Step 4 — Throughput Connections
NOTE: See figure 5 for fiber cable connections. Connect the transmitter to a receiver in one of
three ways:
• One way (transmitter to receiver) only, perform step 4a.
• Two way (transmitter to receiver and return), perform steps 4a and 4b.
• Output B is available to transmit 4K @ 60 Hz uncompressed signal when the FOX3
Uncompressed Video LinkLicense is purchased.
a. Connect the fiber between the A Out port on the transmitter and the A In port on the receiver
( ).
1
NOTE: Ensure that the transmitter and connected receiver are in the same transmission
mode, singlemode (SM) or multimode (MM) and use the correct SM or MM fiber cable to
connect the devices.
b.
To return serial data from the receiver (such as responses from a controlled device), IR data, or
returned audio to the transmitter, connect a cable between the A Out port on the receiver and
A In port on the transmitter (
c. To transmit an uncompressed 4K @ 60 Hz signal, using the Uncompressed Video LinkLicense,
repeat step 4a on the SFP B port on the transmitter and receiver
SFP Link LEDs —
• Transmit Optical OUT LED lights solid green when powered and lights off when there is no power on the endpoint.
Receive Optical IN LED lights solid green when light is present and lights off when there is no power or light present.
•
Step 5 — Power Connection
Connect the IEC power connector to the power inlet (see figure 1,
receiving power.

Operation

After the receiver, the transmitter, and their connected devices are powered up, the system is fully operational. If any problems
are encountered, verify that the cables are routed and connected properly and the display device has a compatible resolution and
refresh rate. If problems persist, call the Extron S3 Sales & Technical Support Hotline. See the contact number on the
this guide.

Indications

A Power LED — Indicates power is applied to the unit.
B
USB Config port — Connect a USB mini-B cable to
a computer to configure the device and update the
firmware via PCS or internal web pages.
C Inputs LEDs —
Signal LED — Lights when the unit detects an input
•
video signal.
• HDCP LED — Lights when the input signal is HDCP
encrypted.
Digital Audio LED — Lights when digital audio is
•
selected on the transmitter.
• Analog Audio LED — Lights when analog audio is
selected on the transmitter.
D USB LEDs — Light when the unit is connected to the host device.
• Transmitter — HID Host LED and 2.0 Host LED
• Receiver — USB HID LED and USB 2.0 LED
NOTE: These LEDs indicate the receiver is communicating with the USB peripheral devices connected to the hub.
).
2
A
on page 1). The power LED lights (
INPUTS USB
SIGNAL DIGITAL AUDIO HID HOST
CONFIG
HDCP ANALOG AUDIO 2.0 HOST
A A A B B B C C C D D D
INPUT
USB
HOST 1 2
SIGNAL USB HID
CONFIG
HDCP USB 2.0
Figure 6. FOX3 T/R 301 Front Panels
OUTPUTS
B
A
OUT IN OUT IN
Transmitter
1 1 2 2
2 2 1 1
INPUTS
A B
Receiver
OUT IN OUT IN
Figure 5.
Fiber Cable Connection
B
) when the unit is
last page of
FOX3 T 301
FOX3 R 301
3
