Page 1 B022/B027 SERVICE MANUAL 001197MIU RICOH GROUP COMPANIES...
Page 3 Š Š RICOH GROUP COMPANIES...
Page 5 B022/B027 SERVICE MANUAL 001197MIU...
Page 7 It is the reader's responsibility when discussing the information contained within this document to maintain a level of confidentiality that is in the best interest of Ricoh Corporation and its member companies. NO PART OF THIS DOCUMENT MAY BE REPRODUCED IN ANY FASHION AND DISTRIBUTED WITHOUT THE PRIOR PERMISSION OF RICOH CORPORATION.
Page 9 Ricoh Corporation. Users of this manual should be either service trained or certified by successfully completing a Ricoh Technical Training Program. Untrained uncertified users utilizing...
Page 11 LEGEND COMPANY PRODUCT CODE GESTETNER LANIER RICOH SAVIN B022 2212 5622AG Aficio 1022 2522 B027 2712 5627AG Aficio 1027 2527 DOCUMENTATION HISTORY REV. NO. DATE COMMENTS 11/2001 Original Printing...
Page 13: Table Of Contents
B022/B027 TABLE OF CONTENTS INSTALLATION 1 OVERALL MACHINE INFORMATION ......... 1-1 1.1 SPECIFICATIONS ..................1-1 1.2 MACHINE CONFIGURATION ..............1-5 1.2.1 SYSTEM COMPONENTS ............... 1-5 1.2.2 INSTALLABLE OPTION TABLE ............1-7 Copier options ..................1-7 Fax option .................... 1-7 Printer/scanner options ................ 1-7 1.3 PAPER PATH ...................
Page 14 Toner bottle replenishment mechanism ..........2-35 Toner supply mechanism ..............2-36 2.6.6 TONER DENSITY CONTROL ............2-37 Overview .................... 2-37 Toner density sensor initial setting ............. 2-39 Toner density measurement .............. 2-39 Vsp/Vsg detection ................2-39 Toner supply reference voltage (Vref) determination ......2-39 B022/B027...
Page 15 2.10.2 FUSING DRIVE AND RELEASE MECHANISM......2-62 2.10.3 FUSING ENTRANCE GUIDE SHIFT MECHANISM ....2-63 2.10.4 PRESSURE ROLLER..............2-64 2.10.5 CLEANING MECHANISM............2-64 2.10.6 FUSING TEMPERATURE CONTROL......... 2-65 Temperature Control ................2-65 Fusing Lamp Control................2-66 2.10.7 OVERHEAT PROTECTION............2-67 2.10.8 PAPER EXIT................2-67 B022/B027...
Page 16 3.7.2 INSTALLATION PROCEDURE............3-23 3.8 SHIFT TRAY................... 3-26 3.8.1 COMPONENT CHECK ..............3-26 3.8.2 INSTALLATION PROCEDURE............3-26 3.9 BY-PASS FEED UNIT INSTALLATION ..........3-28 3.9.1 COMPONENTS CHECK..............3-28 3.9.2 INSTALLATION PROCEDURE............3-28 3.10 DUPLEX UNIT INSTALLATION............3-30 3.10.1 ACCESSORY CHECK ..............3-30 B022/B027...
Page 17 SP1-XXX: Feed ..................4-6 SP2-XXX: Drum ..................4-16 SP4-XXX: Scanner ................4-25 SP5-XXX: Mode..................4-31 SP6-XXX: Peripherals.................4-41 SP7-XXX: Data Log ................4-43 SP9-XXX: Debug/Testing ..............4-52 4.2.3 TEST PATTERN PRINTING (SP2-902-3) ........4-53 4.2.4 INPUT CHECK ................4-54 Main Machine Input Check (SP5-803) ..........4-54 ARDF Input Check (SP6-007).............4-57 B022/B027...
Page 18 SBCU: DIP SW102 ................4-77 4.9 SPECIAL TOOLS AND LUBRICANTS ........... 4-78 4.9.1 SPECIAL TOOLS................4-78 4.9.2 LUBRICANTS ................4-78 PREVENTIVE MAINTENANCE SCHEDULE 5 PREVENTIVE MAINTENANCE SCHEDULE........ 5-1 5.1 PM TABLE ....................5-1 REPLACEMENT AND ADJUSTMENT 6 REPLACEMENT AND ADJUSTMENT......... 6-1 B022/B027...
Page 19 6.7 PCBS AND OTHER ITEMS ..............6-32 6.7.1 CONTROLLER BOARD..............6-32 6.7.2 SBCU BOARD ................6-33 6.7.3 POWER PACK................6-33 6.7.4 MAIN MOTOR................6-34 6.7.5 PSU ....................6-35 6.8 COPY ADJUSTMENTS: PRINTING/SCANNING ........6-36 6.8.1 PRINTING..................6-36 Registration - Leading Edge/Side-to-Side .......... 6-36 B022/B027...
Page 20 7.6 BLOWN FUSE CONDITIONS ..............7-21 PAPER TRAY UNIT (A860/B390) 1 OVERALL MACHINE INFORMATION.......... 8-1 1.1 SPECIFICATIONS..................8-1 1.2 MECHANICAL COMPONENT LAYOUT ...........8-2 1.3 ELECTRICAL COMPONENT LAYOUT.............8-3 1.4 ELECTRICAL COMPONENT DESCRIPTION...........8-4 1.5 DRIVE LAYOUT ..................8-5 2 DETAILED DESCRIPTIONS ............8-6 B022/B027 viii...
Page 21 3.2 REAR FENCE HP SENSOR ..............9-11 3.3 CHANGING THE TRAY PAPER SIZE ............9-12 3.4 LEFT TRAY PAPER END SENSOR ............9-12 3.5 TRAY LIFT MOTOR ................9-13 3.6 TRAY MOTOR..................9-14 3.7 PAPER FEED CLUTCH AND RELAY CLUTCH........9-15 3.8 PAPER FEED UNIT ................9-16 B022/B027...
Page 22 4.7 ORIGINAL SET/ORIGINAL REVERSE SENSOR .........10-25 4.8 ORIGINAL SIZE SENSOR ..............10-26 4.9 ORIGINAL FEED DRIVE ...............10-27 DF Feed Clutch.................10-27 Pick-up Solenoid ................10-27 Transport Motor ................10-27 DF Feed Motor..................10-27 4.10 REGISTRATION SENSOR..............10-28 4.11 STAMP SOLENOID AND ORIGINAL EXIT SENSOR ......10-29 B022/B027...
Page 23 1.2 COMPONENT LAYOUT ................13-2 2 DETAILED SECTION DESCRIPTIONS ........13-3 2.1 BASIC OPERATION................13-3 2.2 PRIMARY MECHANISMS ...............13-4 2.2.1 TRAY SHIFT...................13-4 2.2.2 HALF TURN DETECTION..............13-5 3 REPLACEMENT AND ADJUSTMENT ........13-6 3.1 TRAY COVER REPLACEMENT .............13-6 3.1.1 TRAY COVER REMOVAL..............13-6 B022/B027...
Page 24 Up to A4 sideways/LT sideways ............15-7 2.2 FEED IN AND EXIT MECHANISM ............15-8 When paper is fed into duplex unit:.............15-8 Inversion and Exit: ................15-8 3 REPLACEMENT AND ADJUSTMENT ........15-9 3.1 COVER REMOVAL .................15-9 3.2 ENTRANCE SENSOR REPLACEMENT ..........15-10 3.3 EXIT SENSOR REPLACEMENT............15-11 B022/B027...
Page 25 3.1 DIP SWITCH SETTINGS ................17-9 4 DETAILED DESCRIPTIONS ............. 17-10 4.1 GENERAL LAYOUT ................17-10 4.2 ELECTRICAL COMPONENT LAYOUT..........17-11 4.3 ELECTRICAL COMPONENT DESCRIPTION........17-13 4.4 DRIVE LAYOUT ..................17-15 4.5 JUNCTION GATES ................17-17 Upper tray mode ................17-17 Sort/stack mode ................17-17 Staple mode..................17-17 xiii B022/B027...
Page 26 2.2.1 OUTPUT TRAY MECHANISM .............18-14 Stack height detection...............18-14 Output tray up/down mechanism ............18-15 2.2.2 PAPER FEED ................18-16 Overview...................18-16 Straight feed out mode..............18-16 Shift sorting mode ................18-17 Stapling mode...................18-19 2.2.3 JAM CONDITIONS ...............18-20 2.2.4 ERROR DETECTION ..............18-20 3 OVERALL MACHINE INFORMATION........18-21 3.1 SPECIFICATIONS..................18-21 B022/B027...
Page 27 Rev. 11/2002 FIRMWARE HISTORY 1 FIRMWARE HISTORY ..............19-1 1.1 FIRMWARE MODIFICATION HISTORY ..........19-1 1.1.1 FIRMWARE MODIFICATION HISTORY (CONTROLLER) ....19-1 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) ......19-3 1.1.3 FIRMWARE MODIFICATION HISTORY (LCDC) ......19-4 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) ....19-5 B022/B027...
Page 28 3.4 FIRMWARE UPDATE PROCEDURE............3-11 3.5 POWER-ON SELF TEST ................3-11 3.6 SELF DIAGNOSTIC TEST ..............3-11 3.7 USER PROGRAM MODE ...............3-12 3.7.1 PRINTER USER PROGRAM MODE..........3-12 3.7.2 SCANNER USER PROGRAM MODE ..........3-13 DETAILED SECTION DESCRIPTIONS 4 DETAILED SECTION DESCRIPTIONS ........4-1 B022/B027...
Page 29 SPECIFICATIONS SPECIFICATIONS 1 GENERAL SPECIFICATIONS..............5-1 1.1 PRINTER.....................5-1 1.2 SCANNER ...................5-3 2 SOFTWARE ACCESSORIES ..............5-4 2.1 PRINTER.....................5-4 Printer Drivers..................5-4 Utility Software ..................5-4 2.2 SCANNER ...................5-5 Scanner Driver ..................5-5 Scanner Utilities ..................5-5 3 MACHINE CONFIGURATION ..............5-6 3.1 SYSTEM COMPONENTS ..............5-6 xvii B022/B027...
Page 30 2.3.4 FAX SC CODE TABLE ..............2-16 2.4 ISDN TEST FUNCTION ................2-17 2.4.1 LEDS ....................2-17 2.4.2 BACK-TO-BACK TEST..............2-18 SERVICE TABLES 3 SERVICE TABLES................ 3-1 3.1 SERVICE PROGRAM MODE..............3-1 3.1.1 SERVICE PROGRAM MODE OPERATION........3-1 Entering and Exiting SP mode ..............3-1 B022/B027 xviii...
Page 31 Memory back-up ...................4-3 Switches ....................4-3 4.2.3 NCU (US) ..................4-4 4.2.4 NCU (EUROPE/ASIA) ..............4-5 4.2.5 SG3 BOARD..................4-6 CCP (Communication Control Processor) ..........4-6 Flash ROM....................4-6 DRAM ....................4-6 QM coder ....................4-6 V.34 Modem ..................4-6 4.2.6 SIG4 BOARD..................4-7 ICCP (ISDN Communication Control Processor) ........4-7 CODEC....................4-7 B022/B027...
Page 32 Regular transmission: .................4-19 Print and transmission ................4-19 Using Document Server..............4-19 4.5 ROM HISTRORY..................4-20 4.5.1 FCU ROM HISTORY ..............4-20 4.5.2 FAX APPLICATION ROM HISTORY..........4-21 SPECIFICATIONS SPECIFICATIONS................5-1 1 GENERAL SPECIFICATIONS..............5-1 2 CAPABILITIES OF PROGRAMMABLE ITEMS ..........5-3 3 MACHINE CONFIGURATION ..............5-4 B022/B027...
Page 33 IMPORTANT SAFETY NOTICES PREVENTION OF PHYSICAL INJURY 1. Before disassembling or assembling parts of the copier and peripherals, make sure that the copier power cord is unplugged. 2. The wall outlet should be near the copier and easily accessible. 3. If any adjustment or operation check has to be made with exterior covers off or open while the main switch is turned on, keep hands away from electrified or mechanically driven components.
Page 34 LASER SAFETY The Center for Devices and Radiological Health (CDRH) prohibits the repair of laser-based optical units in the field. The optical housing unit can only be repaired in a factory or at a location with the requisite equipment. The laser subsystem is replaceable in the field by a qualified Customer Engineer.
Page 35 INTERCHANGE UNIT B300/B416 PRINTER/SCANNER CONTROLLERS B453/B461 SERVICE TABLES B022/B027 1-BIN TRAY UNIT A898/B413 FAX UNIT B418 PREVENTIVE MAINTENANCE B022/B027 SHIFT TRAY UNIT B313/B459 REPLACEMENT AND ADJUSTMENT B022/B027 BY-PASS A899/B415 TROUBLESHOOTING B022/B027 DUPLEX A896/B414 PAPER TRAY UNIT A860/B390 BRIDGE UNIT A897/B417 FIRMWARE HISTORY...
Page 37: Overall Machine Information
OVERALL MACHINE INFORMATION...
Page 39: Specifications
, 16 ~ 43 lb (2nd paper tray) By-pass (Option): 52 ~ 157 g/m , 16 ~ 42 lb Reproduction Ratios: 5 Enlargement and 7 Reduction A4/A3 Version LT/DLT Version 400% 400% 200% 200% Enlargement 141% 155% 122% 129% 115% 121% Full Size 100% 100% Reduction B022/B027...
Page 40 63 dB(A) Operating (Full System): 68.5 dB(A) NOTE: 1) The above measurements were made in accordance with ISO 7779. 2) Full System: Mainframe + ADF + 1-bin Sorter + Paper Tray Unit + Duplex Unit + Bridge Unit + Finisher B022/B027...
Page 41 NOTE: Measurement Conditions 1) With the paper tray unit or LCT 2) Without the ADF Weight: Less than 55 kg (121.3lb) Copying Speed (copies/minute): A4 sideways/ B022 A3/11" x 17" 11" x 8 " Non-memory copy mode Memory copy mode A4 sideways/ B027 A3/11"...
Page 42 11 k copies (A4 sideways, 6% full black, 1 to 1 copying, ADS mode) Copy Tray Capacity: Copy Tray: 500 sheets (without 1-bin tray) 250 sheets (with 1-bin tray) Memory Capacity: Standard 32 MB, Optional memory either 32 MB or 64MB B022/B027...
Page 43: Machine Configuration
MACHINE CONFIGURATION Rev. 10/2002 1.2 MACHINE CONFIGURATION 1.2.1 SYSTEM COMPONENTS ⇒ B022/B027...
Page 44 Printer & Scanner unit B453 Common with B031 B462 G335 IEEE 1394 G590 Common with B003/B004 Note: 1) The B022/B027 has a new exterior color (same as B003/B004). 2) The Drive Motor and Control Board for these peripherals have been changed. B022/B027...
Page 45: Installable Option Table
MACHINE CONFIGURATION 1.2.2 INSTALLABLE OPTION TABLE Copier options Option B022/B027 Note ARDF (Optional) Install either no. 1 or 2. Platen Cover (Optional) Install either no. 1 or 2. Paper Tray Unit – two-tray Install either no. 3 or 4. (Optional) LCT (Optional) Install either no.
Page 46: Paper Path
PAPER PATH 1.3 PAPER PATH B022V155.WMF 1. Optional ADF 2. Optional 1-bin Tray 3. Optional Interchange Unit 4. Optional Duplex Unit 5. Optional By-pass Feed Tray 6. Optional Paper Tray Unit 7. Optional 1000-sheet Finisher 8. Optional Bridge Unit B022/B027...
Page 47: Mechanical Component Layout
MECHANICAL COMPONENT LAYOUT 1.4 MECHANICAL COMPONENT LAYOUT B027V502.WMF B022/B027...
Page 48 23. Polygon mirror motor 10. Fusing hot roller 24. Laser unit 11. Fusing pressure roller 25. Toner supply bottle holder 12. Cleaning unit 26. Drum charge roller 13. OPC drum 27. Anti-condensation heater 14. Transfer roller 28. Scanner home position sensor B022/B027 1-10...
Page 49: Electrical Component Descriptions
(related to the APS/ARE functions). Detects original width. This is one of the APS (Auto Original Width Paper Select) sensors. Detects original length. This is one of the APS (Auto Original Length 1 Paper Select) sensors. 1-11 B022/B027...
Page 50 Memory (Option) and scanner features. IPU (Image Processing PCB10 Performs the image processing functions. Unit) Solenoids SOL1 Fusing Drive Release Releases the drive for the fusing unit. Lamps Applies high intensity light to the original for Exposure Lamp exposure. B022/B027 1-12...
Page 51 LSD 1 Detector Mechanical Counter Keeps track of the total number of prints made. Used for control of authorized use. If this feature is Key Counter (Option) enabled for copying, copying will be impossible until it is installed. 1-13 B022/B027...
Page 52: Drive Layout
DRIVE LAYOUT 1.6 DRIVE LAYOUT Scanner B027V301.WMF Fusing PCU/Transfer Drive B027V302.WMF 1. Scanner Drive Motor 2. Main Motor 3. Registration Clutch 4. Upper Paper Feed Clutch 5. Upper Transport Clutch 6. Lower Paper Feed Clutch 7. Lower Transport Clutch B022/B027 1-14...
Page 53: Copy Process
In the dark, the charge roller gives a negative charge to the organic photo- conductive (OPC) drum. The charge remains on the surface of the drum because the OPC layer has a high electrical resistance in the dark. 1-15 B022/B027...
Page 54 8. CLEANING The cleaning blade removes any toner remaining on the drum surface after the image transfers to the paper. 9. QUENCHING The light from the quenching lamp electrically neutralizes the charge on the drum surface. B022/B027 1-16...
Page 55: Board Structure
A R D F S B U Sensors Stabilizer Motor Motor L S D L C T S B C U P S U High Bridge Clutches/ Ther- By-pass Duplex 1-Bin Tray Finisher Sensors Motors Voltage mistors Unit Solenoids B027V500.WMF 1-17 B022/B027...
Page 56 This is the scanned image processing board. It controls the following functions. • Image processing control • Video control 4. SBU (Sensor Board Unit) The SBU deals with the analog signals from the CCD and converts them into digital signals. B022/B027 1-18...
Page 57: Controller
• Fax • Operation panel • PostScript 3 • SBCU (engine control) • NIB • Printer • FCU • Scanner For details about how to download software from an IC card, see “Software Download” in 4.3. Program Download. 1-19 B022/B027...
Page 58 Job Log 10MB Job log. Remains Total 4.8GB Remains When an application uses an image page, first it uses the Image LS area. If this area is in use and not available, then it uses the Image TMP area. B022/B027 1-20...
Page 59: Detailed Section Descriptions
DETAILED SECTION DESCRIPTIONS...
Page 61: Scanning
An optics anti-condensation heater [G] is available as an option. It can be installed on the left side of the scanner. It turns on whenever the power cord is plugged in. B022/B027...
Page 62: Scanner Drive
IPU board, like for book mode. Magnification in the sub-scan direction can be adjusted by changing the ADF motor speed using SP6006. In the main scan direction, it can be adjusted with SP4008, like for book mode. B022/B027...
Page 63: Original Size Detection In Platen Mode
APS sensors. If the copy is made with the platen fully open, the CPU decides the original size from the sensor outputs when the Start key is pressed. B022/B027...
Page 64 However, for each page, the data signal to the laser diode is stopped to match the copy paper length detected by the registration sensor. Original size detection using the ADF is described in the manual for the ADF. B022/B027...
Page 65: Image Processing
The IPU board performs the image processing, such as auto shading, filtering, magnification, gradation processing. The SIMAC on the controller board performs the image editing, such as image repeat, double copy. Finally, the IPU board sends the video data to the LD drive board. B022/B027...
Page 66: Sbu (Sensor Board Unit)
After the above processing, the analog signals are converted to 8-bit signals by the A/D converter. This will give a value for each pixel on a scale of 256 grades. Then, the digitized image data goes to the IPU board. B022/B027...
Page 67: Auto Image Density
Because peak level data is taken for each scan line, ADS corrects for any changes in background density down the page. As with previous digital copiers, the user can select manual image density when selecting auto image density mode, and the machine will use both settings when processing the original. B022/B027...
Page 68: Ipu (Image Processing Unit)
• Test pattern generation IPU-B • Filtering (MTF and smoothing) • ID gamma correction • Grayscale processing • Binary picture processing • Error diffusion • Dithering Video Controller • Video path control The image data then goes to the LD driver (LDD). B022/B027...
Page 69: Image Processing Modes
When the optional hard disk has not been installed, the machine uses binary picture processing. However, when the optional hard disk has been installed, the machine uses grayscale processing. The user or technician cannot select the mode. B022/B027...
Page 70: Image Processing Path
• Characteristic Detection IPU-B • Filtering • ID Gamma Correction • Error Diffusion • Dithering Printer/ Scanner • Binary Picture Processing • Grayscale Processing • Memory Control • Compression Video Path Control Controller LD Unit Fax Unit B027D559.WMF B022/B027 2-10...
Page 71: Sp Modes For Each Image Processing Step
Background 4-904-6 Erase 35%~ None ~34% Text γ Correction 4-904-11 35%~ Character (Text) Binary ~34% Normal error diffusion picture 4-903-1 processing Gradation Binary 35%~ Character error diffusion picture 4-903-2 ~ 4 processing ~34% Line Width 2-907-1 Correction 35%~ 2-11 B022/B027...
Page 72: Photo Mode
4-904-7 Erase 35%~ None ~34% Dither Dither γ Correction Dither (8x8) 4-904-12 (16x16) (Character) 35%~ Normal error ~34% 4-903-5 diffusion Dither Gradation Dither (8x8) Character (16x16) 35%~ error 4-903-6 ~ 8 diffusion ~34% Line Width 2-907-2 Correction 35%~ B022/B027 2-12...
Page 73: Text/Photo Mode
~34% None Independent Dot 4-904-3 Erase 35%~ None ~34% None Background 4-904-8 Erase 35%~ None ~34% Text/Photo γ Correction 4-904-13 35%~ Character (Text/Photo) ~34% Normal error diffusion Gradation 35%~ Character error diffusion ~34% Line Width 2-907-3 Correction 35%~ 2-13 B022/B027...
Page 74: Pale Mode
~34% None Independent Dot 4-904-4 Erase 35%~ None ~34% None Background 4-904-9 Erase 35%~ None ~34% Pale γ Correction 4-904-14 35%~ Character (Pale) ~34% Normal error diffusion Gradation 35%~ Character error diffusion ~34% Line Width 2-907-4 Correction 35%~ B022/B027 2-14...
Page 75: Generation Copy
Independent Dot 4-904-5 Erase 35%~ Weak ~34% Weak Background 4-904-10 Erase 35%~ Weak ~34% Generation copy γ Correction 4-904-15 35%~ Character (Generation copy) ~34% Normal error diffusion Gradation 35%~ Character error diffusion ~34% Line Width 2-907-5 Correction 35%~ 2-15 B022/B027...
Page 76: Auto Shading
ADF mode, the ADF feeds the leading edge of the original to the DF exposure glass, and the opposite top corner of the original is at the main scan start position. To create the mirror image, the IPU-A stores each line in a LIFO (Last In First Out) memory. B022/B027 2-16...
Page 77: Characteristic Detection
35%, MTF (medium) is used for all pixels in the image. However, if the reproduction ratio is 35% or more, the ‘medium’ characteristic filter is used, and the processing depends on whether the pixel was in an edge area, a non-edge area, or in an area shaded using a dot pattern. 2-17 B022/B027...
Page 78: Independent Dot Erase
• Binary picture processing: This has only two output levels (black and white). • Error diffusion: There are two error diffusion processing types (normal and characteristic detection) • Dithering: There are two dithering processing types (normal and characteristic detection). B022/B027 2-18...
Page 79: Grayscale Processing
Line width correction is done in the VCU chip on the LDD board. The line width correction type can be selected with SP2-907. 2-19 B022/B027...
Page 80: Video Control Unit (Vcu)
Fig. C shows an example of how edge smoothing is used. This function only affects the received image for fax mode and for printer mode, even if copy mode is also using binary picture processing. B022/B027 2-20...
Page 81: Laser Exposure
F-theta mirror [E], mirror [F], and BTL (barrel toroidal lens) [G]. Then the laser beam goes to the drum through the toner shield glass [H]. The laser synchronizing detector [I] determines the main scan starting position. The speed of the polygon mirror motor is 28,818.9 rpm for 600 dpi. 2-21 B022/B027...
Page 82: Auto Power Control (Apc)
This auto power control is done just after the machine is turned on and during printing while the laser diode is active. The laser diode power is adjusted on the production line. NOTE: Do not touch the variable resistors on the LD unit in the field. B022/B027 2-22...
Page 83: Ld Safety Switch
The switches are installed on the +5VLD line coming from the power supply unit through the SBCU and IPU boards. When the front cover or the right cover is opened, the power supply to the laser diode is interrupted. 2-23 B022/B027...
Page 84: Photoconductor Unit (Pcu)
The machine informs the user when the PCU life has finished. However, the user can continue to make copies. SP5-912 can be used to enable or disable this warning message, and to change the default replacement interval (the default is 60k). B022/B027 2-24...
Page 85: Drive
The fly-wheel [E] on the end of the drum drive shaft stabilizes the rotation speed (this prevents banding and jitter from appearing on copies). 2-25 B022/B027...
Page 86: New Pcu Detection
(in other words, it checks whether the technician remembered to remove the developer seal from the PCU at machine installation). If the machine does not detect the ID sensor pattern, SC 392 will be generated. B022/B027 2-26...
Page 87: Drum Charge
[A] always contacts the surface of the drum [B] to give it a negative charge of -900V. The high voltage supply board gives a negative dc voltage to the drum charge roller through the spring [C] and terminal plate [D]. 2-27 B022/B027...
Page 88: Charge Roller Voltage Correction
The ID sensor measures the density of this pattern [B], and the output voltage is known as Vsdp. This voltage is compared with Vsg (read from the bare drum at the same time). B022/B027 2-28...
Page 89: Id Sensor Pattern Production Timing
The 30-minute interval can be changed using SP2995-1. • At the end of a job, if an ID sensor pattern has not been made for a certain number of sheets (default: 0 sheets = disabled) The number of sheets can be changed using SP2995-2. 2-29 B022/B027...
Page 90: Drum Charge Roller Cleaning
Because the drum charge roller [A] always contacts the drum, it gets dirty easily. So, the charge roller cleaning roller [B] also contacts the drum charge roller all the time to clean the surface of the drum charge roller. B022/B027 2-30...
Page 91: Development
3. TD sensor This machine uses a single-roller development system. Two mixing augers mix the developer. The toner density (TD) sensor and image density (ID) sensor (see the illustration in the PCU section) are used to control toner density. 2-31 B022/B027...
Page 92: Drive
[D]. When the PCU is pushed in, the development drive shaft engages the development roller gear. The development drive gears (except for the gears in the development unit) are helical gears. These gears are quieter than normal gears. B022/B027 2-32...
Page 93: Developer Mixing
[C] by the doctor blade [D], towards the front of the machine. Mixing auger 1 [B] returns the excess developer, along with new toner, to the rear of the mixing assembly. Here the developer is reapplied to the development roller. 2-33 B022/B027...
Page 94: Development Bias
-650 volts to the development rollers throughout the image development process. The bias is applied to the development roller shaft [A] through the drive shaft [B]. The development bias voltage (-650 V) can be adjusted with SP2-201-1. B022/B027 2-34...
Page 95: Toner Supply
When the bottle holder unit is pulled out to add a new toner bottle, the following happens automatically to prevent toner from scattering. • The chuck releases the toner bottle cap into its proper position. • The toner shutter shuts to block the opening as a result of pressure from a spring. 2-35 B022/B027...
Page 96: Toner Supply Mechanism
[D]. When the PCU is installed in the machine, the shutter [E] above the PCU is opened by the machine frame. Then the toner falls down into the development unit through the slit and the shutter. B022/B027 2-36...
Page 97: Toner Density Control
(Vref), actual TD sensor output voltage (Vt), and ID sensor output data (Vsp/Vsg). Toner Supply Clutch On Time Calculation TD Sensor Output (Vt) Vt Reference Voltage (Vref) New Vref Vt Reference Voltage Update Vref Update ID Sensor Output (Vsp/Vsg) TD Sensor Initial Setting (Vts) B027D517.WMF 2-37 B022/B027...
Page 98 Fixed control 2 (SP2-921, “3”): Use temporarily if the TD Mode sensor needs to be replaced Toner supply decision None Toner control process Toner is supplied every printed page regardless of Vt. Toner supply amount Fixed (SP2-925) Toner end detection Not performed B022/B027 2-38...
Page 99: Toner Density Sensor Initial Setting
• (Vts or the current Vref) - Vt Toner supply determination The reference voltage (Vts or Vref) is the threshold voltage for determining whether or not to supply toner. If Vt becomes greater than the reference voltage, the machine supplies additional toner. 2-39 B022/B027...
Page 100: Toner Supply Motor On Time Determinations
NOTE: 1) The value of “t” can be changed using SP2-922 (default: 0.6 second) 2) The value of “T” can be changed using SP2-923 (default: 30 seconds) 3) T (30) means that toner is supplied intermittently in a half duty cycle (1.5 s on, 1.5 s off) for 30 seconds B022/B027 2-40...
Page 101: Toner Supply In Abnormal Sensor Conditions
If Vt is at level 6 (see the table on the previous page) five times consecutively, the machine enters the toner near end condition and the toner end indicator starts blinking. Then the machine supplies toner for a certain time, which depends on the setting of SP 2-923 (see the previous page). 2-41 B022/B027...
Page 102: Toner Near End Recovery
If the front cover is opened and closed for 10 seconds while a toner end condition exists and the toner bottle is replaced, the machine attempts to recover using the same procedure as for toner near end/end detection. B022/B027 2-42...
Page 103: Drum Cleaning And Toner Recycling
5 mm at the end of every copy job. This feature is controlled with SP 2-998. In addition, cleaning is done in the middle of a job if 100 sheets have been made since the previous cleaning. This feature is controlled with SP 2-211. 2-43 B022/B027...
Page 104: Toner Recycling
Toner picked up by the toner collection coil [A], is transported to the opening [B] in the side of the PCU. Then, this toner falls into the development unit with new toner coming from the toner bottle and it is all mixed together by mixing auger 1 [C] and used again. B022/B027 2-44...
Page 105: Paper Feed
2. Paper Height –1 Sensor 8. Upper Relay Roller 3. Paper Height –2 Sensor 9. Lower Relay Roller 4. Paper End Sensor 10. Lower Relay Sensor 5. Paper Feed Roller 11. Friction Pad 6. Paper Size Sensor 12. Tray Heater (Option) 2-45 B022/B027...
Page 106: Paper Feed Drive Mechanism
The paper feed clutches [B] transfer drive from this motor to the paper feed rollers [C]. When the paper feed clutch turns on, the feed rollers start to feed the paper. The paper feed clutch stays on until shortly after the registration sensor [D] has been activated. B022/B027 2-46...
Page 107: Paper Feed And Separation Mechanism
The paper feed roller [A] drives the top sheet of paper from the paper tray to the copier. The friction pad [B] allows only one sheet to feed at a time. The friction pad applies pressure to the feed roller with a spring [C]. The friction pad pressure cannot be adjusted. 2-47 B022/B027...
Page 108: Paper Lift Mechanism
For smaller paper, it reverses the larger amount (600 ms) to reduce the pressure more. NOTE: The relationship between the bottom plate pressure adjustment, paper size thresholds, and the related SP modes is explained in “Bottom Plate Pressure Adjustment for Paper Size”. B022/B027 2-48...
Page 109: Paper End Detection
[C] in the tray bottom plate and the paper end sensor is activated. When the paper tray is drawn out with no paper in the tray, the shape of the paper end feeler causes it to lift up. 2-49 B022/B027...
Page 110: Paper Height Detection
NOTE: The relationship between the bottom plate re-adjustment timing, paper size threshold, and the related SP modes is explained in “Bottom Plate Pressure Adjustment for Paper Size”. B022/B027 2-50...
Page 111: Feed Pressure Adjustment For Paper Size
Normal paper size range: Paper sizes greater than the ‘Middle’ SP mode. For Two Size Ranges Small paper size range: Paper sizes equal to the ‘Small’ SP mode value, or smaller. Normal paper size range: Paper sizes greater than the ‘Small’ SP mode. 2-51 B022/B027...
Page 112: Feed Pressure Adjustment
(default setting) 1st paper tray SP1908-1 SP1908-2 SP1908-3 2nd paper tray SP1909-1 SP1909-2 SP1909-3 3rd paper tray SP1910-1 SP1910-2 SP1910-3 4th paper tray SP1911-1 SP1911-2 SP1911-3 Default (all trays) 200 ms 600 ms 200 ms (default: not used) B022/B027 2-52...
Page 113: From Paper Near End To Paper End
Paper Size HLT/A5 or smaller None (default setting) (default setting) 1st paper tray SP1908-6 SP1908-7 2nd paper tray SP1909-6 SP1909-7 3rd paper tray SP1910-6 SP1910-7 4th paper tray SP1911-6 SP1911-7 Default (all trays) Near-end Near-end (default: not used) 2-53 B022/B027...
Page 114: Paper Size Detection
When the paper size actuator is at the “*” mark, the paper tray can be set up to accommodate one of a wider range of paper sizes by using user tools. If the paper size for this position is changed without changing the user tool setting, a paper jam will result. B022/B027 2-54...
Page 115: Special Paper Setting
B4 width (10”): 15 µA A4 width (8.5”): 17 µA A5 width (5.5”): 20 µA Note that for the by-pass tray, the fusing and transfer conditions for special paper are also applied if the user uses thick (non-standard) mode. 2-55 B022/B027...
Page 116: Side And End Fences
As the amount of paper in the tray decreases, the bottom plate [C] lifts up gradually. The end fence [D] is connected to the bottom plate. When the tray bottom plate rises, the end fence moves forward and pushes the back of the paper stack to keep it squared up. B022/B027 2-56...
Page 117: Paper Registration
This may be needed when feeding thicker paper. This adjustment is made with SP 1903; it can be adjusted separately for tray 1 and the by-pass feeder, so place the problem paper type in one of these and adjust SP 1-903 for that tray only. 2-57 B022/B027...
Page 118: Image Transfer And Paper Separation
The curvature of the drum and the discharge plate [C] help the paper to separate from the drum. The high voltage supply board also supplies a negative dc voltage to the discharge plate. Drive from the drum through a gear [D] turns the transfer roller B022/B027 2-58...
Page 119: Image Transfer Current Timing
Be careful when increasing the transfer current. This might cause a ghosting effect, in which part of the image at the top of the page is repeated lower down the page at a lower density. It may also damage the OPC drum in the worst case. 2-59 B022/B027...
Page 120: Transfer Roller Cleaning
The high voltage supply board applies a constant dc voltage, -1.8 kV (when feeding from a paper tray) or –2.1 kV (from the duplex unit) to the discharge plate. The discharge plate voltage can be adjusted using SP2-901. B022/B027 2-60...
Page 121: Image Fusing And Paper Exit
1. Paper exit roller 7. Two fusing lamps 2. Fusing exit sensor 8. Two thermistors 3. Hot roller strippers 9. Four thermostats 4. Pressure spring 10. Hot roller 5. Pressure roller 11. Paper overflow sensor 6. Cleaning roller 2-61 B022/B027...
Page 122: Fusing Drive And Release Mechanism
Just after the main switch is turned on, this solenoid is energized and the fusing unit drive gear [D] is disengaged. However, the fusing unit drive is not released when the temperature is lower than 15°C. B022/B027 2-62...
Page 123: Fusing Entrance Guide Shift Mechanism
If creasing occurs frequently in the fusing unit, adjust the entrance guide to the right, by securing it with the other holes [C]. This allows more direct access to the gap between the hot roller and the pressure roller. 2-63 B022/B027...
Page 124: Pressure Roller
2.10.5 CLEANING MECHANISM B022D552.WMF The cleaning roller [A] is always in contact with the pressure roller [B]. It collects toner and paper dust adhered to the surface of the pressure roller. B022/B027 2-64...
Page 125: Fusing Temperature Control
The three-page and 60-second limits can be adjusted with SP1-105-8 and -9. Note that the fusing temperature is higher if the user uses special paper in the 2nd tray or thick paper mode from the bypass tray ( 2.8.9). 2-65 B022/B027...
Page 126: Fusing Lamp Control
NOTE: This feature is effective to counter flickering lights. However, generated noise increases if the setting is changed from the default. If a radio or a TV is close by the machine, the noise may have some effect on the image or sound. B027D512.WMF B022/B027 2-66...
Page 127: Overheat Protection
B027D601.WMF The paper overflow detection sensor [A] is located at the paper exit section of the fusing unit. When this sensor is activated, the machine detects that the paper stack height exceeded a certain limit and stops printing. 2-67 B022/B027...
Page 128: Energy Saver Modes
• Auto off timer: User Tools – System Settings – Timer Setting – Auto Off Timer • Auto off disabling (SP mode): Set SP 5-305 to 1. This allows the user to disable auto off mode by setting the auto off timer to 0. B022/B027 2-68...
Page 129: Energy Saver Mode
• The ADF is lifted • A sheet of paper is placed in the by-pass feed table The recovery time from energy saver mode is about 3 s. Operation Energy Mode Fusing Temp. +24V System +5V Switch Saver LED Energy Saver 2-69 B022/B027...
Page 130: Auto Off Mode
The machine returns to stand-by mode when the operation switch is pressed. The recovery time is about 10 s. Energy Operation System Mode Saver Fusing Lamp +24V Note Switch Mode Off Stand-by (On when printing) +5VE is supplied B022/B027 2-70...
Page 131 INSTALLATION...
Page 133: Installation Procedure
5 mm.) 10. Do not place the machine where it may be subjected to strong vibrations. 3.1.2 MACHINE LEVEL Front to back: Within 5 mm (0.2") of level Right to left: With in 5 mm (0.2") of level B022/B027...
Page 134: Minimum Space Requirements
G: 550 mm (21.7") H: 1137 mm (44.8") B027I202.WMF NOTE: The 750 mm recommended for the space at the front is only for pulling out the paper tray. If an operator stands at the front of the copier, more space is required. B022/B027...
Page 135: Power Requirements
1. Input voltage level: 120 V, 60 Hz: More than 12 A 220 V ~ 240 V, 50 Hz/60 Hz: More than 7 A 110V, 50 Hz/60 Hz: More than 13 A 2. Permissible voltage fluctuation: ±10 % 3. Do not set anything on the power cord. B022/B027...
Page 136: Copier Installation
1. Rating voltage output connector for accessory Max. DC24 V for accessory Max. DC24 V B022I500.WMF 4. By-pass Tray 3. Duplex Unit 1. Rating voltage output connector 1. Rating voltage output connector for accessory Max. DC24 V for accessory Max. DC24 V B022/B027...
Page 137: Installation Flow Chart
Install the Finisher Does the user require the Duplex Unit and/or 1-bin Tray Unit ? Y e s Install the Interchange Unit Install the Duplex Unit and/or 1-bin Tray Unit Install the ARDF or Platen Cover (if required) B022I513.WMF B022/B027...
Page 138: Accessory Check
Check the quantity and condition of the accessories in the box against the following list: Description Q’ty Paper Tray Decal Emblem Model Name Decal NECR End Fence HDD Caution Decal (-17, -57 only) Operating Instructions – System Setting Operating Instructions – Copy Reference B022/B027...
Page 139: Installation Procedure
NOTE: Keep the shipping retainers after installing the machine. They will be reused if the machine is moved to another location in the future. 1. Remove the tapes and the shipping retainer [A] on the exterior of the copier. 2. Install the end fence [B]. B022/B027...
Page 140 NOTE: Do not remove the toner bottle cap [I] until after shaking. 7. Unscrew the bottle cap [I] and insert the bottle into the holder. NOTE: Do not touch the inner bottle cap [J]. 8. Reposition the holder and press down the holder lever to secure the bottle. B022/B027...
Page 141 11. Attach the appropriate paper tray number decal [B] to the paper tray. NOTE: Paper tray number decals are also used for the optional paper tray or the optional LCT. Keep any remaining decals for use with these optional units. B022/B027...
Page 142 16. Initialize the electrical total counter using SP7-825, depending on the service contract type. HDD Caution Decal (for only –17, -57 models) 1. When installing the optional HDD, attach the HDD caution decal [B] to the front cover. B022/B027 3-10...
Page 143: Paper Tray Unit Installation
Unplug the machine power cord before starting the following procedure. 1. Remove the strips of tape. 2. Set the copier [A] on the paper tray unit [B]. NOTE: When installing the copier, be careful not to pinch the cable [C]. 3-11 B022/B027...
Page 144 5. Attach a securing bracket [C] to each side of the paper tray unit, as shown (1 screw each). 6. Re-install the connector cover. 7. Remove the 2nd paper tray [D] and secure the paper tray unit with two screws [E]. B022/B027 3-12...
Page 145 9. Rotate the adjuster [B] until the machine cannot be pushed across the floor. 10. Loads paper into the paper trays and select the proper paper size. 11. Turn on the main switch. 12. Check the machine’s operation and copy quality. 3-13 B022/B027...
Page 146: Accessory Check
Unplug the machine power cord before starting the following procedure. 1. Remove the strips of tape. 2. Set the copier [A] on the LCT [B]. NOTE: When installing the copier, be careful not to pinch the cable [C]. B022/B027 3-14...
Page 147 4. Connect the cable [B] to the copier, as shown. 5. Attach a securing bracket [C] to each side of the LCT, as shown (1 screw each). 6. Re-install the connector cover. 7. Remove the 2nd paper tray and secure the LCT with two screws [D]. 3-15 B022/B027...
Page 148 NOTE: The paper tray number decal is in the accessory box for the main copier. 10. Rotate the adjuster [C] until the machine cannot be pushed across the floor. 11. Loads paper into the paper tray and turn on the main switch. 12. Check the machine’s operation and copy quality. B022/B027 3-16...
Page 149: Accessory Check
Description Q’ty Scale Guide DF Exposure Glass Stud Screw Knob Screw Original Size Decal Screwdriver Tool B386I500.WMF 3.5.2 INSTALLATION PROCEDURE B386I101.WMF CAUTION Unplug the copier power cord before starting the following procedure. 1. Remove the strips of tape. 3-17 B022/B027...
Page 150 5. Install the two stud screws [F]. 6. Mount the DF on the copier, then slide the DF to the front as shown. 7. Secure the DF unit with two screws [G]. 8. Connect the cable [H] to the copier. B022/B027 3-18...
Page 151 10. Turn the main power switch on. Then check if the document feeder works properly. 11. Make a full size copy. Then check to make sure the side-to-side and leading edge registrations are correct. If they are not, adjust the side-to-side and leading edge registrations (refer to the service manual). 3-19 B022/B027...
Page 152: Component Check
INTERCHANGE UNIT INSTALLATION 3.6 INTERCHANGE UNIT INSTALLATION 3.6.1 COMPONENT CHECK Check the quantity and condition of the components against the following list. Description Q’ty Interchange Unit Connector Cover Tapping Screw M3x8 B416I101.WMF B022/B027 3-20...
Page 153: Installation Procedure
If the optional 1-bin tray unit (B413) will be installed, do steps 6 and 7. 6. Loosen the screw, push down tab [F] with a screwdriver, and remove the front right cover [G]. 7. Slide out the exit cover [H]. 3-21 B022/B027...
Page 154 INTERCHANGE UNIT INSTALLATION B416I103.WMF B416I104.WMF 8. Open the cover [A] of the interchange unit. 9. Install the interchange unit (2 connectors) [B]. 10. Secure the interchange unit with the knob screws [C]. 11. Attach the connector cover [D] (1 screw). B022/B027 3-22...
Page 155: 1-Bin Tray Unit Installation
1. Remove all tapes. 2. If the optional bridge unit has been installed, open the right jam removal cover [A] of the bridge unit. If the optional bridge unit is not installed, skip this step. 3-23 B022/B027...
Page 156 5. Connect the connector [C]. 6. Reinstall the front right cover. 7. Peel off the backing [D] of the double-sided tape attached to the paper guide [E]. Then attach the paper guide to the underside of the scanner unit as shown. B022/B027 3-24...
Page 157 1-BIN TRAY UNIT INSTALLATION B413I105.WMF 12. Install the tray guide [A]. 13. Install the tray [B]. 14. Install the sub-tray [C]. 15. Turn on the main power switch and check the 1-bin tray unit operation. 3-25 B022/B027...
Page 158: Component Check
B459I102.WMF CAUTION Unplug the copier power cord before starting the following procedure. 1. Remove all tapes. 2. Remove the plate [A] (1 screw). 3. Install the large paper guide [B] and two small paper guides [C], as shown. B022/B027 3-26...
Page 159 6. Connect the cable [D] to the copier. 7. Turn on the main power switch. Then select the shift tray using the UP mode “2. Copier – 3. Input/Output – 6. Sort – Shift Sort”. 8. Check the shift tray operation. 3-27 B022/B027...
Page 160: Installation Procedure
Unit Holder Tapping Screw Allen Key B415I101.WMF 3.9.2 INSTALLATION PROCEDURE B415I500.WMF CAUTION Unplug the copier power cord before starting the following procedure. 1. Remove all tapes. 2. Remove the entrance cover [A] (2 screws) and two screws [B]. B022/B027 3-28...
Page 161 [C] of the by-pass tray unit [D]. 5. Install the by-pass tray unit (2 screws, 1 connector). 6. Turn the main power switch on and check the by-pass tray function. 7. Make a copy from the by-pass tray. Then check the registration. 3-29 B022/B027...
Page 162: Duplex Unit Installation
3.10 DUPLEX UNIT INSTALLATION 3.10.1 ACCESSORY CHECK Check the quantity and condition of the accessories against the following list. Description Q’ty Duplex Unit Connector Cover Bracket Clip Unit Holder Unit Holder Cover Allen Key Tapping Screw - M3x8 B414I101.WMF B414I102.WMF B022/B027 3-30...
Page 163: Installation Procedure
NOTE: 1) Make sure that the four screws are tightened in the proper order, as shown above. Otherwise, the duplex unit will not properly lock in place. 2) After securing the unit, store the Allen key in the inner cover [G] for future use. 3-31 B022/B027...
Page 164 8. Connect the cable [E] and install the connector cover [F] (1 screw). 9. If the by-pass tray has already been installed, skip this step: Install the unit holder cover [G] (2 screws). 10. Turn on the main power switch and check the duplex unit function. B022/B027 3-32...
Page 165: Bridge Unit Installation
Unplug the copier power cord before starting the following procedure. 1. Remove all tapes. 2. Loosen the screw [A] and remove the front right cover [B]. 3. If the sensor feeler [C] is out, fold it away into the machine. 3-33 B022/B027...
Page 166 8. Attach the securing plate [E], as shown. NOTE: Do not attach it with a screw; this is done when securing the front stand for the optional finisher. 9. Install the optional finisher (refer to the finisher installation procedure). B022/B027 3-34...
Page 167: 1,000-Sheet Finisher Installation
Check the quantity and condition of the accessories against the following list. B408I101.WMF Description Q’ty Front Joint Bracket Rear Joint Bracket Grounding Plate Copy Tray Staple Position Decal Screw - M4x17 Knob Screw – M4x10 Screw - M3x8 Knob Screw – M3x8 3-35 B022/B027...
Page 168: Installation Procedure
CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: If this finisher will be installed on the B022 or B027 copier, the following options must be installed before installing this finisher. Bridge Unit (B417) Paper Tray Unit (B390) or LCT (B391) 1.
Page 169 7. Secure the locking lever (1 knob screw – M3x8) and close the front door. 8. Install the copy tray [G] (1 knob screw – M4x10). 9. Connect the finisher cable [H] to the main machine. 3-37 B022/B027...
Page 170 1,000-SHEET FINISHER INSTALLATION B408I501.WMF 10. Attach the staple position decal [A] to the ARDF as shown. 11. Turn on the ac switch and check the finisher operation. B022/B027 3-38...
Page 171: 500-Sheet Finisher Installation
500-SHEET FINISHER INSTALLATION 3.13 500-SHEET FINISHER INSTALLATION 3.13.1 ACCESSORY CHECK Check the quantity and condition of the accessories against the following list. B442I101.WMF Description Q’ty Unit Holder Entrance Guide Output Tray Snap Ring Knob Screw 3-39 B022/B027...
Page 172: Installation Procedure
NOTE: Before installing the 500-sheet finisher, the optional bridge unit (B417) must be installed. 1. Unpack the finisher and remove the tapes. 2. Install the entrance guide [A]. 3. Install the unit holder [B] (2 screws). 4. Install the 500-sheet finisher [C]. B022/B027 3-40...
Page 173 500-SHEET FINISHER INSTALLATION B442I105.WMF 5. Install the output tray [A] as shown (2 snap rings). 6. Connect the finisher cable [B]. 7. Turn on the main power switch and check the finisher operation. 3-41 B022/B027...
Page 174: Platen Cover Installation
PLATEN COVER INSTALLATION 3.14 PLATEN COVER INSTALLATION B027I555.WMF 1. Install the platen cover [A] (2 screws). B022/B027 3-42...
Page 175: Memory (G578/G579)
1. Remove the connector cover [A] and rear cover [B] (4 screws). 2. Remove the shield cover [C] (7 screws). 3. Install the memory DIMM [D] on the controller board. 4. Replace the controller board cover and rear cover. 3-43 B022/B027...
Page 176: Hdd (B420)
2. Attach the shield plate [C] to the HDD (4 – M3x3 screws). 3. Connect the cable [D] to the HDD. NOTE: The marked location [E] which is not a pinhole must face the HDD. 4. Remove the connector cover [F] and rear cover [G] (4 screws). B022/B027 3-44...
Page 177 5. Connect the other end of the cable to CN509 [A] on the controller board, then install the HDD assembly [B] (2 screws). 6. Replace the rear cover and connector board. 7. Replace the key tops for the appropriate units to be installed. C: Copy D: Document Server 3-45 B022/B027...
Page 178: Key Counter Installation
4. Hold the key counter plate nuts [D] on the inside of the key counter bracket [E] and insert the key counter holder [F]. 5. Secure the key counter holder to the bracket (2 screws). 6. Install the key counter cover [G] (2 screws). B022/B027 3-46...
Page 179 9. Secure the key counter holder assembly with a screw [D]. 10. The key counter function is available for other models by entering the following: • User Tools • System • Key Operator Tools • Key Counter Management 3-47 B022/B027...
Page 180: Anti-Condensation Heater
2. Move the 1st and 2nd scanners to the right. 3. Install the cable clamp [E]. 4. Install the anti-condensation heater [F] (2 screws). 5. Join the connectors [G] 6. Attach the cable cover [H], as shown. B022/B027 3-48...
Page 181: Tray Heater
1. Remove the connector cover [A] and rear cover [B] (4 screws). 2. Slide out the 1st and 2nd paper trays. 3. Pass the connector [C] through the opening [D]. 4. Install the tray heater assembly [E] (1 screw). 3-49 B022/B027...
Page 182 6. Route the heater cable [B] to the side of rivet [C] and under bracket [D]. 7. Clamp the heater cable [B] as shown. 8. Joint the heater cable and the ac cable [E]. 9. Reinstall the paper lift motor [A] and reassemble the machine. B022/B027 3-50...
Page 183: Tray Heater (Optional Paper Tray Unit)
Unplug the machine power cord before starting the following procedure. 1. Remove the joint brackets [A] (1 screw each). 2. Remove the rear cover [B] for the optional paper tray unit (2 screws). 3. Remove the cable guide [C] (1 screw). 4. Install the clamps [D]. 3-51 B022/B027...
Page 184 5. Slide out the two paper trays from the optional paper tray unit. 6. Pass the connector [A] through the opening [B]. 7. Install the tray heater assembly [C] (1 screw). 8. Clamp the cables [D], as shown. 9. Join the connectors [E]. 10. Reinstall the cable guide. B022/B027 3-52...
Page 185 13. Reinstall the two paper trays into the optional paper tray unit. 14. Remove the 2nd paper tray of the copier. 15. Remove two screws [B] and install the screws [C] which were removed in step 16. Reinstall the 2nd paper tray of the copier. 3-53 B022/B027...
Page 186: Tray Heater (Optional Lct)
3. Slide out the paper tray [C]. 4. Push the stopper [D] on both slide rails and remove the paper tray. 5. Pass the connector [E] through the opening [F]. 6. Install the tray heater [G] (1 screw). B022/B027 3-54...
Page 187 8. Connect the cable [B] to the tray heater cable [C]. 9. Route the cable and clamp it. 10. Remove the connector cover of the copier [D]. 11. Join the connectors [E]. 12. Reinstall the connector cover of the copier. 3-55 B022/B027...
Page 188 15. Reinstall the paper tray. 16. Remove the 2nd paper tray of the copier. 17. Remove two screws [B] and install the screws [C] which were removed in step 18. Reinstall the 2nd paper tray of the copier. B022/B027 3-56...
Page 189: User Account Enhancement (B443)
2. Remove the shield cover [C] (7 screws) or the optional fax unit if it has been installed. 3. Install the user account enhancement (IC 29) [D] on the controller board. 4. Replace the shield cover, optional fax unit, connector cover, and rear cover. 3-57 B022/B027...
Page 190: Service Tables
SERVICE TABLES...
Page 192: General Caution
1. Clean the exposure glass with alcohol or with glass cleaner to reduce the amount of static electricity on the surface of the glass. 2. Use a blower brush or a cotton pad with water to clean the mirrors and lens. B022/B027...
Page 193: Laser Unit
2. The toner bottle should be replaced while the main switch is on. 3. If the optional tray, drum, and optics anti-condensation heaters have been installed, keep the copier power cord plugged in, even when the copier main switch is turned off. This keeps the heaters energized. B022/B027...
Page 194: Service Program Mode
On the touch-panel, press Copy SP. To enter the Special Service Mode: Copy SP Hold down and then press Copy SP. Exit 5. Press Exit twice to return to the copy window. NOTE: Use SP2-902 to perform test pattern printing. ( 4.2.3) B022/B027...
Page 195: Sp Mode Button Summary
Press to scroll to the previous or next display in segments the size of the screen display (page). Press to scroll the display to the previous or next line, line by line. Press to move the highlight on the left to the previous or next selection in the list. B022/B027...
Page 196: Switching Between Sp Mode And Copy Mode For Test Printing
Press Start twice, and then press SP Mode (highlighted) in the copy window to return to the SP mode display. 3. When you are finished, press Exit twice to return to the copy window. B022/B027...
Page 197: Service Program Mode Tables
The paper feed clutch timing determines the amount of 2nd, 3rd, 4th Paper paper buckle at registration. (A larger setting leads to Feed, LCT, and By-pass more buckling.) Feed [0 ~ 10 / 5 / 1 mm/step] Duplex, Side2 [0 ~ 20 / 6 / 1 mm/step] B022/B027...
Page 198 1 or 3 seconds. If this is “1 (3 s)”, the power supply fluctuation caused by the fusing lamp turning on is less often. [0 = 1 s / 1 = 3 s] Default: 0 = N. America, 1 = Europe/Asia B022/B027...
Page 199 Do not input a value greater than 1,200. Use this SP when a paper feed problem occurs from the 1st paper tray. See “Paper Lift Mechanism” for details on SP1-908. [0 ~ 2000 / 200 / 1 ms/step] B022/B027...
Page 200 Set this SP to 2 or 3 when a paper feed problem occurs before near-end. See “Paper Lift Mechanism” for details on SP1-908. [0 = None (Empty) / 1 = Near End / 2 = 25% / 3 = 75%] B022/B027...
Page 201 Do not input a value greater than 1200. Use this SP when a paper feed problem occurs from the 2nd paper tray. See “Paper Lift Mechanism” for details on SP1-909. [0 ~ 2000 / 200 / 1 ms/step] B022/B027 4-10...
Page 202 (SP1-909-8). The size used by SP1-909 is determined by paper width. See “Paper Lift Mechanism” for details on SP1-909. [0 = None (Not used) / 1 = HLT/A5 / 2 = A4 / 3 = LT / 4 = DLT / 5 = A3] 4-11 B022/B027...
Page 203 Use this SP when a paper feed problem occurs when paper in the 3rd paper tray is running low. See “Optional Paper Tray Unit - Paper Lift Mechanism” for details on SP1-910. [0 ~ 2000 / 400 / 1 ms/step] B022/B027 4-12...
Page 204 See “Optional Paper Tray Unit - Paper Lift Mechanism” for details on SP1-910. [0 = None (Not used) / 1 = HLT/A5 / 2 = A4 / 3 = LT / 4 = DLT / 5 = A3] 4-13 B022/B027...
Page 205 Use this SP when a paper feed problem occurs when paper in the 4th paper tray is running low. See “Optional Paper Tray Unit - Paper Lift Mechanism” for details on SP1-911. [0 ~ 2000 / 400 / 1 ms/step] B022/B027 4-14...
Page 206 Adjusts the tray motor reverse time. The tray motor reverses when the tray is pulled out. The tray can be put back in the machine without damage while the motor reverses. [0 ~ 9000 / 1700 / 1 ms/step] 4-15 B022/B027...
Page 207: Sp2-Xxx: Drum
50V (e.g. from – 550 to –500). The size of the decrease depends on SP2-005-3. [0 ~ 100 / 95 / 1 %/step] Step Adjusts the size of the charge roller voltage correction. [0 ~ 200 / 50 / 1 V/step] B022/B027 4-16...
Page 208 The actual right side erase margin on the reverse side is this value plus the value of SP2-101-6. The specification is 2 +2.5/–1.5 mm. See “Replacement and Adjustment - Copy Adjustment” for details. [0.0 ~ 9.0 / 0.3 / 0.1 mm/step] 4-17 B022/B027...
Page 209 This SP adjusts the time for applying the charge. [0 ~ 150 / 80 / 1 ms /step] Development Bias Adjusts the development bias off time. [-120 ~ 120 / 0 / 1ms/step] B022/B027 4-18...
Page 210 [0 ~ 10 / –4 / 1 µA/step] Input – Front This is for the designer’s test purposes. Do not change the value. [0 ~ 30 / 0 / 1 µA/step] 4-19 B022/B027...
Page 211 [–1000 ~ 4000 / –2100 / 1 V/step] Rear – Image Area Adjusts the voltage applied to the separation plate, during printing at the image area of the paper on the rear side. See SP2-901-2. [–1000 ~ 4000 / –2100 / 1 V/step] B022/B027 4-20...
Page 212 [-0.5 ~ 0.5 / 0.0 / 0.1%/step] Copy – Long Edge Feed Adjusts the main scan magnification in copy mode when the machine feeds the paper in the long edge feed orientation. [-0.5 ~ 0.5 / 0.0 / 0.1%/step] 4-21 B022/B027...
Page 213 Note that toner recovery is done in a 3-second cycle. So, the input value should be a multiple of 3 (e.g. 3, 6 ,9). See “Toner Density Control” for more details. [3 ~ 60 / 30 / 1 s/step] B022/B027 4-22...
Page 214 TD Sensor Manual Setting Adjusts the TD sensor output. DFU [0.5 ~ 3.5 / 0.0V / 1V/step] 931* TD (V/wt%) Setting Adjusts the TD sensor sensitivity (coefficient: S) for toner density control. DFU [0.01 ~ 1.50 / 0.4 / 0.1/step] 4-23 B022/B027...
Page 215 [0 ~ 999 / 30 / 1 minute/step] 955* Number of Page The machine makes an ID sensor pattern after the specified number of prints has been made. 0 = this feature is disabled. [0 ~ 999 / 0 / 1 page/step] B022/B027 4-24...
Page 216: Sp4-Xxx: Scanner
Adjusts the magnification in the sub scan direction for scanning. Use the key to toggle between + and – before ± entering the value. The specification is 1%. See “Replacement and Adjustment - Copy Adjustment” for details. [–0.9 ~ +0.9 / 0.0 / 0.1% step] 4-25 B022/B027...
Page 217 The default is 4.76 mm. The current setting specifies the difference from this default. [–5.0 ~ +5.0 / 0.0 / 0.1 mm/step] APS Data Display Displays the status of the APS sensors and platen/DF cover sensor ( 4.2.9). B022/B027 4-26...
Page 218 Using this SP mode after replacing the white plate or erasing the memory on the controller board. See “Replacement and Adjustment – Copy Image Adjustments - Standard White Density Adjustment” for details on how to do this. Press Execute on the touch panel to start. 4-27 B022/B027...
Page 219 0 ~ 6 are for a glossy photo image (error diffusion) 7 ~ 20 are for a printed photo image (dithering) If copy quality is not satisfactory, try another setting (trial and error) [0 ~ 20 / 11 / 1/step] B022/B027 4-28...
Page 220 [0 ~ 10 / 0 / 1 step] Photo [0 ~ 10 / 0 / 1 step] Text/Photo [0 ~ 10 / 0 / 1 step] Pale [0 ~ 10 / 0 / 1 step] Generation [0 ~ 10 / 3 / 1 step] 4-29 B022/B027...
Page 221 DFU [0 ~ 255 / 0 / 1 step] Bit 7: Shading Bit 6: Scanner gamma Bit 5: Pre-filtering Bit 4: Magnification Bit 3: Scanner/Printer Mask Bit 2: Gradation Bit 1: Filtering Bit 0: Printer gamma B022/B027 4-30...
Page 222: Sp5-Xxx: Mode
NOTE: Use SCBU firmware ver. 3.2.4 and System firmware ver. 5.19. 118* Disable Copying 120* Opt. Counter Reset Setting This SP is for Japan only. Do not change the value. [0 = Yes / 1 = Stand-by / 2 = None] 4-31 B022/B027...
Page 223 Set the upper right corner of the front side and the upper left corner of the back side so the starting points for vertical printing are the same on both sides. DFU [–10~+10 / 0 / 1 mm step] –10: Extreme top +10: Extreme bottom B022/B027 4-32...
Page 224 0 and 240 minutes.) When set to “0”, the user cannot set the timer to zero. [0 = On (Enabled), 1 = Off (Disabled) ⇒ Deleted and moved to. User tools, System Settings, Key Operator Tools, User Code Management. 4-33 B022/B027...
Page 225 The “Paper Supply Call Level: nn” SPs specify the paper control call interval for the referenced paper 132* sizes. 133* Japan only DFU 134* [00250 ~ 10000 / 1000 / 1 Step] 141* 142* 160* 164* 166* 172* B022/B027 4-34...
Page 226 Initializes items 2 ~ 12 below. Engine Initializes all registration settings for the engine and processing settings. SCS (System Control Initializes default system settings, CSS settings, Service)/SRAM operation display coordinates, and ROM update information. SCS: System Control Service 4-35 B022/B027...
Page 227 To clear the service call, touch “Execute” on the LCD, then turn the main power switch off/on. Serial Number Input Use to input the machine serial number. (This is normally done at the factory.) This serial number will be printed on the SMC report. B022/B027 4-36...
Page 228 Sets the TCP operation mode for the network. Mode Setting [00000000~FFFFFFFFh / 00000000h / 1 hex unit step] Network Syslog Server Sets the syslog server address for the network. Address Setting [00000000~FFFFFFFFh / 7F000001h / 1 hex unit step] 4-37 B022/B027...
Page 229 STP signal to the data transfer. (With 1: FAST there is no delay.) Network ECP Setting Switches the ECP setting for Centronics off/on. (Centronics) 0: Disabled, 1: Enabled With “1” selected, SP5-828-050 must be enabled for 1284 mode compatibility. B022/B027 4-38...
Page 230 Sets the PCU alarm interval. When the machine reaches this value, the PCU alarm will be displayed on the LCD to inform the user. Only used if SP5-912-1 is at “1”. [1 ~ 255 / 60 / 1 k copies/step] 4-39 B022/B027...
Page 231 Key Monitor [0 = Off, 1 = On] Key Monitor - Record [0 = Off, 1 = On] Key Monitor - Play [0 = Off, 1 = On] Key Monitor – Play Check [0 = Off, 1 = On] B022/B027 4-40...
Page 232: Sp6-Xxx: Peripherals
Adjusts the side-to-side registration on the rear side of the original in ADF mode. Use the key to toggle between + and - before entering the value. See “Replacement and Adjustment - Copy Adjustment” for details. [–5.0 ~ +5.0 / 0.0 / 0.1 mm/step] 4-41 B022/B027...
Page 233 Finisher Input Check Displays the signals received from sensors and switches in the finisher. ( 4.2.4) Finisher Output Check Switches on each electrical component of the finisher for testing. ( 4.2.5) Press to switch on or to switch off. B022/B027 4-42...
Page 234: Sp7-Xxx: Data Log
Select a number to display the total original count (number of originals fed) for the selected item. Copier Document Box Scanner Others 003* Total Print Counter All Modes Select a number to display the total print count for the selected item. Copier 4-43 B022/B027...
Page 235 205* Total ADF Counter Displays the total number of originals fed by the ADF. 206* Staple Counter Normal Display the total number of staples fired. Booklet 209* Punch Counter Displays the total times the punch has fired. DFU B022/B027 4-44...
Page 236 Copy Counter – Set Number 1 to 1 Displays the total number of prints for multiple copy jobs. 1 to 2~5 1 to 6~10 1 to 11~20 1 to 21~50 1 to 51~100 1 to 101~300 1 to 301~ Over 4-45 B022/B027...
Page 237 Displays the number of jobs classed by job content. Print 1st Page 325* Document Server: Job Counter – Page Number 1-page Displays the number of print jobs classed by size of the job. 2-pages 3~5 pages 6~10 pages over 11 pages B022/B027 4-46...
Page 238 Latest 3 Latest 4 Latest 5 Latest 6 Latest 7 Latest 8 Latest 9 502* Total Paper Jam Counter Displays the total number of paper jams. 503* Total Original Jam Counter Displays the total number of original jams. 4-47 B022/B027...
Page 239 A “Paper Lag” paper jam occurs when the paper remains at the sensor for longer than the prescribed time. At power on Paper Late Paper Lag Error No. Error No. Registration Sensor ⇒ Exit Sensor Inverter Sensor B022/B027 4-48...
Page 240 Last 6 where: Last 7 CODE is the SP7-505-*** number (see above. Last 8 SIZE is the ASAP paper size code in hex. Last 9 TOTAL is the total error count (SP7-003-001) DATE is the date the jams occurred. 4-49 B022/B027...
Page 241 Usually, this SP mode is done at installation. This SP mode is effective only once, when the counter has a negative value. MF Device Error Count Error Count Japan only DFU Staple Error Count Japan only DFU MF Device Error Count Clear Japan only DFU B022/B027 4-50...
Page 242 Execute this SP to clear the following SP modes: SP7-301 Copy Count: Magnification SP7-304 Copy Count: Copy Mode SP7-305 Copy Counter: Copy Mode SP7-306 Job Counter: Copy Mode SP7-320 Doc. Server: Scan Storage SP7-321 Doc. Server: Original Counter SP7-323 Doc. Server: Paper Size Counter 4-51 B022/B027...
Page 243: Sp9-Xxx: Debug/Testing
913* 2nd Paper Feed Amount Adjusts the amount of paper feed from the 2nd paper tray. Set a larger value when noise occurs during paper feed from the 2nd tray. [0 ~ 99.9 / 60.0 / 0.1 mm/step] B022/B027 4-52...
Page 244: Test Pattern Printing (Sp2-902-3)
Grayscale (Vertical, 8bit, Even) Argyle Pattern Grayscale with White Line (Horizontal 8bit, Even) Grayscale (Horizontal) Grayscale with White Line (Vertical 8bit, Even) ⇒ Grayscale (Vertical) Grid (1-dot pair) (with Outside Data) ⇒ Grayscale (Vertical/Horizontal) Trimming Area (with Outside Data) 4-53 B022/B027...
Page 245: Input Check
Bridge Paper Sensor Activated Deactivated Bridge Right Guide Switch Activated Deactivated Bridge Left Guide Switch Activated Deactivated Bridge Unit Set Unit Set Unit not set Bridge Fan Motor Lock Locked Unlocked Shift Tray Unit Set Unit Set Unit not set B022/B027 4-54...
Page 246 By-pass Paper Size 4 Activated Deactivated By-pass Paper Size 3 Activated Deactivated Not Used Not Used Not Used Not Used Key Counter Set Detected Not detected Key Card Set Detected Not detected Polygon Motor Ready Signal Ready Not ready Not Used 4-55 B022/B027...
Page 247 2nd Paper Size 4 Activated Deactivated 1st Paper Size 1 Activated Deactivated 1st Paper Size 2 Activated Deactivated 1st Paper Size 3 Activated Deactivated 1st Paper Size 4 Activated Deactivated NOTE: Numbers 12 to 14 are not used for this machine. B022/B027 4-56...
Page 248: Ardf Input Check (Sp6-007)
Paper not detected Paper detected ADF cover sensor Cover closed Cover opened DF position sensor ADF closed ADF opened Registration sensor Paper not detected Paper detected Exit sensor Paper not detected Paper detected Inverter sensor Paper not detected Paper detected 4-57 B022/B027...
Page 249 Deactivated Stapler Tray Paper Sensor Activated Deactivated Not Used Lower Tray Lower Limit Sensor Activated Deactivated Not used Stack Height Sensor Activated Deactivated Not Used Not Used Shift HP Sensor Activated Deactivated Exit Guide HP Sensor Activated Deactivated B022/B027 4-58...
Page 250 Entrance Sensor Activated Deactivated Not Used Not Used Not Used Staple Unit Lock Locked Not Locked Staple Cartridge Sensor Activated Deactivated Staple End Sensor Activated Deactivated Staple Hammer HP Sensor Activated Deactivated Staple Unit Cover Switch Closed Opened 4-59 B022/B027...
Page 251 Not used Toner supply motor Exhaust fan (High Speed) Exhaust fan (Low Speed) By-pass feed clutch Upper paper feed clutch Lower paper feed clutch Upper paper lift motor (Up) Upper paper lift motor (Down) Lower paper lift motor (Up) B022/B027 4-60...
Page 252 Junction gate solenoid (Optional bridge unit) 54 ~ 59 Not used Polygonal mirror motor Polygonal mirror motor and laser diode Laser diode - Do not use 53 ~ 80 Not used Duplex unit free run (without paper) Duplex unit free run (with paper) 4-61 B022/B027...
Page 253 11 Positioning Roller Solenoid Not Used 12 Stack Feed-out Motor Not Used 13 Exit Guide Plate Motor Not Used 14 Not Used Paddle Roller Solenoid 15 Not Used Exit Unit Gear Solenoid 16 Not Used Stack Height Lever Solenoid B022/B027 4-62...
Page 254 2. Touch “Execute” on the touch panel 3. Select. “Single Face” or “Both Face” then touch “Execute” to start printing. 4. After printing the list, press Exit twice to close the SP Mode screen and return to copy mode. 4-63 B022/B027...
Page 255 NCS (Network Control Initializes the system defaults and interface settings Service) (IP addresses also), SmartNetMonitor for Admin, WebStatusMonitor settings, and the TELNET settings. R-FAX Initializes the job login ID, SmartNetMonitor for Admin, job history, and local storage file numbers. B022/B027 4-64...
Page 256 • Do SP 3-001-2 (ID Sensor Initial Setting) and SP4-911-1 (HDD media check). • Do the white level adjustment ( Section 6.8.2 Standard White Density Adjustment) 6. Check the copy quality and the paper path, and do any necessary adjustments. 4-65 B022/B027...
Page 257 3. Plug the flash memory card [B] into the card slot. 4. Turn on the main switch. 5. Open SP5-824. 6. Touch “Execute” to start uploading the NVRAM data. 7. Turn off the main switch, then remove the IC card. B022/B027 4-66...
Page 258 • If the correct card for the NVRAM data is not inserted in the card slot, after you press “Execute” a message will tell you that downloading cannot proceed because the card is abnormal and the execution will halt. 4-67 B022/B027...
Page 259 0’s and 1’s. The meaning of the display is as follows. 0 0 0 0 0 0 0 0 7 6 5 4 3 2 1 0 1 = Paper detected [230V Machine] [115V Machine] B027S511.WMF B027S512.WMF Description Not Used Not Used B022/B027 4-68...
Page 260 0’s and 1’s. The meaning of the display is as follows. 0 0 0 0 0 0 0 0 7 6 5 4 3 2 1 0 1 = Paper detected B027S600.WMF Large Small Description Not Used Not Used Not Used 4-69 B022/B027...
Page 261 5.2 ± 0.5 mm 5.3 ± 0.5 mm Lower 2. Envelope feed mode (green lever down) at the 4.7 ± 0.5 mm default pressure spring position If the width is out of the above specification, the pressure spring should be replaced. B022/B027 4-70...
Page 262 9. Turn the main power on and confirm that the new software loads and that the machine starts normally. NOTE: If the download failed, an error message will appear on the panel. Then, download the firmware again using the IC card as usual. 4-71 B022/B027...
Page 263 NOTE: You must press first. B027S503.WMF 3. When the message prompts you to confirm that you want to reset the system settings, press Yes. 4. When the message tells you that the settings have been reset, press Exit. B022/B027 4-72...
Page 264 NOTE: You must press first. B027S504.WMF 3. When the message prompts you to confirm that you want to reset the Copier Document Server settings, press Yes. 4. When the message tells you that the settings have been reset, press Exit. 4-73 B022/B027...
Page 265 Click a tab to display the settings. If the Next button is lit in the lower right corner, press it to display more options. Perform the settings, press Exit to return to the User Tools/Counter display, and then press Exit to return to the copy window. B027S707.WMF B022/B027 4-74...
Page 266 The screen below shows the Printer Features screen. Inquiry In the User/Tools Counter display, press Inquiry. The following SP mode settings will be displayed. • Service Telephone Number (SP5-812-1) • Sales Telephone Number (SP812-4) • Consumable Telephone Number (SP812-3) • Toner Name (SP-841) B027S705.WMF 4-75 B022/B027...
Page 267 The following SP mode counters will be displayed. • Copy Counter (SP5-914-2) • A3/DLT Counter (SP5-918) • Printer Counter (SP5-914-1) View the settings, press Print Counter Exit to return to the User Tools/Counter display, and then press Exit to return to the copy window. B022/B027 4-76...
Page 268 System ROM Boot Keep at “OFF” SBCU: DIP SW102 ⇒ DIP SW No. Function Off: Japan On: NA Off: EU/Asia Off: Not Used Destination Not used OFF (Do not change) 4.9 SPECIAL TOOLS AND LUBRICANTS 4.9.1 SPECIAL TOOLS 4-77 B022/B027...
Page 269 Flash Memory Card - 4MB ⇒ B0049099 NVRAM - Minus Counter A2309003 Adjustment Cam – Laser Unit A2679002 Positioning Pin - Laser Unit 4.9.2 LUBRICANTS Part Number Description Q’ty A0289300 Grease Barrierta - JFE 5 5/2 52039501 Silicone Grease G-501 B022/B027 4-78...
Page 270 PREVENTIVE MAINTENANCE...
Page 272 Relay Rollers Clean with water. Bottom Plate Pad Clean with water. Registration Roller Clean with water. Mylar FUSING UNIT AND PAPER EXIT Fusing Entrance and Clean with water or alcohol. Exit Guide Plates Hot Roller Pressure Roller Fusing Thermistors B022/B027...
Page 273 Paper Feed Clutch Replace if necessary 120K 240K 360K NOTE Paper Feed Roller Pick-up Roller Separation Roller Transport Rollers Clean with water Bottom Plate Pad Clean with water Relay Clutch Replace if necessary Paper Feed Clutch Replace if necessary B022/B027...
Page 274 1-BIN TRAY UNIT Rollers Dry or damp cloth Copy Tray Dry or damp cloth Sensors Blower brush NOTE 1. Main Motor Drive Gear B027P500.WMF Do the following every EM: Lubricate the main motor drive gear [A] with silicone grease G501. B022/B027...
Page 276 REPLACEMENT AND ADJUSTMENT...
Page 278 2. Remove the left scale [A] (2 screws). 3. Remove the rear scale [B] (3 screws). 4. Remove the exposure glass [C]. NOTE: When reinstalling the exposure glass, make sure that the mark [D] is positioned at the rear left corner, as shown. B022/B027...
Page 279 3. Remove the upper front cover [A] (1 screw, 1 hook). 4. Remove the operation panel [B] (5 screws, 1 connector). 5. Remove the right cover [C] (1 screw, 2 hooks). 6. Remove the rear cover [D] (2 screws). 7. Remove the left cover [E] (2 screws, 2 hooks). B022/B027...
Page 280 3. Replace the lens block assembly [B] (4 screws, 1 connector, 2 clamps). NOTE: Do not remove the screws which are locked with white paint. 4. Reassemble the machine and do the scanner and printer copy adjustments. ( 6.8) B022/B027...
Page 281 1. Remove the exposure glass. ( 6.1.1) 2. Remove the lens cover. ( 6.1.3) 3. Remove the original width sensor [A] (1 screw, 1 connector). 4. Remove the lens block. ( 6.1.3) 5. Remove the original length sensors [B] (1 screw, 1 connector each). B022/B027...
Page 282 8. Push down the part [G] then slide out the exposure lamp [H] (1 connector). NOTE: 1) Do not touch the glass surface of the exposure lamp with bare hands. 2) After installing the lamp, the part [G] must be returned to the original position. B022/B027...
Page 283 1. Remove the connector cover [A], disconnect the cable, and remove the rear cover [B]. 2. Replace the scanner motor [C] (3 screws, 1 spring, 1 connector). 3. Replace the lamp stabilizer [D] (2 connectors). 4. Reassemble the machine and do the scanner and printer copy adjustments. ( 6.8) B022/B027...
Page 284 4. Remove the rear bracket. ( 6.1.5) 5. Remove the rear frame. ( 6.1.5) 6. Remove the lens cover. ( 6.1.3) 7. Remove the lens block assembly. ( 6.1.3) 8. Remove the front and rear scanner wire pins [A]. Then, remove the 1st scanner. B022/B027...
Page 285 17. Wind the end of the new wire with the ring as shown ( , and “ 18. Install the tension spring on the wire tension bracket ( 19. Wind the new scanner wire for the other side as well. B022/B027...
Page 286 24. Remove the positioning tools [D]. After sliding the scanner to the right and left several times, re-install the positioning tools to check the scanner wire bracket and tension bracket again. 25. Reassemble the scanner and do the scanner and printer copy adjustments ( 6.8). B022/B027...
Page 287 Turn off the main power switch and unplug the machine before attempting any of the procedures in this section. Laser beams can seriously damage your eyes. 6.2.1 CAUTION DECAL LOCATIONS Two caution decals are located in the laser section as shown below. LASER-4.WMF B027R104.WMF B022/B027 6-10...
Page 288 5. Remove the copy tray [D] (1 hook [E]). 6. Remove the toner bottle holder [F]. 7. Remove the laser unit [G] (2 screws, 2 connectors). 8. After reassembling the machine, do the scanner and printer copy adjustments. ( 6.8) 6-11 B022/B027...
Page 289 6.2.4 LD UNIT B027R105.WMF 1. Remove the laser unit ( 6.2.2). 2. Replace the LD unit [A] (3 screws, 1 connector). NOTE: 1) Do not remove the screws [B]. 2) Do not touch any variable resistors on the LD unit. B022/B027 6-12...
Page 290 1. Remove the laser unit ( 6.2.2). 2. Remove the heat sink [A] (4 screws). 3. Remove the laser unit cover [B] (3 screws). 4. Remove the bracket [C] (1 screw). 5. Replace the laser synchronization detector [D] (1 connector). 6-13 B022/B027...
Page 291 6.3 PHOTOCONDUCTOR UNIT (PCU) 6.3.1 PCU B027R203.WMF 1. Open the right cover [A] and front cover [B]. 2. Pull the PCU [C] out slightly while pushing the release lever [D]. NOTE: Do not touch the drum surface with bare hands. B022/B027 6-14...
Page 292 TRANSFER UNIT 6.4 TRANSFER UNIT 6.4.1 TRANSFER ROLLER UNIT B027R401.WMF 1. Open the right cover [A]. 2. Remove the transfer roller unit [B] (1 hook). NOTE: Do not touch the transfer roller surface. 6-15 B022/B027...
Page 293 2. Remove the unit band [B]. 3. Remove the right cover [A] (1 connector), 4. Remove the sub right cover [C] (2 hooks). 5. Replace the image density sensor [D] (1 connector). 6. Initialize the new sensor with SP 2-935. B022/B027 6-16...
Page 294 1. Release the duplex unit, if it has been installed, and open the right cover. 2. Remove the fusing unit [A] (2 screws). 6.5.2 THERMISTORS B022R551.WMF 1. Remove the fusing unit. ( 6.5.1). 2. Remove the plates [A] (1 screw each). 3. Replace the thermistors [B] (1 connector). 6-17 B022/B027...
Page 295 FUSING/EXIT 6.5.3 THERMOFUSE B027R503.WMF B022R552.WMF 1. Remove the fusing unit. ( 6.5.1) 2. Remove the fusing upper cover [A] (4 screws). 3. Remove the pressure springs [B]. 4. Remove the hot roller stripper bracket [C] (3 screws). B022/B027 6-18...
Page 296 FUSING/EXIT B022R553.WMF B022R554.WMF 5. Remove the thermostat cover [A] (2 tapping screws). 6. Remove the plate [B] (2 screws with spring washer). 7. Remove the thermostat holder [C] (3 screws each). 8. Replace the thermostats [D]. 6-19 B022/B027...
Page 297 After installation, remove the protective sheet. 3) Do not touch the surface of the rollers. 4) When reinstalling the fusing lamp, secure the front screws first. 5) Be careful not to damage the surface of the hot roller. B022/B027 6-20...
Page 298 2. Replace the pressure roller [A] (1 E-ring, 2 bushings, 1 spring). 3. Replace the cleaning roller [B]. NOTE: 1) Apply grease (Barrierta) to the inner surface of the bushing for the pressure roller. 2) Do not touch the surface of the rollers. 6-21 B022/B027...
Page 299 2. Remove the exit cover [B]. NOTE: If the optional 1 bin tray unit and/or interchange unit have been installed, remove them. 3. Replace the exit sensor [C] (1 connector). 4. Replace the overflow sensor [D] (1 connector). B022/B027 6-22...
Page 300 6.6.1 FEED ROLLERS B027R723.WMF 1. Remove the paper tray [A]. 2. Pull the lever [B]. 3. Replace the feed roller [C]. NOTE: Do not touch the roller surface with bare hands. After reinstalling the feed roller, return the lever [B]. 6-23 B022/B027...
Page 301 PAPER FEED 6.6.2 PAPER END SENSOR B027R724.WMF 1. Remove the paper tray [A]. 2. Remove the paper end sensor assembly (1 screw, 1 connector). 3. Replace the paper end sensor [B]. B022/B027 6-24...
Page 302 3. Remove the rear cover [B] (4 screws). 4. Remove the duplex connector cover [C] (1 screw). 5. Remove the lower rear cover [D] (2 screws). 6. Replace the paper lift motors [E] (2 screws each, 1 connector each). 6-25 B022/B027...
Page 303 1. Remove the connector cover and the rear cover. ( 6.6.3) 2. Remove the duplex connector cover and lower rear cover. ( 6.6.3) 3. Remove the fly wheels [A] (1 screw). 4. Remove the registration clutch [B] (1 E-ring, 1 connector). B022/B027 6-26...
Page 304 4. Disconnect the connectors [B] for the SBCU board as shown (14 connectors). 5. Remove 4 screws [C] securing the SBCU board bracket then swing down the I/O board bracket [D]. 6. Remove the bracket [E] (1 screw). 7. Replace the upper paper feed clutch [F] (1 connector). 6-27 B022/B027...
Page 305 6. Swing down the I/O board bracket. ( 6.6.5) 7. Remove the connector bracket [C] (2 screws). 8. Replace the upper relay clutch [D] (1 connector). 9. Remove the right back cover [E] (1 screw). 10. Replace the lower relay clutch [F] (1 connector). B022/B027 6-28...
Page 306 6.6.7 PAPER SIZE DETECTOR B027R721.WMF B022R722.WMF 1. Remove the right lower cover [A]. ( 6.6.6) 2. Remove the paper trays. 3. Remove the paper size detector assembly (1 screw each). 4. Replace the paper size detectors [B] (1 connector each). 6-29 B022/B027...
Page 307 1. Remove the right cover. ( 6.4.2) 2. Remove the registration guide plate [A] (2 screws). 3. Remove the paper support roller [B] (2 snap rings, 2 bushings). 4. Remove the sensor bracket [C] (1 screw). 5. Replace the registration sensor [D] (1 connector). B022/B027 6-30...
Page 308 1. Remove the right lower door [F] (1 clip). 2. Remove the guide plate [G]. 3. Remove the guide plate [H] (2 screws). 4. Remove the sensor bracket [I] (1 screw). 5. Replace the lower relay sensor [J] (1 connector). 6-31 B022/B027...
Page 309 4. Remove the shield plate [B] (8 screws) or the optional fax unit if it has been installed. 5. Remove the controller board [C] (2 connectors, 8 screws). 6. Remove the NVRAM [D], and DIMM (printer/scanner, memory, etc) from the old controller board and put them on the new controller board. B022/B027 6-32...
Page 310 Make sure that the DIPswitch settings on the new board are the same as those on the old board. 6.7.3 POWER PACK B027R710.WMF Remove the rear cover. (☛ 6.6.3) 2. Swing down the I/O board bracket. (☛ 6.6.5) 3. Remove the power pack [A] (5 connectors, 3 screws) 6-33 B022/B027...
Page 311 6.7.4 MAIN MOTOR B027R711.WMF 1. Remove the rear cover. ( 6.6.3) 2. Swing down the I/O board bracket [A]. ( 6.6.5) 3. Remove the fly wheels [B] (1 screw). 4. Replace the main motor [C] (2 connectors, 3 screws). B022/B027 6-34...
Page 312 2. Remove the application cover [A] (1 screw). 3. Remove the left cover [B] (6 screws). 4. 220 V machine only: Remove the transformer [C] (1 screw). 5. Remove the PSU [D] (all connectors, 6 screws, 1 clip). 6-35 B022/B027...
Page 313 SP1-002-2 3rd paper feed (Optional 2 ± 1.5 mm SP1-002-3 PFU tray 1), or LCT 4th paper feed (Optional SP1-002-4 B027R508.WMF PFU tray 2) By-pass feed SP1-002-5 Duplex, side 2 SP1-002-6 A: Leading Edge Registration B: Side-to-side Registration B022/B027 6-36...
Page 314 C: Leading Edge Blank Margin D: Left Edge Blank Margin Main Scan Magnification 1. Print the single-dot grid pattern (SP2-902, no.5). 2. Check the magnification, and adjust the magnification using SP2-909 if necessary. The specification is ± 1%. 6-37 B022/B027...
Page 315 7. Adjust the laser unit position by turning the adjusting cam. (Refer to the above illustration for the relationship between the image and the cam rotation direction). 8. Tighten the adjustment bracket. 9. Print the trimming area pattern to check the image. If it is still unsatisfactory, repeat steps 4 to 8. B022/B027 6-38...
Page 316 1. Place the test chart on the exposure glass and make a copy from one of the feed stations. 2. Check the magnification ratio, and adjust it using the following SP mode if necessary. The specification is ±1%. SP mode Sub Scan Magnification SP4-009 Main Scan Magnification SP4-008 6-39 B022/B027...
Page 317 1. Place 10 sheets of new A4 sideways (do not use any recycled paper) or A3 paper on the exposure glass and close the platen cover or the ADF. 2. Enter SP 4-428 and select “1: Yes”. The standard white density is automatically adjusted. B022/B027 6-40...
Page 318 1. Place the temporary test chart on the ADF and make a copy from one of the feed stations. 2. Check the magnification, and adjust using the following SP modes if necessary. The specification is ±1%. SP mode Sub scan magnification SP6-006-5 6-41 B022/B027...
Page 319 Cancel and repeat from Step 2. 6. When you are finished, press [#] OK on the screen (or press ). 7. Touch [#] Exit on the screen to close the Self-Diagnostic menu and save the calibration settings. B022/B027 6-42...
Page 320 • Only the image’s trailing edge is slanted with respect to the paper. The remaining 3 sides are parallel to the paper’s edges. Feed direction Parallel Trapezoid image may also appear in the opposite orientation. Paper Image Area 6-43 B022/B027...
Page 321 • Like skewed images, the leading/trailing edges and left/right edges are parallel to each other, however here, the leading and trailing edges are both slanted with respect to the paper’s edge. Feed direction Parallel Parallel Parallelogram may also appear in the opposite orientation. Paper Image Area B022/B027 6-44...
Page 322 SP2-902-3 (value: 10). Skewed Parallelogram See Adjusting Skewed Images, See Parallelogram Image pg. 6-46 Adjustment, Service Manual pg. 6-38 Trapezoid Combination skewed and trapezoid image See Adjusting Trapezoid Images, pg. 6-49 Perform Adjusting Skewed Images first, then Adjusting Trapezoid Images. 6-45 B022/B027...
Page 323 Is the image skewed? Are the front and rear transport rollers feeding the original straight? Change the position of the right hinge screw to the longer hole, and make any minor positional adjustments necessary. Perform Procedure B. Procedure complete. B022/B027 6-46...
Page 324 6. Place a washer (P/N 07080050, 1mm thick) in between the two to occupy the gap [A]. Fix the washer in place using an instant-acting adhesive. Note: This washer will also act to absorb minor amounts of shock. 7. Check whether the parallelogram image still appears. 6-47 B022/B027...
Page 325 1) Add a spacer (t = 0.5 to 0.8) between the hinge bracket (mainframe) and ADF left hinge, in order to raise the height of the left side of the ADF, OR: 2) Adjust the stepped height difference between the hinge bracket and scanner housing until it is within 0±0.3mm. B022/B027 6-48...
Page 326 2) Tighten the left fixing screw while pushing up on the unit’s left side (until it stops). 3. If the image is a Pattern B trapezoid, do the same for the unit’s right side. 4. If the image is still printed out as a trapezoid, perform Procedure 2. 6-49 B022/B027...
Page 327 Adjustment Complete. 4. Remove the Fusing Unit and all the washers added in Steps 1 and 2 above. Then, add washer(s) in the same way for the rear side. Recommended Washers: t = 0.5 07080040Z t = 0.8 07080050Z B022/B027 6-50...
Page 328 TROUBLESHOOTING...
Page 330 NOTE: 1) If the problem concerns electrical circuit boards, first disconnect then reconnect the connectors before replacing the PCBs. 2) If the problem concerns a motor lock, first check the mechanical load before replacing motors or sensors. B022/B027...
Page 331 • Harness between SBCU and scanner the scanner returns to the home drive motor power source disconnected position. • Scanner HP sensor defective • Harness between SBCU and HP sensor disconnected • Scanner wire, timing belt, pulley, or carriage defective B022/B027...
Page 332 Installation error (wrong SBCU or The SICU and IPU boards installed are IPU). not for the same model (e.g. the SBCU is for the B022, and the IPU is for the B027). • SBU defective Automatic SBU adjustment error • SBCU board defective An error is detected during automatic •...
Page 333 • ID sensor defective adjustment range (2.0 ±<> 0.2 V) after • TD sensor abnormal the TD sensor initial setting has been • Drum does not turn finished. • Development roller does not turn • Poor connection of the PCU B022/B027...
Page 334 LCT lower limit error • Poor connection of the tray lift motor The lower limit sensor does not activate • Lower limit sensor defective within 8 seconds after the tray has been lowered. • Too much load on the drive mechanism B022/B027...
Page 335 Too much load on the motor drive • Serial line connecting SBCU and Communication break error between SBCU and ADF ADF unstable • External noise The SBCU receives a break signal from • ADF main board defective the ADF main board. • SBCU board defective B022/B027...
Page 336 • Controller board defective After powering on the machine, the communication circuit between the • Operation panel connector loose or controller and the operation panel is not defective opened, or communication with controller is interrupted after a normal startup. B022/B027...
Page 337 The stapler does not return to its home • Poor stapler motor connection position within a certain time after the stapler motor turned on. The stapler H.P sensor does not activate within a certain time after the stapler motor turned on. B022/B027...
Page 338 • Controller board defective Watchdog error • Software malfunction – download The CPU does not access the controller firmware again watchdog register within a certain time. Kernel mismatch error Download controller firmware again Software bug B022/B027...
Page 339 Self-diagnostic Error: Clock Generator Replace the controller board A verify error occurred when setting data was read from the clock generator via the I2C bus. • NIB defective Network I/F Abnormal • NIB interface error. Controller board defective B022/B027 7-10...
Page 340 Printer ready error • Replace the IPU board The printer ready signal is not • Replace the controller board generated within 17 seconds after the • Download the controller firmware IPU received the print start signal. 7-11 B022/B027...
Page 341 PCB targeted for the download and prevent subsequent downloading. If this problem occurs, the damaged PCB must be replaced. B022/B027 7-12...
Page 342 Font ROM Check Memory Check RTC Check IC Card Program ROM, DIMM CRC Check I/FCheck SSCG Check Network Check OPC Check Engine I/F Check Illegal Interrupt NVRAM Check Check System OS, HDD Check Application Check IEEE1284 I/F Check B027T516.WMF 7-13 B022/B027...
Page 343 , press and hold down , and then while pressing both keys at the same time, switch on the machine. You will see “Now Loading” on the touch-panel, and then you will see the results of the test. B022/B027 7-14...
Page 344 : B0045383 FIN_SDL : BANK : A6825150 [Error List @@@] SCCODE (ERROR CODE ) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC835 (110C) SC820 (0001) SC820 (0002) SC820 (0003) SC820 (0004) SC820 (0005) B027T515.WMF 7-15 B022/B027...
Page 345 Tray 1-908-1 1st Tray 1-908-2 1st Tray 1-908-4 1st Tray 1-909-1 2nd Tray 1-909-2 2nd Tray 1-909-4 2nd Tray 1-910-1 3rd Tray 1-910-2 3rd Tray 1-910-4 3rd Tray 1-911-1 4th Tray 1-911-2 4th Tray 1-911-4 4th Tray B027T500.WMF B022/B027 7-16...
Page 346 - Check the side fence position of the original table. - Clean or replace the original feed belt, pick-up roller, and separation roller. - Clean the transport roller and exit roller. - Secure the ADF using the long hole, then adjust the ADF position. B027T501.WMF 7-17 B022/B027...
Page 347 The Paper Jam indicator will light whenever a Open copy is made. 321-6 Registration (SBCU) The Paper Jam indicator lights even if there is Shorted no paper. Open SC501 will be displayed. 305-7 1st Paper Lift (SBCU) Shorted Paper jam will occur during copying. B022/B027 7-18...
Page 348 The CPU cannot determine the paper near- end condition properly. – 2 (SBCU) Shorted NOTE: An SC condition occurs only when a new PCU is being installed in the machine. During copying, if the ID sensor fails, the image density will be changed. 7-19 B022/B027...
Page 349 The Cover Open indicator is lit even if the front Shorted cover is closed. The LCD does not off even if the operation Open switch is turned off. 105-1 Operation (IPU The LCD does not on even if the operation Shorted switch is turned on. B022/B027 7-20...
Page 350 SC792 is displayed. Covers Open indicator is lit then SC901 6.3 A/125 V 6.3 /250 V is displayed 6.3 A/125 V 6.3 A/250V The touch panel does not turn on. 4 A/125 V 4 A/250 V SC990 is displayed 7-21 B022/B027...
Page 352 PAPER TRAY UNIT A860/B390...
Page 354 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS A5 to A3 Paper Size: HLT lengthwise to DLT Paper Weight: 60 ~ 105 g/m , 16 ~ 28 lbs. Tray Capacity: 500 sheets (80 g/m , 20 lbs.) x 2 trays Paper Feed System: Feed roller and friction pad Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Page 355 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B390V101.WMF 1. Upper paper feed roller 5. Upper bottom plate 2. Lower paper feed roller 6. Lower bottom plate 3. Upper tray 7. Optional tray heater 4. Lower tray A860/B390...
Page 356 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT 1. Tray main board 11. Lower paper height 1 sensor 2. Upper lift sensor 12. Vertical transport sensor 3. Upper lift motor 13. Upper paper end sensor 4. Upper paper height 2 sensor 14.
Page 357 ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Tray Drives all rollers. Upper Lift Lifts the upper tray bottom plate. Lower Lift Lifts the lower tray bottom plate. Sensors Upper Lift Detects when the paper in the upper tray is at the correct feed height.
Page 358 DRIVE LAYOUT 1.5 DRIVE LAYOUT B390V103.WMF 1. Tray motor 5. Lower paper feed clutch 2. Drive belt 6. Relay roller 3. Upper paper feed clutch 7. Lower paper feed roller 4. Relay clutch 8. Upper paper feed roller A860/B390...
Page 359 PAPER FEED AND SEPARATION MECHANISM 2. DETAILED DESCRIPTIONS 2.1 PAPER FEED AND SEPARATION MECHANISM B390D104.WMF The paper tray holds 500 sheets. The paper feed roller [A] drives the top sheet of paper from the paper tray to the copier/printer. The friction pad [B] allows only one sheet to feed at a time.
Page 360 PAPER LIFT MECHANISM 2.2 PAPER LIFT MECHANISM B390D106.WMF B390D107.WMF The paper size switch detects when the tray is pushed in. When the paper tray is pushed into the machine, the pin [A] for the lift motor pressure shaft engages the lift motor coupling [B] and the pin [C] for the bottom plate lift shaft in the tray engages the bottom plate pressure lever coupling [D].
Page 361 PAPER LIFT MECHANISM The paper size thresholds for this feature depend on SP1-908-8, 9, 17, and 18. (Note that there are two paper size thresholds for each tray: small and middle. Some models only use the small threshold.) The amount of reverse depends on SP 1-908-1, 2, 3, 10, 11, and 12.
Page 362 PAPER END DETECTION 2.3 PAPER END DETECTION B390D105.WMF If there is some paper in the paper tray, the paper stack raises the paper end feeler [A] and the paper end sensor [B] is deactivated. When the paper tray runs out of paper, the paper end feeler drops into the cutout [C] in the tray bottom plate and the paper end sensor is activated.
Page 363 PAPER HEIGHT DETECTION 2.4 PAPER HEIGHT DETECTION B390D107.WMF The amount of paper in the tray is detected by the combination of on/off signals from two paper height sensors [A] and [B]. When the amount of paper decreases, the bottom plate pressure lever [C] moves the actuator up.
Page 364 PAPER HEIGHT DETECTION The amount of remaining paper depends on SP modes 1-908-6, 7, 15, and 16. The amount of forward rotation depends on SP1-908-4, 5, 13, and 14. Note that there are two paper size thresholds for each tray: small and middle (this is the same as for the paper lift mechanism described earlier).
Page 365 PAPER SIZE DETECTION 2.5 PAPER SIZE DETECTION Size O O O 2 A3, F (8 " x 13") O 2 O 2 A4 Lengthwise O 2 2 2 A4 Sideways O O 2 2 A5 Sideways, 11" x 17" 2 O 2 2 B4, 8 "...
Page 366 SIDE AND END FENCES 2.6 SIDE AND END FENCES B390D110.WMF B390D109.WMF Side Fences If the tray is full of paper and it is pushed in strongly, the fences may deform or bend. This may cause the paper to skew or the side-to-side registration to be incorrect.
Page 367 FEED ROLLER REPLACEMENT 3. REPLACEMENT AND ADJUSTMENT 3.1 FEED ROLLER REPLACEMENT B390R723.WMF 1. Remove the paper tray [A]. 2. Move the release lever [B] to the front. 3. Pull the feed roller [C] to the operation side and remove it. 4.
Page 368 TRAY MAIN BOARD REPLACEMENT B390R101.WMF B390R103.WMF 3.2 TRAY MAIN BOARD REPLACEMENT 1. Remove the rear cover [A] (4 screws). 2. Replace the tray main board [B] (4 screws and 8 connectors). 3.3 TRAY MOTOR REPLACEMENT 1. Remove the rear cover (4 screws). 2.
Page 369 RELAY CLUTCH REPLACEMENT 3.4 RELAY CLUTCH REPLACEMENT B390R101.WMF B390R102.WMF 1. Remove the rear cover [A] (4 screws). 2. Remove the right cover [B] (2 screws). 3. Remove the snap ring [C]. 4. Remove the bushing [D]. 5. Remove the stopper bracket [E] (2 screws). 6.
Page 370 UPPER PAPER FEED CLUTCH REPLACEMENT 3.5 UPPER PAPER FEED CLUTCH REPLACEMENT B390R101.WMF B390R102.WMF 1. Remove the rear cover [A] (4 screws). 2. Remove the bracket [B] (2 screws). 3. Remove the snap ring [C]. 4. Remove the bushing [D]. 5. Remove the stopper bracket [E] (2 screws). 6.
Page 371 LOWER PAPER FEED CLUTCH REPLACEMENT 3.6 LOWER PAPER FEED CLUTCH REPLACEMENT B390R101.WMF B390R102.WMF 1. Remove the rear cover [A] (4 screws). 2. Remove the snap ring [B]. 3. Replace the lower paper feed clutch [C]. A860/B390 8-18...
Page 372 LIFT MOTOR REPLACEMENT 3.7 LIFT MOTOR REPLACEMENT B390R101.WMF B390R104.WMF 1. Pull out the paper tray. 2. Remove the rear cover [A] (4 screws) and the bracket [B] (2 screws). 3. Disconnect the 2P connector [C]. 4. Remove the spring [D]. 5.
Page 373 PAPER END SENSOR REPLACEMENT 3.8 PAPER END SENSOR REPLACEMENT B390R106.WMF 1. Remove the paper tray. 2. Remove the paper end sensor bracket [A] (1 screw and 1 connector). 3. Replace the paper end sensor [B]. NOTE: After replacing the sensor, pull the sensor cable towards the right side of the frame [C] so that it does not touch the paper in the tray.
Page 374 PAPER SIZE SWITCH REPLACEMENT 3.10 PAPER SIZE SWITCH REPLACEMENT B390R108.WMF 1. Remove the upper and lower paper trays. 2. Remove the inner cover [A] (2 screws). 3. Replace the paper size switch [B] (1 connector). 8-21 A860/B390...
Page 376 A862/B391...
Page 378 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS A4 sideways/LT sideways Paper Size: Paper Weight: 60 g/m ~ 105 g/m , 16 lb ~ 28 lb Tray Capacity: 2,000 sheets (80 g/m , 20lb) Remaining Paper Detection: 5 steps (100%, 75%, 50%, 25%, Near end) Power Source: 24 Vdc, 5 Vdc (from copier/printer) Power Consumption:...
Page 379 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B391D101.WMF 1. Pick-up Roller 7. Paper Height Sensors 1, 2, 3 2. Upper Limit Sensor 8. Lower Limit Sensor 3. Paper Feed Roller 9. Left Paper End Sensor 4. Relay Sensor 10. Paper Height Sensors 4,5 5.
Page 380 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT B391D102.WMF B391D103.WMF 1. Main Board 12. Paper Height Sensors 1, 2, 3 2. Tray Sensor (Switch) 13. Lower Limit Sensor 3. Relay Clutch 14. Side Fence Solenoid 4. Paper Feed Clutch 15. Rear Fence Return Sensor 5.
Page 381 ELECTRICAL COMPONENT DESCRIPTIONS 1.4 ELECTRICAL COMPONENT DESCRIPTIONS Symbol Name Function Index No. Motors Tray Motor Drives all rollers. Tray Lift Motor Drives the paper tray up or down. Rear Fence Moves the rear fence to transfer the paper Motor stack from the paper storage (left) side of the tray to the paper feed (right) side.
Page 382 PAPER FEED 2. DETAILED SECTION DESCRIPTIONS 2.1 PAPER FEED B391D104.WMF This products uses an FRR type paper feed mechanism. The paper feed unit consists of the pickup roller [A], paper feed roller [B], reverse roller [C], and grip and transport rollers. There is a torque limiter in the back of the reverse roller (ferrite powder type).
Page 383 REVERSE ROLLER AND PICK-UP ROLLER RELEASE 2.2 REVERSE ROLLER AND PICK-UP ROLLER RELEASE B391D107.WMF B391D108.WMF To prevent the paper from being torn when pulling out the paper feed tray, the reverse and pickup rollers are set so that they release automatically. When the paper tray [A] is not inside the machine, the reverse roller [B] is away from the paper feed roller [C] and the pick-up roller [D] stays in the upper position.
Page 384 TRAY LIFT 2.3 TRAY LIFT B391D110.WMF When the paper feed tray is put in the machine, the tray switch [A] on the back face turns on and the tray lift motor [B] starts up. The base plate lift shaft [C] is coupled to the lift motor at shaft [D], so the base plate of the tray is lifted.
Page 385 NEAR END/END DETECTION 2.4 NEAR END/END DETECTION This tray can hold two stacks of paper, so the machine needs to monitor the status of both these stacks. There are seven sensors to do this. In the right tray (paper feed side), three height sensors measure the height of the stack, and an end sensor detects when all the paper is used up.
Page 386 RIGHT TRAY SIDE FENCE 2.5 RIGHT TRAY SIDE FENCE B391D109.WMF When the paper in the right tray is used up, the side fence solenoid [F] activates and stays on until the side fence open/closed sensor [E] detects that the fence is open.
Page 387 RIGHT TRAY PAPER END DETECTION 2.7 RIGHT TRAY PAPER END DETECTION B391D106.WMF B391D111.WMF The paper end sensor [A] detects when copy paper in the right tray runs out. When there is paper in the tray, the paper pushes up the paper end feeler [B] and causes the actuator to come between the LED and photo diode of the sensor.
Page 388 DETACHING THE TRAY FROM THE MAINFRAME REPLACEMENT AND ADJUSTMENT 3.1 DETACHING THE TRAY FROM THE MAINFRAME While pressing the stopper attached to the guide rail, pull out the large capacity tray. NOTE: When reinstalling the tray, set the tray on the guide rail and carefully push the tray in, making sure to keep the tray level.
Page 389 CHANGING THE TRAY PAPER SIZE 3.3 CHANGING THE TRAY PAPER SIZE B391R103.WMF 1. Remove the screws of all side fences [A], [B]. 2. The position of the rear fence HP sensor can then be changed (see Rear Fence HP Sensor Removal). 3.
Page 390 TRAY LIFT MOTOR 3.5 TRAY LIFT MOTOR B391R105.WMF B391R106.WMF 1. Remove the brackets (1 screw for each). 2. Remove the rear cover [A] (2 screws). 3. Remove the tray lift motor [B] (3 screws, 1 connector). 9-13 A862/B391...
Page 391 TRAY MOTOR 3.6 TRAY MOTOR B391R107.WMF 1. Remove the rear cover. 2. Remove bracket #1 [A] (2 screws). 3. Remove bracket #2 [B] (2 screws). 4. Remove the tray motor [C] (6 screws, 1 connector). A862/B391 9-14...
Page 392 PAPER FEED CLUTCH AND RELAY CLUTCH 3.7 PAPER FEED CLUTCH AND RELAY CLUTCH B391R108.WMF 1. Remove the rear cover. 2. Remove bracket #1 [A] (2 screws). 3. Remove bracket #2 [B] (2 screws). 4. Remove all bushings. 5. Remove the paper feed clutch [C] and relay clutch [D]. 6.
Page 393 PAPER FEED UNIT 3.8 PAPER FEED UNIT B391R109.WMF B391R110.WMF 1. Remove the paper feed clutch and relay clutch (see Paper Feed Clutch and Relay Clutch Replacement). 2. Remove pulleys A [A], B [B], and C [C]. 3. Remove the paper feed harness from the main board. 4.
Page 394 UPPER LIMIT, RIGHT TRAY PAPER END, AND RELAY SENSORS 3.9 UPPER LIMIT, RIGHT TRAY PAPER END, AND RELAY SENSORS B391R111.WMF 1. Remove the paper feed unit (see Paper Feed Unit Replacement). 2. Replace the required sensor. • Upper limit [A] •...
Page 395 REAR FENCE MOTOR 3.10 REAR FENCE MOTOR B391R112.WMF B391R113.WMF B391R114.WMF 1. Pull out the paper feed tray unit. 2. Remove the paper feed tray front cover [A] (2 screws). 3. Remove the left side fence [B]. 4. Remove the rear fence drive gear [C] (1 screw). This is in order to free the end fence [D].
Page 396 PICK-UP/PAPER FEED/REVERSE ROLLERS 3.11 PICK-UP/PAPER FEED/REVERSE ROLLERS B391R115.WMF 1. Remove the paper tray unit (see Paper Tray Unit Replacement). 2. Remove the snap ring (1 each for the paper feed and reverse rollers). 3. Remove the pick up roller [A]. 4.
Page 398 AUTO REVERSE DOCUMENT FEEDER B386...
Page 400 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Original Size: Standard sizes Single-sided mode: A3 to A5, DLT to HLT Double-sided mode: A3 to A4, DLT to LT Non-standard sizes (Single-sided mode only) Max. width 297 mm Min. width 105 mm Max.
Page 401 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B386D201.WMF 1. Separation Roller 11. Reverse Roller 2. Paper Feed Belt 12. Junction Gate 3. Pick-up Roller 13. Exit Roller 4. Original Set Sensor 14. Original Exit Sensor 5. Original Trailing Edge Sensor 15.
Page 402 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT B386D202.WMF 1. DF Feed Clutch 10. DF Feed Motor 2. Feed Cover Open Sensor 11. DF Transport Motor 3. Original Width Sensor Board 12. Original Exit Sensor 4. Original Length Sensor 1 13. Stamp Solenoid 5.
Page 403 ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Index Symbol Name Function Motors DF Feed Drives the feed belt, separation, pick-up, and reverse table rollers. DF Transport Drives the transport and exit rollers Sensors DF Position Detects when the DF is lifted. Registration Detects the leading edge of the original to turn off the DF feed and transport motors, detects...
Page 404 DRIVE LAYOUT 1.5 DRIVE LAYOUT B386D203.WMF 1. Separation Roller 6. DF Feed Motor 2. Original Feed Belt 7. Reverse Table Roller 3. Pick-up Roller 8. 2nd Transport Roller 4. DF Feed Clutch 9. Exit Roller 5. DF Transport Motor 10. 1st Transport Roller 10-5 B386...
Page 405 ORIGINAL SIZE DETECTION 2. DETAILED SECTION DESCRIPTIONS 2.1 ORIGINAL SIZE DETECTION B386D503.WMF The original size detection mechanism consists of the original width sensor board [A] and two original length sensors-1 [B] and -2 [C]. Based on the combined output of the length sensors and the width sensor board, the machine can detect the size of the original.
Page 406 ORIGINAL SIZE DETECTION Original Width-3 Original Original Original Original Width-1 Width-2 Length-1 Length-2 A3 (297 x 420) — — — B4 (257 x 364) — — — A4 (Lengthwise) — — — — (210 x 297) A4 (297 x 210) —...
Page 407 ORIGINAL SIZE DETECTION Original Width Sensor Board GND Pattern Original Width 1 Original Width 2 Original Side Guide Position A3/A4S B4/B5S A4L/A5S B5L/A5L The signal is "L" when the terminal plate is connected to the GND pattern. B386D501.WMF B386 10-8...
Page 408 MIXED ORIGINAL SIZE MODE 2.2 MIXED ORIGINAL SIZE MODE This section explains what happens when the user selects mixed original size mode. Because this ADF is a sheet-through document feeder, the method for original document width detection is the same as when the originals are the same size, but the document length detection method is different.
Page 409 PICK-UP AND SEPARATION 2.3 PICK-UP AND SEPARATION B386D504.WMF B386D505.WMF The original is set with the image facing up. The original pushes actuator [A] and the original set sensor [E] is activated. After pressing the start button, the pick-up solenoid [D] is activated and the lift plate [C] lifts the original up until it comes in contact with the pick-up roller [B].
Page 410 ORIGINAL TRANSPORT AND EXIT 2.4 ORIGINAL TRANSPORT AND EXIT 2.4.1 SINGLE-SIDED ORIGINALS B386D506.WMF The DF feed motor feeds the separated original to the first transport roller [A] at maximum speed. When the registration sensor [B] detects the leading edge, the motor stops for a short while.
Page 411 ORIGINAL TRANSPORT AND EXIT 2.4.2 DOUBLE-SIDED ORIGINALS B386D204.WMF B386D205.WMF When the registration sensor [B] detects the leading edge of the original, the DF feed motor (which drives the feed roller) and transport motor (which drives the transport roller) both switch off. After a brief interval, the transport motor alone reactivates to drive the first [A] and second transport roller [G] and the exit roller [F].
Page 412 ORIGINAL TRANSPORT AND EXIT B386D206.WMF B386D207.WMF The original is then sent to the reverse table [H] a second time to be turned over. This is done so that the duplex copies will be properly stacked front side down in the exit tray [J] in the correct order. 2.4.3 ORIGINAL TRAILING EDGE SENSOR During one-to-one copying, copy paper is fed to the registration roller in advance (while the original is still being scanned), to increase the copy speed.
Page 413 STAMP 2.5 STAMP B386D507.WMF This function is only for fax mode. There is a stamp [A] between the 2nd transport roller [B] and the exit roller [C], and its solenoid is controlled by the copier directly. When the original reaches the stamp position, the DF feed motor stops. At 300 milliseconds after stopping the DF feed motor, the stamp solenoid turns on if the page was sent successfully (immediate transmission) or stored successfully (memory transmission).
Page 414 TIMING CHART 2.6 TIMING CHART LT SIDEWAYS STAMP MODE (DOUBLE-SIDED ORIGINAL MODE) B386D101.WMF 10-15 B386...
Page 415 CONDITION OF JAM DETECTION CONDITION OF JAM DETECTION JAM 1A: If the registration sensor does not turn on within 114 mm x 2 since the feed motor started (twice the distance between the original set position and the (registration sensor). JAM 1B: Duplex mode only: If the registration sensor does not turn on within 161 mm x 1.5 since the feed motor started (1.5 times the distance between the original reverse position and the registration sensor).
Page 416 OVERALL ELECTRICAL CIRCUIT 2.8 OVERALL ELECTRICAL CIRCUIT The DF CPU controls the transport motor, DF feed motor, DF feed clutch, junction Gate solenoid, stamp solenoid, and pick-up solenoid. The DF CPU also monitors all DF sensors and provides updated status information when prompted at regular intervals by the mainframe, which may then take action based on this information.
Page 417 DIP SWITCHES 3. SERVICE TABLES 3.1 DIP SWITCHES SW100 Description Normal operating mode (Default) No function Free run with two-sided original 100% DF feed clutch operates Free run with one-sided original 32.6% DF pick-up solenoid operates Motors rotate No function Free run with one-sided original 100% Junction gate solenoid operates Free run without two-sided original 100%...
Page 418 DF EXIT TABLE AND COVER 4. REPLACEMENT AND ADJUSTMENT 4.1 DF EXIT TABLE AND COVER B386R506.WMF 1. Open the DF feed cover. 2. Remove the front cover [A] (3 screws). Remove the rear cover [B] (3 screws). 3. Open the reverse table [C]. Remove the original exit table [D] (3 screws).
Page 419 ORIGINAL FEED UNIT 4.2 ORIGINAL FEED UNIT B386R500.WMF 1. Open the left cover. 2. Detach the paper feed unit by sliding it toward the front of the machine (spring- loaded side) and then lifting the far side. B386 10-20...
Page 420 LEFT COVER 4.3 LEFT COVER B386R507.WMF 1. Remove the front and rear covers. 2. Remove the left cover [A]. 3. Remove the lower left stay unit [B] (2 screws). 10-21 B386...
Page 421 PICK-UP ROLLER 4.4 PICK-UP ROLLER B386R501.WMF 1. Remove the original feed unit. 2. Replace the pick-up roller [A] (1 snap ring). B386 10-22...
Page 422 FEED BELT 4.5 FEED BELT B386R204.WMF B386R205.WMF 1. Remove the original feed unit. 2. Open the paper feed guide [A]. 3. Remove the belt holders [B]. 4. Replace the feed belt [C]. 10-23 B386...
Page 423 SEPARATION ROLLER 4.6 SEPARATION ROLLER B386R502.WMF 1. Lift the original feed guide [A]. 2. Remove the separation roller cover [B]. 3. Replace the separation roller [C]. B386 10-24...
Page 424 ORIGINAL SET/ORIGINAL REVERSE SENSOR 4.7 ORIGINAL SET/ORIGINAL REVERSE SENSOR B386R201.WMF 1. Open the left cover. 2. While pushing the left and right pawls [A], open the original feed guide plate [B]. 3. Remove the original set sensor [C] 4. Remove the original reverse sensor [D]. 10-25 B386...
Page 425 ORIGINAL SIZE SENSOR 4.8 ORIGINAL SIZE SENSOR B386R503.WMF B386R504.WMF 1. Open the original table [A]. 2. Remove the upper part of the table (3 screws). 3. Replace the width sensor board [B], length sensor (–1 [C] and –2 [D]) and trailing edge sensor [E].
Page 426 ORIGINAL FEED DRIVE 4.9 ORIGINAL FEED DRIVE B386R202.WMF First remove the rear cover. Then follow the instructions below for each part replacement: DF Feed Clutch 1. Replace the DF feed clutch [A] (1 E-ring, 1 connector). Pick-up Solenoid 1. Replace the pick-up solenoid [B] (3 screws, 1 snap ring, 1 connector). Transport Motor 1.
Page 427 REGISTRATION SENSOR 4.10 REGISTRATION SENSOR B386R508.WMF 1. Remove the front and rear covers. 2. Remove the transport guide plate [A]. 3. Replace the registration sensor [B]. B386 10-28...
Page 428 STAMP SOLENOID AND ORIGINAL EXIT SENSOR 4.11 STAMP SOLENOID AND ORIGINAL EXIT SENSOR B386R509.WMF B386R203.WMF 1. Remove the rear cover (1 connector). Also remove the upper cover (the exit tray). 2. Open the exit guide plate [A]. Next, detach the unit by inserting a screwdriver or other tool into one of the small openings [B] on either side of the guide plate holder and pushing firmly.
Page 430 INTERCHANGE UNIT B300/B416...
Page 432 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Standard sizes Paper Size: A6 lengthwise to A3 HLT to DLT Non-standard sizes Width: 100 to 305 mm Length: 148 to 432 mm Paper Weight: 52 g/m ~ 135 g/m , 16 lb ~ 36 lb Power Consumption: 15 W Dimensions (W x D x H):...
Page 433 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B416V501.WMF 1. 1-bin Tray (Option) 2. Exit Sensor 3. Duplex Junction Gate 4. Duplex Unit (Option) 5. Exit Junction Gate 6. Fusing Unit (Inside the Copier) 7. Exit Roller 8. Bridge Unit B300/B416 11-2...
Page 434 DRIVE LAYOUT 1.3 DRIVE LAYOUT B416V503.WMF B416V504.WMF 1. Exit Junction Gate Solenoid 4. Exit Roller 2. Exit Sensor 5. Drive Gear 3. Duplex Junction Gate Solenoid 11-3 B300/B416...
Page 435 JUNCTION GATE MECHANISM 2. DETAILED DESCRIPTION 2.1 JUNCTION GATE MECHANISM B416D504.WMF B416D505.WMF B416D506.WMF Depending on the selected mode, the copies are directed up, left, or right by the exit junction gate [A] and the duplex junction gate [B]. These are controlled by the exit junction gate solenoid [C] and the duplex junction gate solenoid [D].
Page 436 EXIT SENSOR REPLACEMENT 3. REPLACEMENT AND ADJUSTMENT 3.1 EXIT SENSOR REPLACEMENT B416R501.WMF 1. Remove the interchange unit. 2. Remove the upper cover [A] of the interchange unit. 3. Remove the exit sensor [B] (1 connector). 11-5 B300/B416...
Page 438 1-BIN TRAY UNIT A898/B413...
Page 440 SPECIFICATIONS 1. OVERALL INFORMATION 1.1 SPECIFICATIONS Paper Size: Standard Size: A5 Lengthwise to A3 HLT Lengthwise to DLT Non-standard Size: Paper Width: 90 ~ 297 mm Paper Length: 148 ~ 432 mm Paper Weight: 60 ~ 105 g/m², 16 ~ 28 lbs. Tray Capacity: 125 sheets (80 g/m², 20 lbs.) Power Source:...
Page 441 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B413V500.WMF B413V501.WMF 1. Exit Rollers 2. Junction Gate Gear 3. Drive Gear 4. Paper Tray 5. Paper Sensor 6. Junction Gate (Interchange Unit) A898/B413 12-2...
Page 442 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT B413V502.WMF 1. Paper Sensor 2. 1-bin Sorter Exit Tray LED (located in the copier) 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Sensors Paper Detects when there is paper on the tray. LEDs Indicates when there is paper in the tray.
Page 443 BASIC OPERATION 2. DETAILED SECTION DESCRIPTIONS 2.1 BASIC OPERATION B413D101.WMF B413D103.WMF B413D102.WMF At the appropriate time after the leading edge of the first sheet of copy paper reaches the copier’s registration roller, the junction gate solenoid [B] in the interchange unit turns on to switch the junction gate to direct the paper to the tray [C].
Page 444 PAPER SENSOR REMOVAL 3. REPLACEMENT AND ADJUSTMENT 3.1 PAPER SENSOR REMOVAL B413R101.WMF 1. Remove the 1-bin tray. 2. Remove the 1-bin sorter unit [A]. 3. Remove the paper sensor [B] (1 connector). 12-5 A898/B413...
Page 446 SHIFT TRAY UNIT B313/B459...
Page 448 SPECIFICATIONS 1 OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Paper Size: Standard Size: A5 lengthwise to A3 HLT lengthwise to DLT Non-standard Size: Paper Width: 90 ~ 297 mm Paper Length: 148 ~ 432 mm Paper Weight: 60 ~ 105 g/m², 16 ~ 28 lbs. Tray Capacity: 125 sheets (80 g/m², 20 lbs.): B4 or larger 250 sheets (80 g/m², 20 lbs.): A4 or smaller...
Page 449 COMPONENT LAYOUT 1.2 COMPONENT LAYOUT B459D101.WMF B459D102.WMF 1. Half Turn Sensor 2. Tray Cover 3. Slip Disc 4. Tray Motor 5. Driver PCB B313/B459 13-2...
Page 450 BASIC OPERATION 2. DETAILED SECTION DESCRIPTIONS 2.1 BASIC OPERATION B459D500.WMF The shift tray allows copies to be sorted into separate piles on one tray. From the left-right movement of the tray cover [A], the piles of copies are offset into two positions, slightly overlapping one another.
Page 451 PRIMARY MECHANISMS 2.2 PRIMARY MECHANISMS 2.2.1 TRAY SHIFT B459D103.WMF As stated above, the shift tray cover [A] moves from left to right to create two possible positions for the copies to stack up. This motion is driven by the tray motor [B], which connects to the slip disc [C] via a small shaft.
Page 452 PRIMARY MECHANISMS 2.2.2 HALF TURN DETECTION B459D103.WMF Half turn detection is performed through a combination of two components: the slip disc [A] and half turn sensor [C]. The slip disc has a rim extending below the top surface. However, the rim only extends 180°...
Page 453 TRAY COVER REPLACEMENT 3. REPLACEMENT AND ADJUSTMENT 3.1 TRAY COVER REPLACEMENT B459R101.WMF 3.1.1 TRAY COVER REMOVAL 1. Remove the tray cover [A] by pressing on the two pawls [B] on the left side of the cover. 3.1.2 TRAY COVER ATTACHMENT NOTE: The right side of the tray cover should be attached first.
Page 454 TRAY MOTOR AND HALF TURN SENSOR REPLACEMENT 3.2 TRAY MOTOR AND HALF TURN SENSOR REPLACEMENT B459R102.WMF 3.2.1 REPLACING THE TRAY MOTOR 1. Remove the slip disc [A]. 2. Remove the tray motor [B] from the motor holder (1 connector). 3.2.2 REPLACING THE HALF TURN SENSOR: 1.
Page 456 BY-PASS A899/B415...
Page 458 SPECIFICATIONS 1 OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Standard sizes Paper Size: A6 lengthwise to A3 HLT lengthwise to DLT Non-standard sizes Width: 90 to 305 mm Length: 148 to 432 mm Paper Weight: 52 g/m ~ 157 g/m , 16 lb ~ 42 lb Tray Capacity: 50 sheets (80 g/m , 20 lb)
Page 459 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT B415V501.WMF 1. Paper End Sensor 2. Paper Feed Clutch 3. Paper Size Sensor Board 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Sensors Paper End Informs the copier/printer when the by-pass tray runs out of paper. Paper Size Detects the paper width.
Page 460 BASIC OPERATION 2 DETAILED DESCRIPTIONS 2.1 BASIC OPERATION B415D503.WMF The by-pass unit uses a friction pad paper feed mechanism. The transport roller gear in the main copier/printer drives the gear on the paper feed clutch [B] through a series of gears. When paper is placed in the tray, the paper end sensor [C] switches off.
Page 461 PAPER SIZE DETECTION 2.2 PAPER SIZE DETECTION B415D504.WMF The paper size sensor board [B] monitors the paper width. The rear side fence [A] is connected to the terminal plate. The pattern for each paper width is unique. Therefore, the copier/printer determines which paper has been placed in the by- pass tray by the signal output from the board.
Page 462 PAPER FEED ROLLER/FRICTION PAD/PAPER END SENSOR 3 REPLACEMENT AND ADJUSTMENT 3.1 PAPER FEED ROLLER/FRICTION PAD/PAPER END SENSOR B415R501.WMF B415R505.WMF 1. Remove the upper cover [A] (2 screws). 2. Remove the paper end sensor bracket [B] (1 screw). 3. Remove the paper feed roller [C] (snap-fit). 4.
Page 463 PAPER SIZE SENSOR BOARD 3.2 PAPER SIZE SENSOR BOARD B415R502.WMF B415R503.WMF 1. Remove the rear cover [A] (2 screws). 2. Remove the by-pass tray [B] (1 connector, 2 release levers [C]). 3. Remove the lever [D] (1 snap ring, 1 pin). 4.
Page 464 PAPER FEED CLUTCH 3.3 PAPER FEED CLUTCH B415R504.WMF 1. Remove the rear cover [A] (2 screws). 2. Remove the spring. 3. Remove the drive gear and drive gear bracket [B] (1 E-ring, 1 spring). 4. Remove the paper feed clutch bracket [C] (2 screws). 5.
Page 466 DUPLEX A896/B414...
Page 468 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Standard sizes Paper Size: A5 lengthwise to A3 HLT to DLT Non-standard sizes Width: 140 to 297 mm Length: 182 to 432 mm Paper Weight: 64 g/m ~ 105 g/m , 20 lb ~ 28 lb Tray Capacity: 1 sheet Power Consumption:...
Page 469 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT B414V500.WMF 1. Inverter Gate 5. Middle Transport Roller 2. Entrance Sensor 6. Lower Transport Roller 3. Inverter Roller 7. Exit Sensor 4. Upper Transport Roller A896/B414 15-2...
Page 470 ELECTRICAL COMPONENT LAYOUT ELECTRICAL COMPONENT LAYOUT B414V501.WMF 1. Entrance Sensor 5. Transport Motor 2. Inverter Gate Solenoid 6. Exit Sensor 3. Inverter Motor 7. Duplex Unit Open Switch 4. Main Board 15-3 A896/B414...
Page 471 ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Inverter Drives the inverter roller. Transport Drives the upper and lower transport rollers. Sensors Entrance Detects the trailing edge of the copy paper to turn on the inverter gate solenoid and turn on the inverter motor in reverse.
Page 472 DRIVE LAYOUT 1.5 DRIVE LAYOUT B414V502.WMF 1. Inverter Roller 4. Transport Motor 2. Inverter Motor 5. Lower Transport Roller 3. Upper Transport Roller 6. Middle Transport Roller 15-5 A896/B414...
Page 473 BASIC OPERATION 2. DETAILED DESCRIPTIONS 2.1 BASIC OPERATION To increase the productivity of the duplex unit, copies are printed as follows. Longer than A4 sideways/LT sideways The duplex unit can store only one sheet of copy paper. Example: 8 pages. The number [A] in the illustration shows the order of pages. The number [B] in the illustration shows the order of sheets of copy paper (if shaded, this indicates the second side).
Page 474 BASIC OPERATION Up to A4 sideways/LT sideways The duplex unit can store two sheets of copy paper Example: 8 pages. The number [A] in the illustration shows the order of pages. The number [B] in the illustration shows the order of sheets of copy paper (if shaded, this indicates the second side).
Page 475 FEED IN AND EXIT MECHANISM 2.2 FEED IN AND EXIT MECHANISM B414D504.WMF B414D505.WMF When paper is fed into duplex unit: As soon as the paper arrives from the interchange unit, it is sent to the inverter section [C] (the inverter gate solenoid [A] remains off during this process). The inverter section can hold a sheet of paper up to A3 size.
Page 476 COVER REMOVAL 3. REPLACEMENT AND ADJUSTMENT 3.1 COVER REMOVAL B414R501.WMF 1. Remove the duplex unit cover [A] (4 screws). 15-9 A896/B414...
Page 477 ENTRANCE SENSOR REPLACEMENT 3.2 ENTRANCE SENSOR REPLACEMENT B414R502.WMF 1. Remove the duplex unit cover. (Refer to section 3.1.) 2. Remove the sensor holder [A] (1 screw). 3. Replace the entrance sensor [B] (1 connector, 1 screw). A896/B414 15-10...
Page 478 EXIT SENSOR REPLACEMENT 3.3 EXIT SENSOR REPLACEMENT B414R503.WMF 1. Open the duplex unit [A]. 2. Remove the sensor bracket [B] (1 screw). 3. Replace the exit sensor [C] (1 connector). 15-11 A896/B414...
Page 480 BRIDGE UNIT A897/B417...
Page 482 SPECIFICATIONS 1. OVERALL MACHINE INFORMATION 1.1 SPECIFICATIONS Standard sizes Paper Size: A6 lengthwise to A3 HLT to DLT Non-standard sizes Width: 100 to 305 mm Length: 148 to 432 mm Paper Weight: 52 g/m ~ 135 g/m , 16 lb ~ 42 lb Power Source: DC24 V, 5 V (from the copier/printer) Dimensions (W x D x H):...
Page 483 MECHANICAL COMPONENT LAYOUT 1.2 MECHANICAL COMPONENT LAYOUT 1. Upper Exit Roller 6. 2nd Transport Roller 2. Tray Exit Sensor 7. 3rd Transport Roller 3. Junction Gate 8. Left Exit Roller 4. Cooling Fan 9. Relay Sensor 5. 1st Transport Roller 10.
Page 484 ELECTRICAL COMPONENT LAYOUT 1.3 ELECTRICAL COMPONENT LAYOUT B417V501.WMF 1. Left Guide Switch 5. Cooling Fan Motor 2. Right Guide Switch 6. Relay Sensor 3. Junction Gate Solenoid 7. Bridge Unit Drive Motor 4. Tray Exit Sensor 8. Bridge Unit Control Board 16-3 A897/B417...
Page 485 ELECTRICAL COMPONENT DESCRIPTION 1.4 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Cooling Fan Cools the transport unit. Bridge Unit Drive Drives the bridge unit. Sensors Tray Exit Checks for misfeeds. Relay Checks for misfeeds. Switches Right Guide Detects when the right guide is opened. Left Guide Detects when the left guide is opened.
Page 486 DRIVE LAYOUT 1.5 DRIVE LAYOUT B417V502.WMF 1. Left Exit Roller 2. 2nd Transport Roller 3. 1st Transport Roller 4. Upper Exit Roller 5. 3rd Transport Roller 6. Bridge Unit Drive Motor 16-5 A897/B417...
Page 487 JUNCTION GATE MECHANISM 2. DETAILED DESCRIPTION 2.1 JUNCTION GATE MECHANISM B417D104.WMF The junction gate [B] directs any paper reaching the bridge unit to either the upper tray (on top of the bridge unit) or to the finisher, depending on which has been selected.
Page 488 BRIDGE UNIT DRIVE MOTOR REPLACEMENT 3. REPLACEMENT AND ADJUSTMENT NOTE: When taking apart the bridge unit, first take the unit out of the copier. 3.1 BRIDGE UNIT DRIVE MOTOR REPLACEMENT B417R103.WMF 1. Remove the bridge unit from the copier. (See the Installation Procedure in the base copier manual.) 2.
Page 489 TRAY EXIT SENSOR REPLACEMENT 3.2 TRAY EXIT SENSOR REPLACEMENT B417R104.WMF 1. Remove the bridge unit from the copier. (See the Installation Procedure in the base copier manual.) 2. Remove the rear cover (2 screws). See Bridge Unit Drive Motor Replacement. 3.
Page 490 1,000-SHEET FINISHER B408...
Page 492 MAIN PCB 1. REPLACEMENT AND ADJUSTMENT 1.1 MAIN PCB B408R109.WMF B408R110.WMF 1. Rear cover [A] (x 2) 2. Main PCB [B] (x 4, All ) 17-1 B408...
Page 493 STAPLER UNIT 1.2 STAPLER UNIT 1. Side cover [A] ( x 2) 2. Open exit guide plate [B] 3. Upper side cover [C] ( x 2) 4. Front cover support plate [D] ( x 1) 5. Front cover [E] 6. Front inner cover [F] ( x 2) 7.
Page 494 MOTORS 1.3 MOTORS 1.3.1 SHIFT MOTOR 1. Rear cover ( 1.1) 2. Shift motor [A] ( x 2, x 1) B408R123.WMF 1.3.2 STAPLER MOTOR 1. Rear cover ( 1.1) 2. Stapler motor [B] ( x 2, x 1) B408R124.WMF 1.3.3 UPPER TRANSPORT MOTOR AND EXIT MOTOR 1.
Page 495 MOTORS 1.3.4 LOWER TRANSPORT MOTOR 1. Main PCB ( 1.1) 2. Lower transport motor [A] ( x 2, x B408R111.WMF B408 17-4...
Page 496 MOTORS AND SENSORS 1.4 MOTORS AND SENSORS 1.4.1 PREPARATION 1. Front cover and inner cover ( 1.2) 2. Upper side cover [A] ( x 2) 3. Shift tray [B] ( x 1) 4. Lower side cover [C] ( x 2) 5. Loosen the 2 screws [D]. 6.
Page 497 MOTORS AND SENSORS 1.4.2 STACK HEIGHT SENSOR 1. Stack height sensor assembly [A] ( x 2. Stack height sensor [B] ( x 1) B408R121.WMF 1.4.3 STAPLER TRAY PAPER SENSOR 1. Stapler tray paper sensor [C] ( x 1) B408R120.WMF 1.4.4 LOWER TRAY LIFT MOTOR 1.
Page 498 MOTORS AND SENSORS 1.4.5 STACK FEED-OUT MOTOR 1. Stack feed-out motor [A] ( x 2, x 1) B408R122.WMF 17-7 B408...
Page 499 JAM DETECTION 2. TROUBLESHOOTING 2.1 JAM DETECTION Mode Content Shift Staple Entrance sensor: The entrance sensor does not turn on within On check the normal time after the main machine exit sensor turns on Entrance sensor: The entrance sensor does not turn off within Off check the normal time after it turns on.
Page 500 DIP SWITCH SETTINGS 3. SERVICE TABLES 3.1 DIP SWITCH SETTINGS The DIP switch should not be set to any combination other than those described in the table below. SW100 Description Normal operation mode (Default) Packing mode. • Before packing the machine, do the following: Set switch 1 to 1 then back to zero.
Page 501 GENERAL LAYOUT 4. DETAILED DESCRIPTIONS 4.1 GENERAL LAYOUT B408D101.WMF 1. Upper Tray 8. Stapler 2. Upper Tray Exit Roller 9. Stack Feed-out Belt 3. Entrance Roller 10. Positioning Roller 4. Tray Junction Gate 11. Shift Roller 5. Upper Transport Roller 12.
Page 502 ELECTRICAL COMPONENT LAYOUT 4.2 ELECTRICAL COMPONENT LAYOUT B408D102.WMF B408D103.WMF 1. Upper Cover Switch 12. Jogger Fence HP Sensor 2. Paper Limit Sensor 13. Positioning Roller Solenoid 3. Entrance Sensor 14. Stapler HP Sensor 4. Exit Guide Plate Motor 15. Stapler Tray Entrance Sensor 5.
Page 503 ELECTRICAL COMPONENT LAYOUT B408D104.WMF 22. Tray Junction Gate Solenoid 23. Lower Tray Lift Motor 24. Lower Tray Lower Limit Sensor 25. Stapler Motor 26. Jogger Fence Motor 27. Stack Feed-out Motor 28. Main Board 29. Lower Transport Motor 30. Stapler Junction Gate Solenoid 31.
Page 504 ELECTRICAL COMPONENT DESCRIPTION 4.3 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Motors Upper Drives the entrance roller and upper transport Transport rollers. Lower Drives the lower transport rollers and Transport positioning roller. Jogger Fence Drives the jogger fences. Staple Hammer Drives the staple hammer.
Page 505 ELECTRICAL COMPONENT DESCRIPTION Symbol Name Function Index No. Positioning Moves the positioning roller. SOL3 Roller Switches Lower Tray Detects when lower tray is at its upper limit Upper Limit position. Front Door Cuts the dc power when the front door is Safety opened.
Page 506 DRIVE LAYOUT 4.4 DRIVE LAYOUT B408D105.WMF B408D106.WMF 1. Exit Motor 4. Shift Motor 2. Upper Transport Motor 5. Exit Guide Plate Motor 3. Lower Transport Motor 6. Lower Tray Lift Motor 17-15 B408...
Page 507 DRIVE LAYOUT B408D107.WMF 7. Stack Feed-out Motor 8. Jogger Motor 9. Stapler Motor B408 17-16...
Page 508 JUNCTION GATES 4.5 JUNCTION GATES B408D108.WMF Depending on the finishing mode, the copies are directed up, straight through, or down by the combination of the tray junction gate [A] and stapler junction gate [B]. These gates are controlled by the tray junction gate solenoid [C] and stapler junction gate solenoid [D].
Page 509 UPPER TRAY 4.6 UPPER TRAY B408D109.WMF When the paper limit sensor [A] switches on during feed-out for each of three consecutive sheets of paper, paper overflow is detected. B408 17-18...
Page 510 LOWER TRAY UP/DOWN MECHANISMS 4.7 LOWER TRAY UP/DOWN MECHANISMS B408D112.WMF The vertical position of the lower tray [A] depends on the height of the copied paper stack on the lower tray. The stack height sensor feeler [B] contacts the top of the stack, and the lower tray lift motor [C] controls the tray height.
Page 511 PAPER SHIFT MECHANISM 4.8 PAPER SHIFT MECHANISM B408D110.WMF In the sort/stack mode, the shift roller [A] moves from side to side to separate the sets of copies. The horizontal position of the shift roller is controlled by the shift motor [B] and the shift gear disk [C].
Page 512 JOGGER UNIT PAPER POSITIONING MECHANISM 4.9 JOGGER UNIT PAPER POSITIONING MECHANISM B408D114.WMF B408D113.WMF In staple mode, each sheet of copy paper is vertically and horizontally aligned when it arrives in the jogger unit. For the vertical paper alignment, the positioning roller solenoid [A] turns on shortly after the stapler tray entrance sensor [B] turns off, and the positioning roller [C] pushes the copy against the bottom of the stack stopper [D].
Page 513 EXIT GUIDE PLATE 4.10 EXIT GUIDE PLATE [B] [C] B408D111.WMF When stacking a large size of paper (such as A3, DLT) in the jogger unit, the leading edge of the paper reaches the exit rollers. To prevent the paper from running into the exit rollers and not being aligned correctly, the exit guide plate [A] is moved up to make a gap between the exit rollers.
Page 514 STAPLER MECHANISM 4.11 STAPLER MECHANISM B408D116.WMF The staple hammer motor [A] drives the staple hammer. The staple sheet sensor [B] detects the leading edge of the staple sheet at the stapling position to prevent the hammer from operating if there are no staples at the stapling position.
Page 515 STAPLER UNIT MOVEMENT MECHANISM 4.12 STAPLER UNIT MOVEMENT MECHANISM B408D117.WMF The stapler motor moves the stapler [A] from side to side. After the start key is pressed, the stapler moves from its home position to the stapling position. If two-staple-position mode is selected, the stapler moves to the front stapling position first, then moves to the rear stapling position.
Page 516 PAPER FEED-OUT MECHANISM 4.13 PAPER FEED-OUT MECHANISM B408D118.WMF After the copies have been stapled, the stack feed-out motor [A] starts. The pawl [B] on the stack feed-out belt [C] transports the set of stapled copies up and feeds it to the shift roller. The shift roller takes over stack feed-out after the leading edge reaches this roller.
Page 517 SPECIFICATIONS 5. OVERALL MACHINE INFORMATION 5.1 SPECIFICATIONS Upper Tray Paper Size: A3 to A6 DLT to HLT Power Weight: 60 to 157 g/m (16 to 42 lb) Paper Capacity: 250 sheets (A4 sideways / LT sideways or smaller: 80 , 20lb) 50 sheets (A3, B4, DLT, LG: 80 g/m , 20 lb) Lower Tray...
Page 518 500-SHEET FINISHER G302/B442...
Page 520 EXTERIOR 1. REPLACEMENT AND ADJUSTMENT 1.1 EXTERIOR NOTE: This manual uses several symbols. The meanings for these symbols are as follows: : See or refer to : screw : connector : clip Front cover [A]: : Front cover (1) B442R101.WMF Rear cover [A]: Rear cover (1) B442R102.WMF...
Page 521 EXTERIOR Top cover [A]: Top cover (2 links) Front lower guide B442R105.WMF B442R116.WMF B442R104.WMF [A]: Output tray (2) [B]: Front lower guide (2) NOTE: 1) When re-attaching the lower guide, be sure that it is not in contact with the exit lower guide and that the exit lower guide moves smoothly. 2) Make sure that the blue and black cables are in the correct position, as engraved on the inside of the front lower guide.
Page 522 EXTERIOR Right cover [A]: Grounding plate (1) [B]: Right cover (2) B442R103.WMF 18-3 G302/B442...
Page 523 ENTRANCE UPPER GUIDE / PAPER EXIT UNIT 1.2 ENTRANCE UPPER GUIDE / PAPER EXIT UNIT B442R106.WMF • Front, rear, and top covers and front lower guide ( 1.1 Exterior) [A]: Entrance upper guide (2, 1) [B]: Paddle gear spring [C]: Paddle gear (1) [D]: Paddle gear holder [E]: Bushing (1) [F]: Paper exit unit holder (1)
Page 524 ENTRANCE LOWER GUIDE 1.3 ENTRANCE LOWER GUIDE • Entrance upper guide ( 1.2 Entrance upper guide / Exit unit) • Exit unit ( 1.2 Entrance upper guide / Exit unit) [A]: Release tension bracket (1) [B]: Reverse roller gear bracket (2) [C]: Timing belt [D]: Entrance lower guide NOTE: When re-assembling the tension...
Page 525 STAPLER UNIT 1.5 STAPLER UNIT • Rear cover ( 1.1 Exterior) [A]: Stapler unit bracket (2, 1) [B]: Stapler unit (3) B442R115.WMF 1.6 JOGGER TRAY UNIT • Entrance upper guide and paper exit unit ( 1.2 Entrance upper guide / paper exit unit) •...
Page 526 PAPER EXIT SENSOR FEELER 1.7 PAPER EXIT SENSOR FEELER • Jogger tray unit ( 1.6 Jogger tray unit) • Jogger motor ( 1.9 Jogger motor) [A]: Paper exit sensor feeler B442R121.WMF 1.8 MAIN MOTOR • Right cover ( 1.1 Exterior) [A]: Release tension bracket (1) [B]: Main motor (2, 1) B442R113.WMF 18-7...
Page 527 JOGGER MOTOR 1.9 JOGGER MOTOR • Front lower guide ( 1.1 Exterior) [A]: Jogger motor (2, 3) B442R114.WMF 1.10 CONTROL BOARD • Front lower guide ( 1.1 Exterior) [A]: Control board (1, 12) B442R112.WMF G302/B442 18-8...
Page 528 OUTPUT TRAY UNIT 1.11 OUTPUT TRAY UNIT B442R118.WMF B442R117.WMF B442R119.WMF [A]: Output tray cover (2) [B]: Tray holder (1) [C]: Links [D]: Connector cover [E]: Output tray motor link unit (1) [F]: Rear cover (1) [G]: Output tray motor ( 1) NOTE: When re-attaching the motor link unit, the arrows on each of the gears need to face each other as...
Page 529 OVERALL MACHINE INFORMATION 2. DETAILED DESCRIPTIONS 2.1 OVERALL MACHINE INFORMATION 2.1.1 COMPONENT LAYOUT Mechanical component layout B442D101.WMF 1. Output tray 6. Lower entrance guide 2. Stack height detection lever 7. Upper entrance guide 3. Paper exit roller 8. Paper exit unit 4.
Page 530 OVERALL MACHINE INFORMATION Drive layout B442D103.WMF 1. Main motor 5. Output tray link gears 2. Exit roller timing belt 6. Paper exit unit drive gear 3. Main motor timing belt 7. Reverse roller 4. Output tray motor 8. Paper exit roller 18-11 G302/B442...
Page 531 OVERALL MACHINE INFORMATION 2.1.2 ELECTRICAL COMPONENT DESCRIPTIONS B442D102.WMF See the next page for the component description table. G302/B442 18-12...
Page 532 OVERALL MACHINE INFORMATION Symbols Name Function Index No. Motors Main Drives all the rollers Jogger Drives the jogger fence Output Tray Drives the tray up and down Stapler Drives the stapler Sensors Entrance Detects paper at the entrance Exit Detects paper at the exit Stack height Detects the top of the paper stack Lever...
Page 533 DETAILED SECTION DESCRIPTIONS 2.2 DETAILED SECTION DESCRIPTIONS 2.2.1 OUTPUT TRAY MECHANISM Stack height detection B442D104.WMF Stack height detection lever [A]: Driven by stack height lever solenoid [B]. Two sensors detect the height of the stack in the output tray: the stack height [C] and lever [D] sensors.
Page 534 DETAILED SECTION DESCRIPTIONS Output tray up/down mechanism B442D105.WMF Overview The output tray motor [A] lifts/lowers the tray if the stack height is not at the target position. Gears [B] and [C] keep the angle of the tray constant at any tray position. Output Tray Downward Movement The top of the paper stack is checked after every page (or set of pages) has been fed out.
Page 535 DETAILED SECTION DESCRIPTIONS 2.2.2 PAPER FEED Overview The following paper feed out modes can be selected at the printer driver. Mode Description Straight feed out mode Paper is fed directly to the output tray without shifting or stapling. Shift sorting mode Alternate sets are shifted before being fed to the output tray.
Page 536 DETAILED SECTION DESCRIPTIONS Shift sorting mode B442D111.WMF B442D113.WMF At the start of the job, and for odd numbered sets of copies, the mechanism is the same as the straight feed out mode. However, even numbered sets are fed back to the jogger tray, which shifts the sets to one side before feeding them out.
Page 537 DETAILED SECTION DESCRIPTIONS B442D107.WMF After the paper reaches the end fence [A], the jogger fence [B] shifts the paper across. The jogger motor [C] drives the jogger fence. The home position sensor [D] detects when the jogger fence has returned to home position. When the next set begins, the paper exit unit moves down, and the machine operates the same way as straight feed out mode.
Page 538 DETAILED SECTION DESCRIPTIONS Stapling mode B442D112.WMF B442D114.WMF B442D106.WMF The stapler is attached to the jogger tray, so all sets go to the jogger tray. After all pages of a set have entered the jogger tray and been shifted across, the paper exit link [A] pulls the paper exit unit [B] down until knob [C] on the exit unit pushes the link lever [D] for the exit unit switch [E].
Page 539 DETAILED SECTION DESCRIPTIONS 2.2.3 JAM CONDITIONS Sensors Conditions Remaining paper detection Entrance Either the entrance or exit sensor detects Exit paper just after the unit is initialized. Non-feed at the entrance The entrance sensor is not activated within a Entrance certain period after the paper exit sensor detects paper.
Page 540 SPECIFICATIONS 3. OVERALL MACHINE INFORMATION 3.1 SPECIFICATIONS Paper Size: A3, B4, A4, B5 sideways (Metric) DLT, LG, LT (Inch) Paper Weight 52 ~ 128 g/m , 14 ~ 34 lb. Staple Capacity: 20 sheets (A3, B4, DLT, LG : 80 g/m , 20 lb) 30 sheets (A4, B5 sideways, LT : 80 g/m , 20 lb)
Page 542 FIRMWARE HISTORY...
Page 544 The date display on the LCD sometimes delays B0275387 D Oct. 2001 4.16.1 when the main switch is turned on. Production B022/B027 model names added for use with B0315380 B Feb. 2002 5.15.1 Plug and Play. Production Asia version only: The date format has been changed from “yyyy/mm/dd”...
Page 545 FIRMWARE MODIFICATION HISTORY Rev. 11/2002 B022/B027 FIRMWARE MODIFICATION HISTORY (CONTROLLER) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION The default values for the following SP modes 5.15.1 were displayed incorrectly: continued SP1-105-1, 2, 3, 4, 5, 6, 7 SP1-108, SP5-912.
Page 546 FIRMWARE MODIFICATION HISTORY Rev. 11/2002 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) B022/B027 FIRMWARE MODIFICATION HISTORY (SBCU) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275550 F 1st Mass 3.12.1 Production The SC level of SC792 has been changed from B0275550 F Oct.
Page 547 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 1.1.3 FIRMWARE MODIFICATION HISTORY (LCDC) B022/B027 FIRMWARE MODIFICATION HISTORY (LCDC) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275541 B 1st Mass 2.10 Production The wording of the file transfer error message B0275541 B Oct.
Page 548 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) B022/B027 FIRMWARE MODIFICATION HISTORY (LANGUAGE) B022/B027 FIRMWARE MODIFICATION HISTORY (LANGUAGE) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275530 1st Mass 2.25...
Page 550 PRINTER/SCANNER CONTROLLERS B453/B461...
Page 552 INSTALLATION REQUIREMENTS 1. INSTALLATION 1.1 INSTALLATION REQUIREMENTS Please refer to section 3 of the main unit service manual. 1.2 PRINTER/SCANNER INSTALLATION Accessory Check Check the accessories in the box against the following list: Description Q’ty Note Key Top - Copy Key Top - Printer Key Top - Scanner Included only in the B453 (printer...
Page 553 PRINTER/SCANNER INSTALLATION Rev. 03/2002 Printer, Printer/Scanner Controller Installation CAUTION Unplug the main machine power cord before starting the following procedure. ⇒ NOTE: 1) When installing this unit, the 64 MB memory must be installed. 2) The NIB option is required when the printer/scanner controller is installed.
Page 554 PRINTER/SCANNER INSTALLATION B453I109.WMF B453I110.WMF 4. Install the printer or printer/scanner controller ROM DIMM [A] on the controller board. NOTE: Use the slot indicated in the diagram. 5. Install the memory 64 MB DIMM [B] onto the controller board. B453/B461...
Page 555 PRINTER/SCANNER INSTALLATION Rev. 10/2002 B453I113.WMF B453I105.WMF 6. Replace the key top(s) for the appropriate unit(s) to be installed. A: Copy (First position) B: Printer (Fourth position) C: Scanner (Fifth position) 7. Attach the FCC label [D] to the controller panel board, aligned with the slot [E] so the label is hidden when the left rear cover is replaced.
Page 556 PRINTER OPTIONS 1.3 PRINTER OPTIONS 1.3.1 POSTSCRIPT UNIT (B462) CAUTION Unplug the main machine’s power cord before starting the following procedure. NOTE: To install the Postscript option, the printer option (B453 or B461) must be installed first. Please refer to section 1.2 for details of the printer/scanner installation procedure.
Page 557 PRINTER OPTIONS 1.3.2 NIB (G335) CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the NIB option, the printer option (B453 or B461) must be installed first. Please refer to section 1.2 for details of the printer/scanner installation procedure.
Page 558 PRINTER OPTIONS 1.3.3 IEEE1394 INTERFACE (G590) CAUTION Unplug the main machine power cord before starting the following procedure. NOTE: To install the IEEE1394 option, the printer option (B453 or B461) must be installed first. Please refer to section 1.2 for details of the printer/scanner installation procedure.
Page 559 CHECKING THE CONNECTIONS 1.4 CHECKING THE CONNECTIONS 1. Plug in the power cord and turn on the main switch. 2. Enter the printer user mode and print the configuration page. (User Tools/ Printer Settings/ List Test Print/ Config. Page) The same data can also be printed using the printer service mode. (“Print Summary”: SP1-004) All installed options are listed in the “System Reference”...
Page 560 CONTROLLER ERRORS 2. TROUBLESHOOTING 2.1 CONTROLLER ERRORS Refer to section 7.1 of the main unit service manual for descriptions on SC code information because the GW architecture includes controller SC codes in the main unit SC code table. 2.2 LEDS AND TEST POINTS LEDs and test points are not used for this option (except for the NIB section 4.4).
Page 561 SERVICE PROGRAM MODE 3. SERVICE TABLES 3.1 SERVICE PROGRAM MODE CAUTION Before accessing the service menu, do the following: Confirm that there is no print data in the printer buffer (the Data In LED must not be lit or blinking). If there is some data in the buffer, wait until all data has been printed.
Page 562 PRINTER SERVICE MODE 3.2 PRINTER SERVICE MODE 3.2.1 SERVICE MODE TABLE SP No. Description Function and Setting 1001 BitSw#1 Set Adjusts bit switch settings. Note: Currently the bit switches are not being used. 1003 Clear Setting Not used 1004 Print Summary Prints the service summary sheet (An error log is printed in addition to the configuration page).
Page 563 Changes the FTP port number. After changing this value, do the following: Run the Registry Editor Access /HKEY_LOCAL_MACHINE/SOFTWARE/ Ricoh/NetworkScanner Change the value of ‘PortNo’ to this SP mode’s value [0 – 65535 / 3670 / 1 step] 1004* Compression Type Selects the compression type for binary picture processing.
Page 564 SCANNER SERVICE MODE Mode Number Function and [Setting] 2002 MTF Filter Coefficient Selects the MTF filter coefficient in the main (Text / Binary / Main scan) scan direction for Text mode. Select a higher number for a stronger filter. If this is “0”, the MTF filter is not applied. [0-15 / 5 / 1 step] MTF Filter Coefficient As above, for sub scan...
Page 565 SCANNER SERVICE MODE Mode Number Function and [Setting] 2002 20* Contrast – Notch 3 Adjusts the image density for each image (Text / Binary) density level for Text mode when using binary picture processing mode. [0-255 / 59 / 1 step] 21* Threshold Level –...
Page 566 SCANNER SERVICE MODE Mode Number Function and [Setting] 2003 Scanner Gamma Selects the scanner gamma type for Text/Photo (Text/Photo / Binary) mode when using binary picture processing mode. [0-6 / 5 / 1 step] Brightness – Notch 7 Adjusts the image density for each image (Text/Photo / Binary) density level for Text/Photo mode when using binary picture processing mode.
Page 567 SCANNER SERVICE MODE Mode Number Function and [Setting] 2004 MTF Filter Coefficient Selects the MTF filter coefficient in the main (Photo / Binary / Main scan direction for Photo mode. scan) Select a higher number for a stronger filter. If this is “0”, the MTF filter is not applied. [0-15 / 0 / 1 step] MTF Filter Coefficient As above, for sub scan...
Page 568 SCANNER SERVICE MODE Mode Number Function and [Setting] 2004 18* Contrast – Notch 4 Adjusts the image density for each image (Photo / Binary) density level for Photo mode when using binary picture processing mode. [0-255 / 128 / 1 step] 19* Threshold Level –...
Page 569 SCANNER SERVICE MODE Mode Number Function and [Setting] 2005 Brightness – Notch 7 Adjusts the image density for each image (Grayscale) density level when using the grayscale processing mode. [0-255 / 98 / 1 step] Contrast – Notch 7 (Grayscale) [0-255 / 98 / 1 step] Threshold Level –...
Page 570 SCANNER SERVICE MODE Mode Number Function and [Setting] 2006 Compression Ratio (High Quality image) [5-95 / 60 / 1 step] Compression Ratio (Low Quality image) [5-95 / 40 / 1 step] Mode Number Function and [Setting] 8001* Delivery Server IP Sets the IP address for the delivery server.
Page 571 FIRMWARE UPDATE PROCEDURE Rev. 10/2002 3.4 FIRMWARE UPDATE PROCEDURE Firmware updating procedure is described in section 4.3 of the main unit service manual. ⇒ NOTE: In some cases it may be necessary to NVRAM clear the scanner after upgrading the firmware. If ScanRouter is used before performing NVRAM clear, record the following information before clearing NVRAM: Delivery Server IP Address: User Tools (UT)/System/File Transfer...
Page 572 USER PROGRAM MODE 3.7 USER PROGRAM MODE 3.7.1 PRINTER USER PROGRAM MODE Press the “Printer” key on the operation panel to enter the printer mode. Press the “User Tools/Counter “, then select “Printer Settings” to change printer settings. User Mode Tree Printer Mode View Sample Print Jobs (Printer Key pressed)
Page 573 USER PROGRAM MODE 3.7.2 SCANNER USER PROGRAM MODE Press the “User Tools/Counter “, then select “Scanner Settings” to change scanner settings. User Mode Tree User Tools/ Basic Settings Program Change Scanner Features Delete Initial Setup Program 1 ~ 5 Scanner Settings Function Priority Delivery/Store Connection Time out Compression (Black &...
Page 574 OVERVIEW 4. DETAILED SECTION DESCRIPTIONS 4.1 OVERVIEW OPTION Printer OPTION (Fax) OPTION OPTION OPTION Printer/ 2.5" HDD R A M I E E E 1 2 8 4 IC Card S c a n n e r P S 3 Flash ROM (32/64 MB) (Fax)
Page 575 OVERVIEW Optional components: • HDD: Used to store additional soft fonts. Also used for collation, locked print, sample print and form overlay • PostScript3 DIMM • Memory DIMM • NIB • IEEE1394 interface B453/B461...
Page 576 CONTROLLER FUNCTIONS 4.2 CONTROLLER FUNCTIONS 4.2.1 SAMPLE PRINT This feature requires the optional hard disk. This feature was formerly known as “Proof Print”. This function gives users a chance to check the print results before starting a multiple-set print run. •...
Page 577 CONTROLLER FUNCTIONS 4.2.3 PAPER SOURCE SELECTION Tray Priority (Auto Tray Select) Priority Tray Start of Tray Search The Tray Priority setting determines the start of the tray search when the user selects “Auto Tray Select” with the driver. Tray 1 The machine searches for a paper tray with the specified paper size and type.
Page 578 CONTROLLER FUNCTIONS 4.2.4 AUTO CONTINUE When this function is enabled, the machine stops printing and cancels the print job if there is no paper tray which matches the paper size and paper type specified by the driver. If Auto Continue is enabled, the machine waits for a specified period (0, 1, 5, 10, 15 minutes) for the correct size paper to be set in the tray, then cancels the print job if the interval expires.
Page 579 CONTROLLER FUNCTIONS 4.2.5 PAPER OUTPUT TRAY The default paper output tray for each application (copy/fax/printer) can be selected using the System Settings menu in the user tools. (User Tools/ System Settings/ General Features) If a print job does not specify an output tray or if the driver specifies the default tray, the default paper output tray is used.
Page 580 CONTROLLER FUNCTIONS 4.2.7 STAPLING Stapling is available when the 500-sheet finisher or 1000-sheet finisher is installed. The finishers have the following stapling positions. 500-sheet Finisher Paper Feed Direction (Printed side) 1000-sheet Finisher Stapled 2 places Paper Feed Direction (Printed side) B453D501.WMF •...
Page 581 SCANNER FUNCTIONS 4.3 SCANNER FUNCTIONS 4.3.1 IMAGE PROCESSING FOR SCANNER MODE The image processing for scanner mode is done in the IPU board. The IPU board chooses the most suitable image processing methods (gamma tables, dither patterns, etc) depending on the settings made in the driver. The image compression method can be selected with SP mode (MR/MH/MMR for binary picture processing, JPEG for grayscale processing).
Page 582 4.4 NIB 4.4.1 BLOCK DIAGRAM Flash ROM 4 M B Controller E E P R O M P H Y Oscillator DP83846 Filter Module L E D L E D RJ45 Network B453D503.WMF • The Flash ROM contains the NIB firmware. The firmware can be upgraded using an IC card connected to the controller board.
Page 583 IEEE1394 INTERFACE 4.5 IEEE1394 INTERFACE 4.5.1 SPECIFICATIONS Hardware Specification Interface: IEEE1394 (6 pins) (no power supply, cable power repeated, IEEE1394a-2000 compliant) Ports: 2 ports Data rates: 400Mbps/200Mbps/100Mbps System Requirements Windows PC with IEEE1394 port Microsoft Windows 2000 upgraded with service pack 1 Cable length: 4.5m (15ft) 4.5.2 IEEE1394 IEEE1394, also known as FireWire (a name patented by Apple), is an easy-to-use...
Page 584 IEEE1394 INTERFACE 4.5.3 BLOCK DIAGRAM IEEE1394 Board Clock E E P R O M Oscillator 1394 I/F Link Controller TSB41AB2 TSB12LV23A 1394 I/F B453D505.WMF • PHY: Physical layer control device • Link: Link layer control device • EEPROM: 256-byte ROM 4.5.4 PIN ASSIGNMENT Pin assignment Pin 1...
Page 585 IEEE1394 INTERFACE 4.5.5 REMARKS ABOUT THIS INTERFACE KIT Note the following points about this unit. • The machine does not print reports specifically for IEEE1394. Just print the Configuration Page at installation to check that the machine recognizes the card. •...
Page 586 SPECIFICATIONS SPECIFICATIONS 1. GENERAL SPECIFICATIONS 1.1 PRINTER Printing Speed: Maximum 22 ppm (A4/LT LEF): B022 model Maximum 27 ppm (A4/LT LEF): B027 model Printer Languages: PCL6/PCL5e PostScript 3 (option) RPCS (Refined Printing Command Stream) - an original Ricoh PDL) Resolution:...
Page 587 SPECIFICATIONS Supported Paper Sizes Paper Trays By-pass Paper Size (W x L) Duplex Main Unit/Option Tray Eur/Asia 297 x 420 mm 257 x 364 mm A4 SEF 210 x 297 mm A4 LEF 297 x 210 mm B5 SEF 182 x 257 mm B5 LEF 257 x 182 mm A5 SEF...
Page 588 SPECIFICATIONS Rev. 11/2002 1.2 SCANNER Standard Scanner Main scan/Sub scan Resolution: 600 dpi Available scanning Twain Mode: Resolution Range: Book Mode (Main scan/Sub scan) 100 ~ 2400 dpi ADF Mode (Main scan/Sub scan) 100 ~ 1200 dpi Delivery Mode: Book and ADF Mode (Main scan/Sub scan) 100 ~ 600 dpi Grayscales: 8 bits/pixel...
Page 589 SPECIFICATIONS 2. SOFTWARE ACCESSORIES 2.1 PRINTER The printer drivers and utility software are provided on one CD-ROM. An auto-run installer allows you to select which components to install. Printer Drivers Windows Macintosh Printer Language Windows NT4.0 Windows 2000 95/98/ME 8.6 or later PCL 6 PCL 5e RPCS...
Page 590 SPECIFICATIONS 2.2 SCANNER The scanner driver and utility software are provided on one CD-ROM. Scanner Driver • Network Twain Driver for Win95/98/ME/NT3.51/NT4.0/2000 Scanner Utilities • Scan Router V2 Lite (Cherry-Lite) for Win95/98/ME/NT4.0/2000 • Desk Top Binder V2 Lite (Plumeria-Lite) for Win95/98/ME/NT4.0/2000 B453/B461...
Page 591 SPECIFICATIONS 3. MACHINE CONFIGURATION 3.1 SYSTEM COMPONENTS Memory DIMM Controller Board SIMAC NVRAM B453V101.WMF Printer DIMM D I M M Printer/ IEEE1394 Board Scanner D I M M B453V551.WMF Machine Item Remarks Code Printer Module B461 (ROM DIMM) Printer/Scanner Module B453 (ROM DIMM) Internal Options...
Page 592 FAX UNIT B418...
Page 594 FAX UNIT 1. INSTALLATION 1.1 FAX UNIT 1.1.1 CAUTIONS NOTE: 1) Never install telephone wiring during a lightning storm. 2) Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. 3) Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface.
Page 595 FAX UNIT 1.1.2 FLOW CHART Before installing the fax unit and/or fax options, refer to the following flow chart. START Install the Fax Function Upgrade Will you be installing the Unit and/or Expansion Memory to Fax Function Upgrade Unit and/or the FCU board.
Page 596 FAX UNIT 1.1.3 FAX OPTION TYPE 1027 INSTALLATION B418I101.WMF B418I502.WMF B418I504.WMF B418I503.WMF CAUTION Before installing this option, do the following: 1. If the Printer or Printer/Scanner DIMM was previously installed, Do Not remove the installed DIMM and install the Fax DIMM. The Fax option is included on both the printer and Printer/Scanner DIMM.
Page 597 FAX UNIT B418I106.WMF B418I505.WMF B418I108.WMF B418I607.WMF 5. Turn on the battery switch (SW1) [A] on the MBU board, then attach the FCU unit [B] (6 screws). Connect the cables [C], then clamp the cable at [D] as shown. Replace the rear cover and the small cover. 6.
Page 598 FAX UNIT B418I552.WMF 9. If the ADF has been installed, insert the stamp cartridge [A] into the ADF as shown. 10. Connect the telephone line to the “LINE” jack at the rear of the machine. 11. Plug in the machine and turn on the main power switch. NOTE: The copier must be connected to a properly-grounded socket outlet.
Page 599 FAX UNIT OPTIONS 1.2 FAX UNIT OPTIONS 1.2.1 G3 INTERFACE UNIT TYPE 1027 INSTALLATION B448I101.WMF B448I502.WMF B448I503.WMF CAUTION Before installing this option, do the following: 1. If there is a printer option in the machine, print out all data in the printer buffer.
Page 600 FAX UNIT OPTIONS B448I104.WMF B448I105.WMF Do steps 4 and 5 only when installing the G4 unit at the same time. 4. Remove the G4 board [A] (2 screws), the bracket [C] (2 screws) and the ISDN connector [D] from the G4 unit [B]. 5.
Page 601 FAX UNIT OPTIONS B448I506.WMF B448I507.WMF 6. Attach the G3 unit [A] to the machine (6 screws, 1 connector). 7. Connect cable [B] to the interface board and attach bracket [C] (1 screw). Then attach the NCU [D] (removed from the NCU unit in step 3) to the G3 unit (4 screws).
Page 602 FAX UNIT OPTIONS 1.2.2 ISDN OPTION TYPE 1027 INSTALLATION B449I101.WMF B449I502.WMF CAUTION Before installing this option, do the following: 1. If there is a printer option in the machine, print out all data in the printer buffer. 2. Turn off the main switch and disconnect the power cord and the network cable.
Page 603 FAX UNIT OPTIONS B449I503.WMF B449I104.WMF B449I505.WMF 3. Remove the NCU [A] from the NCU unit (4 screws). Connect the cable [B] to the FCU. 4. Attach the G4 unit [C] to the machine (6 screws, 1 connector). 5. Connect the cable [B] to the interface board and attach bracket [D] (1 screw). Then attach the NCU [A] (removed from the NCU unit in step 3) to the G4 unit (4 screws).
Page 604 FAX UNIT OPTIONS 6. Replace the rear cover and the small cover. B360I102.WMF B366I108.WMF B366I101.WMF 7. Connect the cable to the ISDN jack, then plug in the machine and turn the main switch on. 8. Attach the FCC/IC approval label to the machine near the ISDN jack. (This step is only for US/Canada.) 9.
Page 605 ERROR CODES 2. TROUBLESHOOTING 2.1 ERROR CODES If an error code occurs, retry the communication. If the same problem occurs, try to fix the problem as suggested below. Note that some error codes appear only in the error code display and on the service report. Code Meaning Suggested Cause/Action...
Page 606 ERROR CODES Code Meaning Suggested Cause/Action • Check the line connection. 0-06 The other terminal did not • Check the FCU - NCU connectors. reply to DCS • Try adjusting the tx level and/or cable equalizer settings. • Replace the NCU or FCU. •...
Page 607 ERROR CODES Code Meaning Suggested Cause/Action 0-15 The other terminal is not The other terminal is not capable of accepting the capable of specific following functions, or the other terminal’s memory functions. is full. • Confidential rx • Transfer function •...
Page 608 ERROR CODES Code Meaning Suggested Cause/Action • Check the line connection. 0-23 Too many errors during • Check the FCU - NCU connectors. reception • Replace the NCU or FCU. • Defective remote terminal. • Check for line noise or other line problems. •...
Page 609 ERROR CODES Code Meaning Suggested Cause/Action • The calling terminal could not detect a JM due to 0-77 The called terminal fell back to T.30 mode, because it noise, etc. • A network that has narrow bandwidth cannot could not detect a CJ in response to JM pass JM to the other end.
Page 610 ERROR CODES Code Meaning Suggested Cause/Action • Replace the FCU. 2-12 Modem clock irregularity • Turn off the machine, then turn it back on. 2-13 Modem initialization error • Update the modem ROM. • Replace the FCU. • Replace the FCU. 2-20 Abnormal coding/decoding (cpu not ready)
Page 611 ERROR CODES Code Meaning Suggested Cause/Action • Replace the FCU. 5-00 Data construction not possible 5-01 Data reconstruction not possible 5-10 DCR timer expired • Temporary memory shortage. 5-20 Storage impossible because • Test the SAF memory. of a lack of memory •...
Page 612 ERROR CODES Code Meaning Suggested Cause/Action • Check for line noise. 6-10 G3 ECM - error frames still • Adjust the tx level (use NCU parameter 01 or the received at the other end after all communication dedicated tx parameter for that address). attempts at 2400 bps •...
Page 613 ERROR CODES FOR THE ISDN OPTION 2.2 ERROR CODES FOR THE ISDN OPTION The tables on the following pages show the error codes for the ISDN option. The meaning of the numbers in the Action column is as follows. 1. Check Layer 1 signaling with a protocol analyzer to determine the cause of the problem.
Page 614 ERROR CODES FOR THE ISDN OPTION 2.2.1 D-CHANNEL LAYER MANAGEMENT Code Probable Cause Action 7-00 Link reset 7-01 Link set-up failed because of time-out. 7-02 Link release failed because of time-out. 7-03 Link set-up parameter error 2.2.2 D-CHANNEL, LAYER 1 Code Probable Cause Action...
Page 615 ERROR CODES FOR THE ISDN OPTION 2.2.4 D-CHANNEL NETWORK LAYER Code Probable Cause Action 7-40 Insufficient mandatory information elements 7-41 Abnormal LI for a mandatory information element 7-42 T301 timeout; timeout while waiting for R:CONN 7-43 T303 timeout; timeout while waiting for R: CALL-PROC etc. 7-44 T304 timeout;...
Page 616 ERROR CODES FOR THE ISDN OPTION 2.2.6 B-CHANNEL NETWORK LAYER Code Probable Cause Action 7-80 A packet having an abnormal GFI was received 7-81 A packet was received that had a logical channel number different from the logical channel being used for the communication 7-82 A packet containing a format error was received 7-83...
Page 617 ERROR CODES FOR THE ISDN OPTION 2.2.8 SESSION LAYER Code Probable Cause Action 8-30 Invalid frame received 8-31 RSSN received 8-32 CSA received 8-34 Calling terminal identification error in CSS 8-35 Date and time error in CSS 8-36 Window size error in CSS 8-37 Service identification error in CSS 8-38...
Page 618 ERROR CODES FOR THE ISDN OPTION 2.2.9 DOCUMENT LAYER Code Probable Cause Action 8-60 T.62 coding format error (LI error) 8-61 A mandatory PI was absent, or the LI for a mandatory PI was 0 Calling/called terminal identification LI was different from that specified 8-62 by F.184 (LI = 24) 8-63...
Page 619 FAX SC CODES 2.3 FAX SC CODES 2.3.1 OVERVIEW When the FCU detects a Fax SC Code condition other than SC1201 and SC1207, it resets itself automatically (default setting). This initializes the FCU without erasing files in the SAF memory or resetting the switches. NOTE: For details on Fax SC Codes 1201 and 1207, refer to the following sections.
Page 620 FAX SC CODES 2.3.4 FAX SC CODE TABLE Suggested Sys Switch Sys Switch SC Code Description Action 1F bit 7 = 0 1F bit 7 = 1 1101 FCU error Initialize the fax unit. Automatic SC Code (See section 2.3.1.for reset display the initialization...
Page 621 ISDN TEST FUNCTION 2.4 ISDN TEST FUNCTION 2.4.1 LEDS There are four LEDs on the G4 board. These LEDs describe the status of the machine. LED 1 LED 2 LED 3 LED 4 Initial Settings O=ON, --=OFF Initial check (if the flash ROM is updated) Handshaking with the FCU ready Standby Mode Ready to communicate...
Page 622 2.4.2 BACK-TO-BACK TEST To make a back-to-back test, you need: • Two machines, one with the CiG4 board (G4 board used in the B022 and previous models) and the other with the SiG4 board (G4 board used in previous models).
Page 623 SERVICE PROGRAM MODE 3. SERVICE TABLES CAUTION Never turn off the main power switch when the power LED is lit or flashing. To avoid damaging the hard disk or memory, press the operation power switch to switch the power off, wait for the power LED to go off, and then switch the main power switch off.
Page 624 SERVICE PROGRAM MODE SP Mode Button Summary Here is a short summary of the touch-panel buttons. B418S500.WMF Opens all SP groups and sublevels. Closes all open groups and sublevels and restores the initial SP mode display. Not used for the Fax SP mode. Enter the SP mode directly with the number keys if you know the SP number and then press .
Page 625 SERVICE PROGRAM MODE Switching Between SP Mode and Copy Mode for Test Printing 1) In the SP mode, select the test print and then press Copy Window. 2) Use the copy window (copier mode), to select the appropriate settings (paper size, etc.) for the test print. 3) Press Start D to execute the test print.
Page 626 SERVICE PROGRAM MODE 3.1.2 SERVICE PROGRAM MODE TABLES Section 3.2 Bit Switches SP1-XXX (Bit Switches) Mode No. Function System Switch 001 – 032 00 – 1F Change the bit switches for system settings for the fax option Section 3.2 Bit Switches Scanner Switch 001 –...
Page 627 SERVICE PROGRAM MODE Mode No. Function G3-1 NCU Parameters 001 – 023 CC, 01 – 22 NCU parameter settings for the standard G3 board. Section 3.3 NCU Parameters G3-2 NCU Parameters 001 – 023 CC, 01 – 22 NCU parameter settings for the optional G3 board.
Page 628 SERVICE PROGRAM MODE SP4-XXX (ROM Versions) Mode No. Function FCU ROM Version Displays the FCU ROM version. Error Codes Displays the latest 64 fax error codes. G3-1 ROM Version Displays the G3-1 modem version. G3-2 ROM Version Displays the G3-2 modem version. G4 ROM Version Displays the G4 (ISDN) ROM version.
Page 629 SERVICE PROGRAM MODE Mode No. Function G3-1 (1 Prints the protocol dump list of the last Communication) communication for the G3-1 line. G3-2 (All Prints the protocol dump list of all Communications) communications for the G3-2 line. G3-2 (1 Prints the protocol dump list of the last Communication) communication for the G3-2 line.
Page 630 SERVICE PROGRAM MODE SP7-XXX (Test Modes) These are the test modes for PTT approval. Function G3-1 Modem Tests G3-1 DTMF Tests Ringer Test G3-1 V34 (S2400baud) G3-1 V34 (S2800baud) G3-1 V34 (S3000baud) G3-1 V34 (S3200baud) G3-1 V34 (S3429baud) Recorded Message Test G3-2 Modem Tests G3-2 DTMF Tests G3-2 V34 (S2400baud)
Page 631 BIT SWITCHES 3.2 BIT SWITCHES WARNING Do not adjust a bit switch or use a setting that is described as “Not used”, as this may cause the machine to malfunction or to operate in a manner that is not accepted by local regulations. Such bits are for use only in other areas, such as Japan.
Page 632 BIT SWITCHES System Switch 00 SP No. 1-101-001 FUNCTION COMMENTS Rx level calculation Example: 0000 32 V34 288/264 L 01 00 03 04 The four-digit hexadecimal value (N) after “L” indicates the rx level. The high byte is given first, followed by the low byte. Divide the decimal value of N by - 16 to get the rx level.
Page 633 BIT SWITCHES I/O rate 0: 0 ms/line 10: 10 ms/line 25: 2.5 ms/line 20: 20 ms/line 5: 5 ms/line 40: 40 ms/line Note: “40” is displayed while receiving a fax message using AI short protocol. G4 Communication Parameters Compression mode MMR: MMR compression MR: MR compression MH: MH compression Resolution...
Page 634 BIT SWITCHES Rev. 10/2002 System Switch 02 SP No. 1-101-003 FUNCTION COMMENTS Memory read/write by RDS (0,0): All RDS systems are always locked out. Bit 7 Setting (0,1), (1,0): Normally, RDS systems are locked out, Always disabled but the user can temporarily switch RDS on to allow User selectable RDS operations to take place.
Page 635 Rev. 10/2002 BIT SWITCHES ⇒ System Switch 04 SP No. 1-101-005 FUNCTION COMMENTS Telephone line type 0: Telephone line type selection (tone dial or pulse programming dial) must be set from: 0: Enabled User Tools – Key Operator Tools – Select Dial/Push 1: Disabled Phone.
Page 636 BIT SWITCHES Rev. 10/2002 ⇒ System Switch 09 SP No. 1-101-010 FUNCTION COMMENTS Priority given to various types This bit determines which set of priorities the of remote terminal ID when machine uses when listing remote terminal names printing reports on reports.
Page 637 BIT SWITCHES System Switch 0F SP No. 1-101-016 FUNCTION COMMENTS Country/area code for This country/area code determines the factory functional settings (Hex) settings of bit switches and RAM addresses. However, it has no effect on the NCU parameter 00: France 11: USA settings and communication parameter RAM 01: Germany 12: Asia...
Page 638 BIT SWITCHES System Switch 11 SP No. 1-101-018 FUNCTION COMMENTS 1: The machine uses TTI_2 when the user dials the Type of TTI used for transmission using the ten-key destination using the ten-key pad. It is also used for polling transmission and manual transmission using the handset.
Page 639 BIT SWITCHES System Switch 16 SP No. 1-101-023 FUNCTION COMMENTS 1: When the G4 or/and G3 unit is installed, the Parallel Broadcasting machine sends messages simultaneously using 0 : Disabled both available ports (PSTN/ISDN) during 1 : Enabled broadcasting. Priority setting for the G3 line. This function allows the user to select the default G3 line type.
Page 640 BIT SWITCHES Rev. 04/2004 System Switch 1D SP No. 1-101-030 FUNCTION COMMENTS RTI/CSI/CPS display 1: RTI/CSI/CPS is displayed on the top line of the 0: Disabled LCD panel during communication. 1: Enabled Not used Do not change the settings. System Switch 1E SP No.
Page 641 BIT SWITCHES System Switch 1E SP No. 1-101-031 FUNCTION COMMENTS 0: When the machine has both RTI/CSI and the Address display priority in the AI redial mode telephone number information, the machine displays 0: RTI/CSI RTI/CSI. 1: Telephone number 1: The machine always displays the telephone number.
Page 642 BIT SWITCHES System Switch 1F SP No. 1-101-032 FUNCTION COMMENTS Not used Do not change the setting. Report printout after an original 0: When an original jams, or the SAF memory jam during SAF storage or if overflows during scanning, a report will be printed. the SAF memory fills up Change this bit to “1”...
Page 643 BIT SWITCHES 3.2.2 SCANNER SWITCHES Scanner Switch 00 - Not used (do not change the settings) Scanner Switch 01 SP No. 1-102-002 FUNCTION COMMENTS Scan density step value When scan density is adjusted manually away from (Text mode) the Normal setting, the threshold value for binary picture processing changes for each step from the value specified by Scanner Switch 02, by the amount programmed here.
Page 644 BIT SWITCHES Scanner Switch 05 SP No. 1-102-006 FUNCTION COMMENTS Binary picture processing: This setting determines the threshold value for Threshold for colored binary picture processing in colored background background special original 2 special original 2 mode (when the scan density mode - Normal setting (center setting is at the center).
Page 645 BIT SWITCHES Scanner Switch 0B SP No. 1-102-012 FUNCTION COMMENTS Scan margin setting (right and left margin in book scan ADF mode) The setting can be between 0 and F (H) (unit 0.5 mm). Default setting: 2 mm Scan margin setting (top and bottom margin in book scan and ADF mode) The setting can be between 0 and 7 (H) (unit 0.5 mm).
Page 646 BIT SWITCHES Scanner Switch 0D SP No. 1-102-014 FUNCTION COMMENTS Not used Do not change the settings. Scan width for A5 lengthwise or 0: The machine scans the original as 210 mm (8.5") B5 lengthwise originals width. The transmitted image has a blank area on 0: 210 mm (8.5”) the right.
Page 647 BIT SWITCHES 3.2.3 PRINTER SWITCHES Printer Switch 00 SP No. 1-103-001 FUNCTION COMMENTS 0: No marks are printed. Page separation mark 0: Disabled 1 : If a received page has to be printed out on two 1: Enabled sheets, an asterisk inside square brackets is printed at the bottom right hand corner of the first sheet, and a “2”...
Page 648 BIT SWITCHES Relationship between available paper sizes and printer width used in the setup protocol Available Paper Size Printer width used in the Protocol (NSF/DIS) A4 or 8.5" x 11" 297 mm width 256 mm width A5 or 8.5" x 5.5" 216 mm width No paper available (Paper end) 216 mm width...
Page 649 BIT SWITCHES Printer Switch 03 SP No. 1-103-004 FUNCTION COMMENTS Page separation threshold (with reduction disabled with switch 03-0 above) If the incoming page is up to x mm longer than the length of copy paper, the excess portion will not be printed. If the incoming page is more than x mm longer than the length of copy paper, the excess portion will be printed on the next page.
Page 650 BIT SWITCHES Printer Switch 06 SP No. 1-103-007 FUNCTION COMMENTS Printing while a paper cassette is pulled out, when the Just Size Printing feature is Cross reference enabled. Just size printing on/off – User switch 05, bit 5 0: Printing will not start 1: Printing will start if another cassette has a suitable size of paper, based on the paper size...
Page 651 BIT SWITCHES Printer Switch 0E SP No. 1-103-015 FUNCTION COMMENTS 1: If all paper sizes in the machine require page Page separation 0: Enabled separation to print a received fax message, the 1: Disabled machine does not print the message (Substitute Reception is used).
Page 652 BIT SWITCHES 3.2.4 COMMUNICATION SWITCHES Communication Switch 00 SP No. 1-104-001 FUNCTION COMMENTS Compression modes available These bits determine the compression capabilities in receive mode to be declared in phase B (handshaking) of the T.30 Bit 1 Modes protocol. MH only MH/MR MH/MR/MMR MH/MR/MMR/...
Page 653 BIT SWITCHES Communication Switch 01 SP No. 1-104-002 FUNCTION COMMENTS If this bit is set to 0, ECM is switched off for all 0: Off 1: On communications. In addition, V.8 protocol and JBIG compression are switched off automatically. Not used Do not change the setting.
Page 654 BIT SWITCHES Communication Switch 02 SP No. 1-104-003 FUNCTION COMMENTS 0: The next page will be sent even if RTN or PIN is Hang-up decision when a negative code (RTN or PIN) is received. received during G3 immediate 1: The machine will send DCN and hang up if it transmission receives RTN or PIN.
Page 655 BIT SWITCHES Communication Switch 07 SP No. 1-104-008 FUNCTION COMMENTS Fallback from G4 to G3 if the Also see system switch 0A bit 7. other terminal is not a G4 Refer to G4 Internal Switches 17, 18, 1A, 1B, and terminal 1C for the CPS code set (Cause Value set) that 0: Disabled...
Page 656 BIT SWITCHES Communication Switch 0B SP No. 1-104-012 FUNCTION COMMENTS Use of Economy Transmission These bits determine whether the machine uses the during a Transfer operation to Economy Transmission feature when it is carrying end receivers out a Transfer operation as a Transfer Station. 0: Disabled 1: Enabled Use of Economy Transmission during a Transfer operation to...
Page 657 BIT SWITCHES Communication Switch 0C SP No. 1-104-013 FUNCTION COMMENTS Number of digits compared to 00 - 1F (0 to 31 digits) find the requester’s fax number After the machine receives a transfer request, the from the programmed machine compares the own telephone number sent Quick/Speed Dials when acting from the Requesting Terminal with all Quick/Speed as a Transfer Station...
Page 658 BIT SWITCHES Communication Switch 0F - Not used (do not change the settings.) Communication Switch 10 SP No. 1-104-017 FUNCTION COMMENTS Memory transmission: 01 - FE (Hex) times Maximum number of dialing attempts to the same destination Communication Switch 11 - Not used (do not change the settings.) Communication Switch 12 SP No.
Page 659 BIT SWITCHES Communication Switch 16 SP No. 1-104-023 FUNCTION COMMENTS Standard G3 unit Set this bit to 0 if the user wants to use only the 0: Disabled ISDN line (option G4 unit), even for G3 1: Enabled communications. However, for ISDN on hook dialing, bit 7 of user parameter 30 must be set to 1.
Page 660 BIT SWITCHES Communication Switch 18 - Not used (do not change the settings) Communication Switch 19 - Not used (do not change the settings) Communication Switch 1A - Not used (do not change the settings) Communication Switch 1B SP No. 1-104-028 FUNCTION COMMENTS Extension access code (0 to 7)
Page 661 BIT SWITCHES 3.2.5 G3 SWITCHES G3 Switch 00 SP No. 1-105-001 FUNCTION COMMENTS (0, 0): The monitor speaker is disabled all through Monitor speaker during communication (tx and rx) the communication. Bit 1 Bit 0 Setting (0, 1): The monitor speaker is on up to phase B in Disabled the T.30 protocol.
Page 662 CTC transmission conditions When using ECM, the machine will choose a slower 0: Ricoh mode (PPR x 1) modem rate after receiving PPR once (Ricoh mode) 1: ITU-T mode (PPR x 4) or four times (ITU-T mode). This bit is ineffective in V.34 communications.
Page 663 BIT SWITCHES G3 Switch 05 SP No. 1-105-006 FUNCTION COMMENTS Initial Tx modem rate These bits set the initial starting modem rate for Bit 3 2 1 0 Setting (bps) transmission. 0 0 0 1 2.4 k 0 0 1 0 4.8 k Use the dedicated transmission parameters if you 0 0 1 1 7.2 k need to change this for specific receivers.
Page 664 BIT SWITCHES G3 Switch 06 SP No. 1-105-007 FUNCTION COMMENTS Modem types available for The setting of these bits is used to inform the reception transmitting terminal of the available modem type for Bit 7 6 5 4 Setting the machine in receive mode. 0 0 0 1 V.27ter 0 0 1 0 V.27ter, V.29 If V.34 is not selected, V.8 protocol must be...
Page 665 BIT SWITCHES G3 Switch 08 - Not used (do not change the settings) G3 Switch 09 SP No. 1-105-010 FUNCTION COMMENTS ISDN cable equalizer Use a higher setting if there is signal loss at higher (tx mode: Internal) frequencies because of the length of wire between Bit 1 Bit 0 Setting the modem and the telephone exchange.
Page 666 BIT SWITCHES Not used Do not change the settings. Maximum allowable frame This bit set the maximum interval between EOL interval during image data (end-of-line) signals and the maximum interval reception. between ECM frames from the other end. 0: 5 s 1: 13 s Try using a longer setting if error code 0-21 is frequent.
Page 667 BIT SWITCHES G3 Switch 0D SP No. 1-105-014 FUNCTION COMMENTS Not used Do not change the settings. Data rate threshold during V.34 The machine changes the modulation parameters in reception the MPh signal to lower the initial modem rate Bit 5 4 3 2 Setting during V.34 reception.
Page 668 BIT SWITCHES 3.2.6 G3-2 SWITCHES These switches require an optional G3 interface unit. G3-2 Switch 00 SP No. 1-106-001 FUNCTION COMMENTS Monitor speaker during (0, 0): The monitor speaker is disabled all through communication (tx and rx) the communication. Bit 1 Bit 0 Setting (0, 1): The monitor speaker is on up to phase B in...
Page 669 BIT SWITCHES G3-2 Switch 03 SP No. 1-106-004 FUNCTION COMMENTS 0: The machine will hang up if it receives the same DIS detection number (Echo countermeasure) DIS frame twice. 0: 1 1: Before sending DCS, the machine will wait for the 1: 2 second DIS which is caused by echo on the line.
Page 670 BIT SWITCHES G3-2 Switch 05 SP No. 1-106-006 FUNCTION COMMENTS Initial Tx modem rate These bits set the initial starting modem rate for Bit 3 2 1 0 Setting (bps) transmission. 0 0 0 1 2.4 k 0 0 1 0 4.8 k Use the dedicated transmission parameters if you 0 0 1 1...
Page 671 BIT SWITCHES G3-2 Switch 06 SP No. 1-106-007 FUNCTION COMMENTS Modem types available for The setting of these bits is used to inform the reception transmitting terminal of the available modem type for Bit 7 6 5 4 Setting the machine in receive mode. 0 0 0 1 V.27ter 0 0 1 0...
Page 672 BIT SWITCHES G3-2 Switch 08 - Not used (do not change the settings) G3-2 Switch 09 - Not used (do not change the settings) G3-2 Switch 0A SP No. 1-106-011 FUNCTION COMMENTS Maximum allowable carrier These bits set the acceptable modem carrier drop drop during image data time.
Page 673 BIT SWITCHES G3-2 Switch 0B SP No. 1-106-012 FUNCTION COMMENTS Protocol requirements: Europe The machine does not automatically reset these bits 0: Disabled 1: Enabled for each country after a country code (System Switch 0F) is programmed. Protocol requirements: Spain Change the required bits manually at installation.
Page 674 BIT SWITCHES 3.2.7 G4 INTERNAL SWITCHES G4 Internal Switch 00 FUNCTION COMMENTS Country code Bit 4 Country Germany (1TR6 mode) Universal (Europe Euro ISDN) Note: In Germany, use the Universal setting for the Euro ISDN lines. G4 Internal Switch 01 - Not used (do not change the settings) G4 Internal Switch 02 - Not used (do not change the settings) G4 Internal Switch 03 FUNCTION...
Page 675 BIT SWITCHES G4 Internal Switch 05 FUNCTION COMMENTS Not used Do not change these settings. Protocol ID check The Protocol ID is in the CR packet. 0: Yes 1: No Not used Do not change the settings. G4 Internal Switch 06 - Not used (do not change these settings) G4 Internal Switch 07 - Not used (do not change these settings) G4 Internal Switch 08 - Not used (do not change these settings) G4 Internal Switch 09 - Not used (do not change these settings)
Page 676 BIT SWITCHES G4 Internal Switch 13: D channel layer 3 (Attachment IE in S: SETUP) FUNCTION COMMENTS Not used Do not change the setting. Information transfer capability shift 1: The machine changes the ISDN G3 down to retry transmission information transfer capability informed in the [SETUP] signal to “Speech”...
Page 677 BIT SWITCHES G4 Internal Switch 13: D channel layer 3 (Attachment IE in S: SETUP) FUNCTION COMMENTS Condition for fallback from G4 to 0: Fallback occurs when a CPS code is the same as the CPS code settings specified by G4 internal switches 17, 18, 1A, 1B, and 0: Refer to the CPS code setting 1: Fallback in response to any CPS If you wish to enable fallback when any CPS...
Page 678 BIT SWITCHES G4 Internal Switch 15: D channel layer 3 (Judgement R: MSG) FUNCTION COMMENTS Action when receiving [SETUP] This bit depends on user requirements. If it is signal containing no called at 1, communication will be halted if the other subaddress terminal has not input the subaddress.
Page 679 BIT SWITCHES G4 Internal Switch 16: D channel layer 3 (Approval) FUNCTION COMMENTS Transfer capabilities (SI) informed This bit determines whether transfer capabilities informed in the Service Indicator in 1TR6 ISDN G3 transmission for 1TR6 ISDN G3 transmission. This switch is 0: G3 Fax effective in coping with communication 1: Analog...
Page 680 BIT SWITCHES G4 to G3 fallback Bit 0 of Communication Switch 07 must be at 0, or fallback from G4 to G3 will be disabled. The CPS codes for which fallback occurs are decided as follows. • G4 bit switch 17, bit 7 - If set to “0”, fallback occurs on receipt of a code from a set that depends on the country code.
Page 681 BIT SWITCHES 3.2.8 G4 PARAMETER SWITCHES G4 Parameter Switch 00 FUNCTION COMMENTS Network type Do not change the default setting. Bit 2 Type Circuit switched ISDN Other settings: Not used Not used Do not change the default settings. G4 Parameter Switch 01 FUNCTION COMMENTS 0: This setting is used in USA.
Page 682 BIT SWITCHES G4 Parameter Switch 05 FUNCTION COMMENTS Not used Do not change the settings. B-channel T3 timer 1: This switch is useful when used in 0: 30s 1: 57s combination with the Communication Bit SW 07 bit 4. This is to cope with communication problems where G4 communication fails on the ISDN B- channel.
Page 683 BIT SWITCHES G4 Parameter Switch 09 - Not used (do not change the settings) G4 Parameter Switch 0A - Not used (do not change the settings) G4 Parameter Switch 0B FUNCTION COMMENTS Transport block size This value must match the value set in the Bit 3 Value other terminal.
Page 684 NCU PARAMETERS 3.3 NCU PARAMETERS The following tables give the RAM addresses and the parameter calculation units that the machine uses for ringing signal detection and automatic dialing. The factory settings for each country are also given. Most of these must be changed by RAM read/write (SP2-102), but some can be changed using NCU Parameter programming (SP2-103, 104 and 105);...
Page 685 NCU PARAMETERS Address Function Unit Remarks 680500 Country/Area code for NCU Use the Hex value to program the parameters country/area code directly into this address, or use the decimal value to program it using SP2-103-001 Country/Area Decimal Hex France Germany Italy Austria Belgium...
Page 686 NCU PARAMETERS Address Function Unit Remarks 680504 PSTN dial tone frequency upper limit Hz (BCD) If both addresses contain FF(H), tone detection is (high byte) disabled. 680505 PSTN dial tone frequency upper limit (low byte) 680506 PSTN dial tone frequency lower limit Hz (BCD) If both addresses contain (high byte)
Page 687 NCU PARAMETERS Address Function Unit Remarks 68051B PABX dial tone detection time 20 ms If 68051B contains FF, the machine pauses for 68051C PABX dial tone reset time (LOW) the pause time (680520 / 68051D PABX dial tone reset time (HIGH) 680521).
Page 688 NCU PARAMETERS Address Function Unit Remarks 680534 International dial tone frequency Hz (BCD) If both addresses contain upper limit (high byte) FF(H), tone detection is disabled. 680535 International dial tone frequency upper limit (low byte) 680536 International dial tone frequency Hz (BCD) If both addresses contain lower limit (high byte)
Page 689 NCU PARAMETERS Address Function Unit Remarks 680543 Country dial tone detection time 20 ms If 680543 contains FF, the machine pauses for 680544 Country dial tone reset time (LOW) the pause time (680548 / 680545 Country dial tone reset time (HIGH) 680549).
Page 690 NCU PARAMETERS Address Function Unit Remarks 680557 Time between 68054Dh (NCU 1 ms This parameter takes parameter 14) and 68054Eh (NCU effect when the country parameter 15) code is set to France. 680558 Not used Do not change the setting. 680559 Grounding time (ground start mode) 20 ms...
Page 691 NCU PARAMETERS Address Function Unit Remarks 680572 Acceptable ringing signal frequency: 1000/ N SP2-103-003 (parameter range 1, upper limit (Hz). 02). 680573 Acceptable ringing signal frequency: SP2-103-004 (parameter range 1, lower limit 03). 680574 Acceptable ringing signal frequency: SP2-103-005 (parameter range 2, upper limit 04).
Page 692 NCU PARAMETERS Address Function Unit Remarks 6805A1 Acceptable CED detection frequency BCD (Hz) If both addresses contain FF(H), tone detection is upper limit (high byte) disabled. 6805A2 Acceptable CED detection frequency upper limit (low byte) 6805A3 Acceptable CED detection frequency BCD (Hz) If both addresses contain lower limit (high byte)
Page 693 NCU PARAMETERS Address Function Unit Remarks 6805B8 PABX: 1100 Hz tone transmission - 0.5N (dB) 6805B7 6805B8 level 6805B9 PABX: 2100 Hz tone transmission - 0.5N (dB) 6805B7 6805B9 level 6805BA ISDN: Tx level from the modem - dBm The setting must be between -12dBm and - 15dBm.
Page 694 NCU PARAMETERS NOTES 1. If a setting is not required, store FF in the address. 2. Italy and Belgium only RAM address 68055E: the lower four bits have the following meaning. Bit 2 - 1: International dial tone cadence detection enabled (Belgium) Bit 1 - Not used Bit 0 - 1: PSTN dial tone cadence detection enabled (Italy) If bit 0 or bit 2 is set to 1, the functions of the following RAM addresses are...
Page 695 DEDICATED TRANSMISSION PARAMETERS 3.4 DEDICATED TRANSMISSION PARAMETERS Each Quick Dial Key and Speed Dial Code has eight bytes of programmable parameters allocated to it. If transmissions to a particular machine often experience problems, store that terminal’s fax number as a Quick Dial or Speed Dial, and adjust the parameters allocated to that number.
Page 696 DEDICATED TRANSMISSION PARAMETERS 3.4.2 PARAMETERS The initial settings of the following parameters are all FF(H) - all the parameters are disabled. Switch 01 FUNCTION AND COMMENTS ITU-T T1 time (for PSTN G3 mode) If the connection time to a particular terminal is longer than the NCU parameter setting, adjust this byte.
Page 697 DEDICATED TRANSMISSION PARAMETERS Switch 03 FUNCTION COMMENTS Initial Tx modem rate If training with a particular remote terminal always Bit3 2 1 0 Setting (bps) takes too long, the initial modem rate may be too 0 0 0 0 Not used high.
Page 698 DEDICATED TRANSMISSION PARAMETERS Switch 04 FUNCTION COMMENTS V.8 protocol If transmissions to a specific destination always end 0: Off at a lower modem rate (14,400 bps or lower), 1: Disabled disable V.8 protocol so as not to use V.34 protocol. 0: V.34 communication will not be possible.
Page 699 DEDICATED TRANSMISSION PARAMETERS Switch 09 - Optional ISDN G4 kit required FUNCTION COMMENTS Layer 3 protocol If the setting is “Disabled”, the current setting of G4 Bits 3 2 1 0 Setting parameter switch 6 (bit 0) is used. 0 0 0 0 ISO 8208 0 0 0 1 T.70 NULL 1 1 1 1 Disabled Packet modulus...
Page 700 SERVICE RAM ADDRESSES 3.5 SERVICE RAM ADDRESSES CAUTION Do not change the settings which are marked as “Not used” or “Read only.” 680001 to 680004(H) - ROM version (Read only) 680001(H) - Revision number (BCD) 680002(H) - Year (BCD) 680003(H) - Month (BCD) 680004(H) - Day (BCD) 680006 to 680015(H) - Machine’s serial number (16 digits - ASCII) 680018(H) - Total program checksum (low)
Page 701 SERVICE RAM ADDRESSES 6800D3(H) - User parameter switch 03 (SWUSR_03: Automatic report printout) Bit 0: Transmission result report (memory transmissions) 0: Off, 1: On Bit 1: Not used Bit 2: Memory storage report 0: Off, 1: On Bit 3: Polling reserve report (polling reception) 0: Off, 1: On Bit 4: Polling result report (polling reception) 0: Off, 1: On Bit 5: Transmission result report (immediate transmissions) 0: Off, 1: On Bit 6: Polling clear report 0: Off, 1: On...
Page 702 SERVICE RAM ADDRESSES 6800D8(H) - User parameter switch 08 (SWUSR_08) Bits 0 and 1: Not used. Bit 2: Authorized reception 0: Only faxes from senders whose RTIs/CSIs are specified for this feature are accepted. 1: Only faxes from senders whose RTIs/CSIs are not specified for this feature are accepted.
Page 703 SERVICE RAM ADDRESSES 6800DE(H) - User parameter switch 14 (SWUSR_0E) Bit 0: Message printout while the machine is in Night Printing mode 0: On, 1: Off Bit 1: Maximum document length detection 0: Double letter, 1: Longer than double-letter (well log) – up to 1,200 mm Bit 2: Batch transmission 0: Off, 1: On Bit 3: Fax mode settings, such as resolution, before a mode key (Copy/Fax/Printer /Scanner) is pressed...
Page 704 SERVICE RAM ADDRESSES 6800E3(H) - User parameter switch 19 (SWUSR_13) Bit 0: Offset sort function for the fax (only using the shift tray on the 1,000 sheet finisher) 0: Disabled, 1: Enabled Bit 1: Journal format 0: The Journal is separated into transmissions and receptions 1: The Journal is separated into G3-1, G3-2, G3-3 and G4 communications Bit 2: Action when the paper cassette that was selected by the specified cassette selection feature becomes empty.
Page 705 SERVICE RAM ADDRESSES 6800E8(H) - User parameter switch 24 (SWUSR_18) Bits 0 and 1: File retention time (Cross reference: System switch 02 bit 4) Setting File retention impossible 24 hours File retention impossible 72 hours Bits 2 to 7: Not used 6800E9(H) - User parameter switch 25 (SWUSR_19) Bits 0 to 3: Not used Bit 4: RDS operation...
Page 706 SERVICE RAM ADDRESSES NOTE: If the number of characters is less than the maximum (20 for RTI, 64 for TTI), add a stop code (FF[H]) after the last character. 6802E0 to 6802E2(H) - PSTN-1 line settings 6802E0 Bits 0 and 1: PSTN access method from behind a PABX. Setting Loop start Ground start...
Page 707 SERVICE RAM ADDRESSES 68030C(H) - Network type used for the service station number 0 1 (H) - PSTN-1 0 2 (H) - PSTN-2 1 0 (H) - G4 0 7 (H) - G3 auto selection 680310 to 680317(H) - Last power off time (Read only) 680310(H) - 01(H) - 24-hour clock, 00(H) - 12-hour clock (AM), 02(H) - 12-hour clock (PM) 680311(H) - Year (BCD)
Page 708 SERVICE RAM ADDRESSES 6803A6 to 6803AB(H) - Modem ROM version (Read only) 6803A6(H) - Part number (low) 6803A7(H) - Part number (high) 6803A8(H) - Control (low) 6803A9(H) - Control (high) 6803AA(H) - DSP (low) 6803AB(H) - DSP (high) 680406(H) - Time for economy transmission (hour in 24h clock format - BCD) 680407(H) - Time for economy transmission (minute - BCD) 680422(H) - Transmission monitor volume 00 - 07(H) 680423(H) - Reception monitor volume 00 - 07(H)
Page 709 OVERVIEW 4. DETAILED SECTION DESCRIPTIONS 4.1 OVERVIEW Fax Function U pgrade N C U FC U C C U IF N C U C ontroller M B U E xpansion M em ory B418D501.WMF The basic fax unit consists of three PCBs: an FCU, an MBU and an NCU. The FCU controls all the fax communications and fax features, in cooperation with the controller board.
Page 710 BOARDS 4.2 BOARDS 4.2.1 FCU S G 3 IS D N S R AM Flash RO M (256 kB ) (3 M B ) M B U C P U B U S F A C E 2 V .34 C P U D C R FB I...
Page 711 BOARDS DRAM • The 8 MB of DRAM is shared as follows. SAF memory : 2MB Working memory : 2MB Page memory : 4MB • The SAF memory is backed up by a rechargeable battery. Memory back-up • A Rechargeable battery backs up the SAF memory (DRAM) for 1 hour. Switches Item Description...
Page 712 BOARDS 4.2.3 NCU (US) J P 7 O H D I S W . Surge D B 1 Protection TRXD Noise C M L Over- Filter Relay RING DC Loop current Transformer Protection Surge Protection J P 8 Current Sensor O H D I S W C M L S W Hook0...
Page 713 BOARDS 4.2.4 NCU (EUROPE/ASIA) Noise SHUNT CML Relay Filter D C L S W Filter (16Hz) DO Sw. RING TRXD Current Sensor Loop OHDI Sw. D O S W O H D I S W GS Sw. C M L L S W Hook0 Hook1 SHUNT...
Page 714 BOARDS 4.2.5 SG3 BOARD Standard D T M F Hybrid IC C C P Receiver F C U Flash ROM C P U D P R A M D M A C JBIGIF T O N E MN195003MFL ( R U 8 ) (4MB) Modem M o d e m...
Page 715 BOARDS 4.2.6 SIG4 BOARD Flash SiG4 DR AM R O M SYSTEM BUS D c h B c h LAPD ISDN Reset ICCP ISDN Circuit Controller Interface Analog I/F C O D E C Circuit M O D E M B418D500.WMF The SiG4 (Standard ISDN G4) board contains ICCP (ISDN Communication Control Processor), Flash ROM, DRAM, LAPD controller, CODEC, ISDN interface and...
Page 716 VIDEO DATA PATH 4.3 VIDEO DATA PATH 4.3.1 TRANSMISSION S C A N N E R IP U F C U FB I FA C E 2 P ag e M em ory D C R S A F S G 3 Q M - Q M - D C R...
Page 717 VIDEO DATA PATH Memory Transmission and Parallel Memory Transmission The base copier's scanner scans the original at the selected resolution in inch format. The IPU processes the data and transfers it to the FCU. NOTE: When scanning a fax original, the IPU uses the MTF, independent dot erase and thresholding parameter settings programmed in the fax unit’s scanner bit switches, not the copier's SP modes.
Page 718 VIDEO DATA PATH Adjustments • Line used for G3 transmissions (PSTN or ISDN): System switch 0A bit 6 • Line used for G3 transmissions (PSTN 1/PSTN 2): System switch 16 bit 1 • I-G3 modem default: System switch 16 bit 2 and 3 B418 4-10...
Page 719 VIDEO DATA PATH 4.3.2 RECEPTION A nalog G 3 A nalog G 3 IS D N G 3 IS D N G 4 N C U N C U S iG 4 M odem M odem Q M - C O D E R S A F D C R C C D...
Page 720 VIDEO DATA PATH First, the FCU stores the incoming data from either an analog line or an ISDN line to the SAF memory. (The data goes to the FACE at the same time, and is checked for error lines/frames.) The FCU then decompresses the data and transfers it to page memory. If image rotation will be done, the image is rotated in the page memory.
Page 721 FAX COMMUNICATION FEATURES 4.4 FAX COMMUNICATION FEATURES 4.4.1 PERSONAL/INFORMATION/TRANSFER BOXES When an incoming message has a SUB or SEP code attached, the machine will look for a Personal Box, Transfer Box or Information Box with an identical SUB or SEP code. If a matching code is found, the message will be stored in the box and not printed, or it will be forwarded to the receiver if registered.
Page 722 FAX COMMUNICATION FEATURES Transfer Box The user can create transfer boxes in the machine’s memory for forwarding incoming fax messages. Each box must have a name and a code. Each box must also have destinations associated with it; any message arriving in this box will automatically be sent on to these destinations.
Page 723 FAX COMMUNICATION FEATURES Information Box (Polling Tx) The user can set up documents in memory to be picked up by another machine. The user makes an information box for each document. The information box is identified by a code. Anybody who wishes to call the fax machine and receive the document from the information box has to input this code as the SEP code when calling the machine.
Page 724 FAX COMMUNICATION FEATURES 4.4.2 MULTI-PORT When the optional ISDN Unit or optional extra G3 Interface Unit is installed, communication can take place at the same time through the two or three lines at once. Available protocol Option Available Line Type Combinations Standard only PSTN...
Page 725 FAX COMMUNICATION FEATURES 4.4.3 DOCUMENT SERVER S canner C o n tro lle r Com oressed M M R P age IP U M em ory F C U FB I FA C E2 DC R M odem NC U P S T N D A T A /A D D R E S S B U S S iG 4...
Page 726 FAX COMMUNICATION FEATURES 4.4.4 LAN FAX DRIVER A pp lication Fax D river C om pressed M M R Fax N um ber A dd ress/B o ok N IC L A N N IC C O N T R O L L E R IP U P R IN TE R F C U...
Page 727 FAX COMMUNICATION FEATURES The fax driver makes print data from an application, then compresses the print data into MMR data. PJL commands are added to the compressed data and the destination telephone number and the line selection are included in the PJL commands.
Page 728 ROM HISTORY Rev. 06/2002 4.5 ROM HISTORY ⇒ 4.5.1 FCU ROM HISTORY B022/B027 FCU ROM MODIFICATION HISTORY DESCRIPTION OF MODIFICATION FIRMWARE FIRMWARE LEVEL VERSION First mass production B0285771 05.03.00 Even if the prefix number access mode (Loop start) is B0285771 06.00.01...
Page 729 ROM HISTORY Rev. 06/2002 ⇒ 4.5.2 FAX APPLICATION ROM HISTORY B022/B027 FAX APPLICATION ROM MODIFICATION HISTORY DESCRIPTION OF MODIFICATION FIRMWARE FIRMWARE LEVEL VERSION First mass production B4185592 4.11 Documents received in substitute reception are B4185592 4.11.1 successfully stored into SAF memory, however if the main controller goes into Energy Saver mode during reception, the files cannot be printed out later.
Page 730 SPECIFICATIONS SPECIFICATIONS 1. GENERAL SPECIFICATIONS Type: Desktop type transceiver Circuit: PSTN (max. 2ch.) PABX ISDN Connection: Direct couple Original Size: Book (Face down) Maximum Length: 432 mm [17 ins] Maximum Width: 297 mm [11.7 ins] ARDF (Face up) (Single-sided document) Length: 128 - 1200 mm [5.0 - 47.2 ins] Width: 105 - 297 mm [4.1 - 11.7 inch] (Double-sided document)
Page 731 SPECIFICATIONS Modulation: V.34, V.33, V.17 (TCM), V.29 (QAM), V.27ter (PHM), V.8, V.21 (FM) Data Rate: G3: 33600/31200/28800/26400/24000/21600/ 19200/16800/14400/12000/9600/7200/4800/2400 bps Automatic fallback G4: 64 kbps/56 kbps I/O Rate: With ECM: 0 ms/line Without ECM: 2.5, 5, 10, 20, or 40 ms/line Memory Capacity: ECM: 128 KB Standard: 2 MB...
Page 732 SPECIFICATIONS 2. CAPABILITIES OF PROGRAMMABLE ITEMS The following table shows how the capabilities of each programmable item will change after the optional Fax Function Upgrade Unit is installed. With Fax Function Item Standard Upgrade Unit Quick Dial 1200 Groups Destination per Group Boxes (Information/Personal/Transfer) Destinations dialed from the ten-key pad 1000...
Page 733 Rev. 05/2002 SPECIFICATIONS 3. MACHINE CONFIGURATION B418V101.WMF Description Description Description NCU board MBU board CCUIF FCU board FCUIF board SiG4 board Fax Function Upgrade DIMM board for Fax Optional G3 board Unit application Expansion Memory Controller board Optional NCU board Item Machine Code Remarks...
Page 734 TECHNICAL SERVICE BULLETINS...
Page 735 Refer to Facts Line Bulletin # FL002 and Publication Bulletin #023 for more information about the FTP Internet Web Site and EPROM / Flash Card Exchange program. UNITS AFFECTED: All B022/B027 copiers manufactured after the serial numbers listed below will have the newer firmware installed during production. MODEL NAME...
Page 736 The Service Manual pages listed below must be replaced with the pages supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • Updated Information • Updated Information (B453/B461 Section)     CONTROL NO. 123ABW Copyright 2002 RICOH Corporation. All rights reserved.
Page 738 PRINTER/SCANNER INSTALLATION Rev. 03/2002 Printer, Printer/Scanner Controller Installation CAUTION Unplug the main machine power cord before starting the following procedure. ⇒ NOTE: 1) When installing this unit, the 64 MB memory must be installed. 2) The NIB option is required when the printer/scanner controller is installed.
Page 739 1 set of replacement pages. ⇒ An arrow has highlighted the revised areas PAGES: 4-36 SP Mode Updated Information Machine Configuration Updated Information Troubleshooting Updated Information     Copyright 2002 RICOH Corporation. All rights reserved. CONTROL NO 132ABW...
Page 740 To clear the service call, touch “Execute” on the LCD, then turn the main power switch off/on. Serial Number Input Use to input the machine serial number. (This is normally done at the factory.) This serial number will be printed on the SMC report. B022/B027 4-36...
Page 741 Rev. 05/2002 SPECIFICATIONS 3. MACHINE CONFIGURATION B418V101.WMF Description Description Description NCU board MBU board CCUIF FCU board FCUIF board SiG4 board Fax Function Upgrade DIMM board for Fax Optional G3 board Unit application Expansion Memory Controller board Optional NCU board Item Machine Code Remarks...
Page 742 NOTE: 1) If the problem concerns electrical circuit boards, first disconnect then reconnect the connectors before replacing the PCBs. 2) If the problem concerns a motor lock, first check the mechanical load before replacing motors or sensors. B022/B027...
Page 743 Permanent: The manufacturer will ensure that the proper molds are used for both covers. Action in the field: when installing the optional fax unit, please cut off the excess rib material as shown in the illustration below.     Copyright 2002 RICOH Corporation. All rights reserved. CONTROL NO 138ABW...
Page 744 The Service Manual pages listed below must be replaced with the pages supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • Updated Information (Table of Contents) • 4-20,21 New Information (B418 ROM History)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 745 Regular transmission: .................4-19 Print and transmission ................4-19 Using Document Server..............4-19 4.5 ROM HISTRORY..................4-20 4.5.1 FCU ROM HISTORY ..............4-20 4.5.2 FAX APPLICATION ROM HISTORY..........4-21 SPECIFICATIONS SPECIFICATIONS................5-1 1 GENERAL SPECIFICATIONS..............5-1 2 CAPABILITIES OF PROGRAMMABLE ITEMS ..........5-3 3 MACHINE CONFIGURATION ..............5-4 B022/B027...
Page 746 ROM HISTORY Rev. 06/2002 4.5 ROM HISTORY ⇒ 4.5.1 FCU ROM HISTORY B022/B027 FCU ROM MODIFICATION HISTORY DESCRIPTION OF MODIFICATION FIRMWARE FIRMWARE LEVEL VERSION First mass production B0285771 05.03.00 Even if the prefix number access mode (Loop start) is B0285771 06.00.01...
Page 747 ROM HISTORY Rev. 06/2002 ⇒ 4.5.2 FAX APPLICATION ROM HISTORY B022/B027 FAX APPLICATION ROM MODIFICATION HISTORY DESCRIPTION OF MODIFICATION FIRMWARE FIRMWARE LEVEL VERSION First mass production B4185592 4.11 Documents received in substitute reception are B4185592 4.11.1 successfully stored into SAF memory, however if the main controller goes into Energy Saver mode during reception, the files cannot be printed out later.
Page 748 PAGE ITEM B0275317 B0315310 Controller Board Sub Assembly UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style Controller Board Sub Assembly installed during production. MODEL NAME SERIAL NUMBER Gestetner 2212 J01203xxxxx Gestetner 2712...
Page 749 B0314121 Front Side Plate B0244125 B0314125 Rear Side Plate UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style Fusing Units installed during production. MODEL NAME SERIAL NUMBER Gestetner 2212 J01206xxxxx Gestetner 2712...
Page 750 DESCRIPTION PAGE ITEM A2671743 B0271742 Bracket - Scale UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style Bracket - Scale installed during production. MODEL NAME SERIAL NUMBER Gestetner 2212 J0120900001 Gestetner 2712...
Page 751 GESTETNER – 2212/2712 RICOH – AFICIO 1022/1027 SAVIN – 2522/2527 SUBJECT: PARTS CATALOG UPDATES GENERAL: The following parts updates are being issued for all B022/B027 Parts Catalogs. • UPDATE 1: Total Counter – Please correct your parts catalog. REFERENCE OLD PART NO.
Page 752 Tech Service Bulletin No. B022/B027 – 009 Page 2 of 2 • UPDATE 3: NVRAM – Please apply the following P/N correction to your Parts Catalogs. REFERENCE OLD PART NO. NEW PART NO. DESCRIPTION PAGE ITEM 14075324 B0049099 NVRAM •...
Page 753 Registration Roller Cleaner has been changed to a removable Cleaning Pad type. In accordance with this change, the shape of the PCU Guide Plate has also been changed. The following parts updates are being issued for all B022/B027 Parts Catalogs. Continued…...
Page 754 Cleaning Pad – Registration Roller B0272714 Clip DENOTES NEW ITEM NUMBER UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style Cleaning Pad – Registration Roller installed during production. MODEL NAME SERIAL NUMBER Gestetner 2212...
Page 755 GESTETNER – 2212/2712 RICOH – AFICIO 1022/1027 SAVIN – 2522/2527 SUBJECT: TRAY LIFT ASSEMBLY GENERAL: To facilitate assembly of the tray lift unit and DC motor lever, the following parts have been changed. Continued…  2000 RICOH Corporation. All rights reserved.
Page 756 B0312776 Lever – DC Motor DENOTES NEW ITEM NUMBER UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style tray lift unit and DC motor lever installed during production. MODEL NAME SERIAL NUMBER...
Page 757 RICOH – AFICIO 1022/1027 SAVIN – 2522/2527 SUBJECT: TRAY LIFT ASSEMBLY GENERAL: To facilitate assembly of the tray lift unit and DC motor lever, the following parts have been changed. Continued…     2000 RICOH Corporation. All rights reserved.
Page 758 B0312776 Lever – DC Motor DENOTES NEW ITEM NUMBER UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style tray lift unit and DC motor lever installed during production. MODEL NAME SERIAL NUMBER...
Page 759 The revised areas have been highlighted by an arrow • xiii - xiv Updated Information (Table of Contents) • tab page Updated Information (Bleeding Tab Page) • 19-1 through 19-5 New information (Firmware History)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 760 4.6 UPPER TRAY..................17-18 4.7 LOWER TRAY UP/DOWN MECHANISMS ...........17-19 4.8 PAPER SHIFT MECHANISM ..............17-20 4.9 JOGGER UNIT PAPER POSITIONING MECHANISM......17-21 4.10 EXIT GUIDE PLATE................17-22 4.11 STAPLER MECHANISM ..............17-23 4.12 STAPLER UNIT MOVEMENT MECHANISM ........17-24 4.13 PAPER FEED-OUT MECHANISM ............17-25 xiii B022/B027...
Page 761 3 OVERALL MACHINE INFORMATION........18-21 3.1 SPECIFICATIONS..................18-21 FIRMWARE HISTORY 1 FIRMWARE HISTORY ..............19-1 1.1 FIRMWARE MODIFICATION HISTORY ..........19-1 1.1.1 FIRMWARE MODIFICATION HISTORY (CONTROLLER) ....19-1 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) ......19-3 1.1.3 FIRMWARE MODIFICATION HISTORY (LCDC) ......19-4 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) ....19-5 B022/B027...
Page 762 INTERCHANGE UNIT B300/B416 PRINTER/SCANNER CONTROLLERS B453/B461 SERVICE TABLES B022/B027 1-BIN TRAY UNIT A898/B413 FAX UNIT B418 PREVENTIVE MAINTENANCE B022/B027 SHIFT TRAY UNIT B313/B459 REPLACEMENT AND ADJUSTMENT B022/B027 BY-PASS A899/B415 TROUBLESHOOTING B022/B027 DUPLEX A896/B414 PAPER TRAY UNIT A860/B390 BRIDGE UNIT A897/B417 FIRMWARE HISTORY...
Page 763 FIRMWARE HISTORY...
Page 764 The date display on the LCD sometimes delays B0275387 D Oct. 2001 4.16.1 when the main switch is turned on. Production B022/B027 model names added for use with B0315380 B Feb. 2002 5.15.1 Plug and Play. Production Asia version only: The date format has been changed from “yyyy/mm/dd”...
Page 765 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 B022/B027 FIRMWARE MODIFICATION HISTORY (CONTROLLER) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION The default values for the following SP modes 5.15.1 were displayed incorrectly: continued SP1-105-1, 2, 3, 4, 5, 6, 7 SP1-108, SP5-912.
Page 766 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) B022/B027 FIRMWARE MODIFICATION HISTORY (SBCU) B022/B027 FIRMWARE MODIFICATION HISTORY (SBCU) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275550 F 1st Mass 3.12.1...
Page 767 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 1.1.3 FIRMWARE MODIFICATION HISTORY (LCDC) B022/B027 FIRMWARE MODIFICATION HISTORY (LCDC) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275541 B 1st Mass 2.10 Production The wording of the file transfer error message B0275541 B Oct.
Page 768 FIRMWARE MODIFICATION HISTORY Rev. 10/2002 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) B022/B027 FIRMWARE MODIFICATION HISTORY (LANGUAGE) B022/B027 FIRMWARE MODIFICATION HISTORY (LANGUAGE) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275530 1st Mass 2.25...
Page 769 Overview: The B022/B027 is intended as the successor model to the A265/A267. The mechanical components and design of these two models are nearly identical. In addition, the electrical system of the B022/B027 employs next generation architecture (formerly called GW architecture).
Page 770 B462 G335 IEEE 1394 G590 Common with B003/B004 Note: 1) The B022/B027 has a new exterior color (same as B003/B004). 2) The Drive Motor and Control Board for these peripherals have been changed. Mainframe: A265/A267 vs. B022/B027 Unit Item Details...
Page 771 The Overlay feature is added to the Edit tab. The HDD for the B022/B027 is an option, but is required to use the following features with the printer. (Note that these features are always available with the B003/B004, since the HDD comes standard).
Page 772 MACHINE CONFIGURATION Rev. 10/2002 1.2 MACHINE CONFIGURATION 1.2.1 SYSTEM COMPONENTS ⇒ B022/B027...
Page 773 Printer & Scanner unit B453 Common with B031 B462 G335 IEEE 1394 G590 Common with B003/B004 Note: 1) The B022/B027 has a new exterior color (same as B003/B004). 2) The Drive Motor and Control Board for these peripherals have been changed. B022/B027...
Page 774 TECHNICAL SERVICE BULLETIN TECHNICAL SERVICE BULLETIN TECHNICAL SERVICE BULLETIN TECHNICAL SERVICE BULLETIN BULLETIN NUMBER: BULLETIN NUMBER: B022/B027 B022/B027 – – – – 014 10/10/2002 10/10/2002 BULLETIN NUMBER: BULLETIN NUMBER: B022/B027 B022/B027 10/10/2002 10/10/2002 APPLICABLE MODEL APPLICABLE MODEL APPLICABLE MODEL APPLICABLE MODEL: : : : GESTETNER –...
Page 775 0 and 240 minutes.) When set to “0”, the user cannot set the timer to zero. ⇒ [0 = On (Enabled), 1 = Off (Disabled) 401 -Deleted and moved to User tools, System Settings, Key Operator Tools, User Code Management. 4-33 B022/B027...
Page 776 LCD to inform the user. Only used if SP5-912-1 is at “1”. [1 ~ 255 / 60 / 1 k copies/step] 914* Application Counter Display Printer Selects whether the total counters for printer mode 4-39 B022/B027...
Page 777 Grayscale (Vertical, 8bit, Even) Argyle Pattern Grayscale with White Line (Horizontal 8bit, Even) Grayscale (Horizontal) Grayscale with White Line (Vertical 8bit, Even) ⇒ Grayscale (Vertical) Grid (1-dot pair) (with Outside Data) ⇒ Grayscale (Vertical/Horizontal) Trimming Area (with Outside Data) 4-53 B022/B027...
Page 778 System ROM Boot Keep at “OFF” SBCU: DIP SW102 ⇒ DIP SW No. Function Off: Japan On: NA Off: EU/Asia Off: Not Used Destination Not used OFF (Do not change) 4.9 SPECIAL TOOLS AND LUBRICANTS 4.9.1 SPECIAL TOOLS 4-77 B022/B027...
Page 779 Flash Memory Card - 4MB ⇒ B0049099 NVRAM - Minus Counter A2309003 Adjustment Cam – Laser Unit A2679002 Positioning Pin - Laser Unit 4.9.2 LUBRICANTS Part Number Description Q’ty A0289300 Grease Barrierta - JFE 5 5/2 52039501 Silicone Grease G-501 B022/B027 4-78...
Page 780 Make sure that the DIPswitch settings on the new board are the same as those on the old board. 6.7.3 POWER PACK B027R710.WMF Remove the rear cover. (☛ 6.6.3) 2. Swing down the I/O board bracket. (☛ 6.6.5) 3. Remove the power pack [A] (5 connectors, 3 screws) 6-33 B022/B027...
Page 781 • Scanner HP sensor defective • Harness between SBCU and HP sensor disconnected • Scanner wire, timing belt, pulley, or carriage defective B022/B027...
Page 782 • Installation error (wrong SBCU or IPU). IPU board error The SICU and IPU boards installed are not for the same model (e.g. the SBCU is for the B022, and the IPU is for the B027). Automatic SBU adjustment error SBU defective...
Page 783 PC to access documents stored in the eCabinet. Even while the B022/B027 is engaged in Capture file transfer, it is still possible to use all original B022/B027 functions (copier, printer, fax, Document Server). In addition, note that the Document Server can be used in place of the eCabinet in the setup shown below.
Page 784 When enabled, if the client PC operator accesses a Captured file stored in eCabinet and sends it to the B022/B027, the machine will resend this document to the eCabinet. This is to provide an extra safeguard for file backup. However if users wish to minimize network traffic and free up eCabinet memory, this function can be disabled.
Page 785 Tech Service Bulletin No. B022/B027 – 015 Page 3 of 4 5. Necessary UP Settings: UP Mode: Users need to perform the necessary settings (Capture server IP address, etc.) from inside: [Use Tools/Counter] [System Settings]. Please refer to the Operating Instructions for the procedure.
Page 786 Tech Service Bulletin No. B022/B027 – 015 Page 4 of 4 6. To configure the eCabinet: 1. Install the eCabinet, and make sure that it has the same IP address that you used when you set the Capture Server IP address on the copier.
Page 787 3) Remove the cap and inner cap slowly. (to reduce the air pressure in the toner bottle) 4) Reinsert the inner cap in the bottle and then install the bottle in the machine.  Copyright 2002 RICOH Corporation. All rights reserved.
Page 788 TECHNICAL SERVICE BULLETIN TECHNICAL SERVICE BULLETIN BULLETIN NUMBER: BULLETIN NUMBER: BULLETIN NUMBER: BULLETIN NUMBER: B022/B027 B022/B027 B022/B027 B022/B027 – – – – 01 017 7 7 7 10/17/2002 10/17/2002 10/17/2002 10/17/2002 APPLICABLE MODEL APPLICABLE MODEL APPLICABLE MODEL APPLICABLE MODEL: : : :...
Page 789 2 DETAILED DESCRIPT IONS............8 -6 2.1 PAPER FEED AND SEPARATION MECHANISM.........8-6 2.2 PAPER LIFT MECHANISM................8-7 2.3 PAPER END DETECTION.................8-9 2.4 PAPER HEIGHT DETECTION ................8-10 2.5 PAPER SIZE DETECTION................8-12 2.6 SIDE AND END FENCES.................8-13 Side Fences....................8-13 End Fence......................8-13 B022/B027 viii...
Page 790 • Vsg < 3.5V when the maximum • High voltage supply board defective power level (256) is applied. • Vsp ≥ 2.5V • (Vsg – Vsp) < 1.0V • The ID sensor power level required to achieve standard output reaches the maximum (256). B022/B027...
Page 791 • Poor connection between the finisher Finisher connection error and bridge unit The SBCU cannot communicate with • the finisher properly when the bridge SBCU board defective unit is installed. B022/B027...
Page 792 Shield Cover has been added and the Front Cover has been modified to accommodate the cover. (Note: A screw hole has been added to the Front Cover to mount the Cover Shield.) The following parts updates are being issued for all B022/B027 Parts Catalogs. REFERENCE OLD PART NO.
Page 793 Tech Service Bulletin No. B022/B027 – 018 Page 2 of 2 UNITS AFFECTED: All B022/B027 copiers manufactured after the Serial Numbers listed below will have the new style Front Cover with Cover - Shield installed during production. MODEL NAME SERIAL NUMBER...
Page 794 SUBJECT: KEY CARD & COIN BOX SYSTEMS SUPPORT GENERAL: The B022/B027 now supports use with some types of key card, key counters and coin box systems. The specifications are detailed in this bulletin. System Service Firmware 3.03 required: Controller (System) firmware version: 5.19 E SBCU (Engine) firmware version: 3.29 L...
Page 795 Tech Service Bulletin No. B022/B027 – 019 Page 2 of 3 2. SPECIFICATIONS: 1) The Key Card Function After the counting type has been selected in SP5-113, the copy count signal will be sent to the key counter interface (SBCU, CN343, 4 pin connector).
Page 796 Tech Service Bulletin No. B022/B027 – 019 Page 3 of 3 4. PROCEDURE: 1) Attach the key card device or coin box to CN343 on the SBCU board. 2) From SP5-113, select either “Exp. Key Card (Add)” or “Exp. Key Card (Deduct).
Page 797 SAVIN – 2522/2527 SUBJECT: KEY CARD & COIN BOX SYSTEMS SUPPORT GENERAL: The B022/B027 now supports use with some types of key card, key counters and coin box systems. The specifications are detailed in this bulletin. System Service Firmware 3.03 required: Controller (System) firmware version: 5.19 E...
Page 798 Tech Service Bulletin No. B022/B027 – 019 REISSUE 2. SPECIFICATIONS: 1) The Key Card Function After the counting type has been selected in SP5-113, the copy count signal will be sent to the key counter interface (SBCU, CN343, 4 pin connector).
Page 799 Tech Service Bulletin No. B022/B027 – 019 REISSUE 4. PROCEDURE: 1) Attach the key card device or coin box to CN343 on the SBCU board. 2) In UP Mode – System Settings - Key Operator Tools be sure Key Counter Management is turned off.
Page 800 The Service Manual pages listed below must be replaced with the pages supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • 19-2 and 3 Updated Information (Firmware Modification History)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 801 FIRMWARE MODIFICATION HISTORY Rev. 11/2002 B022/B027 FIRMWARE MODIFICATION HISTORY (CONTROLLER) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION The default values for the following SP modes 5.15.1 were displayed incorrectly: continued SP1-105-1, 2, 3, 4, 5, 6, 7 SP1-108, SP5-912.
Page 802 FIRMWARE MODIFICATION HISTORY Rev. 11/2002 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) B022/B027 FIRMWARE MODIFICATION HISTORY (SBCU) FIRMWARE SERIAL FIRMWARE DESCRIPTION OF MODIFICATION LEVEL NUMBER VERSION First Mass Production B0275550 F 1st Mass 3.12.1 Production The SC level of SC792 has been changed from B0275550 F Oct.
Page 803 PAGES: ⇒ The revised areas have been highlighted by an arrow • viii through xx Updated Information (Table of Contents) • 6-43 through 6-50 New Information (Identifying Skewed, Trapezoid & Parallelogram Images)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 804 7.6 BLOWN FUSE CONDITIONS ..............7-21 PAPER TRAY UNIT (A860/B390) 1 OVERALL MACHINE INFORMATION.......... 8-1 1.1 SPECIFICATIONS..................8-1 1.2 MECHANICAL COMPONENT LAYOUT ...........8-2 1.3 ELECTRICAL COMPONENT LAYOUT.............8-3 1.4 ELECTRICAL COMPONENT DESCRIPTION...........8-4 1.5 DRIVE LAYOUT ..................8-5 2 DETAILED DESCRIPTIONS ............8-6 B022/B027 viii...
Page 805 3.2 REAR FENCE HP SENSOR ..............9-11 3.3 CHANGING THE TRAY PAPER SIZE ............9-12 3.4 LEFT TRAY PAPER END SENSOR ............9-12 3.5 TRAY LIFT MOTOR ................9-13 3.6 TRAY MOTOR..................9-14 3.7 PAPER FEED CLUTCH AND RELAY CLUTCH........9-15 3.8 PAPER FEED UNIT ................9-16 B022/B027...
Page 806 4.7 ORIGINAL SET/ORIGINAL REVERSE SENSOR .........10-25 4.8 ORIGINAL SIZE SENSOR ..............10-26 4.9 ORIGINAL FEED DRIVE ...............10-27 DF Feed Clutch.................10-27 Pick-up Solenoid ................10-27 Transport Motor ................10-27 DF Feed Motor..................10-27 4.10 REGISTRATION SENSOR..............10-28 4.11 STAMP SOLENOID AND ORIGINAL EXIT SENSOR ......10-29 B022/B027...
Page 807 1.2 COMPONENT LAYOUT ................13-2 2 DETAILED SECTION DESCRIPTIONS ........13-3 2.1 BASIC OPERATION................13-3 2.2 PRIMARY MECHANISMS ...............13-4 2.2.1 TRAY SHIFT...................13-4 2.2.2 HALF TURN DETECTION..............13-5 3 REPLACEMENT AND ADJUSTMENT ........13-6 3.1 TRAY COVER REPLACEMENT .............13-6 3.1.1 TRAY COVER REMOVAL..............13-6 B022/B027...
Page 808 Up to A4 sideways/LT sideways ............15-7 2.2 FEED IN AND EXIT MECHANISM ............15-8 When paper is fed into duplex unit:.............15-8 Inversion and Exit: ................15-8 3 REPLACEMENT AND ADJUSTMENT ........15-9 3.1 COVER REMOVAL .................15-9 3.2 ENTRANCE SENSOR REPLACEMENT ..........15-10 3.3 EXIT SENSOR REPLACEMENT............15-11 B022/B027...
Page 809 3.1 DIP SWITCH SETTINGS ................17-9 4 DETAILED DESCRIPTIONS ............. 17-10 4.1 GENERAL LAYOUT ................17-10 4.2 ELECTRICAL COMPONENT LAYOUT..........17-11 4.3 ELECTRICAL COMPONENT DESCRIPTION........17-13 4.4 DRIVE LAYOUT ..................17-15 4.5 JUNCTION GATES ................17-17 Upper tray mode ................17-17 Sort/stack mode ................17-17 Staple mode..................17-17 xiii B022/B027...
Page 810 2.2.1 OUTPUT TRAY MECHANISM .............18-14 Stack height detection...............18-14 Output tray up/down mechanism ............18-15 2.2.2 PAPER FEED ................18-16 Overview...................18-16 Straight feed out mode..............18-16 Shift sorting mode ................18-17 Stapling mode...................18-19 2.2.3 JAM CONDITIONS ...............18-20 2.2.4 ERROR DETECTION ..............18-20 3 OVERALL MACHINE INFORMATION........18-21 3.1 SPECIFICATIONS..................18-21 B022/B027...
Page 811 Rev. 11/2002 FIRMWARE HISTORY 1 FIRMWARE HISTORY ..............19-1 1.1 FIRMWARE MODIFICATION HISTORY ..........19-1 1.1.1 FIRMWARE MODIFICATION HISTORY (CONTROLLER) ....19-1 1.1.2 FIRMWARE MODIFICATION HISTORY (SBCU) ......19-3 1.1.3 FIRMWARE MODIFICATION HISTORY (LCDC) ......19-4 1.1.4 FIRMWARE MODIFICATION HISTORY (LANGUAGE) ....19-5 B022/B027...
Page 812 3.4 FIRMWARE UPDATE PROCEDURE............3-11 3.5 POWER-ON SELF TEST ................3-11 3.6 SELF DIAGNOSTIC TEST ..............3-11 3.7 USER PROGRAM MODE ...............3-12 3.7.1 PRINTER USER PROGRAM MODE..........3-12 3.7.2 SCANNER USER PROGRAM MODE ..........3-13 DETAILED SECTION DESCRIPTIONS 4 DETAILED SECTION DESCRIPTIONS ........4-1 B022/B027...
Page 813 SPECIFICATIONS SPECIFICATIONS 1 GENERAL SPECIFICATIONS..............5-1 1.1 PRINTER.....................5-1 1.2 SCANNER ...................5-3 2 SOFTWARE ACCESSORIES ..............5-4 2.1 PRINTER.....................5-4 Printer Drivers..................5-4 Utility Software ..................5-4 2.2 SCANNER ...................5-5 Scanner Driver ..................5-5 Scanner Utilities ..................5-5 3 MACHINE CONFIGURATION ..............5-6 3.1 SYSTEM COMPONENTS ..............5-6 xvii B022/B027...
Page 814 2.3.4 FAX SC CODE TABLE ..............2-16 2.4 ISDN TEST FUNCTION ................2-17 2.4.1 LEDS ....................2-17 2.4.2 BACK-TO-BACK TEST..............2-18 SERVICE TABLES 3 SERVICE TABLES................ 3-1 3.1 SERVICE PROGRAM MODE..............3-1 3.1.1 SERVICE PROGRAM MODE OPERATION........3-1 Entering and Exiting SP mode ..............3-1 B022/B027 xviii...
Page 815 Memory back-up ...................4-3 Switches ....................4-3 4.2.3 NCU (US) ..................4-4 4.2.4 NCU (EUROPE/ASIA) ..............4-5 4.2.5 SG3 BOARD..................4-6 CCP (Communication Control Processor) ..........4-6 Flash ROM....................4-6 DRAM ....................4-6 QM coder ....................4-6 V.34 Modem ..................4-6 4.2.6 SIG4 BOARD..................4-7 ICCP (ISDN Communication Control Processor) ........4-7 CODEC....................4-7 B022/B027...
Page 816 Regular transmission: .................4-19 Print and transmission ................4-19 Using Document Server..............4-19 4.5 ROM HISTRORY..................4-20 4.5.1 FCU ROM HISTORY ..............4-20 4.5.2 FAX APPLICATION ROM HISTORY..........4-21 SPECIFICATIONS SPECIFICATIONS................5-1 1 GENERAL SPECIFICATIONS..............5-1 2 CAPABILITIES OF PROGRAMMABLE ITEMS ..........5-3 3 MACHINE CONFIGURATION ..............5-4 B022/B027...
Page 817 • Only the image’s trailing edge is slanted with respect to the paper. The remaining 3 sides are parallel to the paper’s edges. Feed direction Parallel Trapezoid image may also appear in the opposite orientation. Paper Image Area 6-43 B022/B027...
Page 818 • Like skewed images, the leading/trailing edges and left/right edges are parallel to each other, however here, the leading and trailing edges are both slanted with respect to the paper’s edge. Feed direction Parallel Parallel Parallelogram may also appear in the opposite orientation. Paper Image Area B022/B027 6-44...
Page 819 SP2-902-3 (value: 10). Skewed Parallelogram See Adjusting Skewed Images, See Parallelogram Image pg. 6-46 Adjustment, Service Manual pg. 6-38 Trapezoid Combination skewed and trapezoid image See Adjusting Trapezoid Images, pg. 6-49 Perform Adjusting Skewed Images first, then Adjusting Trapezoid Images. 6-45 B022/B027...
Page 820 Is the image skewed? Are the front and rear transport rollers feeding the original straight? Change the position of the right hinge screw to the longer hole, and make any minor positional adjustments necessary. Perform Procedure B. Procedure complete. B022/B027 6-46...
Page 821 6. Place a washer (P/N 07080050, 1mm thick) in between the two to occupy the gap [A]. Fix the washer in place using an instant-acting adhesive. Note: This washer will also act to absorb minor amounts of shock. 7. Check whether the parallelogram image still appears. 6-47 B022/B027...
Page 822 1) Add a spacer (t = 0.5 to 0.8) between the hinge bracket (mainframe) and ADF left hinge, in order to raise the height of the left side of the ADF, OR: 2) Adjust the stepped height difference between the hinge bracket and scanner housing until it is within 0±0.3mm. B022/B027 6-48...
Page 823 2) Tighten the left fixing screw while pushing up on the unit’s left side (until it stops). 3. If the image is a Pattern B trapezoid, do the same for the unit’s right side. 4. If the image is still printed out as a trapezoid, perform Procedure 2. 6-49 B022/B027...
Page 824 Adjustment Complete. 4. Remove the Fusing Unit and all the washers added in Steps 1 and 2 above. Then, add washer(s) in the same way for the rear side. Recommended Washers: t = 0.5 07080040Z t = 0.8 07080050Z B022/B027 6-50...
Page 825 The Service Manual pages listed below must be replaced with the pages supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • 4-7 and 4-31 Updated Information (Service Programs)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 826 1 or 3 seconds. If this is “1 (3 s)”, the power supply fluctuation caused by the fusing lamp turning on is less often. [0 = 1 s / 1 = 3 s] Default: 0 = N. America, 1 = Europe/Asia B022/B027...
Page 827 NOTE: Use SCBU firmware ver. 3.2.4 and System firmware ver. 5.19. 118* Disable Copying 120* Opt. Counter Reset Setting This SP is for Japan only. Do not change the value. [0 = Yes / 1 = Stand-by / 2 = None] 4-31 B022/B027...
Page 828 The Service Manual pages listed below must be replaced with the pages supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • 7-2 through 7-21 Updated Information (Troubleshooting)  Copyright 2002 RICOH Corporation. All rights reserved.
Page 829 • Harness between SBCU and scanner the scanner returns to the home drive motor power source disconnected position. • Scanner HP sensor defective • Harness between SBCU and HP sensor disconnected • Scanner wire, timing belt, pulley, or carriage defective B022/B027...
Page 830 Installation error (wrong SBCU or The SICU and IPU boards installed are IPU). not for the same model (e.g. the SBCU is for the B022, and the IPU is for the B027). • SBU defective Automatic SBU adjustment error • SBCU board defective An error is detected during automatic •...
Page 831 • Poor connection of the PCU A separation bias leak signal is • detected. Discharge plate defective Toner supply motor leak error Toner supply motor defective Over 1 A supplied to the toner supply motor for longer than 200 ms. B022/B027...
Page 832 • Power supply board defective The fusing temperature does not rise • +15 °C (center) or +12 °C (at the ends) Poor connection of the fusing unit five times within 2 minutes after the fusing lamps have been turned on. B022/B027...
Page 833 • Finisher main board defective • SBCU board defective • Serial line connecting SBCU and Communication timeout error between SBCU and finisher finisher unstable • A break (low) signal was received from External noise the finisher. B022/B027...
Page 834 • Jogger H.P sensor defective finisher) • Jogger motor defective The finisher jogger H.P sensor remains de-activated for a certain time when returning to home position. The finisher jogger H.P sensor remains activated for a certain time when moving away from home position. B022/B027...
Page 835 (1000-sheet finisher) • Shift motor defective Finisher shift motor error (1000-sheet finisher) • Shift tray HP sensor defective Roller shift does not finish within a certain time after the shift motor turned B022/B027...
Page 836 The network interface board returned Controller board defective an error during the self-diagnostic test. Self-diagnostic Error: NVRAM • Replace the NVRAM on the controller board The resident non-volatile RAM returned • an error during the self-diagnostic test. Replace the controller board B022/B027...
Page 837 HD the HD and the number of registered bad sectors reached 101. Up to 101 bad sectors have appeared in the area on the hard disk where image data is archived, and the hard disk may require replacement. B022/B027 7-10...
Page 838 NVRAM. This information can be checked by using SP7-403. Note the above data and the situation in which this SC occurs. Then report the data and conditions to your technical control center. 7-11 B022/B027...
Page 839 PCB targeted for the download and prevent subsequent downloading. If this problem occurs, the damaged PCB must be replaced. B022/B027 7-12...
Page 840 Font ROM Check Memory Check RTC Check IC Card Program ROM, DIMM CRC Check I/FCheck SSCG Check Network Check OPC Check Engine I/F Check Illegal Interrupt NVRAM Check Check System OS, HDD Check Application Check IEEE1284 I/F Check B027T516.WMF 7-13 B022/B027...
Page 841 , press and hold down , and then while pressing both keys at the same time, switch on the machine. You will see “Now Loading” on the touch-panel, and then you will see the results of the test. B022/B027 7-14...
Page 842 : B0045383 FIN_SDL : BANK : A6825150 [Error List @@@] SCCODE (ERROR CODE ) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC CODE (ERROR CODE) SC835 (110C) SC820 (0001) SC820 (0002) SC820 (0003) SC820 (0004) SC820 (0005) B027T515.WMF 7-15 B022/B027...
Page 843 Tray 1-908-1 1st Tray 1-908-2 1st Tray 1-908-4 1st Tray 1-909-1 2nd Tray 1-909-2 2nd Tray 1-909-4 2nd Tray 1-910-1 3rd Tray 1-910-2 3rd Tray 1-910-4 3rd Tray 1-911-1 4th Tray 1-911-2 4th Tray 1-911-4 4th Tray B027T500.WMF B022/B027 7-16...
Page 844 - Check the side fence position of the original table. - Clean or replace the original feed belt, pick-up roller, and separation roller. - Clean the transport roller and exit roller. - Secure the ADF using the long hole, then adjust the ADF position. B027T501.WMF 7-17 B022/B027...
Page 845 The Paper Jam indicator will light whenever a Open copy is made. 321-6 Registration (SBCU) The Paper Jam indicator lights even if there is Shorted no paper. Open SC501 will be displayed. 305-7 1st Paper Lift (SBCU) Shorted Paper jam will occur during copying. B022/B027 7-18...
Page 846 The CPU cannot determine the paper near- end condition properly. – 2 (SBCU) Shorted NOTE: An SC condition occurs only when a new PCU is being installed in the machine. During copying, if the ID sensor fails, the image density will be changed. 7-19 B022/B027...
Page 847 The Cover Open indicator is lit even if the front Shorted cover is closed. The LCD does not off even if the operation Open switch is turned off. 105-1 Operation (IPU The LCD does not on even if the operation Shorted switch is turned on. B022/B027 7-20...
Page 848 SC792 is displayed. Covers Open indicator is lit then SC901 6.3 A/125 V 6.3 /250 V is displayed 6.3 A/125 V 6.3 A/250V The touch panel does not turn on. 4 A/125 V 4 A/250 V SC990 is displayed 7-21 B022/B027...
Page 849 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • 7-4 through 12 Updated Information (Service Call Conditions) • 7-14 Updated Information (Detailed Self-Diagnostic Mode)  Copyright 2003 RICOH Corporation. All rights reserved.
Page 850 • ID sensor defective adjustment range (2.0 ±<> 0.2 V) after • TD sensor abnormal the TD sensor initial setting has been • Drum does not turn finished. • Development roller does not turn • Poor connection of the PCU B022/B027...
Page 851 LCT lower limit error • Poor connection of the tray lift motor The lower limit sensor does not activate • Lower limit sensor defective within 8 seconds after the tray has been lowered. • Too much load on the drive mechanism B022/B027...
Page 852 Too much load on the motor drive • Serial line connecting SBCU and Communication break error between SBCU and ADF ADF unstable • External noise The SBCU receives a break signal from • ADF main board defective the ADF main board. • SBCU board defective B022/B027...
Page 853 • Controller board defective After powering on the machine, the communication circuit between the • Operation panel connector loose or controller and the operation panel is not defective opened, or communication with controller is interrupted after a normal startup. B022/B027...
Page 854 The stapler does not return to its home • Poor stapler motor connection position within a certain time after the stapler motor turned on. The stapler H.P sensor does not activate within a certain time after the stapler motor turned on. B022/B027...
Page 855 • Controller board defective Watchdog error • Software malfunction – download The CPU does not access the controller firmware again watchdog register within a certain time. Kernel mismatch error Download controller firmware again Software bug B022/B027...
Page 856 Self-diagnostic Error: Clock Generator Replace the controller board A verify error occurred when setting data was read from the clock generator via the I2C bus. • NIB defective Network I/F Abnormal • NIB interface error. Controller board defective B022/B027 7-10...
Page 857 Printer ready error • Replace the IPU board The printer ready signal is not • Replace the controller board generated within 17 seconds after the • Download the controller firmware IPU received the print start signal. 7-11 B022/B027...
Page 858 PCB targeted for the download and prevent subsequent downloading. If this problem occurs, the damaged PCB must be replaced. B022/B027 7-12...
Page 859 , press and hold down , and then while pressing both keys at the same time, switch on the machine. You will see “Now Loading” on the touch-panel, and then you will see the results of the test. B022/B027 7-14...
Page 861 Tech Service Bulletin No. B022/B027 – 025 Page 2 of 5 TROUBLESHOOTING – DIRTY BACKGROUND: Symptom Possible Cause Possible Factors Action Entire surface Also appears Toner concentration • The electrostatic properties of the • When the value of Vtref is 2.8 – 3.1, change the value of SP2-929-1...
Page 862 Tech Service Bulletin No. B022/B027 – 025 Page 3 of 5 Symptom Possible Cause Possible Factors Action • Partially 30 – 40 mm Area around the Toner concentration is too high When the value of Vtref is 2.8 – 3.1, change the value of SP2-929-...
Page 863 Tech Service Bulletin No. B022/B027 – 025 Page 4 of 5 Symptom Possible Cause Possible Factors Action • • Horizontal line 44 mm pitch Insufficient drum Cleaning blade has reached its To remove the paper dust in the unit, make 20 sky shot copies or...
Page 864 Tech Service Bulletin No. B022/B027 – 025 Page 5 of 5 TROUBLESHOOTING – SC390: SC390 Poor connection at the • • Bias terminal is dirty Clean the bias terminal (modular jack type connector in the PCU) development bias • •...
Page 865 SC863 (HDD error), and the SC cannot be cleared with power off/on. • SC819 SC819 occurs with 4-to-1 duplex copies made from 9 originals     Copyright 2003 RICOH Corporation. All rights reserved.
Page 866 The Service Manual page listed below must be replaced with the page supplied. Each bulletin package contains 1 set of replacement pages. PAGES: ⇒ The revised areas have been highlighted by an arrow • 4-48 Updated Information (Service Program Mode)  Copyright 2003 RICOH Corporation. All rights reserved.
Page 867 A “Paper Lag” paper jam occurs when the paper remains at the sensor for longer than the prescribed time. At power on Paper Late Paper Lag Error No. Error No. Registration Sensor ⇒ Exit Sensor Inverter Sensor B022/B027 4-48...
Page 868 SAVIN – 2522/2527 SUBJECT: LEFT UPPER SHEET GENERAL: The Left Upper Sheet was omitted from the B022/B027 Parts Catalog. Please update your parts catalog with the following information. The following part update is being issued for all B022/B027 Parts Catalogs. REFERENCE...
Page 869 Make sure to apply enough grease so the metal surface below the area is not visible (left photo), and the grease is still visible after attaching the bushing (right photo). GENERAL: PART NUMBER DESCRIPTION A2579300 GREASE - BARRIERTA S552R Copyright     2003 RICOH Corporation. All rights reserved. Page 1 of 1...
Page 870 SUBJECT: SERVICE MANUAL - INSERT The Service Manual pages listed below must be replaced with the pages supplied. ⇒ The revised areas have been highlighted by an arrow PAGES: • Updated Information (Machine Configuration)  Copyright 2003 RICOH Corporation. All rights reserved.
Page 871 Printer & Scanner unit B453 Common with B031 B462 G335 IEEE 1394 G590 Common with B003/B004 Note: 1) The B022/B027 has a new exterior color (same as B003/B004). 2) The Drive Motor and Control Board for these peripherals have been changed. B022/B027...
Page 872 The Service Manual pages listed below must be replaced with the pages supplied. ⇒ The revised areas have been highlighted by an arrow PAGES: • Table of Contents • 3-57 New Section; User Account Enhancement  Copyright 2003 RICOH Corporation. All rights reserved.
Page 873 SP1-XXX: Feed ..................4-6 SP2-XXX: Drum ..................4-16 SP4-XXX: Scanner ................4-25 SP5-XXX: Mode..................4-31 SP6-XXX: Peripherals.................4-41 SP7-XXX: Data Log ................4-43 SP9-XXX: Debug/Testing ..............4-52 4.2.3 TEST PATTERN PRINTING (SP2-902-3) ........4-53 4.2.4 INPUT CHECK ................4-54 Main Machine Input Check (SP5-803) ..........4-54 ARDF Input Check (SP6-007).............4-57 B022/B027...
Page 874 2. Remove the shield cover [C] (7 screws) or the optional fax unit if it has been installed. 3. Install the user account enhancement (IC 29) [D] on the controller board. 4. Replace the shield cover, optional fax unit, connector cover, and rear cover. 3-57 B022/B027...
Page 875 NIB connector can be attached. SOLUTION: At NIB installation: 1. Be sure to remove the controller board first, 2. Then install the NIB. Copyright  2003 RICOH Corporation. All rights reserved. Page 1 of 1...
Page 876 2) Set SP1105-7 to a value of 160. (The default setting is 175.) 3) Check the fusing NIP width using SP1109, and if the width is 7.5 mm or more, replace the Pressure Roller (P/N AE020138). Copyright  2003 RICOH Corporation. All rights reserved. Page 1 of 1...
Page 877 SUBJECT: SCANNER STAY – LOWER RIGHT GENERAL: Please correct the part number for the Scanner Stay – Lower Right in your B022/B027 Parts Catalog. The following part correction is being issued for all B022/B027 Parts Catalogs. Please correct your parts catalog with the following information.
Page 878 Attach the C-ring on the gear side of the hot roller so the opening on the C-ring faces 90 degrees from the “D” cut sections of the fusing roller. “D” cut 90° The opening on the C- ring is 90° from the two “D” cuts. “D” cut Copyright  2004 RICOH Corporation. All rights reserved. Page 1 of 1...

This manual is also suitable for:

B027

Ricoh B022 Service Manual

1 Overall Machine Information

2 Detailed Section Descriptions

3 Installation Procedure

4 Service Tables

Quick Links

Related Manuals for Ricoh B022

Summary of Contents for Ricoh B022

This manual is also suitable for:

Table of Contents
