Step 5: Positioning The Oral Inflator Hose Of The Backup Wing - Razor SIDE MOUNT SYSTEM Manual

2 Rigging the Razor BAT Wing

Step 5: Positioning the Oral Inflator Hose of the Backup Wing

The oral inflator of the Backup wing should be routed over the right shoulder
and can be held securely in place by passing it under the long neoprene logo
wrap and the bycicle inner tube on the right hand shoulder of the Razor Harness
webbing.
The hose should bend towards the center of the chest just above the right
shoulder D ring and should be long enough to reach the mouth comfortably.
It can be held in place in a clean streamlined fashion by passing it through a
couple of bicycle tire inner tubes placed around the large diameter inflation
hose spaced a few inches apart.
Any excess hose can be cut off to customize the length. Remove the bite on
mouthpiece, cut the hose to the desired length and then replace the mouth-
piece.
