Razor SIDE MOUNT SYSTEM Manual page 39

4 Rigging the Razor Harness 2.5
Step 6: Fixing Attachment Hardware on the Waist Straps
W W W . G O S I D E M O U N T . C O M
Now move the serrated belt slides and 2" straight D Rings until they are posi-
tioned just behind the hipbone on each side of the waist strap webbing.
W W W . G O S I D E M O U N T . C O M
Make sure that both D Rings are positioned evenly and far enough back that
the bottom of the Side-Mount Tanks will not hang down below the body when
trimmed out in a horizontal position.
W W W . G O S I D E M O U N T . C O M
Weights can be added to the Waist Strap between the DAPs and the Hip D ring
if required but it is recommended to use the T Weight System rather than add
weight directly to the Razor Harness itself (see Step 9: Weighting and Trim).
Hardware on both sides of the waist straps will have to be removed in order to
do this.
W W W . G O S I D E M O U N T . C O M
Extra attachment hardware such as a second D ring on each side can be added
at this point if required.
W W W . G O S I D E M O U N T . C O M
39
A
D C C D
B
