LEGRAND Server Technology PRO3X Network Connection Setup Manual page 3

4. For initial login, you are prompted to change the password.
Step 2: Log in to the PRO3X Web Interface
See
5. Now you can view the data or change any PRO3X settings.
For details, refer to the user guide or online help
resources on the Raritan website.
QS Rule
Appendix B: Wireless LAN Information
USB Wireless LAN Adapters
The PRO3X supports the following USB Wi-Fi LAN
adapters.
Wi-Fi LAN adapters
SparkLAN WUBR-508N
Proxim Orinoco 8494
Zyxel NWD271N
Edimax EW-7722UnD
TP-Link TL-WDN3200 v1
Raritan USB WIFI
Connecting the Wireless LAN Adapter
You can connect the wireless LAN adapter either to the PDU or to a
USB hub attached to the PDU.
To make a wireless connection:
Do one of the following:
Plug a supported USB wireless LAN adapter into the USB-
A port on your PRO3X.
Connect a USB hub to the USB-A port on the PRO3X. Then
plug the supported USB wireless LAN adapter into the
appropriate USB port on the hub.
Supported Wireless LAN Configuration
If wireless networking is preferred, ensure that the wireless LAN
configuration of your PRO3X matches the access point. The
following is the wireless LAN configuration that the PRO3X
supports.
Network type: 802.11 A/B/G/N
Protocol: WPA2 (RSN)
Key management: WPA-PSK, or WPA-EAP with PEAP and
MSCHAPv2 authentication
Encryption: CCMP (AES)
Tip 1: Supported 802.11 network protocols vary according to the
wireless LAN adapter being used with the PRO3X. See USB
Wireless LAN Adapters (on page 3).
Server Technology PRO3X Network Setup Guide
v01 QSG-PRO3X
(on page 1).
Supported 802.11
protocols
A/B/G/N
A/B/G
B/G
A/B/G/N
A/B/G/N
A/B/G/N
QS Rule
Appendix C: PRO3X-Specific Features
Dual Networking and Power Sharing
PRO3X with iX7 controller supports the following
™
significant features.
Dual networking with two Ethernet ports (ETH1/ETH2):
•
Both Ethernet ports must connect to two "different" subnets.
Connection to the same subnet is NOT recommended.
Power sharing via the AUX port:
•
Power sharing ensures the continuous accessibility to the
PRO3X controller when a power failure occurs on its inlet.
PRO3X Replaceable Controller
PRO3X Zero U model has a "replaceable" controller. You can
replace the controller if it is not functioning. Contact Server
Technology Technical Support when a replacement controller is
needed.
For detailed information on how to remove it, refer to the topic
titled "Replaceable Controller" in the PRO3X online help.
3
