Specifications - ADC 75 Ohm Interconnect Specification Sheet

Specifications

ELECTRICAL
Insertion Loss
Return Loss:
Monitor Loading Effect:
Monitor Level:
Isolation:
Cross Talk:
Phase Delay
Pulse Template:
MECHANICAL
Retention Force:
Retention Torque:
ENVIRONMENTAL
Thermal Shock:
Moisture Resistance:
Web Site: www.adc.com
From North America, Call Toll Free: 1-800-366-3891 • Outside of North America: +1-952-938-8080
Fax: +1-952-917-3237 • For a listing of ADC's global sales office locations, please refer to our web site.
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, Minnesota USA 55440-1101
Specifications published here are current as of the date of publication of this document. Because we are continuously
improving our products, ADC reserves the right to change specifications without prior notice. At any time, you may
verify product specifications by contacting our headquarters office in Minneapolis. ADC Telecommunications, Inc.
views its patent portfolio as an important corporate asset and vigorously enforces its patents. Products orfeatures
contained herein may be covered by one or more U.S. or foreign patents. An Equal Opportunity Employer
103978AE 12/06 Revision © 2002, 2006 ADC Telecommunications, Inc. All Rights Reserved
Better than -.5 dB, 100 KHz to 100 MHz
Better than -.8 dB, 100 MHz to 300 MHz
Better than -20 dB, 100 KHz to 300 MHz
< .4 dB change in insertion loss to 300 MHz
21.5 ± 1.5 dB, 100 KHz to 300 MHz
< -55 dB at 22.368 MHz
< -55 dB at 22.368 MHz
< 4 nanoseconds to 300 MHz
Conform to CCITT Recomm. G.703
7 lbs. minimum
4" per lbs. minimum
-40ºC to +60ºC operating
-55ºC to +85ºC non-operating
0% to 95%
