Razor SIDE MOUNT SYSTEM Manual page 30

4 Rigging the Razor Harness 2.5
Step 1: Rigging the Razor Harness
W W W . G O S I D E M O U N T . C O M
Pass each shoulder strap through the inside of slot C on the MBP then back out
through slot D.
W W W . G O S I D E M O U N T . C O M
The Harness should assume a "Heart Shape" at this point with the shoulder
straps entering on the inside of the MBP and the Waist Straps exiting on the
outside.
W W W . G O S I D E M O U N T . C O M
Tighten the shoulder straps until you have a snug fit which is even on both sides
with the DSP and MBP centered along the midline of your back and the MBP at
the desired height.
W W W . G O S I D E M O U N T . C O M
30
A
D C C D
B
