Performance Specifications

In order to function properly, some operational parameters must be followed. They include:
1. An operating water pressure between 20 and 125 psi (138-862 kPa). If water pressure is greater than 80 psi, Culligan
recommends following the IAPMO Uniform Plumbing code section 806.2 by installing a Pressure Regulating Valve
before the system. Operating on high presure for extended periods of time can increase the service frequency of re-
placement parts. If water pressure can drop below the minimum water pressure, add a booster pump to maintain a
25 psi (172 kPa) minimum operating pressure.
2. Operating temperature between 33° and 120°F or 1°–49°C.
3. Clear (non-turbid) water supplies (Less than 5 NTU).
Culligan HE 1.5 Depth Filter & Progressive Flow Depth Filter
Tank Size, in. [mm]
Pipe Size, in. [mm]
Temperature
Water Pressure
Water Pressure (Canada Only)
Electrical
Installed Size (HxDxW, in.)
Clear height required above unit
Media Quantity, lb. [kg]
Normal Service Flow, gpm@psi
lpm@kPa
Peak Service Flow, gpm@psi
lpm@kPa
Backwash Flow, gpm [lpm]
pH limitation
Regeneration Time
Culligan® High Efficiency 1.5 Water Filter
4
HE DF 12 HE DF 14
12x52 [305x1321] 14x47 [356x1194]
62x24x14 57x24x14
52"
180 [82] 205 [93]
8@3
30.3@20.7 41.6@20.7
12@5
45.4@34.5 60.6@41.4
10 [38.1] 15 [56.8]
HE DF 16
16x53 [406x1346]
1.5 [38.1]
33–120°F
20–125 psi
20–90 psi
24V/60 Hz/21.6 W
63x24x16
47" 53"
280 [127]
11@3 14@4
50.3@27.6
16@6 21@6
79.5@41.4
20 [75.7]
6–9.5
30 minutes
HE DF 21
21x62 [533x1575]
72x24x21
62"
615 [280]
24@8
90.8@55.2
36@13
136.3@89.6
30 [113.6]
Cat. No. 01024514
