Razor SIDE MOUNT SYSTEM Manual page 42

4 Rigging the Razor Harness 2.5
Step 7: Fitting the Low Profile Buckle
W W W . G O S I D E M O U N T . C O M
The loop of webbing between the buckle and the wide gauge Tri-glide should
be small enough so that neither of the buckle plates can rotate and are held in
the correct orientation.
W W W . G O S I D E M O U N T . C O M
The buckle should be positioned to fasten in the middle of the waist and be
covered by the crotch strap loop to streamline the configuration.
W W W . G O S I D E M O U N T . C O M
Make sure to leave plenty of extra webbing for any adjustments that may be
required later then cut off any excess and burn the end to seal it.
W W W . G O S I D E M O U N T . C O M
The free end of the webbing should be on the inside of the left Waist Strap and
can be held neatly in place with the loop of bicycle tire inner tube provided.
W W W . G O S I D E M O U N T . C O M
