- Page 1 R 18 - C 18 - R 24 - C 24 R 28 - C 28 - R 35 - C 35 INSTALLATION AND SERVICING MANUAL...
- Page 2 http://www.unicalag.it/prodotti/domestico-50/condensazione-gas/774/kon Provisions for proper disposal of the product. At the end of its life cycle the product must not be disposed of as urban waste. It can be taken to a special recycling centre managed by the local authorities, or to a dealer who offers this service. Separate disposal of a domestic appliance avoids possible negative consequences for the environment and human health deriving from inappropriate waste handling and allows the recovery of the materials of which it is made, in order to obtain significant energy and resource savings.
-
Page 3: Table Of Contents
Attention: this manual contains instructions for the exclusive use of the professionally qualified installer and/or maintenance technician in compliance with current legislation. The user is NOT qualified to intervene on the boiler. The manufacturer will not be held liable in case of damage to persons, animals or objects resulting from failure to comply with the instructions contained in the manuals supplied with the boiler. -
Page 4: General Information
Any repairs must be performed solely by personnel regarding installation, use and maintenance safety. authorised by Unical AG S.p.A., using original spare parts only. Failure to comply with the above can Keep the booklet with care for further consultation. -
Page 5: Symbols Used In The Manual
The appliance is designed to work in heating systems, with hot water circulation, for the production of domestic hot water. Any other use is considered improper. For any damage resulting from improper use UNICAL AG. S.p.A. assumes no respon- sibility. Use according to the intended purposes also includes strict compliance with the in- structions in this manual. -
Page 6: Safety Warnings
1.5 - SAFETY wARNINGS ATTENTION! The boiler cannot be used by children. The boiler can be used by adults and only after having carefully read the user’s ma- nual. Children should be supervised to ensure that they do not play or tamper with the device. -
Page 7: Technical Data Plate
1.6 - TECHNICAL DATA PLATE The CE marking KEY: certifies the compliance of the equipment with the 1 = CE monitoring body essential safety requirements defined in the directi- 2 = Type of boiler 3 = Boiler model ves and applicable European regulations and that 4 = Number of stars (directive 92/42 EEC) its functioning satisfy applicable technical stan- 5 = (S.N°) Serial Number... -
Page 8: Water Treatment
1.7 - wATER TREATMENT The treatment of the supply water ATTENTION! allows to prevent inconveniences ANY DAMAGE TO THE BOILER CAUSED BY and maintain the functionality and THE FORMATION OF FOULING OR BY COR- efficiency of the generator over time. ROSIVE wATER wILL NOT BE COVERED BY THE wARRANTY. -
Page 9: Boiler Antifreeze Protection
This protection can intervene only if 1.8 - BOILER ANTIFREEZE the electricity and gas supplies are PROTECTION connected. If one of the two is not available and To activate the antifreeze function only, po- upon reset 11 (SR) a temperature of < 2 sition the two knobs as shown in the figure. -
Page 10: Technical Features And Dimensions
TECHNICAL FEATURES AND DIMENSIONS NOTE! For further details refer to the Technical 2.1 - TECHNICAL FEATURES Information from the website 2.2 - VIEw wITH THE INDICATION OF THE MAIN COMPONENTS AND DIMENSIONS KON m C18 - KON m C24 N° C.E. - Page 11 KON m C28 / KON m C35 Diverter valve Cold water inlet G ½ Heating system flow G ¾ Plate heat exchanger Heating system return G ¾ Obstruction Pressure Fan Filling valve Boiler drain Safety valve Safety valve drain Scond Condensation drain Return temperature sensor C.E.
- Page 12 KON m C18 - KON m C24 ® service View from above View from below Scond...
- Page 13 KON m C28 / KON m C35 ® service View from above View from below Scond 251,5 168,5...
-
Page 14: Available Flow Rate / Pressure Diagram
2.3 - DIAGRAM OF FLOw RATE/PRESSURE AVAILABLE FOR INSTALLATION MODULATING PUMP DIAGRAM OF FLOw RATE/PRESSURE AVAILABLE FOR INSTALLATION 18 - 24 = 6m Flow rate (l/h) 28 - 35 = 7m Flow rate (l/h) -
Page 15: Operation Data
2.4 - OPERATING DATA For the adjustment data: NOZZLES - PRESSURES - DIAPHRAGMS - FLOW RATES - CONSUMPTIONS refer to the paragraph ADAPTATION TO OTHER TYPES OF GAS. R 18 - C 18 R 24 - C24 R 28 - C28 R 35 - C35 Nominal heat input in CH / DHW mode 18,0 / 23,4 23,4 / 23,4 28,0 / 28,0 33,0 / 33,0 Minimum heat input with Nat. - Page 16 2.6 - DATA ACCORDING TO ErP DIRECTIVE Description Symbol Unit Modello: KON C18 R24 C24 R28 C28 R35 Nominal Heat Output Pnominal Seasonal space heating energy ƞ efficiency Seasonal efficiency class in heating mode For CH only and combination boilers: useful heat output Useful Heat Output in high-tempera- ture regime 10,3...
-
Page 17: Installation Instructions
INSTALLATION INSTRUCTIONS 3.1 - GENERAL wARNINGS ATTENTION! If there is dust and/or if there are aggressive/corrosive vapours ATTENTION! present in the installation room, This boiler is intended solely for the appliance must be protected the use for which it was expressly suitably and must be able to designed. -
Page 18: Packaging
- Certificate of conformity they are potential sources of danger. Unical AG S.p.A. will not be held liable for damage to persons, animals or ob- B - Connection predisposition paper template jects due to failure to comply with the instruction above. -
Page 19: Positioning The Boiler
3.5 - POSITIONING THE BOILER When choosing the place of the installation of the Clearance appliance, follow the safety instructions below: - Place the appliance in rooms protected from frost. - Avoid installation in rooms with a corrosive or very dusty atmosphere. -
Page 20: Flue Gas Exhaust Pipe Connection
Please note: these values relate to if < 0 = NO exhausts/made by means of rigid WRONG configuration pipes and smooth original UNICAL. ATTENTION [m] = equivalent meters (*) Values in the MT018 available on the website (technical info section) - Page 21 C43x C63x Boiler intended for connection to a combustion air intake and combustion products evacuation system, approved and sold separately ATTENTION: The flue must comply with standards in force. C83x Collective chimney flue system, consisting of two pipes, one for combustion air intake and the other one for combustion products evacuation, coaxial or double.
- Page 22 B23P It is recommended to only use original Unical exhaust pipes. The supplier will have no contractual or extra-contractual liability for damage caused due to incorrect installation and TOTAL LENGTH (LS) use and in any case failure to comply DOUBLE Ø80 with the instructions provided by the manufacturer.
-
Page 23: Connections
3.7 - CONNECTION Condensation drain The boiler, during the combustion process, pro- 3/4’’ duces condensation that, through pipe “A”, flows into the trap. Danger! The condensation that forms inside the boiler flows The gas connection must be carried out into a suitable drain via pipe “B”. only by a qualified installer who must re- spect and apply that foreseen by relevant laws in force in the local prescriptions of... -
Page 24: Filling The System
This could damage the gaskets and cause noise during operation. Unical will not be held liable for dam- age to persons, animals or objects due to failure to comply with the above instruction. -
Page 25: Electrical Connections
3.9 - ELECTRICAL CONNECTIONS Danger! any type of operation on electrical parts, always Only a qualified technician may per- disconnect electrical power and make sure that form the electrical installation. it cannot be reconnected accidentally. Before performing connections or 00330914 ATTENZIONE! ATTENTION! ACHTUNG! - Page 26 External probe connection (*) Electric power supply connection - Predisposed on the terminal board, terminals See par. 4.5 positioning on the board Isolation transformer (*) Optional The boiler is equipped with a power cable, boiler installation requires electric al con- nection to the mains power supply.
-
Page 27: Commissioning
3.10 - COMMISSIONING Commissioning must be done by profes- failure to comply with the above instruction. sionally qualified personnel. Unical AG Before commissioning the boiler, check that: S.p.A. will not be held liable for damage to persons, animals or objects due to... -
Page 28: Measurement Of Combustion Efficiency During Installation
3.11 - MEASUREMENT OF COMBUSTION EFFICIENCY DURING INSTALLATION 3.11.1- ACTIVATION OF THE CALIBRATION FUNCTION ATTENTION! The user is NOT authorised to activate Function reserved for Authorised the function described below. Assistance Centres only. MINIMUM OUTPUT ACTIVATION By turning the knob (B) in position , the boiler By pressing the button (D) for 3 seconds, the will operate at minimum output:... -
Page 29: Burner Adjustment
3.12 - ADJUSTING THE BURNER Attention, during these operations do not take probe in the flue gas sample point of the intake/ any samples in domestic hot water mode. exhaust terminal, see chap. 3.11.2. All boilers leave the factory already cali- The following instructions are intended brated and tested, however in the event exclusively for authorised service per-... - Page 30 model: KON m 28 - KON m 35 2) Minimum output adjustment 1) Maximum output adjustment - Operate the boiler in “calibration” mode at MAXI- - Operate the boiler in “calibration” mode at MINI- MUM OUTPUT (see 3.11.1) MUM OUTPUT (see 3.11.1) - Once the burner is on check - Once the burner is on check that the CO “MINI-...
- Page 31 NOZZLES - PRESSURE - FLOw RATES TABLE Check the levels of CO2 often, especially with low flow rates. They refer to the boiler with a closed combustion chamber. R 18 - KON C 18 (#) Collector Diaphragm Start-up Type of Heating Supply levels...
-
Page 32: Adaptation Of The Power To The Heating System
3.12.1 - ADAPTATION OF THE POwER TO THE HEATING SYSTEM ATTENTION! The user is NOT authorised to activate the func- Function reserved for Authorised tion described below. Assistance Centres only. It is possible to adjust the maximum thermal capacity Act on parameter HP (par. 4.2 parameters that can in heating mode, by decreasing the burner output be edited from control panel) to achieve the value value. -
Page 33: Maintenance Instructions
• Vent and, if necessary, restore the heating pres- and to avoid altering its approved status, only original sure until reaching a pressure of 0.8/1.0 bar. Unical spare parts must be used. • Open the gas shut-off valve. • Switch the boiler on If a component needs to be replaced: •... - Page 34 It is recommended to use the using a meter and compare the val- products purposely created by ue with that contained in table 3.12. Unical (see system protection The data measured indicates if the ACCESSORIES sect. in the exchanger needs cleaning.
-
Page 35: Parameters That Can Be Edited From The Control Panel
4.2 - PARAMETERS THAT CAN BE EDITED FROM THE CONTROL PANEL ATTENTION! Function reserved for Authorised As- sistance Centres only. Some service parameters can be edited from the control panel: ACTIVATION PREHEATING VALUES FROM DEFAULT By pressing the button (D) for 10 seconds, the function is activated when the key flashes on the display SELECTION... -
Page 36: Adaptation To The Use Of Other Gas
DISABLING To exit the parameters list wait for 20” or quickly turn the domestic hot water knob ‘‘C’’. 4.3 - ADAPTATION TO THE USE OF OTHER GAS To convert the boiler from one type of gas to The boilers are produced for the type of gas specif- ically requested upon ordering. - Page 37 Model KON m 28 - KON m 35: - Disconnect the appliance from the elctrical power supply - Close the gas inlet tap - Remove gas valve (unscrew connection 2, wrench - Insert gaskets 6 30 mm). - Proceed with assembly in reverse order. - Remove the gas diaphragm 4 - Access the modulation board contained in the electric panel and position the jumper in the...
- Page 38 4.3.1 - Ending of gas transformation - Close the electric panel and restore the appliance’s electric power supply; - Check the pressure value upstream of the gas valve (see table “NOZZLES - PRESSURE”) and adjust the CO as indicated in paragraph “3.12”; - Check that the burner is working properly;...
-
Page 39: Wiring Diagram
4.5 - wIRING DIAGRAM Practical connection board Model KON m 18 - KON m 24 DK FLS SS SR SS SR TA 1/OT TA 2 VM (R) 3 2 1 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 4 3 2 1 7 6 5... - Page 40 Model KON m 28 - KON m 35 DK FLS SS SR SS SR TA 1/OT TA 2 VM (R) 3 2 1 4 3 2 1 8 7 6 5 4 3 2 1 8 7 6 5 4 3 2 1 4 3 2 1 7 6 5 4 3 2 1...
-
Page 41: Error Codes
4.6 - ERROR CODES The symbol flashes on the display monitor when the boiler detects an anomaly. service 1) In the event of an anomaly that does not stop boiler operation, press the unblock key to display the error code; in the event the boiler is in stand-by, the error code appears and remains fixed on the display. - Page 42 SPEED OUT OF Check fan operation (18) and CONTROL the connections. Alteration of the fan speed; the speed is not reached. SPEED OUT OF Check fan operation (18) and CONTROL the connections. Alteration of the fan speed; the speed is above that requested. HIGH TEMPERATURE Check pump operation and if Boiler temperature too high.
- Page 43 BLOCK Check the gas supply or that No gas or failed burner ignition the ignition/detection electrode is working properly (4) PARASITE FLAME Check the wiring of the Ign/Det. Flame detected upon ignition. electrode and remove any ox- idation, check for humidity be- tween drain wire and ceramic, if necessary, press the unblock key, if the anomaly persists,...
- Page 44 - export@unical-ag.com - www.unical.eu Unical declines every responsibility for the possible inaccuracies if owed to errors of transcript or press. Also reserves the right to bring those changes that it will hold necessary to it own products or profits, without jeopardizing its essential characteristics.
