BAG ON A ROLL
SYSTEM

USING THIS MANUAL

READ MANUAL FIRST
IMPORTANT: Please read this manual and
familiarize yourself with the equipment
before use. The manual contains valuable
information about the machine, its
operation and the packaging materials
used with it.

SAFETY INFORMATION

This manual contains very important information to
protect both the operator and the machine. Please
pay special attention to the SAFETY WARNINGS.
STOP - Alerts you to dangerous situations or
hazards.
CAUTION - Alerts you to actions and
situations that may affect the machine and
its operation.
NOTE - Important information about the
operation and use of the machine.
PAGE  OF 8
1-800-295-5510
uline.com
Serial number ______________ and voltage
marked on the ID plate _______VAC
Please enter the serial number of your machine in
the space provided above. If service in needed,
please be prepared to furnish both the model
number and serial number.

UNPACK AND INSPECT

Remove all packing materials from the machine.
Do not discard packing materials until you are
sure there is no hidden damage. Find the manual
and related hardware supplied with the machine.
Carefully examine the machine for any indications
of damage that may have occurred in transit.
NOTE: If there is any damage, contact
ULINE immediately.
Remember that even minor damage on the outside
of the machine can cause problems with sensitive
components inside the machine.
2/2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H-1459 and is the answer not in the manual?

Questions and answers

Related Manuals for U-Line H-1459

Summary of Contents for U-Line H-1459

  • Page 1 1-800-295-5510 uline.com BAG ON A ROLL SYSTEM USING THIS MANUAL Serial number ______________ and voltage marked on the ID plate _______VAC READ MANUAL FIRST IMPORTANT: Please read this manual and Please enter the serial number of your machine in familiarize yourself with the equipment the space provided above.
  • Page 2 PARTS OF THE MACHINE Blower Air Flow Knob Bag Length (Fine) Bag Length (Coarse) Bag Adjust Seal temp Cool Cycle Air Deflector Pinch Rollers Pinch Roller Lever Door Upper Teflon Jaw Foot Pedal Compression Pad Power Cord Roller Knob Roller Knob Lower Teflon Jaw Lower Jaw Front Clamp...
  • Page 3 INSTALLATION Unit is for indoor use only. Select a location close to where the products being packaged are stored or manufactured for best workflow. Also consider ELECTRICAL REQUIREMENTS whether the operator will sit or stand while using this machine. Place the unit on a level, sturdy table that can support the weight of the machine, CAUTION! Follow local electrical and safety the products to be packaged and those already...
  • Page 4 Set the sealer control for the material to be To change rolls (See Figure 2): Remove core- sealed. roll shaft from the holding brackets by pulling it toward you and slightly upward in one fluid Dispense the first bag to the filling position motion.
  • Page 5 Flip the BAG ADJUST switch to dispense a bag. SIDE VIEW (See Figure 5) Tear the bag off along perforation, then position the mouth of the bag between the PINCH PINCH ROLLER seal jaws. ROLLERS CONTROL UN-LOCKED CAUTION! NEVER attempt to heat seal through the printed area on a bag, as it will cause sticking and gumming.
  • Page 6 MAINTENANCE RESIDUAL hEAT – hEAT BUILD UP The machine is designed to allow sufficient time for the heating element and sealing compression if you encounter any problems with the pad to cool during the bag dispensing and filling Uline Bag on a Roll System, contact Uline period.
  • Page 7 REPLACING COMPRESSION PAD After repositioning, retighten the clamp using the same two plastic screws. Over time the silicone rubber compression pad ® Tear off the used Teflon material below the becomes brittle and pitted and needs to be clamp. Replace the roll when there is no more replaced.
  • Page 8 HEATING ELEMENT INSTALLATION HEATING ELEMENT REPLACEMENT The heating element expands and contracts during each sealing cycle and will eventually break over time. Replace using only Uline heating elements. SIDE VIEW - HEATING ELEMENT Make sure that the machine is turned off RETAINER NUT RETAINER NUT BROKEN ELEMENT...
