Commissioning

• Refit the product onto the bracket, taking care to fit
the washers back in the correct position.
• Adjust the cable so it does not get snagged. Ensure
that the cable gland is properly tightened.
• Ensure that the seal is intact and fitted correctly. Refit

Fitting/replacing bulbs

• When changing a bulb, always switch off at the mains
and allow the bulb to cool before handling. Dispose of
used bulbs carefully. Use a soft cloth to handle bulbs,
avoid directly touching the bulbs as this will shorten
their life.
• Always ensure that you always use the correct
wattage lamp to match the control gear. Use of
incorrect lamp will damage the lamp and the control
gear. The lamp must be fitted in accordance with the
lamp manufactures instructions. Failed lamps must be
replaced immediately otherwise damaged may occur
THE LUMINAIRE SHALL ONLY BE USED COMPLETE WITH ITS PROTECTIVE SHIELD.
We recommend cleaning with a soft damp cloth.
Do not use solvents or abrasive cleaners as these could

Recycling advice

Waste electrical products should not be disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or retailer for recycling advice.

Safety information

Live Voltages may be present in this unit even when turned of or when completely disconnected.
For your safety, always switch off the supply before changing lightbulbs, or cleaning.
This bulb is protected by a glass shade. This part must be replaced immediately should the glass
shade become cracked or damaged. This fitting must not be used without the glass shade in place.
Replace Cracked
Shade
www.saxbylighting.com
the wiring cover and tighten the screw.
• Set the desired angle for the floodlight and tighten the
bolts.
• Replace fuse or circuit breaker and switch on. Your
light is now ready for use.
to the gear and ignitor.
• The Lamps fitted must be suitable for use
E
with an external ignitor.
PRS250 :
250W E40 SONT or 250W E40 HQIT
PRS400 :
400W E40 SONT or 400W E40 HQIT
250W E40 SONT
250W E40 HQIT
400W E40 SONT
400W E40 HQIT
damage the finish.
Do not jet wash these to clean.
Iss.1 18122012
Saxby Lighting Ltd. BH23 3PE
Instruction leaflet
Deluge Floodlight
PRS250, PRS400

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deluge PRS250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Saxby Lighting Deluge PRS250

  • Page 1 Instruction leaflet Commissioning • Refit the product onto the bracket, taking care to fit the wiring cover and tighten the screw. the washers back in the correct position. • Set the desired angle for the floodlight and tighten the Deluge Floodlight • Adjust the cable so it does not get snagged. Ensure bolts. that the cable gland is properly tightened. • Replace fuse or circuit breaker and switch on. Your • Ensure that the seal is intact and fitted correctly. Refit light is now ready for use. PRS250, PRS400 Fitting/replacing bulbs • When changing a bulb, always switch off at the mains to the gear and ignitor.
  • Page 2 Installation Thank you for purchasing this light fitting. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Please retain these instructions for future reference. Existing fittings must be completely removed before • Undo the screws holding the wiring cover in place installation of a new product. Before removing the and set aside. existing fitting, carefully note the position of each set Warning of wires. • Decide on the most appropriate position based on This is a Class 1 product and must be earthed. gear. Do not operate with a failed bulb or without a the layout instructions given above. bulb as this may damage the unit. Please read these instructions carefully before • We recommend that the bracket is removed from the commencing any work.
