EEI–2801/2802
Thank you for purchasing the MODWAY ARMCHIAR!
Before you start, here are some helpful advice:
1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step
instructions.
2. Owing to the size and weight of the armchair, we recommend that it is assembled by two adults, on a
carpeted or padded area, in the room that it is intended for. Approximate assembly time: 30 minutes.
3. Please do not use any tools other than those provided or recommended in these instructions.
4. Please do not throw away any of the packaging or instructions until you have checked all the components and
hardware and the furniture is fully assembled.
5. Assemble all components loosely until advised to tighten. Depending on use, it may be necessary to tighten the
components from time to time, so please save the tools that have been provided.
6. Please keep all pieces out of reach of small children.
Component:
1
Chair Back
x1
Customer Service 908-368-1025︱www.modwayfurniture.com
ARMCHAIR
1
3
2
Chair Seat
x1
Hardware:
A
B
C
4
2
3
Left Arm
x1
Long Bolt 1/4"x35mm
Flat Washer 1/4"
Allen Wrench 1/4"
4
Right Arm
x1
Page 1 of 3
x 8
x 8
x 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for modway EEI-2801
Summary of Contents for modway EEI-2801
- Page 1 EEI–2801/2802 ARMCHAIR Thank you for purchasing the MODWAY ARMCHIAR! Before you start, here are some helpful advice: 1. We suggest you spend a short time reading through this leaflet and then follow the simple step by step instructions. 2. Owing to the size and weight of the armchair, we recommend that it is assembled by two adults, on a carpeted or padded area, in the room that it is intended for.
- Page 2 EEI–2801/2802 ARMCHAIR STEP 1: Please put Chair Back (1) on a carpeted or padded area. Place Left Arm (3) to Chair Back (1) as shown. Insert 1 piece of Bolt (A) with 1 piece of Flat Washer (B) into the holes on Chair Back (1) through the holes on Left Arm (3). Use Allen Wrench (C) to tighten Bolts (A).
- Page 3 EEI–2801/2802 ARMCHAIR STEP 3: Insert Chair Seat (2) to the assembled Chair Back (1), Left Arm (3) and Right Arm (4) as shown. STEP 4: Insert 6 pieces of Bolt (A) with 6 pieces of Flat Washer (B) into the holes on Left Arm (3) and Right Arm (4) through the holes on Chair Back (1) and Chair Seat (2).
- Page 4 EEI–2801/2802 ARMCHAIR STEP 5: Please carefully turn over the assembled chair. Put a heavy object or seat one adult on top of the Chair Seat (2) to pressure the chair for leveling. Use Allen Wrench (C) to tighten all Bolts (A) clockwise until secure. Assembly is complete.
