Saxby Lighting Scimitar Series Instruction Leaflet

PIR Specification

73452, 73454, 73456, 73458, 73460 and 73462 are fitted with PIR motion sensor. The specification
is as follows:-
Optimum mounting height: 1.8-2.5m
Timer Function (TIME): 10±3 seconds to 7±2 minutes
Detection angle: 120˚
Detection distance (SENS) : 2-8m
Lux Range (LUX): <10-2000 lux
The sensor rotates and the controls can be found on the back of the sensor.
Complete with manual override function:
• Switch unit on for over 1 minute.
Switch off and back on within 2 seconds . Unit then stays permanently on.
•

Fitting/replacing bulbs

• This system contains non-replaceable parts and cannot be serviced. If damage occurs the part should
be scrapped.
We recommend cleaning with a soft dry cloth.
Do not use solvents or abrasive cleaners as these could damage the finish.

Recycling advice

Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.

Safety information

For your safety, always switch off the supply before cleaning.
www.saxbylighting.com
www.saxbylighting.com
TIME SENS LUX
Iss3 18/03/2018
Saxby lighting. BH23 3PE
Saxby Lighting, BH23 3PE
Instruction leaflet
Scimitar Floodlight
73451, 73452, 73453, 73454, 73455, 73456, 73457, 73458, 73459,
73460, 73461, 73462
