattage: 2.7/2.9kW... -
Page 3: Table Of Contents
The Electronic Minute Minder (Somerset) ........ - Page 4 CONTENTS The Fan Oven ............... . . 26 Uses of the Fan Oven .
-
Page 5: Preface
Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. In order that you get the best from your new Tricity Bendix cooker, the following instructions have been prepared. PLEASE MAKE SURE YOU READ THEM CAREFULLY. Particular attention should be paid to cooking times and temperatures which may differ from your previous cooker. -
Page 6: Safety
SAFETY THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. ENSURE THAT THEM ALL BEFORE INSTALLING OR USING THE COOKER. PLEASE READ CAREFULLY BEFORE INSTALLATION This cooker is heavy and care must be taken when moving it. Ensure that all packaging, both inside and outside the cooker has been removed before the appliance is used. -
Page 7: After Use
Ensure that all vents are left unobstructed to ensure ventilation of the oven cavity. You must ensure that the grill control is in the 'OFF' position when the timer control has been set for automatic cooking (Sussex only). Ensure that the anti-tilt shelves are put in place correctly. -
Page 8: Installation Instructions
INSTALLATION INSTRUCTIONS THINGS YOU NEED TO KNOW WARNINGS: This cooker must be installed by a qualified electrician/competent person. Safety may be impaired if installation is not carried out in impaired if installation is not carried out in accordance with these instructions. This cooker must be earthed. -
Page 9: Preparing Cabinet For Fitting Oven
ii) By connecting the cooker point to the hob and then connecting the hob to the oven. Provided that the hob manufacturer permits it, connect the oven to the hob and the hob to the cooker point using the same cabling as described in (a) above. -
Page 10: Recommended Cabinet Dimensions
RECOMMENDED CABINET DIMENSIONS (IN MILLIMETRES) Fig. 3 Built Under Installation Cross section through cabinet showing oven positioned Fig. 4 Built In Installation 560 min 570 max Cross section through cabinet showing oven positioned 600 min 560 min 570 max 550 min 550 min... -
Page 11: How To Finish Unpacking
HOW TO FINISH UNPACKING Place packed cooker next to the cabinet in which it will be installed. Remove the cooker packing except for bottom tray which should be left in position until the cooker is ready to be fitted into its cabinet. Ensure the owner is given these operating instructions. -
Page 12: Connecting To The Mains Terminal
Lift cover and remove screw from cable clamp. See Fig. 7. Fig. 7 CONNECTING TO THE MAINS TERMINAL Warning: This cooker must be earthed. Make connection as shown in Fig. 8 by proceeding as follows:- Fig. 8 Preform wires to the appropriate shape to suit fitting into the mains terminal block. -
Page 13: Fitting Into The Cabinet
FITTING INTO THE CABINET IMPORTANT: Ensure that the oven is switched off at the wall before any further work is carried out. Using a tape measure establish the internal width of the cabinet. Refer to page 8 if greater than 565mm. -
Page 14: Introduction
INTRODUCTION WARNING: THIS COOKER MUST BE EARTHED GETTING TO KNOW YOUR OVEN (SOMERSET) Electronic Minute Minder Oven/Grill Indicator Neon Fan Oven/Grill Temperature Control GETTING TO KNOW YOUR OVEN (SUSSEX) Electronic Timer Selector Thermal Grill Dual Grill Fan Oven D - Selector... -
Page 15: Rating Plate
WHEN FIRST SWITCHING ON (Somerset only) When the cooker is first switched on at the wall the timer will make an audible sound. To stop the sound press both timer buttons together. -
Page 16: Grill And Oven Furniture
GRILL AND OVEN FURNITURE The following items of oven furniture have been supplied with the cooker. 1 grill pan 1 grill pan handle 1 grill pan grid 1 grill deflector 2 straight shelves (Sussex only) Scuffing of the Stayclean oven lining by the oven furniture pack may occur during transit. -
Page 17: The Electronic Minute Minder (Somerset)
ELECTRONIC MINUTE MINDER (SOMERSET ONLY) 1 = ( - ) DECREASE CONTROL & MINUTE MINDER SETTING BUTTON 2 = ( + ) INCREASE CONTROL ) COOKING SYMBOL ) PUSH BOTH CLOCK SETTING SYMBOL ) MINUTE MINDER SYMBOL 1. TO SET THE TIME OF DAY... -
Page 18: To Cancel The Minute Minder
The minute minder will begin to count down once set. At the end of the timed period, the minute minder will sound for up to 30 seconds and the display will flash showing the time of day. See Fig. 6. To stop the sound, press button (1). -
Page 19: The Electronic Timer (Sussex)
THE ELECTRONIC TIMER (SUSSEX ONLY) AUTO DISPLAY MINUTE MINDER BUTTON COOKING HOURS BUTTON STOP TIME BUTTON COOKING SYMBOL MANUAL SELECTOR BUTTON DECREASE CONTROL INCREASE CONTROL NOTE: STEPS 1 AND 2 BELOW MUST BE FOLLOWED BEFORE THE OVEN WILL OPERATE MANUALLY. 1. - Page 20 Release the minute minder button and the display will return to the time of day after 5 seconds. During the operation of the minute minder the remaining time period can be shown in the display by pressing the minute minder button ).
- Page 21 Note: When the automatic timed period starts, the oven neon will cycle ON and OFF during cooking. TO SET THE TIMER TO SWITCH OFF ONLY Ensure the electricity supply is switched ON and that the correct time of day is displayed, e.g.
-
Page 22: Automatic Cooking
5. THINGS TO NOTE The time of day cannot be altered whilst the AUTO symbol is lit. A programme may be cancelled by returning the cooking hours to zero. Press the cooking hours button ( ) depress ( - ) button until 0.00 is displayed. -
Page 23: The Grill
THE GRILL USES OF THE GRILL (SOMERSET ONLY) CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. Use the full heat grill only for foods which require high heat and short cooking times, e.g. toast, blue/rare steaks. -
Page 24: Things To Note
The cooling fan for the controls will operate when grilling. The oven/grill indicator neon will illuminate on the Somerset and the grill indicator neon will illuminate on the Sussex. The grill operates independently of the oven. The outer grill element may appear to glow slightly brighter than the inner element. -
Page 25: Grilling Chart
(Somerset only). Cook toast and rare steaks using the preheated full heat grill. All other foods cook very successfully on thermal grill. When toasting bread, we suggest that the top runner position is used with the grid in its 'High' position. -
Page 26: The Fan Oven
28. As a guide reduce temperatures by about 20°C-25°C for your own recipes. BATCH BAKING The fan oven cooks evenly on both shelf levels, especially useful when batch baking. SELECTING THE FAN OVEN (SOMERSET) SELECTING THE FAN OVEN (SUSSEX) Ensure the selector is set to Fan Oven. -
Page 27: Things To Note
THINGS TO NOTE The oven neon will glow until the oven has reached the desired temperature and then go out. It will cycle ON and OFF periodically during cooking showing that the temperature is being maintained. The oven fan will operate continually during cooking. -
Page 28: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperatures by 10°C to suit individual preferences and requirements. FOOD Biscuits Bread Bread rolls/buns Cakes: Small & Queen Sponges Victoria Sandwich Madeira Rich Fruit... -
Page 29: Thermal Grilling
THINGS TO NOTE The oven/grill indicator neon will glow on the Somerset and the oven indicator neon will glow on the Sussex until the oven has reached the desired temperature and then go out. -
Page 30: Hints And Tips
HINTS AND TIPS Prepare foods in the same way as for conventional grilling. Brush lean meats and fish lightly with a little oil or butter to keep them moist during cooking. Most food should be placed on the grill pan grid in the 'high' position in the grill pan to allow maximum circulation of air around the food. -
Page 31: Defrosting
It is preferable to thaw fish, meat and poultry slowly in the fridge. However, this process can be accelerated by using the defrost function. SELECTING DEFROST (SOMERSET) (Somerset only). 1) Turn the selector to fan oven. a temperature setting. (SUSSEX) (Sussex only). -
Page 32: Things To Note
THINGS TO NOTE The oven light will illuminate. (Sussex only). The indicator neon should remain unlit. If the temperature control is inadvertently set the indicator neon will illuminate, however, no heat is generated. When defrost is selected, the oven indicator neon may occasionally come ON. -
Page 33: Helpful Hints When Buying And Preparing Food
HELPFUL HINTS WHEN BUYING AND PREPARING FOOD Care must be taken when handling foods in the home. Always follow the basic rules of food hygiene to prevent bacterial and microbial growth and cross contamination when preparing, reheating, cooking, cooling, defrosting and freezing foods. 1. -
Page 34: Care And Cleaning
The Stayclean surface inside the oven should not be cleaned manually. (Sussex only). See page 35 'Care of Stayclean Surfaces'. The vitreous enamel coating in the oven cavity of Somerset and on the oven base only, (Sussex) can be cleaned using normal oven cleaners or aerosol oven cleaners with care. -
Page 35: Care Of Stayclean Surfaces (Sussex Only)
4. Using both hands, gently tilt the top of the door glass towards you. Lift slightly to disengage the locators from the two bottom brackets. 5. Clean the outer and inner glass using hot soapy water or Flash Cream Cleaner. DO NOT try to clean the aluminium foil which is inside the door. -
Page 36: Replacing The Oven Light Bulb (Sussex Only)
REPLACING THE OVEN LIGHT BULB (SUSSEX ONLY) The type of bulb required is a 300C 25 watt small Edison Screw. Part number 572 491 5431-00/1. (Available through Tricity Bendix service centres). CAUTION: DISCONNECT THE COOKER FROM THE ELECTRICITY SUPPLY BEFORE REPLACING THE BULB. -
Page 37: Something Not Working
SOMETHING NOT WORKING We strongly recommend that you carry out the following checks on your cooker before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the cooker is under guarantee. -
Page 38: Service And Spare Parts
It is a recommendation by the manufacturer that annual servicing of the product is done by the manufacturers approved service organisation. In the event of your appliance requiring service Tricity Bendix have an arrangement with Electrolux Group Service. Before calling out an Engineer, please ensure that you have read the details under the heading 'Something Not Working?' and have the model number and purchase date to hand. -
Page 39: Customer Service Centres
CUSTOMER SERVICE CENTRES The Regional Electricity Companies are responsible for the servicing of cookers sold by their own outlets. The telephone numbers can be found in the telephone directory. Service for cookers bought from other outlets can be obtained by calling the nearest Customer Service Centre on the numbers given below. - Page 40 EH FK G KA KY1-16 ML GLASGOW PA1-23, PH1-7 GUERNSEY All Codes SA33-39 HAVERFORDWEST SA41-44 SA61-73 HR1-9 LD1-8 HEREFORD SY7 ,18 NP7-8 YO11-18 HULL YO25 HU1-19 DN14 IV1-28, 30-36, 52-56, INVERNESS PH19-26, 42-44 KW1-14 INVERNESS PH30-41 IV40-51 ISLE OF WIGHT PO30-41 ISLE OF ARRAN KA27...
- Page 41 LANCASTER LA1-23 BD DN1-7, 10-12, HD HG HX LEEDS LS S WF YO1-3, 5-8 DE NG1-22 & 25 DN21 sub codes 1 2 & 5 only, LN1, 2 , 4,5,6 LINCOLN LN3 sub codes 4 & 5 only LN8-10 NG 23,24 31-34 PE1-13, 20-25 LIVERPOOL FY PR L WN CH CW WA (Not WA 14/15)
- Page 42 01743-450279 01705-667411 01705-667411 0117-9211876 01472-267978 01252-24505 01732-357722 01273-694341 0181-658-9069 ATB3311/3321 SOMERSET - 311264806 ATB3411/3421 SUSSEX Electrolux After Sales Service Cornwall Domestic Service Unit 7D Pool Industrial Estate Wilson Way Redruth Cornwall TR15 3QW Electrolux After Sales Service D McGlashan Walker...
-
Page 43: Guarantee Conditions
All service work under this guarantee must be undertaken by a Tricity Bendix service representative or authorised agent. Any appliance or defective part replaced shall become the Company's property. - Page 44 This handbook is accurate at the date of printing, but will be superseded and should be disregarded if specifications or appearance are changed. Better Products. Better Value. TRICITY BENDIX,99 OAKLEY ROAD, LUTON, BEDFORDSHIRE, LU4 9QQ A Division of Emaco Limited Registered in England No. 176547 Registered Office. 101 Oakley Road, Luton LU4 9RJ. MODEL NO.
